Potensic Atom LT User Manual

Potensic Atom LT User Manual

Hide thumbs Also See for Atom LT:
Table of Contents

Advertisement

Quick Links

Download this manual
Email: support@potensic.com
Email: support.uk@potensic.com
Email: support.de@potensic.com
Atom
User Manual
V01. 24. 07
Email: support.fr@potensic.com
Email: support.it@potensic.com
Email: support.es@potensic.com
LT
Email: support.jp@potensic.com
Web: www.potensic.com
FB: www.facebook.com/Potensic
DANGER
Only suitable
16+
for ages 16+

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Atom LT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Potensic Atom LT

Summary of Contents for Potensic Atom LT

  • Page 1 DANGER Atom Only suitable for ages 16+ User Manual V01. 24. 07 Email: support@potensic.com Email: support.fr@potensic.com Email: support.jp@potensic.com Email: support.uk@potensic.com Email: support.it@potensic.com Web: www.potensic.com Email: support.de@potensic.com Email: support.es@potensic.com FB: www.facebook.com/Potensic...

  • Page 2: Table Of Contents

    Contents 1. Disclaimer & Precautions 6. PotensicPro App 1.1 Disclaimer 6.1 App Homepage 1.2 Safety Precautions 6.2 Flight Interface 1.3 Warning & Prompts 7. Flight 2. Reading Tips 7.1 Requirements of Flight Environment 2.1 Legend 7.2 Precautions of Flight 7.3 Connection 2.2 Suggestions of Use 2.3 Tutorial Video/Download App 7.4 Flight Modes...

  • Page 3: Disclaimer & Precautions

    User Manual to grasp basic knowledge and become familiar with the drone's functions. For the initial use of ATOM LT, it is recommended to operate it in GPS mode in a spacious outdoor area to acquaint yourself with its functions.

  • Page 4: Reading Tips

    06. The product contains small parts. Please place them out of reach of children to prevent accidental ingestion. 07. Do not operate the product over roads or standing water to avoid accidents. 08. Dismantling or refitting the product, except for the propellers, is forbidden, as it may lead to drone malfunctions. 09.

  • Page 5: Technical Terms

    Help Thanks for purchasing Potensic Atom LT. Before using the drone for the first time, we recommend that you read the user manual carefully. Please contact our support team at support@potensic.com if you encounter any problem or issue with the drone.

  • Page 6: Drone Diagram

    • Test conditions of the max. flight time: Fly at an even speed of 5m/s at 25°C and in breezeless condition. • Test conditions of the max. transmission distance: Measured at an open and no-interference environment, with a flight height of 120m, and without considering the return of the drone. •...

  • Page 7: Remote Controller Diagram

    3.3 Remote Controller Diagram 1. Power button 6. Control stick Long press for 2s to power on/off. 7. Foldable double antennas 2. Power indicator 8. Placement for mobile device Indicate the power level or other status To place mobile device. of the remote controller.

  • Page 8: Preparing The Drone

    3.4 Preparing the Drone The product is delivered under folded status. Please unfold it as follows: 1. Unfold the front arm before the rear arm. 2. Unfold the propeller blades. 3.5 Preparing the Remote Controller Installation of mobile phone and control stick 1.

  • Page 9: Charging/Startup And Shutdown

    3.6 Charging / Startup and Shutdown Before the first flight, it is essential to wake up the battery, otherwise the drone won't start. Connect the TYPE-C charging port of the battery and a USB charger to the AC power supply to finish a single charging (USB charger is not included in the package.

  • Page 10: Drone

    4. Drone ATOM LT consists of a flight control system, a communication system, a positioning system, a power system and a smart flight battery. This chapter sets down the functions of all parts of the drone. 4.1 Positioning Atom LT adopts Potensic's new SurgeFly™ flight control technology, enabling GPS positioning: GPS positioning: Provide precise positioning and navigation to the drone;...

  • Page 11: Smart Battery

    4.3 Smart Battery 4.3.1 Function Atom LT's smart battery is equipped with high-energy cells and utilizes an advanced battery management system. Detailed information is as follows: Basic Parameters Model: DSBT02C Cell Qty. Battery Capacity 2 series 3000mAh Charge Completion Rated Voltage 7.2V...
  • Page 12 4.3.2 Battery Installation & Removal Installation: Removal: Insert the battery in the battery compartment and Press the battery buckle and detach the battery secure the buckle. You will hear a clicking sound from the battery compartment to remove it. when the battery is fully engaged. •...

  • Page 13: Propellers

    4.4 Propellers There are two types of Atom LT propellers, which are designed to spin in different directions. Marks are used to indicate which propellers should be attached to which motors, the two blades attached to one motor are the same.

  • Page 14: Flight Data

    4.6 Single Axis Gimbal Camera 4.6.1 Single Axis Gimbal The Atom LT camera is mounted with a single-axis gimbal, to adjust pitch angle freely from +20° to -90° (horizontal direction is 0°). The angle of the gimbal can be adjusted by dialing the left thumbwheel of the remote controller.

  • Page 15: Remote Controller

    4.6.3 Image Storage Videos and pictures recorded by ATOM LT will be stored on the SD card instead of the App or your phone gallery. Make sure to insert the SD card prior to flight. Otherwise, it's unable for ATOM LT to record videos or capture pictures. (SD card is not included in the pack list.) You can preview and download the videos and pictures (the drone and the remote controller should be connected) in App.

  • Page 16: Control Stick Mode

    5.2 Control Stick Mode Mode 1 (Left Hand Throttle) Left stick Right stick Forward Down Backward Turn left Turn right Left Right Mode 2 (Right Hand Throttle) Left stick Right stick Forward Down Backward Turn left Turn right Left Right...

  • Page 17: Function

    5.3 Function 5.3.1 Function List 1. Connect the USB Charger to the TYPE-C charging port. 2. The battery is being charged when the LED indicators start flashing. Charge 3. Charging is completed when 4 LED indicators are solid on and data cable can be removed.
  • Page 18 5.3.2 Indicator As shown in the picture below, the remote controller is fitted with 4 white LED indicators to indicate the power level and other status. Indicator is on LED 4 LED 1 Indicator is flashing LED 2 LED 3 Indicator is off Charging indication LED 1...

  • Page 19: Antenna Angle

    5.3.3 Remote Controller Function Atom LT drone and the remote controller can be used immediately after startup since they have passed frequency pairing before delivery. If a new remote controller or drone is used for the first time, user must conduct frequency pairing for them as follows prior to use: 1.

  • Page 20: Remote Controller Calibration

    5.5 Remote Controller Calibration 5.5.1 When to perform remote controller calibration 1. When the drone drifts automatically in one direction without any toggling of the control sticks. 2. When the drone automatically and continuously rotates in one direction. 3. When the control sticks are over-sensitive or lack sensitivity. 5.5.2 Calibration Procedure 1.

  • Page 21: Potensicpro App

    6. PotensicPro App 6.1 App Homepage Tap to view the flight logs and Potensic Academy Tap to choose the corresponding model. The drone model will be matched automatically if user has connected the remote controller to the mobile phone Display connection status...

  • Page 22: Flight Interface

    6.2 Flight Interface 1. Return button: 2. Navigation prompt bar: Tap to return to the homepage Display drone status and flight mode 3. Flight mode: 4. Positioning mode: Video GPS positioning Normal Attitude mode, no positioning Sport 5. GPS status: Display GPS signal status and quantity of satellites connected 6.
  • Page 23 Camera General Settings: Tap to set white balance, gridlines, segmental recording, etc. Tap to check Micro-SD card capacity and format. Other Settings: Enable/disable Telemetry Data. About View device information, firmware information, App version, etc. 9. Shooting Information Display/Settings Photo Mode: displays photo format, EV (exposure value) and the remaining numbers of photos or the available capacity of the current microSD card.
  • Page 24 The attitude indicator displays information of drone direction, tilt angle, remote controller direction, HOME point and more. The attitude indicator can show the angle and direction of the drone in real time as follows: Legend Tilt forward: Tilt backward: Tilt to the right: Tilt to the left: Tilting the horizon line tilts...

  • Page 25: Flight

    • It is recommended to replace any outdated mobile device which may have a negative impact on user experience of App and lead to potential dangers. For any poor user experience and safety problems due to the use of an outdated mobile device, Potensic does not bear any liability. 7. Flight This chapter introduces safe flight practices and requirements.

  • Page 26: Precautions Of Flight

    • It is advised to tap and follow the animated guide to operate for first-time users. 7.4 Flight Mode Atom LT has three flight modes-Video/Normal/Sport, which can be switched via the App. Video Mode Ascent speed: 2m/s, descent speed: 1.5m/s, flight speed: 6m/s The drone enters Beginner Mode by default when being used for the first time.

  • Page 27: Compass Calibration

    7.5 Compass Calibration 7.5.1 Scenarios Requiring Compass Calibration 1. Compass calibration is required for first-time use. 2. Flying the drone at a location more than 500 km (310 miles) away from its last flight. • DO NOT calibrate the compass in locations where magnetic interference may occur such as close to magnetite deposits or large metallic structures such as metal mines, steel reinforced basements, bridges, cars, or scaffolding.

  • Page 28: Takeoff/Landing/Hovering

    7.7 Takeoff/Landing/Hovering 7.7.1 Manual Takeoff/Landing Takeoff Step 1: Start the motors Use a combination stick command to start the motors. Push both sticks to the bottom inner or outer corner depending on your control stick mode to start the motors. Release both sticks simultaneously once the motors are spinning.

  • Page 29: Smart Flight

    7.8 Smart Flight 7.8.1 Circle Flight Start circle flight, the drone will fly forwards by taking the current position as circle center until it reaches the starting point of circle flight; When user Description in App, the drone will fly around the circle at a set speed and direction.
  • Page 30 7.8.3 Waypoint Flight When waypoint flight function is enabled, User can freely set 1 or multiple Description waypoint coordinates in App map, and the drone will fly over the corresponding coordinates according to the sequence of set waypoint coordinates. When GPS signal is strong, tap in App and select to enter Waypoint Flight.

  • Page 31: Return(Rth)

    7.9 Return(RTH) 7.9.1 Regular Return Regular Return consists of three steps, as follows: 1. Ascent: The drone ascends to the preset return altitude (this step is skipped if the drone's altitude is already higher than the return altitude). 2. Level flight: The drone maintains a straight flight at the set altitude towards the home point. 3.

  • Page 32: Emergency Stop

    7.9.2 Descending Return How to Activate After 10 seconds into the RTH course, if the flight altitude is greater than 150m and the flight distance greater than 300m, the App will prompt a message for you to confirm whether to initiate the descending return. Once confirmed, the drone will start the descending return(the drone will descend its altitude while approching the HOME point).

  • Page 33: Appendix

    8. Appendix 8.1 Specification & Parameters Drone Model: DSDR04D Takeoff Weight: < 249g (the takeoff weight includes battery and propeller blades) Folded Size: 88x143x58mm Unfolded Size (propeller blades included): 300x242x58mm Unfolded Size (propeller blades excluded): 210x152x58mm Diagonal Distance: 219mm Max Speed (Sport Mode): Ascent speed: 5m/s; Descent speed: 4m/s; Flight speed: 16m/s Max Flight Time: 40min Max Wind Speed Resistance: 38km/h (Level 5) Operating Temperature: 0°C~40°C...
  • Page 34 Remote Controller Model: DSRC02A Operation Frequency: 2.402~2.483GHz Max Transmission Distance (unobstructed, free of interference): 4km Operating Temperature: 0°C~40°C Battery: 3000mAh, lithium battery, 1S Transmitter Power (EIRP): 2.4GHz: ≤20dBm Charging Interface: TYPE-C Charging Specification: 5V/1A Video Transmission System: PixSync™ 2.0 Image Transmission Quality: 576P Latency (depending on environment and mobile device): 200ms Supported Mobile Device Size: Length: 170mm, Width: 100mm, Thickness: 6.5mm~8.5mm Smart Flight Battery...

  • Page 35: Post-Flight Checklist

    Check if the Smart Flight battery and the remote controller are activated by charging. If the problem persists, contact Potensic support. 3. Power-on and start-up problems Check if the battery has power. If yes, contact Potensic support if it cannot be started normally.

  • Page 36: Risk And Warnings

    18700RPM MTOM Statement The MTOM of ATOM LT (Model DSDR04D), including the Smart Flight Battery, Propellers, and a microSD card, is 248 g to comply with C0 requirements. Users must follow the instructions below to comply with the MTOM requirements for each model: 1.
  • Page 37 Visit the link below for more EASA notice information on traceability. https: //www.easa.europa.eu/en/document-library/general-publications/drones-information-notices Original instructions This manual is provided by Potensic Intelligent Co., Ltd. and the content is subject to change. Address: Room 1901, Jinqizhigu Building, Tangling Road, Nanshan District, Shenzhen, China.
  • Page 38 20cm between the radiator & your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Manufacturer: Shenzhen Potensic Intelligent Co., Ltd. Address: Room 1901, Jinqizhigu Building, Tangling Road, Nanshan District, Shenzhen, China E-CrossStu GmbH.
