Radio

Built-In AFC

The Built-In Automatic Frequency Control (AFC)
works only on FM. It helps to reduce drift on FM
reception and to keep the radio locked in on the
EN
FM station to which it is tuned.
When tuning in FM stations, you may notice that
often the station you desire can be heard on two
or three nearby points on the dial. Always tune
carefully to the loudest and clearest point.

Antennas

AM Antenna - A built-in ferrite rod antenna
eliminates the need for an outside antenna for
AM reception.
FM Antenna - The power cord acts as your FM
antenna. The power cord picks up moderate to
strong stations and eliminates the need for an
external antenna in most strong signal areas. Be
sure the power cord is stretched out to its full
length. Do not coil or bunch the cord together.
Changing position of the power cord may
improve reception.

Turning on the Radio

Press BAND RADIO ON to turn on the radio.
Turning off the unit
Press OFF to turn off the radio.

Adjusting Volume

Press VOL - to decrease volume level.
Press VOL + to increase volume level.
Selecting Radio / TV Band
Press BAND RADIO ON to select between FM,
AM and TV band.
9

Tuning to a Station/Channel

Press TRACK / SEARCH / TUNE
to tune
down radio frequency or select the previous TV
channel.
Press TRACK / SEARCH / TUNE
to tune up
radio frequency or select the next TV channel.
Note:
Note:
Note:
Note:
Note:
The display will return to the clock
time after displaying the station
fequency or channel number for a few
seconds. To view the current station
frequency or channel number, press TRACK /
TRACK /
TRACK /
TRACK /
TRACK /
SEARCH/ TUNE
SEARCH/ TUNE
SEARCH/ TUNE
SEARCH/ TUNE
SEARCH/ TUNE
or
.

Automatic Station/Channel Search

Press and hold TRACK / SEARCH / TUNE
or
for more than 1 second and release to start
automatic station/channel search in the direction
selected.
Search will stop once a station is found.
Tips:
Tips:
Tips:
Tips:
Tips:
Press TRACK / SEARCH /TUNE
TRACK / SEARCH /TUNE
TRACK / SEARCH /TUNE
TRACK / SEARCH /TUNE
TRACK / SEARCH /TUNE
or
to quit automatic station/channel
search.
Radio

Radio Frequency Memory

1. Follow steps in "Selecting Radio Band" and
"Tuning to a Station/Channel" to tune to the
station you want to store into memory.
2. Press MEMO SET to assign the next available
memory location to the selected station.
P will flash with the next available memory
location light on the display
If you wish to assign another memory location
or overwrite a previously set memory, press
MEMO RECALL repeatedly to select the
memory location.
3. Press MEMO SET again to confirm selection.
• A Maximum of 10 preset memory locations
are available.

Memory Recall

Press MEMO RECALL repeatedly to recall preset
stations.

TV Band

CH 2-13 are available for TV Band.
The TV indicator and the channel number lights
on the display when TV band is selected.
TV Band
ch 2
59.75 MHz
ch 3
65.75 MHz
ch 4
71.75 MHz
ch 5
81.75 MHz
ch 6
87.75 MHz
ch 7
179.75 MHz
ch 8
185.75 MHz
ch 9
191.75 MHz
ch 10 197.75 MHz
ch 11 203.75 MHz
ch 12 209.75 MHz
ch 13 215.75 MHz

Using the Weather Band

Weather information is given continuously from
U.S. Government Weather Stations on frequencies
from 162.4MHz to 162.55MHz.
Weather Band
ch 1 162.550 MHz
ch 2 162.400 MHz
ch 3 162.475 MHz
ch 4 162.425 MHz
ch 5 162.450 MHz
ch 6 162.500 MHz
ch 7 162.525 MHz
Important:
Important:
Important:
Important:
Important:
The listening range of NOAA
weather stations varies from 10 miles
up to a maximum of 40 miles from
the station's transmitter. In some areas of the
United States, weather transmissions cannot be
monitored. The effective range of this radio will
have side variations due to the height of the
local transmitting antenna, atmospheric
conditions, and the terrain between the
transmitter and your radio's location.
The Weather transmission, broadcast 24 hours a
day, are taped messages that are repeated every
4 to 6 minutes and revised and updated as
needed to match the changing weather
conditions. For additional information, check
your location office of the National Weather
Service (Department of Commerce).
1. Press the INSTANT WEATHER
button to
access Weather Bands with strong signals to
the unit.
The Wx indicator and the channel number
lights on the display when weather band is
selected.
2. Use the TRACK / SEARCH / TUNE
or
arrow buttons to select among the 7 weather
channels.
Note:
Note:
Note: You may not be able to receive
Note:
Note:
TV broadcast or weather band
information with this unit in some
areas of Canada. Please check with
your local TV broadcasters and weather
information services.
10
EN
