  • Page 2: Preliminary Checks

    It is the operators duty to ensure that the area is clear prior to operation. Photo sensors or Reflective sensors should always be installed to assist in accident or death prevention. Rubber Motor Specifications BM30/30X/HS BH30/60X/HS BH30/80X Gate Max.

  • Page 3: Installation Layout

    Installation Layout Entry Button or Keypad Wireless Available Gate Stop Safety Sensors External Antenna Exit Button Power Source or Keypad Induction Loop Solar Panel Wireless Available Exit Sensor Solar Box U Guide/Keep Wheels Rollers and Bracket Requiring Wiring: Gate Stop Floor Track •...
  • Page 4 Emergency Override/Clutch Override Unlocking 1. Operate the manual release moving back the key hole cover (J). 2. Insert the key in the cylinder lock (K) and turn it of 90° clockwise direction. 3. Pull the lever (L) till it is perpendicular to the gear-motor. Locking 1.
  • Page 5 Quick Reference Guide 1.Power Input (24V AC/DC) 2.Parameter display mode 3.Receiver Chip 4.Command and safety terminal block Courtesy light 230Vac 100 blue brown brown FUSE max 1A (operational voltage) +LAM Open gate light Flashing light 24Vdc 3W 24Vdc 5W +24V (Constant voltage) Photocell 2 Photocell 1...

  • Page 6: High Voltage

    Internal Transformer,Wiring HIGH VOLTAGE ANY High voltage Connections MUST be carried out by a QUALIFIED Electrician. 3x2,5 mm² MOTOR PROG TEST 24V Volts AC/DC 230 V POWER SUPPLY 230 V Battery Backup connections To Install the ba ery charger and 2x12V 1.2 Ah ba ery backup follow this procedure.
  • Page 7 APC External AC Transformer (Low Voltage Systems) The diagram below will illustrate the low voltage transformer connec on to the control board. The Low Voltage transformer should be connected to the power input as shown in the picture below. The ac transformer wires Brown should go to the + Ve and Black/ Blue...
  • Page 8 Solar System Installation Taking into account that the solar panels maximum cable distance is 20 metres and the maximum distance between the solar box and the gate controller is 10 metres nd a suitable location for the mounting of the box accordingly. Both the solar box and the solar panel are completely weatherproof and can be mounted in complete exposure to the elements.
  • Page 9 Step 2: Mounting the APC UNO Solar Box 1. Install the bracket to the wall or post using the 2. Position the solar box onto the installed bracket appropriate xings whilst adhering to the maximum and secure in place using the two 4mm allen 265mm cable distance of 10m (note that the system is screws at the bottom.

  • Page 10: Parameter Value

    Parameter Display Mode PARAMETER PARAMETER VALUE DOWN PROG TEST -Press the UP or Down buttons to view the Parameter you intend to modify. -Use the + and - buttons to modify the values of the Parameter. The value starts to Flash. -To save the new value, wait for few seconds or move onto the another parameter using UP or Down button.
  • Page 11 NOTE: IF one or more contacts are open, it will not operate the gate to Open or close. This does not apply to the Limit switch signal state. Press the Test bu on again to Exist the Test mode. Gate System Setup Cycle Step 1: Selecting the Motor type KEY: HIGH SPEED Motors...
  • Page 12 Step 4 : Press the TEST button and Check the command signal and safety device states. TEST SEE CHAPTER 16 and 17 1 click Until ... TEST PROG ACQUISITION TEST ta ta AP P- PROCEDURE CHAP. 11.2 1 click CLOSE 1 click Press and hold on TEST...
  • Page 13 Service Free Pairing(Remote Controls Only) -Simultaneously, Press and Hold button A and button B on the New remote. -The LED Flashes for 5s. -Hold Button A only on the new Remote you want to store. -the LED Flashes for 3s. -Hold the Previously stored remote as close as possible to the New Remote.
  • Page 14 Connecting an APC-ULA Light with External Antenna The APC-ULA external antenna can boost the remote range substantially with the added feature of a safety light. • APC-RC450S remote can be boosted UP TO 600m distance • APC-RC4-SV remote can be boosted UP TO 80m distance •...
  • Page 15 Enabling the photocell and setting the parameters Prior to enabling the Photocell you will first need to choose the logic system in which it will operate. FT1 and FT2 can be programmed to specific use as per the required logic by changing the values of 50,51,52,53,54,55and56. Default to usage FT1 can be set to func on the photocell in Closing.
  • Page 16 Connecting an APC Keypad (APC-KP1-C) Unlike a push button entry switch using a keypad can provide a much higher security for access control for guests, workers, tenants etc. Using a keypad will allow you to manage the users by adding and deleting as required. Its backlit illumination also allows for ease of use at night. Relay time should be set to ONE seconds (COM) (COM)
  • Page 17 Connecting APC Connect4 GSM Receiver A GSM Receiver is the absolute most flexible form of access control. Providing there is good mobile reception at the gate the GSM switch can operate the gate from anywhere in the world. When receiving a call it will automatically reject the call and open or close the gate. SIM CARD IS NOT SUPPLIED. APC Connect Relay time should be set to ONE seconds Relay Output...
