- Page 1 PRO. SIS. TEL. Produzione sistemi telecomunicazioni Antenna Rotator Azimuth “D” DC version User’s manual Rev.1.7b-usb C.da Conghia 298 - 70043 Monopoli BA Italy Tel-Fax ++39 080 8876607 E-mail:prosistel@prosistel.it Copyright ® PRO.SIS.TEL. 2017...
- Page 2 Warning This manual must be read carefully before proceeding to assembly. Warranty 1) The rotator with the control box, hereinafter called “product”, or “rotator”, is warranted for 2 years from date of purchase, provided that it is supported by the document of sale issued by the manufacturer or authorized distributor.
- Page 3 Important Read this instruction manual carefully before attempting to operate with the antenna rotator. Save this instruction manual. This instruction manual contains important safety and operating instruction for antenna rotator. Precautions ! WARNING, never connect or disconnect rotor cable or USB connectors while power is on.
- Page 4 Section 1 The controller “D” version 1-1 Front panels description. 1 - POWER SWITCH (POWER) Turns power ON and OFF 2 – Right lever: CW momentary switch Pushing and holding this switch will make the rotator turn clockwise If you have used the preset, or computer control to start rotation, you can over-ride those commands by momentarily depressing the switch.
- Page 5 1-2 Rear panel description. 1 – USB connector Enables connection to a PC port for remote operation. Pin 5 = computer ground Pin 2 = serial data out (to computer data in) Pin 3 = serial data in (from computer data out) 2 - Rotator control cable male connector.
- Page 6 The bearing values in degree as shown by the display, are not absolute but relative, as show in the conversion tables: South stop absolute values Deg. east side west side outrange outrange South stop relative values North stop absolute values Deg.
- Page 7 Calibration Two on board trimmers are provided to calibrate the controller. Note – adjustment of these trimmers which leads to a “fault” is not covered by the warranty. Please do not adjust them if you are not sure of the correct procedure. If necessary, you can recalibrate your controller via USB port.
- Page 8 On the motor side is located a five-contact connector for motor power supply and potentiometer terminals. The potentiometer, used as the antenna position reader, is located inside the foot plate, and driven by the transmission output shaft. PST 110 - 71 - 61 PST2051 - 641 Rotator cable ends Rotators end...
- Page 9 Section 2 Installation and connections 2.1 Unpacking After unpacking, immediately report any damage to the delivering carrier or dealer. Keep the shipping cartoon. 2.2 Power supply connection Connect the power cable and switch power on, display will show PHH and 110. Switch power OFF. 2.3 Rotator control cable preparation &...
- Page 10 readout should increase for CW and decrease for CCW. If these tests give incorrect results, refer to the troubleshooting section of this manual. If the results are correct, test full rotation to the electronic limits in both CW and CCW directions. When this test has been performed turn the rotator to 000 degrees with the leverl switches.
- Page 11 Section 3 Principles of operation 3.1 Rotator The rotator is manufactured with a worm-wheel geared motor drived by a high torque dc motor.This method, normally used in heavy duty industrial and professional machinery, permits a very high reduction ratio, with high power torque with both low power motor drive and high brake torque, due the self-braking property of the worm-wheel geared motor.
- Page 12 Rotation Motor Wires area torque torque load speed Redout RS232 Preset Kg speed range Volts Kg/cm 360° PST 641D 1.000 ± 60” 12 Vdc digital PST 2051D 2.000 ± 60” 12 Vdc digital PST 61D 3.800 1.180 ± 90” 12 Vdc...
- Page 13 Section 5 With this user’s manual a CD is provided. CD contains several folders in which there are some files with some extra informations about your antenna rotator, as a copy of this manual as well. We suggest you pay attention on such extra informations, from which you can learn more about this antenna rotator, but in meantime they are intended for expert technicians, so make sure to well undestand what you are reading before to do anything.
- Page 14 DICHIARAZIONE DI CONFORMITA’ DECLARATION OF CONFORMITY according to EN45014: 1998 Si dichiara che il prodotto: Rotore d’antenna mod. PST ……….D è conforme ai requisiti essenziali delle seguenti direttive comunitarie: This product: Antenna rotator model PST………..D is fully conforms to the council directives:...
- Page 15 PST2051: PST641: 5 1/8" 4 1/2" (ø130mm) (ø115mm) ø10mm 3/8" PST61 - 71: 6 1/2" ø12mm (ø165mm) 1/2" PRO.SIS.TEL. C.da conghia 298 70043 Monopoli BA ITALY www.prosistel.it DRAW: Rotor plates holes diagram Note – this drawing is not to scale...
- Page 17 Fixing plate down view Draw: PST61D, general dim. PRO.SIS.TEL. C.da Conghia 298 Scale: Drawn by: Serial number: Capitanio Piero 70043 Monopoli BA ITALY Date: Checked by: Rev: Feb 02/2007 tel. ++39 80 8876607 Note: measurements in mm...
- Page 18 Fixing plate down view Draw: PST71DC general dimensions PRO.SIS.TEL. C.da Conghia 298 Scale: Drawn by: Serial number: Capitanio Piero 70043 Monopoli BA ITALY Date: Checked by: Rev: tel. ++39 80 8876607 April 09/2008 Note: measurements in mm...
- Page 19 Company: Pro.Sis.Tel. Draw: PST110D-Dimensions Date: Sept. 03/2010 Rev: Note: Quotes in millimeters...
- Page 20 A1- Bolt, stainless steel, M10x40mm A2- Washer ø10mm, stainless steel A3- Mast clamps 3”, zinc galvanized steel A4- Split washer ø8mm, stainless steel A5- Bolt, stainless steel, M8x100mm A6- Stainless steel nut, M8 A7- Rotator shaft with plate, zinc galvanized steel A8- Split washer ø10mm, stainless steel A9- Nut M10, stainless steel...
- Page 21 Appendix 2 Warning Protect your equipement The rotator and controller are electronic devices containing sensitive components that could be damaged from lightning, heavy electrostatic charges or electric fields. Make sure to disconnect rotator cable from the controller and controller power cord when not used as you do with your coax cables when a tunder storm is approaching.
