Philips Consumer Lifestyle
Service Manual
PRODUCT INFORMATION
Design
• Colour
: Falcon Blue
Usability
• Tube type
: Metal 2-piece telescopic tube
• Handgrip
: Ergonomic grip with air slider
• Tube coupling
: Smart lock
• Action radius
: 11.0 m
• Cord length
: 8.0 m
• Carrying handle
: Top and front
• Dust bag full indicator
• Park or storage assist : Vertical and horizontal
• Power control
: Electronic on appliance
• Wheel type
: Rubber
Filtration
• Dust bag type
: S-bag
• Dust capacity
: 5 l
• Exhaust filter
: HEPA 13 filter
• Motor filter
: Triple layer
Safety
• This product meets the requirements regarding
interference suppression on radio and TV.
• After the product has been repaired, it should function
properly and has to meet the safety requirements as
officially laid down at this moment.
Published by Philips Consumer Lifestyle
16/04 Version 1.3
TECHNICAL INFORMATION
Performance
• Input power
• Noise level
Weight and dimensions
• Dimensions of product : 500 x 310 x 300 mm
(L x W x H)
• Weight of product
ACCESSORIES
• Standard nozzle
• Additional nozzle
• Accessories
• Accessory storage
OPTIONAL (accessories)
• Starter kit FC8060 (Filters and dustbags)
Printed in the Netherlands
Vacuum cleaner
FC8725/09
: 650 W
: 79 dB
: 5.4 kg
:
Tri-Active Z nozzle
:
Tri-Active nozzle Max and
Alma HF nozzle
: Crevice tool, 2-in-1 Brush/
Small nozzle
: On tubeclip
© Copyright reserved
Subject to modification
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Philips FC8725/09
Summary of Contents for Philips FC8725/09
- Page 1 • After the product has been repaired, it should function properly and has to meet the safety requirements as officially laid down at this moment. Published by Philips Consumer Lifestyle Printed in the Netherlands © Copyright reserved Subject to modification...
- Page 2 DISASSEMBLY- AND RE-ASSEMBLY ADVISE FC8725/09 • To open the appliance, first remove outlet grill (28) and • Then with a small screwdriver lift the Handle cover over exhaust filter (7). the nock on the Top housing (see picture). • Remove Dustcover (1) using a screwdriver (see picture).
- Page 3 DISASSEMBLY- AND RE-ASSEMBLY ADVISE FC8725/09 • When the Motor and/or Cordwinder have to be replaced • When replacing the Cordwinder (21) the Lower housing the Upper housing (17) must be removed. insert (19) needs to be removed. Move the Lower housing insert upwards so the cordwinder can easily be •...
-
Page 4: Wiring Diagram
FC8725/09 DISASSEMBLY- AND RE-ASSEMBLY ADVISE WIRING DIAGRAM • To replace Caster assy (4) turn the appliance upside down, push the Caster assy with a screwdriver up and pull it out (see picture). Black/White Black CORD WINDER Brown Blue MOTOR POWER... -
Page 5: Parts List
PARTS LIST FC8725/09 Service code Description Remark 4322 009 01031 Dustcover assy Falcon Blue 4322 003 46801 Dustbag holder Basic Blue 61192 4322 005 33431 Caster assy Deep Black 4322 003 46671 On/Off pedal Deep Black 80231 4322 003 46681... - Page 6 EXPLODED VIEW FC8725/09 6-10...
- Page 7 EXPLODED VIEW FC8725/09 7-10...
- Page 8 EXPLODED VIEW FC8725/09 8-10...
- Page 9 EXPLODED VIEW FC8725/09 9-10...
- Page 10 FC8725/09 Version history 14/08 Version 1.1 : FC8725/09 initial release. 15/03 Version 1.2 : On page 1 under Accessories Added Additional nozzle : Alma HF nozzle. In Parts List and Exploded view: Added Pos. 38: 4322 004 26051 Alma HF nozzle Conical 35 mm PH Deep Black.
