OPERATION MANUAL
WHISPERWATT™ SERIES
MODEL DCA15SPXU4F
60Hz GENERATOR
(KUBOTA D1503-M DIESEL ENGINE)
Revision #1 (02/10/17)
To find the latest revision of this
publication, visit our website at:
www.mqpower.com
THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES.
