  • Page 1 Interface Converter Instruction Manual RS-232C SI-60F RS-232C SI-60 RS-422/485 SI-65 (The twelfth Edition)
  • Page 2 This manual has been designed and edited with great care to give you all information. If you have any questions, feel free to direct your inquiries to LINEEYE. LINEEYE makes no warranty or guarantee, either expressed or implied with respect to its quality, performance, merchantability, or fitness for a particular purpose. LINEEYE shall not be liable for direct, in-direct, special, incidental, or consequential damages resulting from any defect in the product.
  • Page 3 LINEEYE does not manufacture this product under the purpose of using with equipment which may cause malfunction to do harm to the human body: control equipment for nuclear, aircraft equipment, life maintenance equipment, traffic signals, etc.
  • Page 4 Do not use the damaged cables. Doing so may cause fire by overheating. Use the included AC adapter or ones specified by LINEEYE. Failure to do so may cause overheating, fire, an electric shock, or injury. Do not connect the power cord to an outlet that has an illegal number of connections.

  • Page 5: Table Of Contents

    6-6. SI-60F/SI-60/SI-65 Setting..........................51 6-7. ComPortRediretor Ver4.2.0.0 Setting ......................51 Chapter7 Ethernet Connector Specification ...................... 53 7-1. Ethernet Connector Specification (SI-60F, SI-60, SI-65) ................53 7-2. Installation Method............................53 Chapter8 Warranty and After-Sales Service ..................... 55 8-1. Troubleshooting ............................. 55 8-2.

  • Page 6: Chapter1 Before Using The Product

    Refer to “4-4 SI-65 cable connection” SI-60 cannot have speed at 460.8 or 921.6Kbps. To use SI-60F/SI-65 at 460.8 or 921.6Kbps, a built-in XPort is required to set to a high performance mode. For more information about this mode, refer to “5-4.

  • Page 7: Unpacking And Product Composition

    AC Adapter (DC6V 500mA) Utility CD-ROM Instruction Manual Warranty Please let your LINEEYE distributor or LINEEYE know if you find any damage to the product caused by transportation, or if there are accessories lacking. 1-4. CD-ROM Included The converter includes the following CD-ROM.

  • Page 8: Chapter2 Si-60F Usage

    Chapter2 SI-60F Usage 2-1. SI-60F Overview and Features SI-60F is a converter to convert asynchronous communications for devices equipped with the RS-232C interface to TCP/IP communications on Ethernet LAN. It connects RS-232C interface device to a PC without a serial port via LAN, with a small DTE(fixed) Dsub9 pin (male).

  • Page 9: 60F Cable Connection

    “In” means a direction to input signals to the converter. *2 Inputs the negated signals to the CP1 terminal on a built-in XPort. 2-3. SI-60F Cable Connection Connect by the proper UTP cable to the Ethernet connector. For 10Base-T ------------------- Category 3, 4, 5...

  • Page 10: 60F Built-In Xport Setup

    RS-232C, use the RS-232C cable of straight connection. We provide the following optional cables. SI-RS259 Is the RS-232C cable for connecting the serial port (Dsub9 pin - male) of SI-60F to the device (Dsub25 pin, female) of DCE specification. LE2-8C Is the AUX cable for connecting the AUX port (Mini DIN8 pin, female) of analyzers, (LE-8200/3500/2500/7200/3200/2200/1200) to SI-60F.

  • Page 11: Chapter3 Si-60 Usage

    Chapter3 SI-60 Usage 3-1. SI-60 Overview and Features SI-60 is a communication converter to convert asynchronous communications for devices equipped with the RS-232C interface to TCP/IP communications on Ethernet LAN. Since the slide switch on the converter is designed for DTE/DCE switchable, any devices can be connected to the RS-232C side.

  • Page 12: Panel Explanation

    3-2. SI-60 Panel Explanation DTE/DCE Change-Over Switch Changes the RS-232C connector specification of the converter to DTE or DCE. Power Supply LED Lights when powering the converter. Data Status Display LED Indicates a data transmission and reception status for the RS-232C side.

  • Page 13: Cable Connection

    RS-232C Connector Pin Assignment I/O Direction *2 Pin No. *1 Name Description Frame Grand Transmission Data Reception Data Transmission Request Transmission Permit Internal connection to 20 pin *3 Signal Grand +5V IN External power supply input *4 Internal connection to 6 pin *3 *1 Pins not mentioned in this table indicate the non-connected terminals.

  • Page 14: Built-In Xport Setup

    RS-232C Connect with the proper RS-232C cable which fits the shape of the RS-232C connector on the target devices. Then, make sure of the input/output specification of signal pins and connection of the RS-232C cable. Set DTE/DCE switch. (eg.) When connecting to the PC which is DTE specification using the RS-232C cable of straight connection, set as DCE for the switch.

  • Page 15: Chapter4 Si-65 Usage

    Chapter4 SI-65 Usage 4-1. SI-65 Overview and Features SI-65 is a communication converter to convert asynchronous communications for devices equipped with the RS-422/485 interface to TCP/IP communications on Ethernet LAN. Since the converter supports both two-wire and four-wire full duplex, using the device allows you to support various systems.

  • Page 16: Panel Explanation

    4-2. SI-65 Panel Explanation Power Supply LED Lights when powering the converter. Data Status Display LED Indicates a data transmission and reception status for the RS-422/485 side. Blinks the SD LED for data from LAN to RS-422/485. Blinks the RD LED for data from RS-422/485 to LAN. Driver Status Display LED Lights when the driver for RS-485 is active.

  • Page 17: Hardware Setup

    6 Pole Terminal Block Pin Assignment for RS-422/485 Full Duplex Mode *1 Half Duplex Mode *1 Terminal Name Direction Description Direction Description Transmission Data + Cannot use *3 Transmission Data – Cannot use *3 Reception Data + Transmission/Rece SD/RD+ ption Data + Reception Data –...
  • Page 18 SW-A Meaning No.4 RS-422/485 transmission driver control Active Auto SW-A No.4 (Driver Control) Selects two kinds of control methods in the RS-422/485 driver control line of the converter: active and auto. OFF (Active) Setting This setting keeps the driver active. To keep the driver active in the RS-422 line, conduct the OFF/active setting.

  • Page 19: Cable Connection

    Note: Be sure to set this switch to OFF in the full duplex RS-422 mode. SW-B No.3 (Terminal End Between SD+ and SD-) Setting this switch to ON inserts the terminator 100 ohm between SD+ and SD- (terminal block 1, 2) in a direction of parallel. SW-B No.4 (Terminal End Between SD/RD+ and SD/RD-) Setting this switch to ON inserts the terminator 100 ohm between SD/RD+ and SD/RD- (terminal block 3, 4) in a direction of parallel.
  • Page 20 For actual use, be sure to conduct a communication test to check. The following chart shows the connection example to connect the converter to LINEEYE SI-20FA in the full duplex mode by 1 to 1. SD -...

  • Page 21: Built-In Xport Setup

    The following chart shows a connection example to connect the converter to more than two devices in the half duplex mode by N to N. Power Source Supply power to the converter in either of two ways. • Supplies power by plugging the included AC adapter or the optional AC adapter into the AC adapter plug on the converter.

  • Page 22: Chapter5 Xport Setup

    Chapter5 XPort Setup 5-1. Built in XPort-03 The version of XPort-03 have updated a few times. Thus, LINEEYE has sold SI-60F/SI-60/SI-65 with XPort-03 version of v1.8 and v6.x (v6.1.0.0 or former). (You should have v6.6.0.2 if you have this instruction manual.) How to find the XPort-03 version: Open the DeviceInstaller(v4.2.0.1) and find “XPort-03-firmware v6.6.0.2”...

  • Page 23: Ip Address Assignment

    Before using the converter, you need to assign IP address to built-in XPort. LINEEYE’s factory setting automatically assigns IP address by DHCP function and AutoIP function. If you have you own management rule to provide IP address, you need to assign the IP address for your network by yourself.
  • Page 24 be disabled. Setting it to 0.0.1.0 keeps the DHCP function enable, and only makes the AutoIP function disable. Using the Device Installer The Included CD-ROM contains a utility “Device Installer” for setup. Note: Depending on when the product was shipped, the firmware version of built-in XPort is different.
  • Page 25 (If there are devices other than SI-60F/SI-60/SI-65 using XPort on the network, they are also listed in a table..) Select what matches the hardware address for the device being set from the table.
  • Page 26 Note: We recommend you to disable DHCP and BOOTP or always keep Auto-IP effective because when failing in the address assignment, Device Installer cannot detect SI-60F/SI-60/SI-65 even if DHCP, BOOTP or both are effective. The screen and steps will be different in each version of DeviceInstaller. For more details...
  • Page 27 Using ARP and Telnet If you know the IP address for XPort, you can change the address by connecting the normal Telnet. However, if not at the first setup or other conditions, you can conduct the setup for IP address by connecting the Telnet following the following procedure. The following operation is for windows command prompt (DOS prompt).
  • Page 28 4. When the connection is successful, the following message appears. To enter the setup mode, press the Enter key within 5 seconds. If more than 5 seconds pass without pressing, XPort will restart. MAC address XXXXXXXXXXXX Software version XX.X (XXXXXX) XPTEXE AES library version X.X.X.X Press Enter for Setup Mode 5.
  • Page 29 Using the Serial Port Connection (SI-60F/SI-60 Only) SI-60F/SI-60 allows you to set an IP address from the RS-232C port using the setup mode. To go to the mode, see “Setup Mode Usage” of “4-2 Setup Method.” For information about the settings, see process 6 and after of “Using ARP and Telnet.”...

  • Page 30: Setup Method (Serial Communication Conditions)

    3. “Done!” appears. After it disappears, click “Apply Settings” to make XPort save the settings and restart. Note: When using SI-60F/SI-65 with baud rate 460800/921600bps of the serial port, select “Server” and set High to “CPU Performance Mode”. Then, set baud rate of “Serial Settings”.
  • Page 31 Press Enter for Setup Mode Serial Port Connection Procedure Connect the RS-232C port of SI-60F/SI-60 to the serial port on a PC by the RS-232C cable. Use a cross cable for SI-60F. When using SI-60, confirm the cable specification and conduct the setup for the DTE-DCE change-over switch.
  • Page 32 To enter the setup mode, send more than 3 characters of “x” from a PC within 1 second after powering the converter. If the converter fails to receive them within a time limit, XPort normally starts operating. To certainly conduct this procedure, power the converter pressing the “x”...
  • Page 33 Set the serial flow control in HEX. Flow (00) ? Flow No flow contorol Software Flow(Xon/Xoff) Hardware Flow(RTS/CTS) Software Flow(Xon/Xoff transmit to LAN) 05 Port No (10001) ? Set the received port number. ConnectMode (C0) ? Input the connect mode in Hex. Connect Mode Do not allow connection Allow connection...

  • Page 34: Setup Example

    When you conduct the setup by using the Telnet or serial port connection, conduct the setup referring to the XPort user’s manual and others. SI-60F/SI-60/SI-65 basic setting IP address Set the IP address, subnet mask, default gateway. (Refer to “4-1. IP Address Assignment) Receive IP address automatically if you cannot have any IP address from DHPC server.
  • Page 35 SI-60/65, and IP address and port number for target device (client mode). When having some kind of data input from A or B of serial port, SI-60F/SI-60/SI-65 will connect to the other side of SI-60F/SI-60/SI-65. You can have (expand) the serial data of device 1 (or 2) in the device 2 (or 1) using LAN.

  • Page 36: Xport Io Pin, Cp1 Control

    XPort CP1 pin set on the IO pin can be controlled by TCP/IP or UDP/IP directly. CP1 for SI-60F/SI-60 is set as input and for SI-65 is set as output. To read input status of CP1(SI-60F/SI-60) on IO pin, send 9 byte for port number 30704 and check the response of 5 byte from XPort.

  • Page 37: Default Setup

    Items excepting OEM Configurable Pins have the same setups with the factory default for XPort. The following shows the main factory default values, which are common for SI-60F/SI-60/SI-65. To learn about the factory default values not mentioned below, read the XPort user’s manual.

  • Page 38: Default Setup Using The Setup Record

    You can have XPort-03 default value (except IP address) using DeviceInstaller Ver4.2.0.1 if you have firmware version Ver6.x. Note: LINEEYE is not responsible for other versions of DeviceInstaller or firmwares. <step> 1. In the DeviceInstaller Ver4.2.0.1, select XPort-03 IP address to have the default value.
  • Page 39 5. [Device upgrade wizard –step 3/5] will appear. Select [Install setup records from a file] and click [Browse]. 6. Open the document [SI_60_V6602_xxxx.rec](SI-60 Ver6.6.0.2) in the file of “\LINEEYE\SetupRecord” in the CD. Click [next]. Below is the table of SI-60/65 version and file name. Ver6.6.0.2 Ver6.5.0.7...

  • Page 40: Xport-03 Firmware Version Update And Downgrade

    XPort-03 firmware v1.8 to v6.x. Please read the following instruction carefully. If you fail to update/downgrade the firmware, SI-60F/SI-60/SI-65 will not work correctly. If it is not necessary to update/downgrade the firmware, please use it as it is.
  • Page 41 4. “Device upgrade wizard –step 2/5” will appear. Click “Browse” in the “Firmware file (ROM)” and select the file to upgrade/downgrade. Select “xpt03_6xxx.rom” in the folder of “lantronix\v6\6.x.x.x” from the attached CD. For example, to upgrade to v6.6.0.2, “xpt03_6602.rom” in the folder of “lantronix\v66\6.6.0.2” from the attached CD. Click [next]. 5.
  • Page 42 9. Click upgrade icon or go to [device] [upgrade] 10. “Device upgrade wizard –step 1/6” will appear. Select “custom install” and click [next]. 11. “Device upgrade wizard –step 2/6” will appear. Click [next]. 12. “Device upgrade wizard –step 3/6” will _appear. Select “install COB” and click [next]. 13.
  • Page 43 15. “Device upgrade wizard –step 5/6” will appear. Click [next]. 16. “Device upgrade wizard –step 6/6” will appear. “installation is completed” will be displayed. Close the window. 17. After changing the firmware, XPort setting may be changed. Please check the Xport version. (Refer to “Default setting”...
  • Page 44 1. Open the Windows command prompt. 2. Input “C:_cd C:\XPortUpgrade” and press [Enter]. Start “C:\XPortUpgrade” directly. 3. Connect PC and SI-60F/SI-60/SI-65 by LAN. Check whether or not XPort have ping response. Input “C:\XPortUpgrade>ping 192.168.0.4” if IP address of XPort-03 is “192.168.0.4”.
  • Page 45 1. Open the Windows command prompt. 2. Input “C:_cd C:\XPortDowngrade” and press [Enter]. Start “C:\XPortUpgrade” directly. 3. Connect PC and SI-60F/SI-60/SI-65 by LAN. Check whether or not XPort have ping response. Input “C:\XPortDowngrade>ping 192.168.0.4” if IP address of XPort-03 is “192.168.0.4”.

  • Page 46: Chapter6 Com Port Redirector

    (　○: support, △:support only some parts） *LINEEYE recommend you to use the latest version of COM Port Reader, because Ver2.2/2 and Ver3.1.0.1 cannot use some of new function of Ver6.5.0.7(or later). Ver4.2.0.0 has some problems in Visual Basic6 and MSCOOMM, and cannot communicate with COM Port Redirector. If you cannot communicate with COM Port Redirector, please use Ver3.1.0.1.

  • Page 47: Com Port Redirector Ver3.1.0.1 Installation Procedure

    6-2. COM Port Redirector Ver3.1.0.1 Installation Procedure To install COM Port Redirector Ver3.1.0.1, follow the following procedures. For Windows XP/2000/NT4.0, log in as Administrator to install. 1. Insert the utility CD-ROM into the CR-ROM drive. a) Select “RUN…” from the start menu. b) Enter “<CD-ROM Drive name>:\lantronix\v61\Redirector\red32bit.exe”.

  • Page 48: 60F/Si-60/Si-65 Setup

    XPort using DeviceInstaller, Webmanager, Talnet. (Reper to the user’s manual of XPort) LINEEYE recommends to have fixed IP addres. Setting values for application should be same as communication speed, data bet, parity , stop bit, flow control for XPort.
  • Page 49 5. Click the “Port Settings” button. The “Port Setting” dialog box appears. 6. Select “Raw Mode” and other options in the “Port Settings”dialog box, and click the OK button. Those setups for each of the virtual COM ports are independent. Item Description Timeout Reconnect...

  • Page 50: Comport Redirector Ver4.2.0.0 Install Procedure

    6-5. ComPort Redirector Ver4.2.0.0 Install Procedure Install ComPortRedirector Ver4.2.0.0 in the following procedure. If you use Window XP/2000/NT4.0, log in as manager and install. 1. Insert the CR-ROM(utility CD) in the CD-ROM drive. a). select “select file name and execute” from start menu. b).
  • Page 51 6. Select added virtual COM port. 7. Click [Settings] tab and set the IP address of XPort in the “Host” and the port number in the “TCP Port” of “Service 1”. To input data to the “Host” and “TCP Port”, double click the XPort in the “Devices”...

  • Page 52: 60F/Si-60/Si-65 Setting

    XPort using DeviceInstaller, Webmanager, Talnet. (Reper to the user’s manual of XPort) LINEEYE recommends to have fixed IP addres. Setting values for application should be same as communication speed, data bet, parity , stop bit, flow control for XPort.
  • Page 53 Note: Support only XPort-03 firmware Ver6.5.0.7 or later. Set "Telnet Com Port Cntrl" to be "enable" in the WebManager. LINEEYE does not liable for this to use in SI-60F/SI-60. Please do not use this for SI-65 because control function may not work correctly.

  • Page 54: Chapter7 Ethernet Connector Specification

    Chapter7 Ethernet Connector Specification 7-1. Ethernet Connector Specification (SI-60F, SI-60, SI-65) Ethernet Connector Pin Assignment Pin No. Name I/O Direction *1 Description Transmission Data + Transmission Data - Reception Data + Not Used Not Used Reception Data - Not Used Not Used “Out”...
  • Page 55 SI-60 SI-65 Note: To fix the converter, screw the screws within 7mm in the surface of the bottom case. When you screw the screws deeper than that, it may damage the board inside.

  • Page 56: Chapter8 Warranty And After-Sales Service

    Chapter8 Warranty and After-Sales Service 8-1. Troubleshooting The “PWR” LED does not light. <When using the AC adapter> Check that you plug the AC adapter into the AC Is the AC adapter connected correctly? adapter plug or wall outlet correctly. <When powering from the connector or terminal Check that you connect the RS-232C connector block>...
  • Page 57 Accessing from the Web browser cannot start the Web manager. Is the “PWR” LED on the converter lighting? If not, read ‘The “PWR” LED does not light.’ Is either the left or right LED for the Ethernet If both LEDs turn out the lights, read “Neither connecter on the converter lighting or blinking? the left and right LEDs for the Ethernet connector do not light or blink.”...
  • Page 58 Cannot communicate on the serial port side. Is the “PWR” LED on the converter lighting? If not, read ‘The “PWR” LED does not light.’ <Using SI-60F/SI-60> Check that the connector is connected correctly, Is the RS-232C cable connected correctly? or that the cable breaks, etc.

  • Page 59: Warranty And Repair

    8-2. Warranty and Repair Warranty Within a period of 12 months from the date of shipment, LINEEYE warrants that your purchased products (excepting consumable parts such as the batteries and software) are free of charge from any defects in material and workmanship, only when the products are operated in accordance with procedures described in the documents supplied by LINEEYE.
  • Page 60 The card packed with the product is the user registration card for Japanese customers. For overseas customers, there is a registration page on our web site.(www.lineeye.com) Head Office : 39-1, Karahasi, Nishihiragaki-cho, Minami-ku, Kyoto, 601-8468, Japan TEL: 075-693-0161 FAX: 075-693-0163...
