Delta Electronics SFBD-155E2J1RM Specification

Small Form Factor Bi-Directional Transceiver Module
for Fast Ethernet, ATM, SONET OC-3/SDH STM-1
Description
DELTA's SFF Bi-Directional transceiver is
designed for point-to-point Bi-Directional Optical
Network transmission.
multiple quantum
Preamplifier and WDM filter in a high-integrated
optical sub-assembly, and it receives up to
155Mbps of continuous data at 1550nm, and
transmits 155Mbps of continuous data at 1310nm.
The module is contained in a 2x5 SFF
industry standard package with a SC receptacle
connector, and support LVTTL transmitter disable
input, LVPECL electrical signal Interface and
receiver signal detect output.
DELTA ELECTRONICS, INC.
The module consists
well laser, InGaAs
FEATURES
RoHS compliant
2x5 Pin SFF Package with SC Receptacle
Single Mode Fiber, Bi-Directional
Transmission with 1310nm Transmitter and
1550nm Receiver
Link Distance up to 15km
Single +3.3V power supply and PECL logic
interface
Wave Solderable and Aqueous Washable
Bellcore GR-468 compliant
Laser Class 1 Product which comply with the
requirements of IEC 60825-1 and IEC 60825-2
Application
TTC TS-1000
ITU-T G.985
PIN,
IEEE 802.3ah 100BASE-BX/ Fast Ethernet
SONET OC-3/SDH STM-1/ ATM Network
FTTx Broadband Access System
Performance
SFBD-155E2J1RM data link up to 15km in
9/125um single mode fiber.
1
SFBD-155E2J1RM
Revision: S0
12/20/2006
www.deltaww.com
