Gas Ultrasonic Meter (USM)
Aclara Communications Module
Instruction Manual
Y21058-TUM
Revision A
www.Aclara.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Aclara 3511-066-LCW and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Hubbell Aclara 3511-066-LCW

  • Page 1 Gas Ultrasonic Meter (USM) Aclara Communications Module Instruction Manual Y21058-TUM Revision A www.Aclara.com...
  • Page 3 Disclaimer The information in this document is subject to change without notice and should not be construed as a commitment by Aclara. Aclara assumes no responsibility for any errors that may appear in this document. No responsibility is assumed for the use or reliability of software on equipment that is not supplied by Aclara.
  • Page 4 G a s U S M A c l a r a C o m m u n i c a t i o n s M o d u l e I n s t r u c t i o n M a n u a l...
  • Page 5: Table Of Contents

    Table of Contents Chapter 1: Safety Guidelines & Compliance Declarations Warning, Cautions, and Notices ..... . 1 FCC Compliance Statement ......1 IC Compliance Statement .
  • Page 6 Table of Contents G a s U S M A c l a r a C o m m u n i c a t i o n s M o d u l e I n s t r u c t i o n M a n u a l...
  • Page 7: Chapter 1: Safety Guidelines & Compliance Declarations

    CHAPTER & C AFETY UIDELINES OMPLIANCE ECLARATIONS Always consult and adhere to all local and national safety codes, regulations, and standards. WARNING, CAUTION and NOTE statements are used throughout this manual to emphasize important and critical information to help you ensure safety and prevent product damage.
  • Page 8: Ic Compliance Statement

    IC Compliance Statement equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •...
  • Page 9: Fcc/Ic Exposure Statement

    FCC/IC Exposure Statement Aclara Technologies LLC low power RF devices and their antennas must be fixed-mounted on indoor or outdoor permanent structure(s) providing a separation distance of at least 1 meter (about 3 feet) from all persons during normal operation. This device is not designed to operate in conjunction with any other antennas or transmitters.
  • Page 10 FCC/IC Exposure Statement G a s U S M A c l a r a C o m m u n i c a t i o n s M o d u l e I n s t r u c t i o n M a n u a l...
  • Page 11: Chapter 2: Aclara Communications Module And Gas Ultrasonic Meter Overview

    CHAPTER CLARA OMMUNICATIONS ODULE AND LTRASONIC ETER VERVIEW The SSM-iCON 250 is Pietro Fiorentini’s ultrasonic gas flow meter. It’s a smart meter used to measure dry gas on low pressure gas distribution networks in a residential environment and is suitable for use with natural gas, biomethane, and hydrogen blends (up to 20%).
  • Page 12: Gas Ultrasonic Meter (Usm)

    Gas Ultrasonic Meter (USM) Gas Ultrasonic Meter (USM) Figure 2.1 SSM-iCON 250 Gas Ultrasonic Meter (USM) G a s U S M A c l a r a C o m m u n i c a t i o n s M o d u l e I n s t r u c t i o n M a n u a l...
  • Page 13: Aclara Communications Module

    Chapter 2 • Aclara Communications Module and Gas Ultrasonic Meter Overview Aclara Communications Module The Aclara Communications Module is installed in the PF SSM-iCON 250 Gas Ultrasonic Meter (USM) at the factory. Please refer to Figure 2.2 below. Potential electrostatic charging hazard. See special conditions of use below. ARNING Risque potentiel de charge électrostatique.
  • Page 14: Special Conditions Of Use

    Aclara Communications Module The Aclara Communication Module enclosure is constructed of polycarbonate ARNING plastic. Install the device in a way which prevents the enclosure from being subjected to impacts or fiction, which could cause sparks in the presence of a potentially explosive atmosphere.
  • Page 15: Labels

    Chapter 2 • Aclara Communications Module and Gas Ultrasonic Meter Overview Labels The following images depict information that can be located on the outside of the Aclara Communications Module. Figure 2.3 Aclara Communications Module Front Label Beneath this information, on the underside of the Aclara Communications Module, you will find the following information: Figure 2.4 Bottom Right of Aclara Communications Module...
  • Page 16: Maintenance

    RMAs, access Aclara University’s Online Learning Center, track your orders, join communities and discussions with other Aclara customers and Aclara personnel, and much more. If you do not have access to Aclara Connect, email aclarasupport@hubbell.com and request access. Aclara University Aclara’s on-demand training makes content available to you in a convenient,...
  • Page 17: Chapter 3: Pairing, Programming, And Installation

    CHAPTER AIRING ROGRAMMING NSTALLATION The Aclara Communications Module is physically installed on the PF SSM-iCON 250 Gas Ultrasonic Meter (USM) at the factory. This section provides instructions for pairing a mobile device with the Aclara Communications Module and pro- gramming the Aclara Communications Module with the Mobile Programmer application.
  • Page 18: Pairing A Mobile Device With The Aclara Communications Module

    Pairing a Mobile Device with the Aclara Communications Module Pairing a Mobile Device with the Aclara Communications Module Be sure to start each day by: Verifying the time and date on your mobile programming device are • correct Verifying the mobile programming device batteries are fully charged •...
  • Page 19 Chapter 3 • Pairing, Programming, and Installation to view the pairing window. At this point, no devices may Login display. Use a magnet of 20 mT or greater to wake up the Aclara Communications Module by placing the magnet above the sensor as indicated in the following image.
  • Page 20 Pairing a Mobile Device with the Aclara Communications Module Tap the button, located in the upper right corner of the display, to Search view a list of devices detected by Bluetooth. Tap the icon for the device you wish to pair. G a s U S M A c l a r a C o m m u n i c a t i o n s M o d u l e I n s t r u c t i o n M a n u a l...
  • Page 21 Chapter 3 • Pairing, Programming, and Installation Once pairing is successful, the icon for the device will enlarge as illustrated below. To unpair a mobile device and USM that were previously paired, use the Unpair OTICE icon, indicated in the following image, Unpair Icon Proceed to Programming the Aclara Communications Module (MTU) on page 16, and follow the instructions for either Installing a New MTU and...
  • Page 22: Programming The Aclara Communications Module (Mtu)

    Programming the Aclara Communications Module (MTU) Programming the Aclara Communications Module (MTU) Installing a New MTU and Meter Aclara’s Meter Transmission Unit (MTU) is a legacy name for, and is OTICE synonymous with, the Aclara Communications Module. Follow the instructions in Pairing a Mobile Device with the Aclara Communications Module on page 12.
  • Page 23 Chapter 3 • Pairing, Programming, and Installation You will need to scroll down to view all required fields. , and fields will be populated via Vendor Model Meter Type drop-down menus. Verify all required fields have been populated. If you have missed any, you will not be able to proceed.
  • Page 24 Programming the Aclara Communications Module (MTU) When programming is complete, a confirmation screen will open showing configuration and status information for both the meter and the Aclara Communications Module. You will need to scroll down to view the entire summary. G a s U S M A c l a r a C o m m u n i c a t i o n s M o d u l e I n s t r u c t i o n M a n u a l...
  • Page 25 Chapter 3 • Pairing, Programming, and Installation At this point you can tap the icon to return to the main menu to Unpair perform a new installation. To view activity logs tap in the main menu, and then tap the Settings Logs button found at the bottom of the screen.
  • Page 26 Programming the Aclara Communications Module (MTU) You will need to scroll down to see the complete activity log. To return to the main screen, tap the back arrow to the right of the user’s name in the top left region of the display. At least once per day, programming records must be uploaded.
  • Page 27: Replacing An Mtu

    Chapter 3 • Pairing, Programming, and Installation Replacing an MTU Aclara’s Meter Transmission Unit (MTU) is a legacy name for, and is OTICE synonymous with, the Aclara Communications Module. Once the Aclara Communications Module is installed, use Aclara Mobile Programmer to program it. Follow the instructions in Pairing a Mobile Device with the Aclara Communications Module on page 12.
  • Page 28 Programming the Aclara Communications Module (MTU) in the upper right corner to view the Replace MTU - Miscellaneous Miscellaneous window, and complete all remaining fields. Map Pin Icon Start Button For the Lat. and Lon. coordinates, tap the map pin icon to have your device gather that information and populate the fields automatically.
  • Page 29 Chapter 3 • Pairing, Programming, and Installation You will need to scroll down to view the entire summary. Unpair Icon At this point you can tap the icon to return to the main menu to Unpair perform a new installation. To view activity logs tap in the main menu, and then tap the Settings...
  • Page 30 Programming the Aclara Communications Module (MTU) If upload fails, verify that the device is able to access the Internet (WiFi or cellular data active), then try again. If upload fails again, tap the icon at the bottom of the screen and verify that the FTP settings are present. If not, contact your system administrator or Aclara Support for the proper credentials and enter them.
  • Page 31: Chapter 4: Field Replacement Instructions

    CHAPTER IELD EPLACEMENT NSTRUCTIONS These instructions provide a procedure for replacing an Aclara Communications Module, catalog numbers 3511-066-LC and 3511-066-LCW, on a Pietro Fiorentini (PF) SSM-iCON 250. (The images in this document are for reference only.) The instructions in this chapter provide details for replacing an Aclara OTICE Communications Module on a PF meter that has already been installed in the field.
  • Page 32: Parts Included In Mounting Kit

    Parts Included in Mounting Kit Parts Included in Mounting Kit Item General Description Aclara Communications Module Transmission unit M4 x 12 self-tapping screws Screws Snap seal anti-tamper plugs Safety seals Tools Required To install the Aclara Communications Module on these meters, you will need the following tools and equipment: •...
  • Page 33 Field Replacement Instructions Remove the two T20 Torx screws securing the Aclara Communications Module to the meter. Remove the Aclara Communications Module by pulling it from left to right. G a s U S M A c l a r a C o m m u n i c a t i o n s M o d u l e I n s t r u c t i o n M a n u a l...
  • Page 34: Install Aclara Communications Module

    Install Aclara Communications Module Install Aclara Communications Module Verify the O-ring on the new Aclara Communications Module is correctly positioned in the outermost seat of the communication channel. O-Ring The Aclara Communications Module comes with the O-ring already in place. OTICE Align the communication channel and the guides, and push the Aclara Communications Module onto the PF SSM-ICON 250 gas meter from right...
  • Page 35: Putting The Device Into Service

    Field Replacement Instructions Insert the two M4 x 12 self-tapping Torx screws into the screw holes on the Aclara Communications Module. You may have to hold the Aclara Communications Module in place until the first screw is started as the communication channel compresses the air and may cause the meter and Aclara Communications Module to push apart.
  • Page 36: Applicable Standards

    Applicable Standards Applicable Standards • ANSI B109.1 • PS-G-06 • S-G-03 part 1 and part 7 • UL 60079-0, Edition 7, Revision Date 04/15/2020 • CSA C22.2 No. 60079-0, Edition 4, Issue Date 02/2019 • UL 913, Edition 8, Revision Date 05/10/2022 •...
  • Page 37: Maintenance And Repair

    Field Replacement Instructions • EN 60079-32-1: 2016 – Electrostatic hazard, guidance • 47 CRF Part 15B: Unintentional radiators (15.109) • ICES 003 issue 7: Product standard for Information Technology Equipment (ITE) • ANSI C63.4-2014: American National Standard For Methods Of Measurement Of Radio-Noise Emissions From Low-Voltage •...
  • Page 38: Battery Disposal

    Battery Disposal Battery Disposal The lithium battery may cause a fire or chemical burn if it is not disposed of properly. Batteries, especially end-of-life (discharged) batteries, are dangerous and ARNING sensitive to shock, vibration, and exposure to open flames. Failure to comply with this document can lead to the risk of explosion, fire, and harmful emissions that can have serious health consequences.
  • Page 39: Index
