Model 378-003 E3 IP MIM
(Monitored Input Module) Station
Confidentiality Notice
This manual is provided solely as an installation, operation, and maintenance guide and contains sensitive
business and technical information that is confidential and proprietary to GAI-Tronics. GAI-Tronics
retains all intellectual property and other rights in or to the information contained herein, and such
information may only be used in connection with the operation of your GAI-Tronics product or system.
This manual may not be disclosed in any form, in whole or in part, directly or indirectly, to any third
party.

General Information

The Model 378-003 E3 IP MIM (Monitored Input Module) station operates in an Elemec3 system. The
E3 controller software configuration controls its operation.
The MIM monitors up to eight input circuits. Each input activates by a voltage-free contact (either
opening or closing) or the presence/absence of a 24 V dc input voltage. The MIM can supervise the
cabling between the input terminal and the remote contact device when using voltage-free input contacts.
Program each input circuit to initiate one of the following functions in the Elemec3 system:
•
activate an alarm
•
reset all alarms
•
cancel the current alarm
•
report a fault condition
•
reset the system MCU
The Model 378-003 E3 IP MIM station's housing is a NEMA 4X stainless steel enclosure measuring
13.00 W × 14.30 H × 6.23 D inches (330.2 × 363.2 × 158.2 mm). Internal components include:
•
24 V dc power supply
•
No. 030-02-0098-001 E3 IP MIM
•
one terminal block
The No. 030-02-0098-001 E3 IP MIM has two components (see Figure 1):
•
No. 999-02-1203-001 IP CPU PCBA
•
No. 999-02-3011-002 Monitored-Input PCBA
The scope of this manual is mounting and wiring the Model 378-003 IP MIM station. Refer to Pub. 502-
20-0672-001 ISS 4 for additional information on the No. 030-02-0098-001 E3 IP MIM (see the Reference
Documentation section).
