SIMATIC IPC BX-53A
SIMATIC
Industrial PC
SIMATIC IPC BX-53A
Operating Instructions
02/2025
A5E53556103-AB
Preface
Product description
Safety instructions
Installing and connecting
the device
Commissioning the device
Operating the device
Expanding and assigning
parameters to the device
Device maintenance and
repair
Technical specifications
Dimension drawings
Standards and approvals
BIOS description
Hardware description
Technical support
Markings and symbols
List of abbreviations
1
2
3
4
5
6
7
8
9
10
11
12
A
B
C

Advertisement

loading
Need help?

Need help?

Do you have a question about the SIMATIC IPC BX-53A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Siemens SIMATIC IPC BX-53A

Summary of Contents for Siemens SIMATIC IPC BX-53A

  • Page 1 SIMATIC IPC BX-53A Preface Product description SIMATIC Safety instructions Installing and connecting the device Industrial PC SIMATIC IPC BX-53A Commissioning the device Operating the device Operating Instructions Expanding and assigning parameters to the device Device maintenance and repair Technical specifications...
  • Page 2 Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.
  • Page 3 The updates of the document will be published on the Siemens Industry Online Support (https://support.industry.siemens.com/cs/ww/en/view/109744171). Conventions The terms "PC" and "device" are sometimes used to refer to the SIMATIC IPC BX-53A in this documentation. Instead of the specific names of the operating system, we are using the abbreviation "Windows 10"...
  • Page 4 Device identification data ....................29 3.1.3 Permitted mounting positions .................... 31 Mounting the device ......................32 3.2.1 Mounting instructions......................32 3.2.2 Horizontal mounting ......................32 3.2.3 Vertical mounting ......................33 Connecting the device ....................... 35 SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 5 Restoring or installing the operating system ............... 63 7.4.2 Installing software and drivers ................... 63 Recycling and disposal ....................... 65 Beep code .......................... 66 Technical specifications ........................67 Applicability of technical specifications ................67 General technical specifications ..................67 SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 6 PCI-E Signal Select Jumper ....................106 12.2 External interfaces ......................107 12.2.1 USB 3.0 port ........................108 12.2.2 USB 2.0 port ........................108 12.2.3 Serial interface ........................ 108 12.2.4 Ethernet .......................... 109 12.2.5 HDMI ..........................110 SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 7 Problems when using expansion cards ................124 Markings and symbols ........................125 Overview ......................... 125 Safety ..........................125 Operator controls......................125 Certificates, approvals and markings ................126 Interfaces ........................127 List of abbreviations .......................... 128 Index ..............................130 SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 8 Information on: • Online at: bootable USB flash SIMATIC IPC Creating a bootable • Creating a bootable USB flash drive USB flash drive drive for recovery of operating (https://support.industry.siemens. system, software and drivers com/cs/ww/en/view/109811224) SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 9 Product description 1.2 Product highlights Product highlights The SIMATIC IPC BX-53A is an industrial Box PC that is widely utilized in the field of industrial automation due to its exceptional performance. • Powerful processors up to Intel Core i7 (10th generation) •...
  • Page 10 The SIMATIC IPC has CE certification for use in the industrial sector as well as in residential and commercial areas and small businesses. In addition to the industrial applications, therefore, it can also be used in building automation or in public facilities. SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 11 ④ Connection for functional earthing (Page 36) ② Power supply connection (Page 14) ⑤ Interfaces (Page 13) ③ Power button (Page 14) ⑥ Slot for PCIe/PCI expansion cards (X100-X106) Rear view ① Mounting bracket ② Air inlet SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 12 ② Mounting location 2 Mounting location for 2.5" or 3.5" drive directly into shock/vibration-proof bracket Additional information Technical notes and information on the rated conditions are available in the section Installation options for drive (Page 49). SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 13 USB port in BIOS. On how to disable the USB port, see USB configuration in Ad- vanced menu. If you want to select different COM modes, see Internal COM Connector (Page 115) to configure them, and you must also configure the BIOS accordingly. SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 14 10 seconds. Automatic startup may endanger the operation of the machine or plant, for example, after a power failure. Take this into account when designing the plant. SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 15 Perform a hardware reset only in the case of an emergency. Close all running programs. Make sure that there is no more read or write access to drives and I/O before performing the hardware reset. SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 16 The Ethernet interfaces are numbered on the enclosure to identify them clearly. The numbering by the operating system can differ. Status display Meaning Status Meaning of the status LED 1 Data transmission rate 10 Mbps Green 100 Mbps Orange 1000 Mbps SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 17 Internal construction of the device ① System fan ② Processor ③ Slots for expansion cards ④ On the enclosure: slots reserved for expansion cards ⑤ Power supply ⑥ Motherboard ⑦ Slots for memory slots ⑧ Drive cage SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 18 Siemens' products and solutions undergo continuous development to make them more secure. Siemens strongly recommends that product updates are applied as soon as they are available and that the latest product versions are used. Use of product versions that are no longer supported, and failure to apply the latest updates may increase customers' exposure to cyber threats.
  • Page 19 • Disconnect the device from the power supply in good time when a thunderstorm is approaching. • Do not touch power cables and data transmission cables during a thunderstorm. • Keep sufficient distance from electric cables, distributors and systems. SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 20 Take corresponding precaution measures before you open the device. Disclaimer for third-party software updates This product includes third-party software. Siemens AG only provides a warranty for updates/patches of the third-party software, if these have been distributed as part of a Siemens software update service contract or officially released by Siemens AG.
  • Page 21 • Do not expose the device to direct heat radiation from a heating device. • If condensation develops, wait approximately 12 hours or until the device is completely dry before switching it on. SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 22 If the following conditions are not met when installing the system, the EN 61010-2-201 approvals are voided and there is a risk of overheating and personal injury. • You should observe the following information on ambient and environmental conditions. SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 23 IEC/EN 61010-2-201. • The device conforms to IP 20 degree of protection on the front. Ensure that there is no splash water in the installation area. SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 24 Regenerative feedback of voltage to ground by a connected or installed component can damage the device. Connected or built-in I/Os, for example, a USB drive, are not permitted to supply any voltage to the device. Regenerative feedback is generally not permitted. SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 25 • Only install device or system expansions designed for this device. • Observe the information on "Electromagnetic compatibility" provided in the technical specifications. WARNING 火災危險和電擊危險 通/斷開關沒有將設備從電網斷開。在違規打開或設備損壞時，會出現電擊危險。如果設備或 連接線受損，則會進一步出現火災危險。 请如下保护自身和设备安全： • 在不使用設備時或設備損壞時，始終拨出電源插頭。電源插頭必須便于接觸。 • 將設備與安全引線正確相連。 • 爲機櫃中的裝配使用集中式的電源隔離開關。 SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 26 運行條件下使用設備。 • 僅使用適當的清潔劑。注意互聯網中的耐化性提示信息 (參見操作說明，“服務和支持”章 節 SIMATIC PC/PG 系統售後信息)。 WARNING 爲避免電磁干擾， 本產品不應安裝或使用於住宅環境。 Contact your technical support team or the point of sale to find out which device and system expansions are suitable for installation. SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 27 • UL approval of the device only applies when the UL-approved components are used according to their "Conditions of Acceptability". • We are not liable for functional limitations caused by the use of third-party devices or components. SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 28 5. Please keep the documentation in a safe place. It is required for initial commissioning and is part of the device. 6. Record the Device identification data (Page 29). SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 29 Ethernet address 2 (MAC) Product label The following image shows the product label on the SIMATIC IPC BX-53A as an example. ID link for the digital nameplate The ID link is a globally unique identifier according to IEC 61406, which you will find in the future as a QR code on your product and the product packaging.
  • Page 30 The COA label is only attached to the rear of the device containing a preinstalled and activated Windows operating system. Note The COA label is only available for devices delivered with Microsoft® Windows® operating system installed. Example of the COA label: SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 31 Ensure that the following clearances are maintained between the device and other components: • At least 100 mm from the interface panel of the device • At least 50 mm on the side of the device SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 32 • Four M4 screws Procedure 1. Place the mounting bracket on the rear of the device. 2. Secure the mounting brackets on the device using six #6-32 screws. Each side with three screws. SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 33 6. Screw on the device. 3.2.3 Vertical mounting Vertical mounting is also a recommended mounting type. Requirements • Two mounting brackets are supplied. • Six #6-32 screws are supplied. • A PH2 screwdriver • Four M4 screws SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 34 3. Place the device with the mounting brackets onto the mounting surface. 4. Mark the fixing holes. 5. Insert the four M4 screws in the drilled holes. 6. Screw on the device. SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 35 • Conductor cross-section ≤ 18 AWG • Cable length ≤ 3 m 220V supply voltage • Type RVV with three conductors • conductor cross-section ≤ 18 AWG • Cable length ≤ 3 m SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 36 Note: Make sure the cable plug is located behind the head of the assembly screw and the spacer. 3. Connect the functional ground to the equipotential bonding rail or grounding bar of the control cabinet or the plant in which the device is installed through an equipotential bonding line. SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 37 1. Connect the power plug to the socket. Information on the position of the socket is available in Power supply connections (Page 14). 2. Insert the power cable in the electrical socket. 3. Press the power button. The "PWR" LED lights up. SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 38 • Audio device with line in • Headphones • Microphone • Headset (with headphones and microphone) with the following standards: – OMTP: Standard for audio devices from Nokia, etc. – CTIA: Standard for audio devices from Apple® SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 39 Control level. Additional information is available under SIMATIC NET (https://new.siemens.com/global/en/products/automation/industrial-communication.html). The software package and the documentation are not included in the scope of delivery. Additional information You can find additional information on the Internet at: Technical support (https://support.industry.siemens.com) SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 40 2. Press the power button. The "PWR" LED lights up. 3. Operating system starts automatically. Follow the instructions on the screen. Press <ESC> or <DELETE> to enter setup. Note Once the operating system has been set up, the device may restart. SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 41 • Shut down the operating system and unplug the power plug from the device, see "Power supply connections (Page 14)". The device is switched off and fully disconnected from the mains voltage. No trickle current is flowing. SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 42 • Data on the data storage media might be lost. • The device might be damaged. Perform a hardware reset only in the case of an emergency. For all operating systems: • Press the power button for more than 4 seconds. SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 43 • Be sure to observe the respective import restrictions of the country in which the device will be used. Activate the Trusted Platform Module You can find information on activating the Trusted Platform Module in the detailed firmware/BIOS description, see "Security menu (Page 96)". SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 44 Take corresponding precautionary measures before you open the device. Requirement • The device is fully disconnected from the line voltage, see "Switching off the device (Page 41)". • All connection cables are unplugged. • PH2 screwdriver SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 45 • PCI; Rev 2.3 Expansion cards with 3.3 V and 5 V supply voltage can be operated • PCIe; Gen. 1, Gen. 2, Gen. 3(supported for PCIe X4 slot and PCIe X16 slot) SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 46 "Useable expansion cards (Page 45)". • The device is open, see important information in "Open the device (Page 44)". Procedure 1. Remove the retaining screws and remove the slot cover plate for the expansion card. SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 47 32 GB DDR4-2400/2666/2933MHz-UDIMM-288pin Combination options for memory modules There are four DIMM slots on the motherboard, which provide the necessary electrical and physical interfaces for DIMM modules to communicate with the computer system. SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 48 • DDR2 and DDR3 memory modules are not compatible. Please make sure to install DDR4 Memory Module on this motherboard. SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 49 Installation options for drive The SSD and HDDs can be installed in the drive cage at different mounting locations. You can find information on the mounting locations under: • Drive cage (Page 12) SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 50 1. Open the device. (Page 44) 2. Unplug the connection cable of the driver module on the motherboard. 3. Remove the highlighted five screws. 4. Lift the drive cage completely out of the device. SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 51 • The device is fully disconnected from the line voltage, see "Switching off the device (Page 41)". • The device is open, see important information in "Open the device (Page 44)". • PH2 screwdriver SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 52 3. Install the driver cage back into the device. 4. Connect the power and data cables to the drive. 5. Install the drive cage according to the reverse steps of removing the drive cage. SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 53 PC components that are subject to wear. The table below indicates the intervals for this replacement. Component Replacement interval Drives 3 years Backup battery 5 years 5 years Filter pad Depending on the degree of soiling SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 54 5. Press and hold the fan bracket at position (marked in above image) with your hand, and slide the fan to the left to remove it. 6. Take the fan and fan bracket out of the device. SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 55 • An original spare part, for example, a filter pad with the same type. • The device is open. (Page 44) Procedure 1. Take the fan and fan bracket out of the device. (Page 54) 2. Remove the filter in the direction of the arrow. SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 56 – Rated voltage: 3 VDC – Max abnormal charging current: 10 mA • For any requirements on product maintenance, contact Siemens Technical support (Page 121). • Do not throw lithium batteries into fire, do not solder on the cell body, do not recharge, do not open, do not short-circuit, do not reverse polarity, do not heat above 100°C and...
  • Page 57 – Courant de charge anormal max. : 10 mA • Pour toute demande concernant la maintenance du produit, contactez le support technique (Page 121) Siemens. • Ne jetez pas au feu des piles au lithium, n'effectuez pas de soudage sur la pile, ne la rechargez pas, ne l'ouvrez pas, ne la court-circuitez pas, n'intervertissez pas les pôles, ne...
  • Page 58 (Page 41)". • The device is open, see important information in "Open the device (Page 44)". • An original spare part, for example, a power supply with the same type. • PH2 screwdriver SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 59 If the processor is operated with a higher clock frequency than permitted, it can be destroyed or cause loss of data. • Operate the processor only at a clock frequency that is equal to or less than the permitted clock frequency. SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 60 2. Remove the highlighted fan connector. 3. Remove the highlighted screws. The fourth screw is hidden by the heat sink in the figure. 4. Remove the heat sink. 5. Unlock the socket and lift the socket cover. SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 61 Processor type and clock frequency If you use a processor of a different type, perform the BIOS update firstly. During the BIOS update, the microcode matching the processor is loaded. Contact the SIEMENS support to update the BIOS if you changed a different processor.
  • Page 62 Installing operating system, software and drivers You can restore the factory settings of the target system (i.e. the volume partitions, the operating system with installed device drivers, and the SIEMENS software products). This allows you to restore your device quickly if it has suffered damage.
  • Page 63 Information on commissioning the operating system, restoring the operating system and configuration of the operating system, see Microsoft® Windows® 10 Operating Instructions. (https://support.industry.siemens.com/cs/ww/en/view/109749498) Note After installing the operating system, Siemens strongly recommends that you install antivirus software to ensure system security. 7.4.2 Installing software and drivers Requirements •...
  • Page 64 6. Select destination folder and click Next to start the driver installation. 7. Click Finish. The installation is completed. Step 3: install the Network Connection Software 1. Click Step 3: Intel(R) Network Connections Software. 2. Click to install the LAN driver. SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 65 Due to their low level of pollutants, the devices described in these operating instructions can be recycled. Contact a certified disposal service company for environmentally sound recycling and disposal of your old devices. SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 66 Device maintenance and repair 7.6 Beep code Beep code Beeps Description 1 short beep Memory training success Beep loop Memory error SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 67 Light load (20%, 70 W) at 82% efficiency • 650 W: – Typical load (100%, 650 W) at 87% efficiency – Typical load (50%, 375 W) at 90% efficiency – Light load (20%, 130 W) at 87% efficiency SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 68 6.08 A 0.1 A 0.34 A Total power consumption , permitted 260 W Depends on the selected device configuration. Based on the maximum heat dissipation test. This value included external USB load 28W. SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 69 0.3 A ± 5% +5 VSB 2.0 A ± 5% DC output power should be less than 650 W. Total output power of +3.3 V and +5 V should be less than 115 W. SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 70 80% AM (1 kHz) Conducted Immunity (according to IEC 61000-4-6) • 150 kHz to 80 MHz: 10 V, 80% AM (1 kHz) Magnetic field 30 A/m; 50 Hz; 60 Hz (according to IEC 61000-4-8) SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 71 Information on the drives is available in your order documents. Drive Maximum number of drives Types of drive 2 (depends on the selected configura- • 3.5" SATA, 6 Gb/s; 1 TB tion) • 256 GB • 512 GB SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 72 Dynamic Video Memory Technology, uses 32 MB and 1.7 GB RAM in main memory Resolutions/frequencies/colors • HDMI up to 4096 x 2160@30Hz • VGA up to 1920 x 1200@60Hz • DVI-D up to 1920 x 1200@60Hz SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 73 Depending on the ordered device configuration, the device is equipped with or without the following installed operating systems. • Microsoft® Windows® 10 Enterprise 2021 LTSC, 64-bit, Multi-Language* *Multi-Language User Interface (MUI): 6 languages (English, Chinese, German, French, Spanish, Italian) SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 74 An electronic module is equipped with highly integrated components. Due to their design, electronic components are highly sensitive to overvoltage and thus to the discharge of static electricity. Such electronic components or modules are labeled as electrostatic sensitive devices. SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 75 The figure shows the maximum electrostatic voltages with which a person is charged, depending on humidity and material. These values conform to the specifications of IEC 61000-4-2. ① Synthetic materials ② Wool ③ Antistatic materials such as wood or concrete SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 76 This way, the discharge energy does not reach and damage the sensitive components. – Discharge your body electrostatically by touching grounded metallic parts before you take a measurement at a module. Always use grounded measuring instruments. SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 77 Dimension drawings Dimension drawing of device Front view and top view All dimensions in mm. SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 78 Dimension drawings 9.2 Dimension drawing of the expansion cards Dimension drawing of the expansion cards Long PCI card, PCIe card SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 79 The following are approvals that may be available. For the device itself, the actual certification information should be based on the product label and packaging label. ISO 9001 certificate The Siemens quality management system for all production processes (development, production and sales) meets the requirements of ISO 9001:2015, ISO 14001:2015 and ISO 45001:2018.
  • Page 80 This product meets the requirements of the standard IEC/EN 61000-6-4 and AS/NZS 61000.6.4; Generic standards - Emission standard for industrial environments. This product meets the requirements of the standard IEC/EN 61000-6-4 and AS/NZS 61000.6.4; Generic standards - Emission standard for industrial environments. SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 81 This product meets the requirements of India certification. BSMI This product meets the requirements of CNS15936, CNS 15598-1 generic standard. Table 10- 1 限用物質含有情況標示聲明 設備名稱：工業用電腦 Industrial PC, 型號（型式）：SIMATIC IPC BX-53A Equipment name Type designation (Type) 單元 Unit 限用物質及其化學符號 Restricted substances and its chemical symbols 铅 Lead 汞...
  • Page 82 Manchester M20 2UR United Kingdom The UK Declaration of Conformity is also available for download from the Siemens Industry Online Support website under the keyword "Declaration of Conformity". Mexico NOM Certification This product meets the requirements of the Norma Oficial Mexicana (NOM) certification.
  • Page 83 To enter BIOS Setup at startup: 1. Power on the device. 2. Press ESC key on your keyboard during the Power - On - Self - Test (POST) when the SIEMENS logo is shown on screen. The Aptio TSE main BIOS setup menu is displayed.
  • Page 84 • Save & Exit: For selecting the exit options and loading default settings. Function description fields Function description fields are at the top right corner of the menu screen and a brief description of the selected item. SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 85 The Main menu provides you an overview of the basic system information, and allows you to set the system date and time. Note Take the BIOS version installed on your IPC as standard. SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 86 3. Press F10 key and save the change. Note Enter the time in the 24-hour format. For example, you should enter 06:30:00 for 6:30 AM. License/Version Information License/Version Information contains the Readme OSS information. SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 87 Enable or disable the intel virtualization technology. [Enabled] • [Enabled] Virtualiza- • [Enabled]: A VMM can utilize the additional hardware capabili- • [Disabled] tion Tech- ties provided by Vanderpool Technology. nology • [Disabled]: Disable this function. SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 88 Enable or disable the High Precision Event Timer. [Enabled] • [Enabled] sion Timer • [Disabled] Refer to the following table to select the correct configuration options for Primary Display when you connect external graphic cards. SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 89 • [Enabled] • [Disabled] PCIE_16X_SLOT1 Configure PEG 0:1:0 Max Speed. [Auto] • [Auto] Speed • [Gen1] • [Gen2] • [Gen3] PCIE_16X_SLOT2 Enable or disable the PCIE_16X_SLOT2. [Enabled] • [Enabled] (MaxWidth 8x) • [Disabled] SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 90 • [Gen2] • [Gen3] Detect Non-Compliance PCI Express Device in [Disabled] • Detect Non- • [Enabled] PCIE_4X_SLOT3. Compliance De- • [Disabled] vice PCI1&PCI2 SLOTS Control the PCI Slots. [Enabled] • [Enabled] • [Disabled] SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 91 Enable or disable Me FW Image Re-Flash function. [Disabled] Me FW Image Re- • • [Enabled] Flash • [Disabled] Enable or disable Me FW update function. [Enabled] • FW Update • [Enabled] • [Disabled] SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 92 Enable or disable the serial port (COM) 3. [Enabled] • [Enabled] • Serial Port • [Disabled] COM4 X33 Enable or disable the serial port (COM) 4. [Enabled] • [Enabled] • Serial Port • [Disabled] SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 93 Enable or disable the USB X64. [Enabled] • [Enabled] • [Disabled] USB X65 Enable or disable the USB X65. [Enabled] • [Enabled] • [Disabled] Internal Enable or disable the Internal USB3_1. [Enabled] • [Enabled] USB3_1 • [Disabled] SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 94 Enable or disable the LAN X2P1 PXE BOOT. [Disabled] • [Enabled] PXE BOOT • [Disabled] Add-on PCIE Enable or disable the Add-on PCIE LAN card PXE Boot. [Disabled] • [Enabled] LAN card • [Disabled] PXE Boot SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 95 [Maximum Mode Mode] • [Maximum Mode]: Uses Maximum speed. • [Automatic • [Automatic Mode]: CPU Fan speed change based on CPU Mode] temperature. • [Silent Mode] • [Silent Mode]: A lower sound mode. SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 96 Select Security item in BIOS Setup screen to enter Security menu. Administrator Password This option allows you to set an administrator password level password for BIOS. If you have set an administrator password, Siemens recommends that you enter the administrator password for accessing the BIOS. To set an administrator password: 1.
  • Page 97 Follow the same steps as in changing a user password, but click OK when prompted to create/confirm the password. Note Record the new password when the password is changed. If you forget the password, you can contact Siemens Technical support. TPM Device Selection System parameters Function description...
  • Page 98 • [Enabled]: Select to accelerate the boot speed. • [Disabled] • [Disabled]: Select to go back to normal boot. Quiet Boot Enable or disable the Quiet Boot option. [Enabled] • [Enabled] • [Disabled] SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 99 UEFI Hard Disk Drive BBS Priorities In the UEFI Hard Disk Drive BBS Priorities page, you can modify the boot up screen between POST message and SIEMENS logo. The actual system parameter depends on the above configuration option for Fixed BOOT order Priorities.
  • Page 100 Restore Defaults Restore/load default values for all setup options. Save as User Defaults This option saves current configuration as User Defaults. Restore User Defaults This option restores User Defaults to all setup options. SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 101 PCIEX16_SLOT1-2 slot support PCIe x16 or dual PCIe x8, you can refer to PCI-E Signal Select Jumper (Page 106) (J_PEG_CFG1) for jumper configuration. Technical features of the motherboard Technical features of the motherboard can be found under "Technical specifications of the motherboard (Page 72)". SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 102 ⑧ Full-Size SIM Card Slot ⑱ • LAN RJ45 Connector • Dual USB3.0 TYPE-A Connector2 ⑨ USB3.0 TYPE-A Connector ⑲ • Line Out • Microphone • Line In ⑩ USB2.0 Internal Vertical TYPE-A Connector SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 103 • The screws are not allowed to connect with motherboard circuit or components. The motherboard can be damaged by this action. • Do not leave the screws or the metal components on the motherboard or inside of the chassis. SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 104 12.1.3.1 CMOS Clear Jumper CMOS Clear Jumper Pin setting Function 1-2(Default) Normal Clear CMOS Note Set the jumper back to protected mode after clearing CMOS. SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 105 (0xA06 Bit5, H) (0xA06 Bit6, H) SIO_GPO77 + 5V (0xA06 Bit7, H) : "H" or "L" means the default voltage is High or Low level. (5V GPIO) 12.1.3.3 AT or ATX Select Jumper SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 106 Enable PCI CLK 66MHz 12.1.3.5 PCI-E Signal Select Jumper J_PEG_CFG1 (PCI-E Signal Select Jumper 3*1 Pin 2.54mm) Pin setting Function 1-2(Default) PCIE_16X_SLOT1: PCIe 16X PCIE_16X_SLOT2: No resources PCIE_16X_SLOT1: PCIe 8X PCIE_16X_SLOT2: PCIe 8X SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 107 Audio AUDIO1 3.5 mm jack 1. Line-In 2. Line-Out 3. Mic-In DVI VGA1 Connection of an analog monitor PS/2 X10 PS/2_USB1 PS/2 Connector (Keyboard and Mouse) DVI X70 DVI-I 24+4P/F Connector (Support DVI-D) SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 108 USB 2.0 port Short description Meaning USB_P5V_fused (O) +5 V, fused USB_D0M (I/O) Data– USB_D0P (I/O) Data+ USB_GND 12.2.3 Serial interface RS232 Pin assignment RS232 Short description Meaning Data carrier detect (I) Received data (I) SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 109 Green: 100 Mbps • Orange: 1000 Mbps LED 2 – • Off: Stop • Yellow: Active connected • Yellow flashing: Data transfer active The Ethernet interface supports MDXI (auto crossover) for all transmission rates. SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 110 TMDS clock+ 12.3 Internal connector 12.3.1 Fan connector The pin assignment in the table below applies to all fan connectors on motherboard. FAN Header Pin setting Function +12V FAN Speed Detection FAN Speed Control SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 111 POWER 3.3V LED+ HDD 3.3V LED- POWER 3.3V LED- RESET- POWER+ RESET+ POWER- 12.3.3 Internal USB 2.0 connector Internal USB 2.0 Connectors provides front USB 2.0 Header which require appropriate cable to support. SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 112 + 5V + 5V + 5V + 5V USB2_12- USB2_13- USB2_7- USB2_8- USB2_12+ USB2_13+ USB2_7+ USB2_8+ 12.3.4 Internal USB 2.0 Vertical Type A Connector USB 2.0 Vertical Connector Definition Definition S_USB_PN10 S_USB_PP10 SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 113 ATX Power 4‐Pin Connector is for ATX PSU plug. Make sure you insert the ATX PSU plug on motherboard in the right orientation, otherwise the plug cannot be inserted. ATX 4-Pin Power Input Connector Definition +12V +12V SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 114 ATX Power 24‐Pin connector is for ATX PSU plug. Make sure you insert the ATX PSU plug on motherboard in the right orientation, otherwise the plug cannot be inserted. Note ATX Power 24‐Pin connector must be connected, otherwise the system cannot be turned on. SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 115 Internal COM Connectors provides five ports which require appropriate cable to support: • COM2/5/6 support RS232 • COM3 supports RS232/RS422/RS485 • COM4 supports RS232/RS485 RS232 Short description Meaning Data carrier detect (I) Received data (I) Transmitted data (O) Data terminal ready (O) Ground SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 116 Transmit / receive data - (I/O) for half-duplex mode JP3 (COM1 DCD/RI Select Jumper 3*2 Pin 2.54mm) Pin setting Function Graphic 1-3, 2-4 COM1_PIN1: + 5V COM1_PIN9: + 12V 3-5, 4-6(Default) COM1_PIN1: DCD COM1_PIN9: RI SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 117 COM3_PIN9: + 12V 3-5, 4-6(Default) COM3_PIN1: DCD COM3_PIN9: RI JP9 (COM4 DCD/RI Select Jumper 3*2 Pin 2.54mm) Graphic Pin setting Function 1-3, 2-4 COM4_PIN1: + 5V COM4_PIN9: + 12V 3-5, 4-6(Default) COM4_PIN1: DCD COM4_PIN9: RI SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 118 For JP3, JP8, JP9, JP10, JP11, JP12, do not short-circuit PIN1 and PIN2 with jumpers or the device will be damaged. 12.3.10 M.2 Key M slot This socket allows you to install an M.2 module. Note This slot supports PCIe x4 NVMe/ SATA SSD Auto Detect, 2242/2280 storage devices. SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 119 Memory Modules. Refer to the chapter Installing memory module (Page 48) for detailed installation instruction. 12.3.12 SATA 6.0 Gbps Port Connectors The motherboard provides four pieces of 7‐pin SATA Port Connectors, which support SATA devices through the connection of SATA Cable. SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 120 Hardware description 12.3 Internal connector 12.3.13 Battery socket The Battery Socket on the motherboard is for CR2032 Battery used for COMS data retention. SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 121 Please check regularly if updates and hotfixes are available for download to your device. The download area is available on the Internet at the following link: After Sales Information System SIMATIC IPC/PG (http://www.siemens.com/asis) SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 122 2. Set the date and the time in the "Main" tab. Time and date are wrong even The backup battery is dead. Replace the backup battery. after correctly setting them in the firmware (BIOS) SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 123 You can find the files and descriptions needed for GPT data storage medium is this on the supplied data storage medium. aborted with the following error message: "Status: 0xc0000225 Info: The boot selection failed because a required device is inaccessible" SIMATIC IPC BX-53A Operating Instructions, 02/2025, A5E53556103-AB...
  • Page 124 Different pin assignment expansion card and restart the device. If the error no longer occurs, the expansion card was the cause of the fault. Replace this with a Siemens expansion card or contact the supplier of the ex- pansion card.
