HVE-6701T/R HDMI POE Extender over IP User manual
1.Description
The HVE-6701 HDMI extender adopts standard Ethernet TCP/IP protocol, transmit HD
video and audio over single cat6 cable, and support One-to-many applications with
POE switches. The equipment has excellent image processing and transmission
capacity, makes signal transmission more smooth and steady, is a kind of economic
and efficient way of HDMI signal extension.
2.Features
⚫ Transmits HDMI video and audio signals up to 150m over a single CAT6 cable.
⚫ Support video resolution up to 1920*1080P@60Hz.
⚫ Supports over TCP/IP protocol, One-to-many，many-to-many applications with
POE switches.
⚫ Supports Stereo Audio over IP, independent to HDMI extension Support over
TCP/IP.
⚫ Supports USB (Keyboard, Mouse) extension over IP.
⚫ Compliance with HDMI 1.3 and HDCP 1.2 standard;
⚫ High compatibility, can auto-match source and display device.
⚫ Built-in automatic adjustment system, make the image smooth, clear and stable.
⚫ Simple to install, plug and play.
3.Package list
⚫ HDMI transmitter(HVE-6701T)
⚫ HDMI receiver(HVE-6701R)
⚫ USB-A to USB-MINI data cable
⚫ Power adapter
⚫ User manual
⚫ IR Transmitter(T)/Receive cable(R)
1
1 pcs
1 pcs
1 pcs
1 pcs
1 pcs
1pcs
