Delta Electronics Optical Transceiver Modules OPT-155Axxxx Specification Sheet

155Mbps 1x9 SC/ST Duplex Optical Transceiver Module for
Fast Ethernet, ATM, SONET/OC-3, SDH/STM-1
Description
The OPT-155AxHxx series
transceiver modules
high-speed communication applications that require
rates of up to 155Mbps. They are all compliant with
the SONET/SDH standards.
The OPT-155AxHxx transceivers are supplied in
industry standard 1x9 SIP package style with either
duplex SC or duplex ST connector. Moreover the
OPT-155AxHx series also include a Signal-Detect
circuit that provides PECL logic output state.
The OPT-155AxHxx series meet Class-1 eye safety
standard and effective distance up to 2Km.
The transmitter sections utilize 1310nm Surface
Emitting InGaAsP LEDs. These LEDs are packaged
in the optical subassembly portion of the transmitter
section. A custom silicon IC that converts differential
PECL logical signals into an analog LED driving
current drives it.
The receiver sections
photodiodes coupled into
DELTA ELECTRONICS, INC.
www.deltaww.com
are 1x9 optical
designed expressly
utilize InGaAs
a custom silicon
Features:
Full Compliance with the Optical
Performance Requirement of ATM
100Mbps and 100 Base-FX Version of
IEEE 802.3u.
Industry Standard 1x9 Footprint and
Duplex SC or ST Connector Interface.
Single 5V OPT-155A1Hxx or 3.3V
OPT-155A2Hxx Power Supply.
PECL Differential Inputs and Outputs.
PECL Receiver Signal Detect Indicator.
Wave Solder and Aqueous Wash Process
Compatible.
RoHS Compliant per Directive 2002/95/EC.
trans-impedance
packaged in the optical subassembly portion of
receiver.
for
The receiver
photodiodes
trans-impedance
packaged in the optical subassembly portion of
receiver.
These PIN/Preamplifier combinations are coupled
into a custom quantizer IC which provides the final
pulse shaping for logic output and the signal Detect
function. The data output is differential. The signal
detect output is signal-ended.
Application:
Multimode Fiber Backbone Links.
Fast Ethernet and ATM Compatible.
Multimode Fiber Media Convert
PIN
1
OPT-155Axxxx
preamplifier IC. These are
sections utilize
coupled into a custom
preamplifier IC.
InGaAs PIN
silicon
These are
Jan., 2008
Rev. :0F
