Clas Ohlson SP-LS2M96RGBIC7WIR-SMD-01 Instruction Manual

LED Strip Light, RGBIC
Art.no 36-9920 Model SP-LS2M96RGBIC7WIR-SMD-01
Read the entire instruction manual before use and save it for future
reference. We apologise for any text and picture errors and any
changes of technical data. If you have any questions concerning
technical problems please contact our Customer Services.
Safety
Warning:
• Never use the product if it is in any way damaged or malfunctio-
ning. Unplug the product immediately if it is damaged.
• Do not use the product in environments where explosive or
flammable gases are stored or used.
• The product must not be installed on a wet or electrically con-
ductive surface.
• Make sure that the cable is not damaged whilst the product is
being installed.
• Do not carry the product using the mains lead and do not use it
for other unsuitable purposes.
• Never let children play with the product.
• The product may be used by persons with reduced physical,
sensory or mental capabilities or persons with a lack of ex-
perience or knowledge which could jeopardise their safety,
provided they have been instructed in the safe operation of
the product and understand the hazards involved.
Important
• The LEDs cannot be replaced. When the LEDs have reached
the end of their service life, the entire product must be discarded.
• This product is intended only for private use.
Risk of eye damage. Do not look directly at
the light source.
The product is intended for indoor use only.
Class III strip light
Installation
Decide the pacement of the light strip and screw the six included
clips (a) to place. Note! Ensure that there are no electrical wires or
water pipes in the ceiling or wall where you intend to drill/screw.
a
1
1. Strip light: Bend the light strip to the desired shape and press it
into the clips.
2. Connectors: Connect the strip light and the control box
together. Note: Make sure the strip light is connected in
the right way, with the arrows pointing towards each other.
Otherwise the strip light will not work.
3. IR Receiver. Note: Make sure there are no obstacles between
the IR receiver on the LED control unit and the remote control.
4. Control Box
5. Connection cable USB-A: Connect the connection cable to a
USB adaptor.
Remote control
Remove the plastic battery tab.
6. Press [ IC Set ] and use
[ ] and [ ] to gradually turn
off or turn on 6 LED lights
at a time (You can never
have fewer than 48 active
LEDs). Select a colour with
the colour selection buttons
(6) and adjust the brightness
with [ ] and [ ].
English
3
2
4
5
8
W/WW
6
Auto
IC Set
CS
9
7
C3 Flash
C7 Jump
C16 Meters
10
