GTDU
Installation Instructions
! IMPORTANT SAFEGUARDS !
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
1. This product is for use with generator or central inverter supplied fl uorescent, incandescent or LED fi xtures. Make
sure all connections are in accordance with the National Electrical Code or Canadian Electrical Code and any local regu
lations.
2. To reduce the risk of electric shock, disconnect all power sources before servicing.
3. This product is for factory or fi eld installation.
4. This product is suitable for damp locations where the ambient temperature is -20°C minimum, +65°C
maximum. The product is also suitable for installation in sealed and gasketed fi xtures. Product is not
suitable for heated air outlets and wet or hazardous locations.
5. This product is UL Listed as either a Branch Circuit Emergency Lighting Transfer Switch (BCELTS) under UL 1008 or
a Switch Bypass under UL 924. Use the proper wiring diagram in the appropriate section of these instructions.
6. An unswitched, normal AC power source and a direct, unswitched connection to a generator or central inverter
supplied emergency panel is required (120 through 277 VAC, 50/60 Hz).
7. Do not install near gas or electric heaters.
8. The use of accessory equipment not recommended by the manufacturer may cause an unsafe condition.
9. Do not use this product for other than intended use.
10. Servicing should be performed by qualifi ed service personnel.
11. Equipment should be mounted in locations and at heights where it will not readily be subjected to tampering by
unauthorized personnel.
12. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2) this device must accept any indifference that may cause
undesired operation.
13. This product must be grounded. See wiring diagrams for details.
14. This product has a Short Circuit Current Rating (SCCR) of 5kA when protected by fuses. See Table 1 for details.
CAUTION:
NOTE:
AVAILABLE. AN UNSWITCHED SOURCE OF NORMAL POWER IS REQUIRED. A SEPARATE CONNECTION TO A
GENERATOR-SUPPLIED (OR CENTRAL INVERTER SYSTEM-SUPPLIED) CIRCUIT MUST ALSO BE PROVIDED.
236 Mt. Pleasant Rd. • Collierville, TN USA 38017-2752 • Tech Support 888-263-4638 • Fax 901-853-5009 • www.bodine.com
SAVE THESE INSTRUCTIONS
THIS UNIT HAS MORE THAN ONE POWER SUPPLY CONNECTION POINT. TO REDUCE
THE RISK OF ELECTRIC SHOCK, DISCONNECT ALL POWER SOURCES BEFORE
INSTALLING OR SERVICING THIS UNIT.
SERVICE BY QUALIFIED PERSONNEL ONLY
BEFORE INSTALLING THIS DEVICE, MAKE SURE THE NECESSARY BRANCH CIRCUIT WIRING IS
Bodine © 2019 Signify Holding. All rights reserved.
442294707731
WHEN USING ELECTRICAL EQUIPMENT, BASIC
SAFETY PRECAUTIONS SHOULD ALWAYS BE
FOLLOWED, INCLUDING THE FOLLOWING:
12/05/19
UL 1008-BCELTS
UL 924-Switch Bypass
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Bodine GTDU
Summary of Contents for Bodine GTDU
- Page 1 AVAILABLE. AN UNSWITCHED SOURCE OF NORMAL POWER IS REQUIRED. A SEPARATE CONNECTION TO A GENERATOR-SUPPLIED (OR CENTRAL INVERTER SYSTEM-SUPPLIED) CIRCUIT MUST ALSO BE PROVIDED. 12/05/19 Bodine © 2019 Signify Holding. All rights reserved. 236 Mt. Pleasant Rd. • Collierville, TN USA 38017-2752 • Tech Support 888-263-4638 • Fax 901-853-5009 • www.bodine.com 442294707731...
- Page 2 (see Illustrations 1, 2 and 3). > The GTDU metal case must be grounded. One way is to electrically bond it to the luminaire metal surface by exposing bare metal on both and installing the mounting hardware to establish a proper metal-to-metal connection. The GTDU will then be electrically bonded to the AC supply ground through the luminaire.
- Page 3 MAINTENANCE No routine maintenance is required to keep the GTDU functional. However, it should be checked periodically to ensure it is working properly. The entire generator (or central inverter) system, including all designated emergency lighting loads, should be exercised every 30 days per Code to ensure proper operation. To do this: 1) power up the generator, 2) place the main automatic transfer switch in the generator position, 3) turn off the local, unswitched normal power circuit breaker, and 4) verify the designated emergency lighting loads are operating properly from the generator/central inverter supply.
- Page 4 WIRING DIAGRAMS for UL 924 - SWITCH BYPASS APPLICATIONS ILLUSTRATION 6 ILLUSTRATION 7...
