Page 1 IPC BX-56A and IPC BX-59A Preface Product description SIMATIC Safety instructions Installing and connecting the device Industrial PC IPC BX-56A and IPC BX-59A Commissioning the device and device functions Operating the device Operating Instructions Expanding the device Maintaining and repairing the device Technical specifications Technical support...
Page 2: Legal Information
Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.
Page 3: Preface
General knowledge in the field automation control engineering is recommended. Validity of the operating instructions These operating instructions are valid for all versions of the SIMATIC IPC BX-56A and IPC BX- 59A. The updates of the document will be published on the Siemens Industry Online Support (https://support.industry.siemens.com/cs/ww/en/view/109744171).
Page 4 Preface History The following editions of these operating instructions have been published: Edition Comment 04/2024 First edition 06/2024 Add 2-slot EM information 02/2025 Add 1-slot EM and 4-slot EM information IPC BX-56A and IPC BX-59A Operating Instructions, 02/2025, A5E52426179-AC...
Page 5: Table Of Contents
Table of contents Preface ..............................3 Product description ..........................10 Important instructions and manuals for operating the device..........10 Product highlights......................11 Product portfolio ........................ 13 Configuration options and product configuration limitations ..........15 Structure of the devices ..................... 17 1.5.1 Base module (BM) ......................
Page 6 Table of contents Notes on device and system extensions ................44 Installing and connecting the device ....................46 Preparing for installation ....................46 3.1.1 Checking the delivery ......................46 3.1.2 Identification data of the device ..................47 3.1.3 Permitted mounting types ....................48 Mounting the device ......................
Page 7 Table of contents Trusted Platform Module (TPM) ..................92 Buffer memory NVRAM ...................... 93 Operation without monitor and keyboard ................93 Fan control ........................93 Expanding the device .......................... 95 Base module (BM) ......................95 6.1.1 Opening the BM device ...................... 95 6.1.2 Drives ..........................
Page 8 Table of contents 6.4.6.3 Connecting power supply on the adapter board ............... 149 6.4.6.4 Installing/removing expansion card .................. 152 6.4.6.5 Installing active cooling GPU .................... 152 Maintaining and repairing the device ....................155 Maintenance intervals...................... 155 Repair information ......................155 Installing operating system, software and drivers .............
Page 9 Table of contents 8.5.2.2 2-slot EM bus board 2.1 ....................203 8.5.2.3 4-slot EM bus board 4.1 ....................203 8.5.2.4 Power adapter board......................204 8.5.3 External Interfaces ......................205 8.5.3.1 Power supply ........................205 8.5.3.2 USB ..........................206 8.5.3.3 DisplayPort ........................206 8.5.3.4 Ethernet port ........................
Page 10: Product Description
• Important firmware settings • Supplied data storage medium • Firmware settings in the factory state • Online at: Firmware/BIOS description • Boot modes (SIMATIC IPC BX-56A, IPC BX-59A) (https://support.industry.siemens.com/cs/ ww/en/view/109825688) IPC BX-56A and IPC BX-59A Operating Instructions, 02/2025, A5E52426179-AC...
Page 11: Product Highlights
Commissioning the operating system • Online at: • Restoring the operating system Microsoft® Windows® 10 • Configuration of the operating system (https://support.industry.siemens.com/cs/ ww/en/view/109749498) SIMATIC IPC Creating a Information on: • Online at: bootable USB flash drive SIMATIC IPC Creating a bootable USB flash •...
Page 12 Product description 1.2 Product highlights Features SIMATIC IPC BX-56A and IPC BX-59A are the first modular product portfolio solutions offered by Siemens. Flexible power supply options and multiple expansion module options enhance industrial functionality and accelerate the performance of edge AI.
Page 13: Product Portfolio
The various Base Modules, Extension Modules and other optional PC modules offer you a highly flexible and adaptive system to suit your specific tasks. For SIMATIC IPC BX-56A and IPC BX-59A, you can use the Base Module (BM) independently, or combination with the following Extension Modules (EM): •...
Page 14: Base Module
Product description 1.3 Product portfolio Base module The Base module can work alone or with an extension module. Motherboard IPC BX-56A (Page 200) and IPC BX-59A (Page 201) have different BM motherboards. Power supply unit Base module can be equipped with the following types of power supply unit (PSU): •...
Page 15: Configuration Options And Product Configuration Limitations
Product description 1.4 Configuration options and product configuration limitations Configuration options and product configuration limitations Configuration options IPC BX-56A IPC BX-59A MLFB 6AG4132-0..-..6AG4133-0..-..Mounting The device supports 10 positions within the following four mounting types: • Desk mounting • Wall mounting •...
Page 16 Product description 1.4 Configuration options and product configuration limitations IPC BX-56A IPC BX-59A Power supply Base Module can be equipped with the following types of power supply unit (PSU): • DC 220W PSU • DC 400W PSU The optimal power supply solution (Page 32) is recommended for you after you select the product portfolio and estimate the maximum power consumption of PCIe cards on EM.
Page 17: Structure Of The Devices
Limitations of product configuration SIMATIC IPC BX-56A and IPC BX-59A are the first modular product portfolio solution offered by Siemens. When using the product in a modular way, you need to be aware of the following limitations: • Power limitation (Page 33) •...
Page 18: Interfaces Of The Base Module Device
Product description 1.5 Structure of the devices Rear view BM without fan module BM with fan module ① Heat sink ② Fan module 1.5.1.2 Interfaces of the Base Module device IPC BX-56A interfaces ① SIM card slot (X50-X51) 2 × slot for SIM cards ②...
Page 19 Product description 1.5 Structure of the devices ⑨ USB (X63-X66) 2 × USB3.2 Gen 1 port and 2 × USB3.2 Gen 2 port ⑩ Protective conductor Connection for protective conductor ⑪ DPP (X70-X71) 2 × DisplayPort connection ⑫ Power connector(X80) Connection for DC power supply Note : IPC BX-56A without PSU does not have this power connector.
Page 20: Status Displays Of The Base Module Device
Product description 1.5 Structure of the devices Note : Only if the X53 slot doesn't use a SATA SSD module, the X52 slot will work. : IPC BX-59A without PSU does not have this power connector. 1.5.1.3 Status displays of the Base Module device State Description PC ON/WD...
Page 21: 1-Slot Em
Product description 1.5 Structure of the devices 1.5.2 1-slot EM 1.5.2.1 Overview of 1-slot EM The 1-slot EM is as follows: 1.5.2.2 Views of the 1-slot EM Front view ① Expansion card slot (SLOT1/X301) ② Ventilation hole IPC BX-56A and IPC BX-59A Operating Instructions, 02/2025, A5E52426179-AC...
Page 22: Rear View
Product description 1.5 Structure of the devices Rear view ① Ventilation hole Top view ① Screws for fixing the cover IPC BX-56A and IPC BX-59A Operating Instructions, 02/2025, A5E52426179-AC...
Page 23: Internal Structure
Product description 1.5 Structure of the devices 1.5.2.3 Internal structure ① 1-slot EM motherboard ② Slot for expansion cards ③ Card retainer ④ Power supply connectors for PCIE card ⑤ Cable clamp IPC BX-56A and IPC BX-59A Operating Instructions, 02/2025, A5E52426179-AC...
Page 24: 2-Slot Em
Product description 1.5 Structure of the devices 1.5.3 2-slot EM 1.5.3.1 Overview The 2-slot EM is as follows: 1.5.3.2 Views of the 2-slot EM Front view ① Two slots for expansion cards (SLOT1/X301, SLOT2/X302) ② Ventilation hole IPC BX-56A and IPC BX-59A Operating Instructions, 02/2025, A5E52426179-AC...
Page 25 Product description 1.5 Structure of the devices Rear view ① Ventilation hole Top view ① Screws for fixing the cover ② Mounting holes IPC BX-56A and IPC BX-59A Operating Instructions, 02/2025, A5E52426179-AC...
Page 26: Internal Structure
Product description 1.5 Structure of the devices 1.5.3.3 Internal structure ① 2-slot EM motherboard ② Slots for expansion cards ③ Card retainer ④ Power supply connectors for PCIE card ⑤ Fan plug ⑥ Air duct (optional) ⑦ Cable management bracket (Built-in three cable clamps) ⑧...
Page 27: 4-Slot Em
Product description 1.5 Structure of the devices 1.5.4 4-slot EM 1.5.4.1 Overview of 4-slot EM The 4-slot EM is as follows: IPC BX-56A and IPC BX-59A Operating Instructions, 02/2025, A5E52426179-AC...
Page 28: Views Of The 4-Slot Em
Product description 1.5 Structure of the devices 1.5.4.2 Views of the 4-slot EM Front view ① Removable drives Slots for SATA 2.5" SSD (Slot1/X54, Slot2/X55) ② Power supply unit ③ Protective conductor Connection for protective conductor ④ PCI/PCIe expansion 4 slots for expansion cards (SLOT1/X301, SLOT2/X302, SLOT3/X303, cards SLOT4/X304) ⑤...
Page 29 Product description 1.5 Structure of the devices Side view_left ① Reserved screw holes for connecting the BM ② Reserved screw holes for captive screws Side view_right ① Screws for fixing the cover IPC BX-56A and IPC BX-59A Operating Instructions, 02/2025, A5E52426179-AC...
Page 30: Internal Structure
Product description 1.5 Structure of the devices Top view ① Screws for fixing the cover ② Mounting holes 1.5.4.3 Internal structure ① Fan module ② 4-slot EM motherboard ③ Cable clamp ④ Gold finger for BM connection ⑤ Card retainer ⑥...
Page 31: Status Displays Of The 4-Slot Em
Product description 1.5 Structure of the devices 1.5.4.4 Status displays of the 4-slot EM State Description ① Drive Activity Drive is not present or powered Drive is present and not active Flashing "GREEN" Drive is active Drive Status LED Off RAID is OK, and the drive is OK Flashing "RED"...
Page 32: Flexible Power Supply Solution
Product description 1.6 Flexible power supply solution Flexible power supply solution 1.6.1 Introduction To adapt to different application scenarios, BX-56A/BX-59A offers flexible power supply solutions. Power solution with DC 220W/400W None For BM stand-alone use when BM is operating at a low load. With DC 400W PSU 2-slot without PSU BM provides the power supply to the 2-slot EM.
Page 33: Selection Of The Optimal Power Supply Solution
Product description 1.6 Flexible power supply solution : When using a 4-slot EM with AC 1200W power supply, you can choose between the following two types of BMs: • BM without DC power supply; • For BM with DC power supply, the DC power supply must be removed. For how to remove the DC power supply, refer to Replacing the DC power supply (Page 116).
Page 34 Product description 1.6 Flexible power supply solution Product portfolio Maximum Allowed BM fan selec- Power Supply selec- Power on EM tion tion 745 W With fan • AC 1200 W (110V 945 W With fan • AC 1200 W (220V BX-56A G7400E only BM •...
Page 35: Applications
Accessories and spare parts Accessories from Siemens are available for your device that are not included in the scope of delivery. Obtaining accessories and original spare parts via the SIEMENS Industry Mall 1.
Page 36 : Ensure that the power supply port of the selected graphics card or PoE card is compatible with this power cable. SIEMENS spare parts services Information on ordering, the provision and delivery of spare parts can be found under "Expansion components and accessories...
Page 37: Safety Instructions
Safety instructions General safety instructions WARNING Life-threatening voltages are present with an open control cabinet When you install the device in a control cabinet, some areas or components in the open control cabinet might be carrying life-threatening voltages. If you touch these areas or components, you might be killed by electric shock. Switch off the power supply to the cabinet before opening it.
Page 38 Safety instructions 2.1 General safety instructions NOTICE Use in the scope of application for the UL 61010-2-201 When the BM device and BM with 2-slot EM device are used in the area of Industrial Control Equipment in accordance with UL 61010-2-201, note that the device is classified as "Enclosed equipment".
Page 39 Safety instructions 2.1 General safety instructions Battery WARNING Risk of explosion and release of harmful substances Improper handling of lithium batteries can result in an explosion of the batteries. Explosion of the batteries and the released pollutants can cause severe physical injury. Worn batteries jeopardize the function of the device.
Page 40: Cybersecurity Information
Siemens' products and solutions undergo continuous development to make them more secure. Siemens strongly recommends that product updates are applied as soon as they are available and that the latest product versions are used. Use of product versions that are no longer supported, and failure to apply the latest updates may increase customers' exposure to cyber threats.
Page 41: Data Protection
Data protection Siemens observes the data protection guidelines, especially the requirements regarding data minimization (privacy by design). This means the following for this SIMATIC product: The product does not process / save any personal information, but only technical functional data (e.g.
Page 42: Disclaimer For Third-Party Software Updates
2.5 Disclaimer for third-party software updates Disclaimer for third-party software updates This product includes third-party software. Siemens AG only provides a warranty for updates/patches of the third-party software, if these have been distributed as part of a Siemens software update service contract or officially released by Siemens AG. Otherwise, updates/patches are undertaken at your own risk.
Page 43: High Frequency Radiation
Safety instructions 2.7 Information on I/O devices When you plan your project, you should make allowances for: • The climatic and mechanical environmental conditions specified in the operating instructions. • Do not operate the device in severe operating conditions which are subject to caustic vapors or gases.
Page 44: Notes On Device And System Extensions
Safety instructions 2.8 Notes on device and system extensions NOTICE Damage through regenerative feedback Regenerative feedback of voltage to ground by a connected or installed component can damage the device. Connected or built-in I/Os, for example, a USB drive, are not permitted to supply any voltage to the device.
Page 45 Safety instructions 2.8 Notes on device and system extensions WARNING 爲避免電磁干擾，本產品不應安裝或使用於住宅環境。 Contact your technical support team or the point of sale to find out which device and system expansions are suitable for installation. Limitation of liability • All technical specifications and approvals of the device only apply if you use expansion components that have a valid CE approval (CE mark).
Page 46: Installing And Connecting The Device
Please inform the delivery service immediately if the package contents are incomplete or damaged or do not correspond with your order. Fax the enclosed form SIMATIC IPC/PG Quality Control Report. (https://ipcdownload.siemens.com/new-en) IPC BX-56A and IPC BX-59A Operating Instructions, 02/2025, A5E52426179-AC...
Page 47: Identification Data Of The Device
Installing and connecting the device 3.1 Preparing for installation 6. If the contents of the packaging are incomplete, damaged or do not match your order, inform the responsible delivery service immediately. WARNING Electric shock and fire hazard due to damaged device A damaged device can be under hazardous voltage and trigger a fire in the machine or plant.
Page 48: Permitted Mounting Types
Installing and connecting the device 3.1 Preparing for installation ID link for the digital nameplate The ID link is a globally unique identifier according to IEC 61406, which you will find in the future as a QR code on your product and the product packaging. You can recognize the ID link by the frame with a black frame corner at the bottom right.
Page 49 Installing and connecting the device 3.1 Preparing for installation The permissible mounting positions of the "BM with EM" are as follows: • BM with 1-slot EM: Position 1 and Position 5 • BM with 2-slot EM: Position 1 to Position 10 •...
Page 50 Installing and connecting the device 3.1 Preparing for installation Mounting type BM without fan BM with fan BM with EM (Using 4-slot EM as an example) Wall mounting Position 5 (Interfaces face down): (Recommended) Position 6 (Interfaces face left): Position 7 (Interfaces face up): Position 8 (Interfaces face right): IPC BX-56A and IPC BX-59A Operating Instructions, 02/2025, A5E52426179-AC...
Page 51 Installing and connecting the device 3.1 Preparing for installation Mounting type BM without fan BM with fan BM with EM (Using 4-slot EM as an example) Tower mounting Position 9: Desk mounting Position 10: Permitted temperature range is different for each mounting positions. See "Ambient conditions (Page 189)"...
Page 52: Mounting The Device
Installing and connecting the device 3.2 Mounting the device Note The clearance refers to installation space. If you want to meet the product's temperature specifications in a harsh application environment, device should maintain enough space for heat dissipation. Mounting the device 3.2.1 Mounting instructions Note...
Page 53 The equipment is enclosed type and needs to be installed within the machine/system according to NFPA79. Note Wall mounting and book mounting are the recommended mounting types. Siemens suggest you selecting the recommended mounting type. Otherwise, the permitted temperature for the product should be lower than the specified range. Fasten securely NOTICE...
Page 54: Mounting Bm
Installing and connecting the device 3.2 Mounting the device Material Bore diame- Fixing element Concrete 8mm diame- Dowel: 8mm diameter; 50 mm depth ter, Screws: 4.5mm diameter; 50 mm depth 60 mm depth Metal, M4 bolt+nut, length >=T+10mm, T=wall thickness. (at least 2 mm thick) Metal tapped hole Screw M4 x L, L= screw length...
Page 55: Book And Tower Mounting
Installing and connecting the device 3.2 Mounting the device Procedure for mounting 1. Place the mounting bracket on the rear of the device. 2. Secure the mounting brackets on the device using six M3 screws. Each side with three screws. 3.
Page 56: Mounting Bm And 1-Slot Em
Installing and connecting the device 3.2 Mounting the device Procedure for mounting 1. Place the mounting bracket on the rear of the device. 2. Secure the mounting brackets on the device using five M3 screws. Three screws at the bottom and two at the middle of the device. 3.
Page 57 Installing and connecting the device 3.2 Mounting the device • A T10 screwdriver • Six M3 screws and four M4 screws Procedure for mounting 1. Place the two mounting brackets on the two sides of the 1-slot EM and secure each mounting bracket with three M3 screws.
Page 58: Book And Tower Mounting
Installing and connecting the device 3.2 Mounting the device 3.2.3.2 Book and tower mounting Requirements • BM and 1-slot EM are connected (Page 65); • An original spare part, optional when purchasing 1-slot EM device separately, mounting brackets (MLFB: 6ES7648-1AA10-3YC0); •...
Page 59: Mounting Bm And 2-Slot Em
Installing and connecting the device 3.2 Mounting the device 3.2.4 Mounting BM and 2-slot EM 3.2.4.1 Desk and wall mounting Requirements • BM and 2-slot EM are connected (Page 67); • An original spare part, optional when purchasing 2-slot EM device separately, mounting brackets (MLFB: 6ES7648-1AA10-3YG0);...
Page 60: Book And Tower Mounting
Installing and connecting the device 3.2 Mounting the device 4. Insert the four M4 screws in the drilled holes. 5. Screw on the device. 3.2.4.2 Book and tower mounting Requirements • BM and 2-slot EM are connected (Page 67); • An original spare part, optional when purchasing 2-slot EM device separately, mounting brackets (MLFB: 6ES7648-1AA10-3YF0);...
Page 61 Installing and connecting the device 3.2 Mounting the device Procedure 1. Place the following mounting bracket on the side of the device and secure the mounting bracket with five M3 screws. 2. Place the following mounting bracket on the rear of 2-slot EM and secure bracket with three M3 screws.
Page 62: Mounting Bm And 4-Slot Em
Installing and connecting the device 3.2 Mounting the device 4. Insert the four M4 screws in the drilled holes. 5. Screw on the device. 3.2.5 Mounting BM and 4-slot EM 3.2.5.1 Desk and wall mounting Requirements • BM and EM are connected (Page 68) •...
Page 63: Book And Tower Mounting
Installing and connecting the device 3.2 Mounting the device Procedure for mounting 1. Place the mounting bracket on the rear of the device. 2. Secure each of the mounting bracket with three screws. 3. Place the device with the mounting brackets onto the mounting surface. 4.
Page 64 Installing and connecting the device 3.2 Mounting the device Procedure for mounting 1. Place the mounting bracket on the rear of the device. 2. Put the mounting bracket on the BM side and secure it with five screws. 3. Put the mounting bracket on the EM side and secure it with three screws. 4.
Page 65: Connecting Bm With Em
Installing and connecting the device 3.3 Connecting BM with EM Connecting BM with EM Note The following installation steps are only applicable for BM without EM. If your BM already has EM installed, you can skip these steps. Before proceeding, confirm the current configuration of your BM to ensure the correct installation.
Page 66 Installing and connecting the device 3.3 Connecting BM with EM 4. Insert the 1-slot EM busboard into the corresponding slot of the BM as shown. Ensure that the two devices are on the same plane. Note When separating the BM and EM, ensure to separate the two devices on the same plane. 5.
Page 67: Connecting Bm With 2-Slot Em
Installing and connecting the device 3.3 Connecting BM with EM 3.3.2 Connecting BM with 2-slot EM Requirements • The BM device is disconnected from the power supply and all connecting cables have been removed. • A flat-head screwdriver • A T10 screwdriver (diameter ≤ 5mm, length >50mm) Procedure 1.
Page 68: Connecting Bm With 4-Slot Em
Installing and connecting the device 3.3 Connecting BM with EM 5. Insert the T10 screwdriver into the marked holes and secure the 2-slot EM and BM with the three captive screws. 6. Again insert the T10 screwdriver into the marked holes and secure the other side of the 2- slot EM and BM with the three M3 screws.
Page 69 Installing and connecting the device 3.3 Connecting BM with EM Procedure 1. Open the BM device (Page 95). And release the rear panel. 2. Remove the removable plate of the BM rear panel with a flat-head screwdriver. Then install the rear panel to the BM and fasten with original screws. 3.
Page 70: Connecting The Device
Installing and connecting the device 3.4 Connecting the device 5. Insert the T10 screwdriver into the marked holes and secure the 4-slot EM and BM with the three captive screws. 6. Insert the T10 screwdriver into the marked holes and secure the other side of the 4-slot EM and BM with the three M3 screws.
Page 71 Installing and connecting the device 3.4 Connecting the device WARNING Risk of lightning strikes A lightning flash may enter the mains cables and data transmission cables and jump to a person. Death, serious injury and burns can be caused by lightning. Take the following precautions: •...
Page 72: Country-Specific Information On Supply Voltage
Installing and connecting the device 3.4 Connecting the device 3.4.2 Country-specific information on supply voltage USA and Canada Supply voltage 120 V / 230 V / 240 V AC Ensure that the power cords used are rated for the maximum current input and ambient temperature of the device and meet the requirements of the following standards: •...
Page 73 Installing and connecting the device 3.4 Connecting the device WARNING Electric shock and risk of fire High voltage may be present in a defective device, which can cause fire or an electric shock if touched. This can result in death and serious injury. •...
Page 74: Connecting The Power Supply
DC module's external power supply (Page 186). Note It is not recommended for DC power supply to use external filter. If you need to use the external filter, consult Siemens technical support. IPC BX-56A and IPC BX-59A Operating Instructions, 02/2025, A5E52426179-AC...
Page 75 Installing and connecting the device 3.4 Connecting the device WARNING Risk of incorrect cable connections All four cables must be connected when connecting the power supply plug connector. If only two cables are connected, personal injury and equipment damage may result. NOTICE Risk of damaging the device Improper grounding (PE) and power connections can cause equipment damage.
Page 76: Connecting The Ac Power Supply On 4-Slot Em
Installing and connecting the device 3.4 Connecting the device Procedure 1. Switch off the 24 V DC power supply. 2. Connect the four cables to the power supply plug connector. 3. Plug the cable-connected power supply plug connector into the power connector. 3.4.4.2 Connecting the AC power supply on 4-slot EM WARNING...
Page 77 Installing and connecting the device 3.4 Connecting the device WARNING Risk of electric shock There is also a risk of fire if the device or connecting lines are damaged. • Always fully disconnect the device from the mains voltage before performing work on the device or when the device will not be used over an extended period of time.
Page 78: Installing The Cable Strain Relief
Installing and connecting the device 3.4 Connecting the device To prevent unintentional removal of the power cable, you secure the plug as follows: 1. Remove the retaining screw. 2. Connect the power cable to socket. 3. Screw on the latch for the power plug. Secure the power cable with cable tie 1.
Page 79: Connecting Device To Networks
Installing and connecting the device 3.4 Connecting the device Procedure 1. Place the cable strain relief in the front of BM Interfaces panel. 2. Secure the cable strain relief with two M3 screws. 3.4.6 Connecting device to networks The following options are available for integrating the device in existing or planned system environments and networks.
Page 80: Additional Information
Installing and connecting the device 3.4 Connecting the device SIMATIC NET Use this software package to create, operate and configure an innovative network for Field & Control level. Information on this can be found on the SIMATIC NET Manual Collection CD. The software package and the documentation are not included in the product package.
Page 81: Commissioning The Device And Device Functions
Commissioning the device and device functions General information on commissioning CAUTION Danger of burns The device surface can reach over 65 °C. You may get burned without any protection when touching it. Don't directly touch the device during its operation. Always wear protective gloves before touching the device.
Page 82: Faulty Installation
Commissioning the device and device functions 4.2 Switching the device on/off For the configurations without operating system pre-installed, contact the operating system provider to install the operating system first. Following the initial startup, the operating system preinstalled on the drive is automatically configured on the device.
Page 83: Hardware Reset
Commissioning the device and device functions 4.3 Configuring automatic switch-on of device Fully disconnecting the device from the line voltage WARNING Risk of electric shock The power button and on/off switch do not fully disconnect the device from the supply voltage.
Page 84 Commissioning the device and device functions 4.3 Configuring automatic switch-on of device Configure this function with the firmware setting (Setup Utility > Advanced>Miscellaneous Configuration > State After power failure): • State After G3 You can find information on this in the detailed firmware/BIOS description, see Important instructions and manuals for operating the device (Page 10).
Page 85: Operating The Device
Operating the device Drive configurations for RAID system Both RAID1 and RAID5 systems are supported by IPC BX-59A. The RAID1 system works on the principle of "data mirroring on two drives". In the event of a defective drive the RAID1 system can continue to work on the remaining drive and thus achieves a high level of availability.
Page 86: Raid System: Installation Options For Drives
Operating the device 5.2 Operating RAID systems "Intel® Optane™ Memory and Stor- Status indicator for the system Mounting location age Management" Controller 3, Port 0 SSD in SSD slider in IPC BX-59A BM Mounting location X52 Controller 4, Port 0 SSD in SSD slider in IPC BX-59A BM Mounting location X53 Controller 2, Port 5...
Page 87 Operating the device 5.2 Operating RAID systems 3. From the firmware selection menu, using the arrow keys, select the entry "Device Management" and confirm your selection. 4. From the "Devices List", select the entry "Intel <R> Rapid Storage Technology". 5. Select "Create RAID Volume". 6.
Page 88: Monitoring The Onboard Raid System
Operating the device 5.2 Operating RAID systems 5.2.4 Monitoring the onboard RAID system Open the "Intel® Optane Memory and Storage Management" onboard RAID system 1. Select "Start" > "Intel® Optane™ Memory and Storage Management". Display status of the onboard RAID system (faulty drive) 1.
Page 89: Integrating A New Drive Into The Onboard Raid System
Operating the device 5.2 Operating RAID systems Creating RAID Volume 1. Select the "Create RAID Volume" tab. 2. In the "Create RAID Volume" area on the right side of the window, you need to fill in the following information: – Name: Enter the name for RAID Volume. –...
Page 90 Operating the device 5.2 Operating RAID systems Configure "Automatic integration of a new drive" (before replacing a defective drive) NOTICE Risk of data loss If a new drive is automatically integrated, the new drive is not checked for partition information or existing data. All partitions and data of the new drive are deleted without warning.
Page 91 Operating the device 5.2 Operating RAID systems 3. Select the "Manage" menu. You will find the following components in the "Storage System View" area: ① The drives mounted in the onboard RAID system with the information that a drive is not yet mounted (Unknown hard disk).
Page 92: Data Synchronization In The Raid System
Operating the device 5.3 Trusted Platform Module (TPM) 5.2.6 Data synchronization in the RAID system NOTICE Danger of incorrect operations on machine and plant: delayed system reaction during data synchronization Data is synchronized if a drive fails. The system can respond with a delay depending on the size of the drive and system load. In extreme cases, the execution of keyboard, mouse or touch screen commands may be briefly delayed.
Page 93: Buffer Memory Nvram
The fan speed or control mode of BM and EM can be set in the BIOS setup menu, for the detailed information, refer to the SIMATIC Industrial PC Firmware/BIOS description (SIMATIC IPC BX-56A, IPC BX-59A) (https://support.industry.siemens.com/cs/ww/en/view/109825688). BM fan control Mode of speed con-...
Page 94 Operating the device 5.6 Fan control If the default coefficient does not meet the actual application scenario, you can adjust the variation coefficient based on the actual temperature of the PCIE card. At the same ambient temperature, the higher the coefficient, the faster the fan speed. Mode of Description Application scenario...
Page 95: Expanding The Device
Expanding the device Base module (BM) 6.1.1 Opening the BM device Requirements • The device is disconnected from the power supply. • All connecting cables on the device are removed. • A T10 screwdriver Procedure - opening the device 1. Remove the marked four screws on the rear panel of the device. 2.
Page 96: Drives
Expanding the device 6.1 Base module (BM) 6.1.2 Drives 6.1.2.1 Replacing the 2.5" SATA SSD Requirements • The device is disconnected from the power supply and all connecting cables have been removed. • The device is open (Page 95). • An original spare part, that is a hard disk drive of the same type, see information under Accessories and spare parts (Page 35).
Page 97: Replacing The Nvme Ssd On Motherboard
The device has a slot for NVMe SSD on the back of the 2.5" SATA SSD drive. You can use the NVMe SSD module produced by Siemens or other third-party suppliers. Our device provides one Key M interface and mounting positions. key M SSD module can be connected to the interface slot X8100 on the motherboard.
Page 98: Replacing The Ssd In Ssd Slider
Note: Make sure the NVMe SSD module board is located between head and spacer of assembly screw. 5. Place the thermal interface material on the NVMe SSD and reinstall the heat sink. Note: To avoid SSD card bending, Siemens recommends that you use the soft thermal interface material (TIM). 6. Close the device.
Page 99 Expanding the device 6.1 Base module (BM) Requirements • The device is disconnected from the power supply. • A M.2 NVMe/SATA SSD that is approved for industrial applications. • A T10 screwdriver Procedure - installing the M.2 NVMe/SATA SSD 1. Remove the retaining screw and SSD slot cover. 2.
Page 100 Expanding the device 6.1 Base module (BM) 3. Remove the two screws on the black SSD cover. 4. Place the M.2 NVMe/SATA SSD in the slot and secure it with the designated screw. Note: Keep the marked Key M notch on the left side of the module as shown in the image. 5.
Page 101: Replacing A Drive In The Raid System
Expanding the device 6.1 Base module (BM) 6. Plug in the slot back into the device and tighten it with designated screw. Procedure - removing the M.2 NVMe/SATA SSD To remove the M.2 NVMe/SATA SSD, carry out the steps for installing the M.2 NVMe/SATA SSD in the reverse order.
Page 102: Replacing A Defective Drive In The Raid System
Expanding the device 6.1 Base module (BM) Replacing a defective drive in the RAID system • Determine which drive was reported by the RAID software as defective. – Assignment of the port numbers for labeling on the device: - SATA port 2 => HDD 0 - SATA port 3 =>...
Page 103: Replacing The Memory Module
Expanding the device 6.1 Base module (BM) Usable memory modules • SO-DIMM DDR5 memory modules • Memory transaction rate 4800 MT/sec "unbuffered" • "without ECC" • "with ECC" Conditions for using expansion cards • Memory is operated in dual-channel mode if two modules are installed. •...
Page 104: Installing The M.2 Module
Installing the M.2 module Introduction to the M.2 module Siemens uses the M.2 module to extend the Siemens IPC. You can use the M.2 module produced by Siemens or other third-party suppliers. Our device provides two M.2 Key B interfaces and mounting positions. M.2 key B module can be connected to the interface slot X100 or X101 on the motherboard.
Page 105 Support NVRAM : You can insert a 4G/5G SIM card into the SIM card slot to connect to network. However, the SIM card function has not been certified by UL. Siemens recommends you to use SIM cards without PIN codes.
Page 106 Expanding the device 6.1 Base module (BM) 4. Align the golden finger of the M.2 module on the motherboard, and then press firmly until it is completely seated on the slot. 5. Fasten a screw to M.2 module (with torque 0.6 Nm). Note: Make sure the M.2 module board is located between head and spacer of assembly screw.
Page 107: Inserting The Nano Sim Card
Expanding the device 6.1 Base module (BM) 8. Get the cable of the M.2 module installation accessory out of the housing through reserved antenna holes. 9. Close the device. Procedure - Removing the M.2 module Follow the above steps in reverse order to remove the M.2 module. 6.1.5 Inserting the Nano SIM card Requirements...
Page 108 Expanding the device 6.1 Base module (BM) 1. Push the card cover to the left. 2. Insert the Nano SIM card correctly into the supporting frame. Note This SIM card slot supports the installation of two cards at the same time. When you install two SIM cards, •...
Page 109: Replacing The Device Fans
Expanding the device 6.1 Base module (BM) 6.1.6 Replacing the device fans If you have the device fan, you can replace the device fan directly without opening the BM device. Requirements • The device is disconnected from the power supply. •...
Page 110 Expanding the device 6.1 Base module (BM) 3. Disconnect the fan cable connectors and pull out the fan, replace with a new fan, reconnect the fan cable to the connector, and insert the new fan back into the fan slot. 4.
Page 111: Installing The Device Fans
6.1.7 Installing the device fans For better cooling the device, you may choose the BM device with fan module, or purchase the fan module alone in Siemens Industry Mall. Requirements • The BM device is disconnected from the power supply.
Page 112 Expanding the device 6.1 Base module (BM) 3. Connect the fan cable connectors to the fan plugs on the motherboard, and install the marked two black snap rivets to secure the device fan. Note Keep the fan cable away from the 2.5" SATA SSD bracket. 4.
Page 113: Replacing The Backup Battery
– Rated voltage: 3 VDC – Max abnormal charging current: 10 mA • For any requirements on product maintenance, contact Siemens Technical support (Page 219). • Do not throw lithium batteries into fire, do not solder on the cell body, do not recharge, do not open, do not short-circuit, do not reverse polarity, do not heat above 100°C and...
Page 114 – Courant de charge anormal max. : 10 mA • Pour toute demande concernant la maintenance du produit, contactez le support technique (Page 219) Siemens. • Ne jetez pas au feu des piles au lithium, n'effectuez pas de soudage sur la pile, ne la rechargez pas, ne l'ouvrez pas, ne la court-circuitez pas, n'intervertissez pas les pôles, ne...
Page 115 Expanding the device 6.1 Base module (BM) NOTICE Disposal of batteries Batteries do not belong in domestic garbage. The user is legally obliged to return used batteries. Used batteries pollute the environment as special waste. You as a user are liable to prosecution if you do not properly dispose of batteries.
Page 116: Replacing The Dc Power Supply
Expanding the device 6.1 Base module (BM) 2. Remove the battery from the battery bay and disconnect the marked cables. 3. Press the new battery into the socket applying slight pressure. 4. Place the battery cover back into the battery bay and replace the screws removed in step one.
Page 117 Expanding the device 6.1 Base module (BM) Procedure 1. Remove the marked screw on the cover of the power supply. 2. Unplug power supply plug connector and remove the marked three screws on the power supply motherboard. 3. Remove the DC power supply and replace with another one. 4.
Page 118: 1-Slot Em
Expanding the device 6.2 1-slot EM 1-slot EM 6.2.1 Opening the 1-slot EM device WARNING Risk due to unauthorized opening and improper repairs or expansions Improper procedure when carrying out expansions may result in substantial damage to equipment or endanger the user. If you install or exchange system expansions and damage your device, the warranty becomes void.
Page 119: Expansion Cards
Expanding the device 6.2 1-slot EM Procedure 1. Remove the marked five screws in the cover. 2. Remove the cover by lifting it up. 6.2.2 Expansion cards 6.2.2.1 Usable expansion cards Expansion cards compliant with the following standards are supported: •...
Page 120 Expanding the device 6.2 1-slot EM Procedure - Removing the slot cover 1. Open the 1-slot EM device (Page 118). 2. Remove the two screws below the ventilation hole. 3. Remove the marked PCIE cover. 4. Remove the screw above slot. IPC BX-56A and IPC BX-59A Operating Instructions, 02/2025, A5E52426179-AC...
Page 121: Installing And Removing A Pcie Card
Expanding the device 6.2 1-slot EM 5. Remove the slot I/O bracket. 6.2.3 Installing and removing a PCIe card Requirements • The 1-slot EM is open. (Page 118) • The slot cover is removed. (Page 119) • A T10 screwdriver Procedure - Installing a PCIe card NOTICE Damage to the expansion card.
Page 122 Expanding the device 6.2 1-slot EM 1. Insert the PCIe card into the relevant slot. 2. Secure the expansion card with the card retainer. 3. Fasten the PCIe card and the PCIe cover in the reverse order from step 2 to step 4 in the "Remove the slot cover (Page 119)"...
Page 123: 2-Slot Em
Expanding the device 6.3 2-slot EM 2-slot EM 6.3.1 Opening the 2-slot EM device WARNING Risk due to unauthorized opening and improper repairs or expansions Improper procedure when carrying out expansions may result in substantial damage to equipment or endanger the user. If you install or exchange system expansions and damage your device, the warranty becomes void.
Page 124: Replacing The Filter Pad
Expanding the device 6.3 2-slot EM 6.3.2 Replacing the filter pad Requirements • An original spare part, i.e. a filter pad of the same type; or clean and reuse the filter pad. Procedure 1. Loosen the marked screw and remove the filter pad cover of the fan module. IPC BX-56A and IPC BX-59A Operating Instructions, 02/2025, A5E52426179-AC...
Page 125: Replacing The Fan
Expanding the device 6.3 2-slot EM 2. Remove the filter pad. 3. Place a new filter pad with the same type. 4. Fasten the filter pad cover with screw. 6.3.3 Replacing the fan Requirements • The device is disconnected from the power supply and all connecting cables have been removed.
Page 126 Expanding the device 6.3 2-slot EM Procedure - Removing a fan 1. Remove the marked screw on the fan module. 2. Take the fan module out of the enclosure by pulling handle marked with "Push/Pull" on the fan module. 3. Remove the two marked screws and filter pad support part. IPC BX-56A and IPC BX-59A Operating Instructions, 02/2025, A5E52426179-AC...
Page 127 Expanding the device 6.3 2-slot EM 4. Use a T10 screwdriver to press the end of each of the fan's four black snap rivets to separate the ends from the clips. 5. Remove the four plastic rivets on the enclosure, and pull out the fan plug. Procedure- Installing a fan To install the fan, follow the steps for removing it in reverse order.
Page 128: Expansion Cards
Expanding the device 6.3 2-slot EM 6.3.4 Expansion cards 6.3.4.1 Usable expansion cards Expansion cards compliant with the following standards are supported: • PCIe: Gen. 1, Gen. 2, Gen. 3 and Gen.4. Conditions for using expansion cards Note Requirement for expansion cards •...
Page 129: Remove The Slot Cover
Expanding the device 6.3 2-slot EM 6.3.4.2 Remove the slot cover Requirements • The device is disconnected from the power supply. • All connecting cables on the device are removed. • A screwdriver of type Torx T10 Procedure - Removing the slot cover 1.
Page 130: Installing And Removing A Pcie Card
Expanding the device 6.3 2-slot EM 4. Remove the screw above slot. 5. Remove the slot I/O bracket. 6.3.4.3 Installing and removing a PCIe card Requirements • The 2-slot EM is open. (Page 123) • The slot cover is removed. (Page 129) •...
Page 131 Expanding the device 6.3 2-slot EM Procedure - Installing a PCIe card NOTICE Damage to the expansion card. The expansion card can break if excessive force is used. • Do not apply any pressure. • Do not apply excessive force on the slider when you push it onto the expansion card. 1.
Page 132: Installing And Removing A Passive Cooling Gpu
Expanding the device 6.3 2-slot EM 6.3.4.4 Installing and removing a passive cooling GPU When you install a passive cooling GPU, such as Nvidia T4, Nvidia L4 and Nvidia A2 Tensor Core GPU cards, you need to install an air duct for two purposes: •...
Page 133 Expanding the device 6.3 2-slot EM 3. Install the GPU card into the slot. 4. Fasten the GPU card and the PCIe cover in the reverse order from step 2 to step 4 in the "Remove the slot cover (Page 129)" section. 5.
Page 134: Installing And Removing An Active Cooling Gpu
Expanding the device 6.3 2-slot EM 7. Secure the cable management bracket to the EM enclosure with the marked screw. 8. Reinstall the 2-slot EM enclosure. Procedure - Removing a passive cooling GPU Proceed in the reverse order of installation to remove a passive cooling GPU card. 6.3.4.5 Installing and removing an active cooling GPU When you install an actively cooling GPU, you can install it directly in the 2-slot EM.
Page 135 Expanding the device 6.3 2-slot EM 2. Install the spacer stud on the housing. 3. Connect the power cable port to NVIDIA RTX A4000 card and insert the NVIDIA RTX A4000 card into the relevant slot. 4. Install a screw in the spacer stud to secure the L bracket. 5.
Page 136: Installing And Removing The Pre-Installed Configurations
Expanding the device 6.3 2-slot EM 7. Secure the cable management bracket to the EM enclosure with the marked screw. 8. Reinstall the 2-slot EM enclosure. Procedure - Removing an active cooling GPU card Proceed in the reverse order of installation to remove an active cooling GPU card. 6.3.4.6 Installing and removing the pre-installed configurations One product configuration has NVIDIA®...
Page 137 Expanding the device 6.3 2-slot EM Procedure - Installation process 1. Remove the marked screw on the cable management bracket. 2. Attach the two marked hexagonal studs to the back of the air duct. 3. Install the GPU card into the slot. IPC BX-56A and IPC BX-59A Operating Instructions, 02/2025, A5E52426179-AC...
Page 138 Expanding the device 6.3 2-slot EM 4. Place the air duct cover on the bracket and insert into the front groove. 5. Secure the air duct cover with two marked screws. 6. Insert the network interface card into the relevant slot. 7.
Page 139: Connecting An Additional Power Supply For The Expansion Card
Expanding the device 6.3 2-slot EM 8. Loosen the marked card retainer and then secure the network interface card with the card retainer. 9. Secure the cable management bracket to the EM enclosure with the marked screw. 10.Insert a fiber transceiver to network interface card. 11.Reinstall the 2-slot EM enclosure.
Page 140 Expanding the device 6.3 2-slot EM Requirements • The 2-slot EM is open (Page 123). • The slot cover is removed. (Page 129) • A T10 screwdriver Procedure Connect the additional power supply as follows: 1. Insert the power cable into the marked cable clamps and plug the cable into the power connector on the EM motherboard.
Page 141: 4-Slot Em
Expanding the device 6.4 4-slot EM 4-slot EM 6.4.1 Opening the 4-slot EM device WARNING Risk due to unauthorized opening and improper repairs or expansions Improper procedure when carrying out expansions may result in substantial damage to equipment or endanger the user. If you install or exchange system expansions and damage your device, the warranty becomes void.
Page 142: Replacing The Filter Pad
Expanding the device 6.4 4-slot EM 6.4.2 Replacing the filter pad Requirements • An original spare part, i.e. a filter pad of the same type; or clean and reuse the filter pad. Procedure 1. Loosen the two marked screws and remove the filter pad cover of the fan module. 2.
Page 143: Replacing The Fan Of 4-Slot Em
Expanding the device 6.4 4-slot EM 6.4.3 Replacing the fan of 4-slot EM Requirements • The device is disconnected from the power supply and all connecting cables have been removed. • The 4-slot EM device is open (Page 141). • An original spare part Procedure - Removing the device fan 1.
Page 144 Expanding the device 6.4 4-slot EM 5. Unplug the fan cable connector and release the fan cable from the clips as shown. 6. Push the four plastic screws to release the device fan. Then take the fan out of the enclosure.
Page 145: Changing The Drive In The Removable Tray
Expanding the device 6.4 4-slot EM 6.4.4 Changing the drive in the removable tray NOTICE Risk of damaging the drive and data loss Drives in the removable drive bays can only be replaced during operation in connection with RAID1 (hot swap). When you remove the drive while data is being written to it, you may damage the drive and destroy data.
Page 146: Replacing The Power Supply
Expanding the device 6.4 4-slot EM 3. Loosen the highlighted screws on the sides of the removable tray and remove the drive. 4. Carefully insert the new drive into the removable tray. Take care not to touch the contacts of the drive when you do this. 5.
Page 147 Expanding the device 6.4 4-slot EM Procedure - Removing the PSU 1. Remove the cable relief of the power supply cable. 2. Pull out the power cable. 3. While pushing the latch upward, pull the handle to scrape out the power supply unit. WARNING Don't pull in/out the power supply unit when the power cable is connected.
Page 148: Expansion Card
Expanding the device 6.4 4-slot EM 6.4.6 Expansion card 6.4.6.1 Usable expansion card Expansion cared with PCIe Gen. 1, Gen. 2, Gen. 3 and Gen. 4 are supported. Conditions for using expansion cards NOTICE Damage to the expansion card. The expansion card can break if excessive force is used. •...
Page 149: Connecting Power Supply On The Adapter Board
Expanding the device 6.4 4-slot EM Procedure - Removing the PCIe I/O Bracket 1. Opening the 4-slot EM device (Page 141). 2. Remove the marked screw and remove the cover as shown. 3. Remove the marked screws and the panels. 6.4.6.3 Connecting power supply on the adapter board Requirements...
Page 150 Expanding the device 6.4 4-slot EM MLFB Content Mating receptacle Remark 6ES7648- Cable 1 x 1 PCIe 2 x 4 pin auxiliary power connector GPU extra power cable 3AA00-1XA0 Cable 2 x 1 Peripheral connector (IDE 4 pin) PoE extra power cable IPC BX-56A and IPC BX-59A Operating Instructions, 02/2025, A5E52426179-AC...
Page 151 Expanding the device 6.4 4-slot EM Procedure - Connecting power supply on adapter board 1. Remove the marked screws. Then slide the adapter board cover on the left to remove the cover. 2. Remove the socket cover on the cover of adapter board. 3.
Page 152: Installing/Removing Expansion Card
Expanding the device 6.4 4-slot EM 6.4.6.4 Installing/removing expansion card Requirements • The 4-slot EM device is open (Page 141). • The slot cover is removed (Page 148). • A screwdriver of type Torx T10 Power supply connection for high-performance expansion cards If your expansion card has a power rating of more than 75 W, use the power cable to connect the GPU to the power socket on the adaptor card (Page 149).
Page 153 Expanding the device 6.4 4-slot EM Power supply connection for high-performance expansion cards If your expansion card has a power rating of more than 75 W, use the power cable to connect the GPU to the power socket on the adaptor card (Page 149). Procedure - Installing active cooling GPU 1.
Page 154 Expanding the device 6.4 4-slot EM 5. Insert the GPU card into the relevant slot and secure it on the GPU bracket unit. 6. Fasten the PCIe I/O bracket of the GPU card . IPC BX-56A and IPC BX-59A Operating Instructions, 02/2025, A5E52426179-AC...
Page 155: Maintaining And Repairing The Device
Maintaining and repairing the device Maintenance intervals To maintain high system availability, Siemens recommend the preventative replacement of those PC components that are subject to wear. The table below indicates the intervals for this replacement. Component Replacement interval Hard disk drive...
Page 156: Limitation Of Liability
Installing operating system, software and drivers You can restore the factory settings of the target system (i.e. the volume partitions, the operating system with installed device drivers, and the SIEMENS software products). This allows you to restore your device quickly if it has suffered damage.
Page 157: Installing The Operating System
"Important instructions and manuals for operating the device (Page 10)". Note After installing the operating system, Siemens strongly recommends that you install antivirus software to ensure system security. 7.3.2 Installing the drivers and software Requirements •...
Page 158 Maintaining and repairing the device 7.3 Installing operating system, software and drivers Procedure 1. Insert the bootable USB flash drive into the device. 2. Start the "Documentation and Drivers" suite from the USB flash drive by executing the "START_DocuAndDrivers.CMD" file. 3.
Page 159 Maintaining and repairing the device 7.3 Installing operating system, software and drivers Step 4: install the network connection TSN driver 1. Click Step4: Intel® Network Connections TSN Driver. 2. Click to install the driver. Step 5: install the Serial I/O driver 1.
Page 160: Recycling And Disposal
Maintaining and repairing the device 7.4 Recycling and disposal Step 9: install the Graphics Command Center 1. Click Step9: Intel® Graphics Command Center. 2. Click to install the driver. Step 10: install the Optane Memory and Storage Management(RST) 1. Click Step10: Intel® Optane Memory and Storage Management(RST). 2.
Page 161: Technical Specifications
ISO 9001 certificate The Siemens quality management system for all production processes (Development, Production, Sales and Service of Automation Products, -Systems and -Solutions) meets the requirements of ISO 9001:2015 Certificate registration no.
Page 162 Cet appareil numérique de la classe A est conforme à la norme NMB- 003 (A) du Canada. Responsible party for Supplier's Declaration of Conformity Siemens Industry, Inc. Digital Factory - Factory Automation 5300 Triangle Parkway, Suite 100 Norcross, GA 30092 Mail to: (amps.automation@siemens.com)
Page 163 • Electromagnetic Compatibility Regulations 2016 (EMC) • Regulations on the restriction of the use of certain hazardous substances in electrical and electronic equipment 2012 (RoHS). UK Declarations of Conformity for the respective authorities are available from: Siemens plc Princess Road Manchester M20 2UR...
Page 164 Technical specifications 8.1 Certificates and approvals The UK Declaration of Conformity is also available for download from the Siemens Industry Online Support website under the keyword "Declaration of Conformity". This product meets the requirements of India certification. BSMI This product meets the requirements of CNS15936, CNS 15598-1 generic standard.
Page 165: Directives And Declarations
Technical specifications 8.2 Directives and declarations Directives and declarations 8.2.1 Electromagnetic compatibility, Industrial and Residential Areas Electromagnetic compatibility This product meets the requirements of EU Directive 2014/30/EU "Electromagnetic Compatibility". The device is designed for the following areas of application corresponding to the CE marking: Scope of application Requirements for Interference emission...
Page 166 Technical specifications 8.2 Directives and declarations NOTICE Damage to ESD from touch Electrostatic sensitive devices, ESD, can be destroyed by voltages which are far below the human perception limit. If you touch a component or electrical connection of a module without discharging any electrostatic energy, these voltages may arise.
Page 167 Technical specifications 8.2 Directives and declarations NOTICE Grounding measures There is no equipotential bonding without grounding. An electrostatic charge is not discharged and may damage the ESD. Protect yourself against discharge of static electricity. When working with electrostatic sensitive devices, make sure that the person and the workplace are properly grounded. Protective measures against discharge of static electricity •...
Page 168: Dimensional Drawing
Technical specifications 8.3 Dimensional drawing Dimensional drawing 8.3.1 Dimensional drawing of the BM Desk and wall mounting All dimensions in mm. IPC BX-56A and IPC BX-59A Operating Instructions, 02/2025, A5E52426179-AC...
Page 169 Technical specifications 8.3 Dimensional drawing Book and tower mounting All dimensions in mm. IPC BX-56A and IPC BX-59A Operating Instructions, 02/2025, A5E52426179-AC...
Page 170: Dimensional Drawing Of The 1-Slot Em Device
Technical specifications 8.3 Dimensional drawing 8.3.2 Dimensional drawing of the 1-slot EM device 1-slot EM All dimensions in mm. IPC BX-56A and IPC BX-59A Operating Instructions, 02/2025, A5E52426179-AC...
Page 171 Technical specifications 8.3 Dimensional drawing 1-slot EM with BM (without fan) (Desk and wall mounting) All dimensions in mm. IPC BX-56A and IPC BX-59A Operating Instructions, 02/2025, A5E52426179-AC...
Page 172 Technical specifications 8.3 Dimensional drawing 1-slot EM with BM (with fan) (Desk and wall mounting) All dimensions in mm. IPC BX-56A and IPC BX-59A Operating Instructions, 02/2025, A5E52426179-AC...
Page 173 Technical specifications 8.3 Dimensional drawing 1-slot EM with BM (without fan) (Book and tower mounting) All dimensions in mm. IPC BX-56A and IPC BX-59A Operating Instructions, 02/2025, A5E52426179-AC...
Page 174 Technical specifications 8.3 Dimensional drawing 1-slot EM with BM (with fan) (Book and tower mounting) All dimensions in mm. IPC BX-56A and IPC BX-59A Operating Instructions, 02/2025, A5E52426179-AC...
Page 175: Dimensional Drawing Of The 2-Slot Em Device
Technical specifications 8.3 Dimensional drawing 8.3.3 Dimensional drawing of the 2-slot EM device 2-slot EM All dimensions in mm. IPC BX-56A and IPC BX-59A Operating Instructions, 02/2025, A5E52426179-AC...
Page 176 Technical specifications 8.3 Dimensional drawing 2-slot EM with BM (Desk and wall mounting) All dimensions in mm. IPC BX-56A and IPC BX-59A Operating Instructions, 02/2025, A5E52426179-AC...
Page 177 Technical specifications 8.3 Dimensional drawing 2-slot EM with BM (Book and tower mounting) All dimensions in mm. IPC BX-56A and IPC BX-59A Operating Instructions, 02/2025, A5E52426179-AC...
Page 178: Dimensional Drawing Of The 4-Slot Em Device
Technical specifications 8.3 Dimensional drawing 8.3.4 Dimensional drawing of the 4-slot EM device 4-slot EM All dimensions in mm. IPC BX-56A and IPC BX-59A Operating Instructions, 02/2025, A5E52426179-AC...
Page 179 Technical specifications 8.3 Dimensional drawing 4-slot EM with BM (Desk and wall mounting) All dimensions in mm. IPC BX-56A and IPC BX-59A Operating Instructions, 02/2025, A5E52426179-AC...
Page 180 Technical specifications 8.3 Dimensional drawing 4-slot EM with BM (Book and tower mounting) All dimensions in mm. IPC BX-56A and IPC BX-59A Operating Instructions, 02/2025, A5E52426179-AC...
Page 181: Dimension Drawing Of The Supported Expansion Card
Technical specifications 8.3 Dimensional drawing 8.3.5 Dimension drawing of the supported expansion card Supported PCIe expansion card The supported PCIe expansion card sizes are listed as below: Supported PCIe Expansion card sizes (W x H x D in mm) 1-slot EM 2-slot EM 4-slot EM 152.4 x 312 x 59.4...
Page 182: Technical Data
Technical specifications 8.4 Technical data Technical data 8.4.1 Applicability of technical specifications Note The following technical specifications only apply under the following conditions: • The device is in good working order. • The device is closed. • The I/O devices fulfill the requirements for the respective area of application (interference emission according to EN IEC 61000-6-3 and EN IEC 61000-6-4, interference immunity according to EN IEC 61000-6-1 and EN IEC 61000-6-2).
Page 183: Current/Power Requirements And Power Supply
Note: You can manually set the fan speed in the BIOS setup according to user scenario. For more detailed information, refer to the chapter Fan control (Page 93) and Firmware/BIOS description (SIMATIC IPC BX-56A, IPC BX- 59A). (https://support.industry.siemens.com/cs/ww/en/view/109825688) Degree of protection •...
Page 184 Technical specifications 8.4 Technical data Component/Interface Voltage SO-DIMM × 2 1.2 A 2.4 A Fan Module (60*25 FAN 1.5 A 1.5 A × 2) Max individual current 3.3 A 6.8 A 10.3 A 13.1 A Max total power (turbo 11 W 34 W 123 W 157 W...
Page 185 Technical specifications 8.4 Technical data 1-slot EM Component/Interface Voltage +3.3V +5.0 V +12 V Basic device (no turbo) 0.1 A PCIe Slot - PoE Card 3.5 A 5.5 A Max individual power current 3.6 A 6.6 A Max total power 79 W : Basic device includes motherboard.
Page 186: Electrical Requirements For Dc Module's External Power Supply
Technical specifications 8.4 Technical data Component/Interface Voltage Max individual power current 0.1 A 1.6 A 36.8 A Max total power 441 W : Basic device includes motherboard. : PCIe Card current data depends on the selected PCIe Card. : For 4-slot EM power limit, Max support PCIe Cards total power: 420W. : Total max individual power current calculated according to: 3.3V 5.0V efficiency 90%.
Page 187: Technical Specifications Ac Power Supply (Ac)
Technical specifications 8.4 Technical data Note It is not recommended for DC power supply to use external filter. If you need to use it, consult Siemens technical support. 8.4.3.4 Technical specifications AC power supply (AC) Degree of protection IP20 (in installed state)
Page 188: Electromagnetic Compatibility
Technical specifications 8.4 Technical data Power supply characteristics AC power supply Peak Power Capability • 180 to 264 VAC: 12V/97A, 12Vsb/3A – Rated(Max. continous): 12V/97A, 12Vsb/3A; – CLST Peak 20sec duration: 12V/Rated+10A, 12Vsb/4A; – Pmax.app Peak 10msec duration: 12V/Rated+72A; – Pmax Peak 100usec duration: 12V/Rated+105A •...
Page 189: Ambient Conditions
8.4.5 Ambient conditions Operating temperature on BM Note Siemens suggest you selecting the recommended mounting type. Otherwise, the temperature specifications of the product will decrease. Note • The operating temperature range is based on the specified hardware configuration with expansion cards of the test environment. The operating temperature of the device varies with your actual configuration.
Page 190 If you select a high-performance card, you will need to manually set the "Fan Control Mode" option for the EM fan speed in the BIOS setup according to user scenario. For more detailed information, refer to Firmware/BIOS description (SIMATIC IPC BX-56A, IPC BX-59A). (https://support.industry.siemens.com/cs/ww/en/view/109825688)
Page 191 Technical specifications 8.4 Technical data Operating temperature on IPC BX-56A with EM For the detailed position information, refer to Permitted mounting types (Page 48). Mounting type IPC BX-56A (BM without fan) + 1-slot EM IPC BX-56A (BM with fan) + 1-slot EM (up to (up to 35W CPU) 65W CPU) Configuration 4...
Page 192: Climatic Ambient Conditions
Technical specifications 8.4 Technical data Mounting type IPC BX-59A + 4-slot EM (up to 65W CPU) Configuration 5 and Configuration 6 PCIe card up Passive cooling PCIe card PCI card up to 6W PoE card up to Without card to 350W up to 72W with air duct 11.5W Position 1 to Position...
Page 193: Technical Specifications Of The Drives
Technical specifications 8.4 Technical data Operation • 5 to 8.4 Hz: 3.5 mm • 10 to 58 Hz: 0.0375 mm • 8.4 to 200 Hz: 9.8 m/s² • 58 to 200 Hz: 4.9 m/s² Storage/transport • 5 to 8.4 Hz: 3.5 mm •...
Page 194: Technical Specifications Of The Motherboard
Technical specifications 8.4 Technical data 8.4.7 Technical specifications of the motherboard Motherboard IPC BX-56A BM IPC BX-59A BM Processor • Pentium G7400E 46W • Core i5-13500E 65W • Core i3-13100TE 35W • Core i7-13700TE 35W • Core i5-13500E 65W • Core i7-13700E 65W •...
Page 195: Technical Specifications Of Graphic
Technical specifications 8.4 Technical data 8.4.8 Technical specifications of graphic See the note in "Applicability of technical specifications (Page 182)". IPC BX-56A BM IPC BX-59A BM Graphics controller • Pentium: Intel® UHD Graphics • Core i5: Intel® UHD Graphics 770 •...
Page 196: Technical Specifications Of The Operating Systems
Technical specifications 8.4 Technical data Interfaces 2-slot EM PCIe • 1 × PCIe x16 Gen4(X301) + 1 × PCIe x4 Gen3 (X302) • 1 × PCIe x16 (X301) + 1 × PCIe x4 with pre-installed NVIDIA® L4 Tensor Core GPU, 1 ×...
Page 197: Technical Specifications Of The Broadcom® Bcm957412A4120Ac Network Interface Card
Technical specifications 8.4 Technical data VBIOS EEPROM: 16 Mbits UEFI: Supported Memory clock frequency 6251 MHz Memory type GDDR 6 Memory size 24 GB Memory bus width 192 bits Peak memory bandwidth 300 GB/sec Environmental Specifications of device with NVIDIA L4 GPU card Ambient temperature tested in accordance with IEC 60068-2-1, IEC 60068-2-2 and IEC 60068-2-14 0 °C to 40 °C •...
Page 198: Power Consumption
Technical specifications 8.4 Technical data Power consumption Power Power Reduction Disabled Power Reduction Enabled Media Media Passive DAC Cable Typical – 50% Ethernet traffic 6.5W 5.3W Max – 100% Ethernet traffic 9.1W 6.5W : Power consumption of adapter at 55°C ambient temperature. : Reference the Broadcom Product Advisory PA-253336 for power reduction details or contact the Broadcom FAE for additional information.
Page 199: Technical Specifications Of The Fiber Transceiver
Technical specifications 8.4 Technical data NVRAM Manufacturer Device Mbit Activity No Activity Green blinking Traffic Flowing Activity Link No Link Green Linked at 10 Gb/s Yellow blinking Linked at 1 Gb/s 8.4.13 Technical specifications of the fiber transceiver See the note in "Applicability of technical specifications (Page 182)". Product features •...
Page 200: Environmental Specifications
Storage tem- ℃ perature Hardware descriptions 8.5.1 Motherboard 8.5.1.1 Motherboard of IPC BX-56A The following figures show the motherboard of the SIMATIC IPC BX-56A. Component/interface Description Meaning COM connector COM connector SIM card slot X100 M.2 Key B Support WiFi/BT, NVMe SSD, NVRAM through PCIe ×1/USB2.0...
Page 201: Motherboard Of Ipc Bx-59A
Technical specifications 8.5 Hardware descriptions Component/interface Description Meaning X6601 Power connector for EM to BM X9300 USB 2.0 dongle X12200 Fan connector X12201 SIM card slot DisplayPort 2 × DisplayPort connection X63-X66 USB 3.0 Type A port 2 × USB3.2 Gen 1 port and 2 × USB3.2 Gen 2 port COM D-Sub9 2 ×...
Page 202: Bus Board
Technical specifications 8.5 Hardware descriptions Component/interface Description Meaning X8100 SSD connector X6600 Extension module connector Memory connector X6601 Power connector for EM to BM X9300 USB dongle X12200 Fan connector X12201 SIM card slot USB 3.0 Type C port 1 × USB 3.0 Type C port DisplayPort 2 ×...
Page 203: 2-Slot Em Bus Board 2.1
Technical specifications 8.5 Hardware descriptions Component/interface Description Gold finger for BM power connection Power connector for PCIe card 8.5.2.2 2-slot EM bus board 2.1 Component/interface Description X1/X301 PCIe slot x16 Gen4 X2/X302 PCIe slot x4 Gen3 X6600 Gold finger for BM signal connection X6601 Gold finger for BM power connection X3/X4...
Page 204: Power Adapter Board
Technical specifications 8.5 Hardware descriptions Compo- Description nent/interface X100/X303 Slot 2 PCIe x4, Support Gen 4 X2/X304 Slot 1 PCI x4, Support Gen 3 Gold finger for BM signal connection Gold finger for BM power connection Fan adapter board connector Fan connector X16/X17 Connectors for SATA HDD signals...
Page 205: External Interfaces
Technical specifications 8.5 Hardware descriptions 8.5.3 External Interfaces Interface Posi- Description tion IPC BX-56A IPC BX-59A External • 2 × USB3.0 Gen1 Type A port and 2 × • 1 × USB3.2 Type C port (X60) USB3.0 Gen2 Type A port (X63-X66) •...
Page 206: Usb
Technical specifications 8.5 Hardware descriptions 8.5.3.2 USB 3.2 Type A Name of interface on the device: • IPC BX-56A: X63-X66 • IPC BX-59A: X61, X62, X63-X66 Short name Meaning Input / output VBUS + 5 V (Power switch) Power out Data channel USB2 Input / output Data channel USB2...
Page 207: Ethernet Port
Technical specifications 8.5 Hardware descriptions DisplayPort interface Ground ML_Lane 0- DP data 0- Output ML_Lane 1+ DP data 1+ Output Ground ML_Lane 1- DP data 1- Output ML_Lane 2+ DP data 2+ Output Ground ML_Lane 2- DP data 2- Output ML_Lane 3+ DP data 3+ Output...
Page 208: Serial Port
You can expand the PoE port by using the M.2 slot or EM PCIe slot. Siemens recommends that you use an isolated PoE port design. Non-isolated PoE ports can only be used if they meet the conditions specified in Environment A (IEEE 802.3) and the length of the network cable used to power the device over Ethernet does not exceed 10 meters.
Page 209: Internal Interfaces
Technical specifications 8.5 Hardware descriptions Assignment RS422 Short description Meaning Transmitted data - (O) for full-duplex mode Transmitted data + (O) for full-duplex mode Receive data + (I) for full-duplex mode Receive data - (I) for full-duplex mode Signal ground Assignment RS485 Short description Meaning...
Page 210: M.2 Interface
Technical specifications 8.5 Hardware descriptions 8.5.4.2 M.2 interface M.2 Key B module Name of interface on the device: X100, X101 Pin no. Signal Signal Pin no. CONFIG_2 3.3V VIO_CFG (O) 3.3V 3.3V CONFIG_1 SUSCLK (I) RESET# (I) SIM_DETECT (I) ANTCTL3 (O) COEX_TXD (O) ANTCTL2 (O) COEX_RXD (I)
Page 211 Technical specifications 8.5 Hardware descriptions M.2 Key M module Name of interface on the device: • IPC BX-56A: None • IPC BX-59A: X8100 Pin no. Signal Signal Pin no. 3.3V VIO_CFG (O) 3.3V 3.3V PEDET=NC (PCIe) SUSCLK ADD-IN CARD KEY M ADD-IN CARD KEY M ADD-IN CARD KEY M ADD-IN CARD KEY M...
Page 212: System Resources
SIO logic device 7 CR FDh USER MAINT LED control register (Page 214) SIO logic device 7 CR FDh Battery status register (Page 214) For more information and reference code for accessing to Super IO, contact Siemens Technical support. 8.5.6.2 Watchdog control register...
Page 213: Watchdog Counter Register
Technical specifications 8.5 Hardware descriptions Read/Write Meaning of the bits state Read/Write Select Watchdog Timer I count mode. • 0: Second Mode. • 1: Minute Mode. 4 to 7 Reserved 8.5.6.3 Watchdog counter register Read/Write Meaning of the bits state 0 to 7 Read/Write Watch Dog Timer I Time-out value.
Page 214: User Leds Control Register
Technical specifications 8.5 Hardware descriptions 8.5.6.5 User LEDs control register Meaning of the bits The "PC ON/WD" LED flashes yellow to indicate the progress of the BIOS self-test during device startup. After the BIOS self-test has been completed, the "PC ON/WD" LED lights up continuously green.
Page 215: Nvram Address Register
Technical specifications 8.6 BIOS description Battery status register (read-only, SIO logic device 7 CR FDh) CMOS battery capacity is exhausted (remaining capacity is suffi- cient for approx. one month) CMOS battery is empty 8.5.6.7 NVRAM address register NVRAM occupies a 512 KB memory address area that can be read via PCI registers. Meaning of the bits NVRAM address register PCI register address:...
Page 216: Changing The Device Configuration
BIOS update Check regularly if updates are available for download to your device. You can find additional information on the Internet at the following address: After-sales information system for SIMATIC PC/PG (http://www.siemens.com/asis). IPC BX-56A and IPC BX-59A Operating Instructions, 02/2025, A5E52426179-AC...
Page 217: Performing A Bios Update
If you have purchased a new BIOS update for your device, follow these steps to install the update: 1. Connect the device to the power supply. 2. Take the BIOS update you downloaded from the Siemens Industry Online Support (https://support.industry.siemens.com/cs/ww/en/view/109763408)page and place it on the USB stick.
Page 218: Alarm, Error And System Messages
Technical specifications 8.6 BIOS description Reboots There may be several reboots after a BIOS update. These reboots are initiated by the Management Engine (ME). The reboots are required by the ME to adapt itself to the changes of the BIOS update. 8.6.3 Alarm, error and system messages During startup (the boot process), the BIOS first performs a Power On Self Test (POST) and...
Page 219: Technical Support
You can find additional information and support for the products described on the Internet at the following addresses: • Technical support (https://support.industry.siemens.com) • Support request form (https://support.industry.siemens.com/cs/my/src) • After Sales Information System SIMATIC IPC/PG (http://www.siemens.com/asis) • Documentation for SIMATIC Industrial PCs (https://support.industry.siemens.com/cs/us/en/view/109744171) • Your local representative (https://www.automation.siemens.com/aspa_app) •...
Page 220 Technical support A.2 Troubleshooting Problem Possible cause Possible remedy The mouse pointer does not The mouse driver is not loaded Check whether the mouse driver is properly installed appear on the screen and available when you start the user program. De- tailed information about the mouse driver is available in the corresponding documentation.
Page 221: Thermal Pad
Thermal pad Thermal pad IPC BX-56A and IPC BX-59A Operating Instructions, 02/2025, A5E52426179-AC...
Page 222 Thermal pad Number Specification Function Quantity ① 4.5W/(m·K)-10mm*10mm-Thickness 1.5mm BM thermal pad 4 pcs ② 4.5W/(m·K)-15mm*15mm-Thickness 2.5mm BM thermal pad 2 pcs ③ 4.5W/(m·K)-20mm*10mm-Thickness 1.5mm BM thermal pad 4 pcs ④ 4.5W/(m·K)-10mm*60mm-Thickness 1.5mm BM thermal pad 2 pcs ⑤ 4.5W/(m·K)-20mm*20mm-Thickness 1.5mm NVMe SSD thermal pad 1 pcs ⑥...
Page 223: Markings And Symbols
Markings and symbols Overview The following tables show all the symbols which may be found on your SIMATIC industrial PC, SIMATIC industrial monitor or SIMATIC Field PG in addition to the symbols which are explained in the operating instructions. The symbols on your device may vary in some details from the symbols shown in the following tables.
Page 224: Certificates, Approvals And Markings
Markings and symbols C.4 Certificates, approvals and markings Certificates, approvals and markings The following table shows symbols relating to certificates, approvals and markings which may be on the device. You can find more information in the operating instructions for your device: Symbol Meaning...
Page 225: Interfaces
Markings and symbols C.5 Interfaces Interfaces Symbol Meaning Symbol Meaning Connection to the power supply PS/2 mouse interface Protective conductor terminal PS/2 keyboard-interface Connection for functional earthing Multimedia Card Reader (equipotential bonding line) DisplayPort interface Smart Card Reader DVI-D interface Line In LAN interface, not approved for con- Line Out...
Page 226: List Of Abbreviations
List of abbreviations Abbreviations Alternating current Alternating current ACPI Advanced Configuration and Power Interface AHCI Advanced Host Controller Inter- Standardized controller interface for SATA devic- face es. This is supported in Microsoft Windows XP as of SP1 and IAA driver. APIC Advanced Programmable Inter- rupt Controller...
Page 227 List of abbreviations D.1 Abbreviations European standard EEPROM Electrically Erasable Programma- ble Read-Only Memory Electrostatic Sensitive Device Electrostatic Sensitive Devices Electrostatic discharge Electrostatic discharge Enhanced Write Filter FBWF File Based Write Filter Ground Chassis ground Hard disk Hard disk Human Machine Interface User interface HORM Hibernate Once - Resume Many...
Page 228 List of abbreviations D.1 Abbreviations PCIe Peripheral Component Intercon- High-speed serial, differential full-duplex PtP nect express interface with high data rate. Programming device POST Power On Self Test Preboot Execution Environment Software for running new PCs without hard disk data via the network RAID Redundant Array of Independent Redundant hard disk array...
Page 229: Glossary
Glossary AHCI mode AHCI is a standardized method to address the SATA controller. AHCI describes a structure in the RAM, which contains a general area for control and status, as well as a command list. APIC mode Advanced peripheral interrupt controller. 24 interrupt lines are available. Automation system A programmable controller (PLC) of the SIMATIC S7 system consist of a central controller, one or several CPUs, and various I/O modules.
Page 230 Glossary Cold restart A start sequence, starting when the computer is switched on. The system usually performs some basic hardware checks within the cold start sequence, and then loads the operating system from the hard disk to work memory -> boot COM interface The COM interface is a serial V.24 interface.
Page 231 Glossary Error checking and correction is a method for detecting and correcting errors when saving and transferring data, frequently used in conjunction with RAM modules with and without ECC. EMC directive Directive concerning Electromagnetic Compatibility. Compliance is confirmed by the CE symbol and the EC certificate of conformity.
Page 232: Hyper Threading
Glossary Extensible Firmware Interface Refers to the central interface between the firmware, the individual components of a computer and the operating system. EFI is located logically below the operating system and represents the successor to PC BIOS, focusing on 64-bit systems. File Based Write Filter Configurable write filter to protect individual files from write access.
Page 233: Low Voltage Directive
Conventional drives can be used as USB devices. License key The license key represents the electronic license stamp of a license. Siemens AG issues a license key for each software that is protected by a license. License key USB flash drive The license key USB flash drive contains the authorizations or license keys required to enable protected SIMATIC software.
Page 234: Programmable Controller
Glossary Motherboard The motherboard is the core of the computer. Here, data are processed and stored, and interfaces and device I/Os are controlled and managed. Operating system Generic term which describes all functions for controlling and monitoring user program execution, distribution of system resources to the user programs and the operating mode in cooperation with the hardware (for example, Windows 7 Ultimate).
Page 235 Glossary PXE server A Preboot Execution Environment server is part of a network environment and can provide software to connected computers even before they boot. This can involve operating system installations or servicing tools, for example. Restricted Access Location: Installation of the device in a production facility with restricted access, for example, a locked control cabinet.
Page 236: Trusted Execution Technology
Glossary STEP 7 Programming software for the creation of user programs for SIMATIC S7 controllers. Troubleshooting Error cause, cause analysis, remedy Trusted Execution Technology Hardware implementation that allows secured execution of programs and applications. It is only effective when all relevant system components, such as processors, operating systems and applications are supported.
Page 237: Index
Index 1-slot EM, 21 Base module, 14 Expansion cards, 119 BM, 104 Front view, 21 Combination options for memory modules, 102 Installing and removing a PCIe card, 121 Conditions for using expansion cards, 103 Internal structure, 23 Front view, 17 Opening the 1-slot EM device, 119 Inserting the Nano SIM card, 107 Rear view, 22...
Page 238 Index Connecting Network, 79 Identification data, 47 Peripherals, 71 Industrial Ethernet, 79 Power supply, 74 Initial commissioning, 82, 82 protective conductor, 72 Installing the M.2 module, 104 Connecting BM with 2-slot EM, 65, 67 Installing the NVMe SSD, 98 Connecting BM with 4-slot EM, 68 Integration Connecting the protective conductor, 74 Ethernet, 79...
Page 239 Index Safety instructions Device and system extensions, 44 Onboard RAID system SIMATIC NET, 80 Manually integrating a new drive, 90 SIMATIC S7, 79 Show faulty drive, 88 Integration, 79 On-screen error messages, 218 Single power supply On-screen error messagesDiagnosticsError Lock for power plug, 77 MessagesMessagesOn the screen, 218 Slot cover, 152, 154 Operating system...

This manual is also suitable for:

Simatic ipc bx-59a

Siemens SIMATIC IPC BX-56A Operating Instructions Manual

Quick Links

Need help?

Questions and answers

Related Manuals for Siemens SIMATIC IPC BX-56A

Summary of Contents for Siemens SIMATIC IPC BX-56A
