- Page 1 Zeus Camera Manual Zeus 455M Pro Camera Manual V1.0 Dec, 2024...
-
Page 2: Table Of Contents
Zeus Camera Manual Table of Contests Product Features ........................3 Technical parameters ......................4 Product Description....................... 5 New Cutting-edge Design .................. 5 Rear Adjustment 4 Point Sensor Tilt Plate ............. 6 Deep Cooling ......................7 512MB DDR3 Cache ................... 8 STARVIS Technology .................. -
Page 3: Product Features
Zeus Camera Manual Product Features DSO cooled camera line is the most advanced product line in Player One history. We start the project from 2021, through a lot of modify and rebuild we made this final version. It brings our newest technology and design to everyone, we are very proud to introduce this... -
Page 4: Technical Parameters
Zeus Camera Manual Technical parameters Sensor New SONY IMX455AQK-K full-frame CMOS (mono) Diagonal 43.3mm Total Pixels 61 Mega Pixels Max Resolution 9576×6388 3.76μm Pixel Size Chip Size 36mm×24mm Frame Rate Under USB3.0 mode Resolution 10bit ADC 16bit ADC 9576×6388 6.5FPS 3.2FPS 3840×2160 47FPS 11FPS 1920×1080 105FPS 22FPS 800×600 184FPS 39FPS... -
Page 5: Product Description
Product Description New Cutting-edge Design Polygon like regular hexagon is very Player One, the DSO cooled cameras we want to make it more beautiful and practical. After a lot of trying, we fix the final style, which uses a scientific and technological octagon to construct the main body line and 4 sides are cambered surface, supplemented by round chamfers to achieve both rigidity and flexibility. -
Page 6: Rear Adjustment 4 Point Sensor Tilt Plate
Zeus Camera Manual Rear Adjustment 4 Point Sensor Tilt Plate When taking deepsky objects, using sensor tilt plate can get a much smaller field curvature of the telescope. We adopt rear Adjustment and 4 points tilt plate, it has a lot advantages in usage. -
Page 7: Deep Cooling
For understand 4 point adjustment method, we made a example for users: Deep Cooling Player One cooled camera series use 2 Stage TEC Cooling unit, after improved the structure design to reject the heat back to camera chamber, Zeus Camera Delta-T can... -
Page 8: 512Mb Ddr3 Cache
Zeus Camera Manual 512MB DDR3 Cache As an improvement, DDR3 cache in cooled cameras are increased to 512MB. It helps stabilize and secure data transmission, it effectively avoids frame dropping and greatly reduces readout noise. With the DDR3 cache, the camera does not have high demands on computing needs any longer, it will still have excellent performance even if it is connected to a USB 2.0 port. -
Page 9: Starvis Technology
Zeus Camera Manual STARVIS Technology ZEUS 455M Pro cooled camera based on Sony STARVIS technology, it is back- illuminated pixel technology used in CMOS image sensors. Full-Frame Format ZEUS 455M Pro cooled camera has full-frame format (36mm*24mm), it is very suitable for professional DSO imaging. -
Page 10: Non-Amp-Glow
16bit can make the color more vivid. Non-Amp-Glow ZEUS 455M Pro cooled camera is a Non-Amp-Glow camera too! 300s, gain=0, offset=5, dark frame at -5℃ of ZEUS 455M Pro cooled camera: DOWNLOAD ℃ Preview of Dark frame: Exposure=300s, gain=0, offset=5, temp=-5... -
Page 11: Type-C Data Port And Power Port
Zeus Camera Manual Non-Amp-Glow can give us very clean background, much easier to get high quality images. Type-C Data port and Power port Back piece of cooled camera has 2 Type-C data port and 12V DC 5.5×2.1mm power port. Main data port support USB3.0 protocol, the camera can run 6.5fps under RAW8 mode. Type-C port is easier to plug in when assemble the imaging equipment in night. -
Page 12: Standard Cable Usage
Zeus Camera Manual Standard Cable Usage Cooling System and Anti-Dew Heater In ASCOM window, we provide 3 adjustable parameters: Target temperature, Fan Speed and Anti-Dew power. Standard Delta-T: 35℃ (± 2℃) , when ambient temp 30℃, fan speed 100%, dew heater 10%. -
Page 13: Overvoltage And Overcurrent Protection Mechanism
Dew problem is the biggest enemy in astro imaging, the camera integrated anti-dew heater in front of the camera. The heat power is adjustable. Overvoltage and overcurrent protection mechanism Player One cameras produced by us ensures the safety of your camera and other equipment through overvoltage and overcurrent protection mechanisms. -
Page 14: Performance
Zeus Camera Manual Performance Dual Sampling Mode ZEUS series has dual sampling mode. Normal mode and Low Noise mode, they have different advantages in imaging. 1. Normal mode has faster FPS, it is more suitable for planetary imaging. 2. Low Noise mode (LRN) mode has lower readout noise and higher dynamic range. it is more suitable for DSO imaging. - Page 15 Zeus Camera Manual...
-
Page 16: Frame Rate
Zeus Camera Manual Frame rate ZEUS 455M Pro cooled camera can run 6.5FPS under RAW8 mode, 3.2FPS under RAW16 mode. Extended Full well ZEUS 455M Pro cooled camera has 71.6Ke full well. Readout Noise Regarding readout noise, we solemnly promise that all values are obtained from actual tests. -
Page 17: Qe Curve
Zeus Camera Manual QE Curve... -
Page 18: Mechanical Drawing
Zeus Camera Manual Mechanical Drawing... -
Page 19: Bfl Solutions
Zeus Camera Manual BFL Solutions... - Page 20 Zeus Camera Manual Notice: Some BFL solution is 56mm (Compensate light path differences which caused by filters)
-
Page 21: Package List
Zeus Camera Manual Package List... -
Page 22: Warranty & Shipping Policy
For best experiences, we recommend customers to purchase our products form local dealers. After-sales Service Warranty Policy 2-year free warranty (time start from delivered) for Player One products. If the product has any issue, please send the image or video and description to support@player-one- astronomy.com for further check to confirm. ... - Page 23 × Legal proof-of-purchase, receipts, or invoices are not provided, or are reasonably believed to have been forged or tampered with. × A product sent to Player One for replacement does not include all original accessories, attachments and packaging, or contains items damaged by user error.
