Quick Links
Package Contents
Camera (x1)
Screw Kit (x1)
Basics
LED Indicator
Reset Button
Name
LED Indicator
Lens
Camera Module The camera module can be rotated 10 degrees left
Reset Button
Description
• Solid Red: Camera starting up.
• Slow-flashing Red: Wi-Fi connection failed.
• Fast-flashing Red: Camera exception
(e.g. memory card error).
• Solid Blue: Video being live viewed in the EZVIZ app.
• Slow-flashing Blue: Camera running properly.
• Fast-flashing Blue: Camera ready for Wi-Fi
connection.
The lens can be adjusted 15 degrees downwards.
and right.
Hold for 4 seconds to restart and reset all parameters
to default.
Drill Template (x1)
Quick Start Guide (x1)
Light Module
MIC
Lens
Camera Module
Speaker
1
Advertisement
Related Manuals for Ezviz LC3
Summary of Contents for Ezviz LC3
- Page 1 • Slow-flashing Red: Wi-Fi connection failed. • Fast-flashing Red: Camera exception (e.g. memory card error). • Solid Blue: Video being live viewed in the EZVIZ app. • Slow-flashing Blue: Camera running properly. • Fast-flashing Blue: Camera ready for Wi-Fi connection.
-
Page 2: Installation
Installation • Recommended installation height: 6-7 ft (1.8-2.2 m) above the ground. • The camera has a built-in memory card for video storage. There is no need to install an additional SD card. 1. Shut off the electricity at the breaker. •... - Page 3 Anchor Screw Drill Template Mounting Base 4. Connect the wires. - Connect the Neutral wire (N) and Live wire (L) one by one. - Secure them using screwdriver. 1 Live wire (L) 2 Neutral wire (N) 5. Insert the camera to the mounting base. - Buckle the bottom of the mounting base into the camera.
- Page 4 Base Screw Mounting Base 6. Adjust camera module's angle. You can adjust the horizontal and vertical angle of the camera module as needed. 7. Restore power at the breaker. 8. Confirm the camera has power. After restoring power, the camera will be ready for setup when the light is on and the LED Indicator on the front of the camera fast flashes blue.
- Page 5 1. Get the EZVIZ app - Connect your mobile phone to Wi-Fi. - Download and install the EZVIZ app by searching “EZVIZ” in the App Store or Google Play Store - Launch the app and register an EZVIZ user account.
- Page 6 INFORMATION FOR PRIVATE HOUSEHOLDS 1. Separate collection of waste equipment: Electrical and electronic equipment that has become waste is referred to as waste equipment. Owners of waste equipment must dispose of it separately from unsorted municipal waste. In particular, waste equipment does not belong in household waste, but in special collection and return systems.
