- Page 1 www.weslo.com Model No. WLTL29613.1 USER’’S MANUAL Serial No. Write the serial number in the space above for reference. Serial Number Decal ACTIVATE YOUR WARRANTY To register your product and activate your warranty today, go to www.wesloservice.com/ registration. CUSTOMER CARE For service at any time, go to www.wesloservice.com.
-
Page 2: Table Of Contents
If a decal is missing or illegible, see the front cover of this manual and request a free replacement decal. Apply the decal in the location shown. Note: The decal(s) may not be shown at actual size. WESLO is a registered trademark of ICON IP, Inc. -
Page 3: Important Precautions
IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read all important precautions and instructions in this manual and all warnings on your treadmill before using your treadmill. ICON assumes no responsibility for personal injury or property damage sustained by or through the use of this product. - Page 4 20. The heart rate monitor is not a medical 24. Do not change the incline of the treadmill by device. Various factors, including the user’’s placing objects under the treadmill. movement, may affect the accuracy of heart rate readings. The heart rate monitor is 25.
- Page 5 STANDARD SERVICE PLANS...
-
Page 6: Before You Begin
BEFORE YOU BEGIN Thank you for selecting the new WESLO CADENCE reading this manual, please see the front cover of this ® G 5.9 treadmill. The CADENCE G 5.9 treadmill offers a manual. To help us assist you, note the product model selection of features designed to make your workouts number and serial number before contacting us. -
Page 7: Part Identification Chart
PART IDENTIFICATION CHART Use the drawings below to identify small parts used for assembly. The number in parentheses below each drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity used for assembly. -
Page 8: Assembly
ASSEMBLY •• To hire an authorized service technician to •• Left parts are marked ““L”” or ““Left”” and right parts assemble the treadmill, call 1-800-445-2480. are marked ““R”” or ““Right.”” •• Assembly requires two persons. •• To identify small parts, see page 7. ••... - Page 9 3. Attach the Handrails (69) to the Uprights (73) with four M10 x 45mm Screws (2). Start all four Screws, and then tighten them. 4. With the help of a second person, hold the con- sole assembly near the Uprights (73). Remove Console Assembly the tie from the Upright Wire (71).
- Page 10 5. Attach the console assembly to the Uprights (73) and the Handrails (69) with five M4.2 x 19mm Console Assembly Screws (3). Be careful not to pinch the wires. 6. Attach the Latch Housing (72) to the left Upright (73) with two #10 x 1" Tek Screws (7); start both Tek Screws, and then tighten them.
-
Page 11: Operation And Adjustment
OPERATION AND ADJUSTMENT HOW TO CONNECT THE POWER CORD nominal 120-volt circuit capable of carrying 15 or more amps. To avoid overloading the circuit, do Use a Surge Suppressor not plug other electrical devices, except for low- power devices such as cell phone chargers, into Your treadmill, like other electronic equipment, can be the surge suppressor or into an outlet on the same damaged by sudden voltage changes in your home’’s... -
Page 12: Console Diagram
CONSOLE DIAGRAM Thumb Heart Rate Monitor Clip FEATURES OF THE CONSOLE IMPORTANT: If there is a sheet of plastic on the face of the console, remove the plastic. To prevent The treadmill console offers a selection of features damage to the walking platform, wear clean ath- designed to make your workouts more effective. - Page 13 HOW TO TURN ON THE POWER HOW TO USE THE MANUAL MODE IMPORTANT: If the treadmill has been exposed to 1. Insert the key into the console. cold temperatures, allow it to warm to room tem- perature before you turn on the power. If you do See HOW TO TURN ON THE POWER at the left.
- Page 14 4. Follow your progress with the displays. 5. Measure your heart rate if desired. The track——The track To measure your heart rate, stand on the foot represents a distance rails and place your thumb on the heart rate moni- of 1/4 mile (400 m). As tor (see the drawing on page 12).
- Page 15 HOW TO USE A PRESET WORKOUT and the next segment of the profile will begin to flash. If a different speed setting is programmed for 1. Insert the key into the console. the next segment of the workout, the new speed setting will flash in the display to alert you.
- Page 16 THE INFORMATION MODE HOW TO CHANGE THE INCLINE OF THE TREADMILL The console features an information mode that allows To vary the intensity of your exercise, you can change you to turn on and turn off the demo mode and to the incline of the treadmill.
-
Page 17: How To Fold And Move The Treadmill
HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL HOW TO MOVE THE TREADMILL Before folding the treadmill, remove the key and Before moving the treadmill, fold it as described at the unplug the power cord. CAUTION: You must be left. -
Page 18: Troubleshooting
TROUBLESHOOTING Most treadmill problems can be solved by follow- SYMPTOM: The console displays remain lit when ing the simple steps below. Find the symptom that you remove the key from the console applies, and follow the steps listed. If further assis- tance is needed, see the front cover of this manual. - Page 19 c. Your treadmill features a walking belt coated with b. If the walking belt slips when walked on, first high-performance lubricant. IMPORTANT: Never remove the key and UNPLUG THE POWER apply silicone spray or other substances to CORD. Using the hex key, turn both idler roller the walking belt or the walking platform unless screws clockwise, 1/4 of a turn.
-
Page 20: Exercise Guidelines
EXERCISE GUIDELINES Burning Fat——To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy. -
Page 21: Suggested Stretches
SUGGESTED STRETCHES The correct form for several basic stretches is shown at the right. Move slowly as you stretch ——never bounce. 1. Toe Touch Stretch Stand with your knees bent slightly and slowly bend forward from your hips. Allow your back and shoulders to relax as you reach down toward your toes as far as possible. - Page 22 NOTES...
- Page 23 NOTES...
-
Page 24: Part List
PART LIST Model No. WLTL29613.1 R0613B Key No. Qty. Description Key No. Qty. Description M10 x 65mm Screw Belt Guide M10 x 45mm Screw Latch Pin Assembly M4.2 x 19mm Screw 1/4" Flat Washer M8 x 35mm Screw Upright Grommet M4.2 x 13mm Washer Head Screw Drive Belt M4.2 x 13mm Screw... -
Page 25: Exploded Drawing
EXPLODED DRAWING A Model No. WLTL29613.1 R0613B... - Page 26 EXPLODED DRAWING B Model No. WLTL29613.1 R0613B 23 11...
- Page 27 EXPLODED DRAWING C Model No. WLTL29613.1 R0613B...
-
Page 28: Ordering Replacement Parts
This warranty provides speci c legal rights; the customer may have other rights that vary from state to state. ICON Health & Fitness, Inc., 1500 S. 1000 W., Logan, UT 84321-9813 Part No. 346601 R0613B Printed in China © 2013 ICON IP, Inc.
