PARTS AND OPERATION MANUAL
Model DCA-10SPX3
Digital Generator Set
MQ POWER
Voice Stream
Revision #0 (07/12/00)
MULTIQUIP INC.
18910 WILMINGTON AVE.
CARSON, CALIFORNIA 90746 FAX: 800-672-7877
310-537-3700
800-421-1244
FAX: 310-537-3927
E-mail:mq@multiquip.com
PARTS DEPARTMENT:
800-427-1244
SERVICE DEPARTMENT:
800-478-1244
FAX: 310-537-4259
•
www:multiquip.com
