PRO.SIS.TEL. PST-60F Installation Instructions

PST-60F wire dipole antenna
Installation instructions:
Unroll the two antenna wires arms carefully and be careful not to cause creases on the wires. The
dipole can be installed open horizontally or best in Inv V.
For optimal operation, bring the top of the Inv. V at least 10-15m over the ground, greater heights
will shift the resonance upwards, lesser heights will shift the resonance down.
Make sure to keep an arms opening between 90 and 110 degrees.
If necessary improve the tuning stretching and folding the length of the terminal. The proper
operation can be influenced by environmental conditions.
If necessary do several tests and try the best condition.
Specifications:
Gain = 0 dBd
Impedence Inv V = 50 ohm
Balun 1:1 SO239
Max power pep: 1.5KW ssb, 1KW CW-RTTY
SWR 60m = 1:1 band center (in the best instastalling conditions)
Length = about 28m
Dimensions and specifications may also be different from the description,
without prejudice to the final performances.
DO NOT use the antenna on bands other than the projected ones, you could
damage the balun.
Security Notice
Be responsible, avoid possible accidents
Do not install the antenna near exposed power lines or other sources of
electrocution risk, you could be killed or seriously injured. Make sure that nobody
can come into contact even accidental with it during use
Install the antenna on supports adequately sized to withstand its load even in
rushing wind conditions.
The fall of all or part of it could affect people and / or things with incalculable
damages.
In the event the responsibility is to be charged exclusively to the user.
