M1574200B
4.0 GPM, 4000 PSI Pressure Washer — EPA, CARB-Compliant
Instructions for Installation/Set-up, Operation, Maintenance, & Storage
This pressure washer produces cold water high pressure spray. Cleaning chemicals may be incorporated into the
spray if desired. The pressure pump for this equipment is powered by a gasoline internal combustion engine.
WARNING: SPECIAL HAZARDS
• CO Poisoning: Exhaust from engine contains carbon monoxide, a poisonous gas that can cause carbon monoxide
poisoning and possible death if inhaled.
• Injection Injury: High-pressure spray can pierce skin and underlying tissues, leading to serious injury and possible
amputation. Such an injection injury can result in blood poisoning and/or severe tissue damage.
• Flying Debris: High-pressure spray can cause flying debris and possible surface damage.
• Electric shock: Operating equipment in wet conditions or near water can cause electric shock.
• Chemical Exposure: Cleaning chemical vapors or contact with skin may be hazardous.
• Fire/Explosion: Engine sparking can ignite fuel or other flammable liquids or vapors in the vicinity. Hot exhaust from engine
can ignite combustible materials. Always keep a fire extinguisher rated "ABC" nearby.
• Burns: Pressure Washer pump and engine are hot surfaces that can cause burn injuries.
Detailed safety information about these hazards appears throughout this manual.
Inspect Upon Delivery: FIRST! Inspect for missing or damaged components. See "Initial Set-Up/Installation" section
for where to report missing or damaged parts.
Add Engine Oil: Engine is shipped without oil. See the "Engine Manual" section of this manual for instructions on
capacity and viscosity recommendations.
Replace Temporary Shipping Plug: Pump is shipped with oil but with temporary shipping plug. Check pump oil
level before starting and replace temporary shipping plug with permanent breather plug provided within plastic bag
attached to the pump.
Water Flow Requirements: Make sure your supply water flow rate is 20% higher than the pressure washer's flow
rate (see "Operations", section for detail), and that your water is clean and particle free.
Chemical Spraying: Use only approved pressure washer chemicals designed for high-pressure use. Use soap
adjustment knob to regulate cleaning power (on select units).
Storage: Do not allow water to freeze in the pump, hose, or spray gun(s). See "Storage" for more information.
Maintenance Schedule: Engine and pump require periodic inspection and servicing to keep pressure washer
functioning efficiently. See "Maintenance Schedule Summary" for frequency of servicing.
Owner's Manual
Equipment Protection Quick Facts
Any Questions, Comments, Problems, or Parts Orders
Call Powerhorse Product Support 1-866-443-2576
ITEM NUMBER: 1574200
SERIAL NUMBER: _____________
