EZ Page Front Panel Controls
Confidentiality Notice
This manual is provided solely as an operational, installation, and maintenance guide and contains sensitive
business and technical information that is confidential and proprietary to GAI-Tronics. GAI-Tronics
retains all intellectual property and other rights in or to the information contained herein, and such
information may only be used in connection with the operation of your GAI-Tronics product or system.
This manual may not be disclosed in any form, in whole or in part, directly or indirectly, to any third party.
General Information
The Model 12504-009 Front Panel Controls Replacement Kit is used with the following EZ Page Intercom
models: GC-AC1, GC-DC1, and GC-AC2. This kit includes the following components:
Qty
Description
1
Knob
1
Front cover sealing nut for Listen/Talk switch
1
Front cover sealing nut for speaker volume/on-off switch
1
Wired Listen/Talk switch and speaker volume/on-off switch assembly
1
Hex nut
1
Anti-rotation ring
Required Tools
•
#2 Phillips screwdriver
•
5/8-inch wrench
•
1/2-inch wrench
•
.078-inch (5/64 inch) hex allen wrench
GAI-TRONICS 3030 KUTZTOWN RD. READING, PA 19605 USA
610-777-1374
V
ISIT WWW
G A I - T R O N I C S ®
A H U B B E L L C O M P A N Y
Replacement Kit
Model 12504-009
800-492-1212
.
-
.
GAI
TRONICS
COM FOR PRODUCT LITERATURE AND MANUALS
Fax: 610-796-5954
Pub. 42003- 177A
