LineEye SI-60 Instruction Manual

Interface converter, lan/lan poe - rs-232c/x2
Hide thumbs Also See for SI-60:
Table of Contents

Advertisement

Quick Links

Download this manual
Interface Converter
Instruction Manual
LAN
RS-232C
SI-60 / SI-60F / SI-60F-L
LAN
RS-232C x2
SI-60X
LAN(PoE)
RS-232C
SI-60P / SI-60FP
The CD-ROM attached to a product contains the newest English and Japanese
instruction manuals in a PDF format. Please also refer to them.
34th

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SI-60 and is the answer not in the manual?

Questions and answers

Related Manuals for LineEye SI-60

Summary of Contents for LineEye SI-60

  • Page 1 Interface Converter Instruction Manual RS-232C SI-60 / SI-60F / SI-60F-L RS-232C x2 SI-60X LAN(PoE) RS-232C SI-60P / SI-60FP The CD-ROM attached to a product contains the newest English and Japanese instruction manuals in a PDF format. Please also refer to them.
  • Page 2 This manual has been designed and edited with great care to give you all information. If you have any questions, feel free to direct your inquiries to LINEEYE. LINEEYE makes no warranty or guarantee, either expressed or implied with respect to its quality, performance, merchantability, or fitness for a particular purpose. LINEEYE shall not be liable for direct, in-direct, special, incidental, or consequential damages resulting from any defect in the product.
  • Page 3 Safety Information Be sure to read the following LINEEYE has developed and manufactured this product for purpose of using with electrical devices such as a computer, a personal device, a measurement device, semiconductor manufacturing equipment, a vending machine, a sequencer, display equipment and so on.
  • Page 4 Do not use the damaged cables. Doing so may cause fire by overheating. Use the included AC adapter or ones specified by LINEEYE. Failure to do so may cause overheating, fire, an electric shock, or injury. Never touch the converters and cables while thunderbolts are occurring.

  • Page 5: Table Of Contents

    9-5. Installation Method ....35 2-4. SI-60F Power Source ....9 9-6. Ordering information ....37 9-7. Option ........37 Chapter 3 SI-60 Usage ....10 Chapter 10 Warranty and 3-1. SI-60 Overview and Features ..10 3-2. SI-60 Panel Explanation ..11 After-Sales Service ... 38 3-3.

  • Page 6: Chapter 1 Before Using The Product

    SI-60FP and SI-60P SI-60FP and SI-60P are the model which has the same function as that of SI-60F and SI-60 and also support PoE (Power over Ethernet: IEEE 802.3af/at) power supply. When you need information about SI-60FP or SI-60P, please see the...

  • Page 7: Overview

    Act as a Class 1 receive device of Power over Ethernet: IEEE802.3af/at In the case of using the attached AC adapter (AC100V). When the power supply voltage, which is supplied from the connector (SI-60), is DC10V or higher the operating temperature is limited up to +40 degree.

  • Page 8: Chapter 2 Si-60F Usage

    Chapter 2 SI-60F Usage 2-1. SI-60F Overview and Features SI-60F converts asynchronous communications of RS-232C interface to TCP/IP or UDP/IP communications on Ethernet LAN. Having XPort as its LAN interface, SI- 60F offers highly-reliable communication. * For further detail about configuration and IP address setting, please refer to chapter 5, 6, and 8. SI-60F/SI-60FP * The appearance of SI-60FP differs at model name and description on the LAN connector.

  • Page 9: 60F Panel Explanation

    2-2. SI-60F Panel Explanation Name Explanation Note Power LED It lights when the SI-60F is powered. It lights when SD/RD signal of RS-232C is active. Data Status LED The numbers in the parentheses indicate the pins of RS-232C. AC Adapter Jack A socket to connect to an AC adapter.

  • Page 10: 60F Cable Connection

    2-3. SI-60F Cable Connection Connect to the LAN connector of SI-60F with a LAN cable of category 5e or more. [ 5-1.Connect to the LAN network] RS-232C Connect by the proper RS-232C cable which fits the shape of the RS-232C connector on the target devices.

  • Page 11: Chapter 3 Si-60 Usage

    For further detail about configuration and IP address setting, please refer to chapter 5, 6, and 8. SI-60 adopts DSUB25 pin connector and you can switch it to DTE or DTC, which allows you to connect any device to RS-232C interface of SI-60.

  • Page 12: Panel Explanation

    DTE/DCE Switch [ 3-1.] of SI-60 to DTE or DCE. Power LED It lights when the SI-60 is powered. It lights when each signal of RS-232C is active. Data Status LED The numbers in the parentheses indicate the pins of RS-232C.

  • Page 13: Cable Connection

    3-3. SI-60 Cable Connection Connect to the LAN connector of SI-60 with a LAN cable of category 5e or more. [ 5-1. Connection to the Networok ] RS-232C Connect with the proper RS-232C cable which fits the shape of the RS-232C connector on the target devices.

  • Page 14: Chapter 4 Si-60X Usage

    Chapter 4 SI-60X Usage 4-1. SI-60X Overview and Features SI-60X converts two ports of asynchronous communications of RS-232C interface to TCP/ IP or UDP/IP communications on Ethernet LAN. Having WiPortNR as its LAN interface, SI- 60X offers access to two RS-232C ports through two local ports of IP addresses set on SI- 60X.

  • Page 15: 60X Panel Explanation

    4-2. SI-60X Panel Explanation Name Explanation Note DC-IN 1 A socket to connect to an AC adapter. [ 4-4. ] XH connector for DC supply (non-polar)Inside of SI-60X , DC-IN 2 is DC-IN 2 [ 4-4. ] connected in parallel with DC-IN 1. INIT SW A switch to initialize SI-60X Ethernet IEEE802.3 RJ-45 connector 10Base-T/100Base-TX auto-...

  • Page 16: 60X Cable Connection

    DTE specification, use cross connection cable which has ends of DSUB9pin (female). 4-4. SI-60X Power Source There are two ways to supply power to SI-60. Supply by AC 1. Connect the plug of the AC adapter to the DC-IN1 jack of SI-60X.

  • Page 17: Chapter 5 Basic Configuration

    Chapter 5 Basic Configuration 5-1. Connect to the LAN network Connect LAN connector of converter to the HAB/PC using LAN cable. LAN Cable LAN Cable(Cross Cable) * This converter does not have AutoMDI/MDI-X function to find the LAN port. To connect LAN port of PC directly, use the LAN cable with cross connection.

  • Page 18: Default Ip Address

    5-3. Default IP address As a factory setting, DHCP client mode and AutoIP function automatically set IP address. * When the IP address is 0.0.0.0 (factory setting), those functions are valid. When IP address is 0.0.1.0, only DHCP client function is valid. When having DHCP server in the network IP address is automatically set from the DHCP server when turning on the power of device.

  • Page 19: Confirm Ip Address

    3.Click [No] if following dialog is appeared. 5-5. Confirm IP address 1. Connect the converter to the network and turn on the power. 2. Open the DeviceInstaller from Start menu. 3. A device which has a LAN device of Lantronix is displayed on the main window 4.

  • Page 20: Assign Ip Address

    5-6. Assign IP address 1.Click on IP assignment. 2.Select the method and then click [Next]. To valid the DHCP client and AutoIP address function. To set fixed IP address. When selecting When selecting [ Obtain an IP address automatically ] [ Assign a specific IP address ] 3.

  • Page 21: Web Manager

    Chapter 6 Configuration Using Web Manager 6-1. Web Manager Usage The configuration can be changed from a Web manager. For more details refer to [ XPort User Guide (XPort_UG.pdf) ] and [ WiPort NR User Guide (WiPort-NR_UG.pdf) ] in the CD-ROM. Accessing from the deviceinstaller Select the device being set.
  • Page 22 Web Manager Usage SI-60F/SI-60 Server setting such as CPU Performance Serial Commnunication Conditions setting LAN Connection setting.. *1: For SI-60P and SI-60FP, use only “Serial Settings” and “Connection(1)” of Channel 1 and do not use Channel2 and Connection(2). SI-60X Server setting such as CPU Performance Serial Commnunication1 Conditions setting LAN Connection setting.

  • Page 23: Communication Conditions Of Serial Port

    6-2. Communication conditions of serial port 1.When using SI-60F/SI-60FP/SI-60P/SI-60X with baud rate 460800 or above, select "Server" and set High to "CPU Performance Mode". If baud rate is less than 460800, do not need to set it. 2.Select [Channel1 ] -> [Serial Settings]. Set "Protocol"...

  • Page 24: Other Setting

    6-4. Other Setting You can set various settings according to your usage. For more details refer to [ XPort User Guide (XPort_UG.pdf) ], [ xPico User Guide (xPico_UG.pdf) ], or [ WiPort NR User Guide (WiPort-NR_UG.pdf) ] in the CD-ROM. Pack Control The packing algorithms define how and when packets are sent to the network.

  • Page 25: Chapter 7 Setup Example

    Chapter 7 Setup Example 7-1. Server mode usage To use Device A (connected with the serial port of converter)through network connection by TCP connection request from a device on the network such as PC to the converter, please refer following setting. Device Serial IP Address:...

  • Page 26: Client Mode Usage

    7-2. Client Mode Usage To use the serial port of the Device A through network connection by TCP connection request from the converter to a server on the network when the converter has received a serial data of Device A, please refer following setting. Device A Server Serial...

  • Page 27: Using Two Units Of Converter

    7-3. Using two units of converter To extend serial communication between Device A and Device B through network by using two units of converters, please refer following setting. Device A Device B Serial Serial converter 1 converter 2 Condition: Condition: IPAddress : IPAddress : Speed 9600bps,...
  • Page 28 LANConnection Mode Converter 1 (Server Mode: Enable, ClientMode: Enable) Remote Host2 Remote Host2 IPAddress Port No Converter 2 (Server Mode: Enable, ClientMode: Disable) After turning on the power, the converter 1 in which Active Connect is set to Auto Start connect with the converter 2 by TCP and starts data transmission via network.

  • Page 29: Chapter 8 Com Port Redirector

    Chapter 8 COM Port Redirector 8-1. About Virtual COM Port The COM Port Redirector by Lantronics is the utility software to get the serial communication application not supporting the network connection to be able to use on the network. The redirector creates the virtual COM ports in Windows. Communications for these virtual COM ports are transferred to the serial port on the converter through the network.

  • Page 30: Com Port Redirector

    8-4. COM Port Redirector Connect the converter to the network. Login to the PC as administrator. 1. From start menu, go to "Lantronix" -> "CPR 4.x" -> "CPR Manager. "CPR Manager" window will be displayed. 2. Click [Com Port]-[Add and Remove] of toolbar to open the dialog to register/delete the virtual COM port.

  • Page 31: Chapter 9 Documents

    IP Address 0.0.0.0 (DHCP Client Function and AutoIP Function: Enable) Telnet password: (Password: Disable) Configuration pins (general purpose IO pin) [Chapter 1.2] SI-60F/SI-60 Definition Active Level CP1 HW Flow Control Out CP2 General Purpose I/O Input CP3 HW Flow Control In *Do not change the setting of CP2 and Active Level.

  • Page 32: How To Apply The Factory Setting

    (xPico_UG.pdf) ], or [ WiPort NR User Guide (WiPort-NR_UG.pdf) ] in the CD-ROM. 9-2. How to apply the factory setting To apply the factory setting into SI-60/SI-65/SI-65A/SI-60F/SI-60X, download the configuration file from the utility CD([ /LINEEYE/SetupRecord ]).Apply the downloaded file when selecting the setup record file. SI-60F / SI-60F-L...
  • Page 33 Operation of [ SILANIOinit ](configuration tool) 1. Copy "SILANIOinit.exe" from the "/LINEEYE/SILANIOinit" folder in the utility CD to the appropriate folder (For example, "c:/setup/"). 2. Set your device in the same network segment as your PC. 3. To execute the program, double click on "SILANIOinit" and click "search" to display all XPort/WiPortNR embedded Select your target device.
  • Page 34 Operation of DeviceInstaller Install DeviceInstaller to your PC and download the configuration file from the utility CD to the appropriate folder (For example, "c:/setup/"). [ 5-4. Usage of DeviceInstaller ] Set your device in the same network segment as your PC.(If your devices are not in the same network segment, you may not able to set.) Start Deveiceinstaller and click [Search] to display all XPort/WiPortNR embedded Select your target device.

  • Page 35: General-Purpose I/O Pins

    To read the input status of CP2 on the general purpus I/O pin, send TCP/IP or UDP/IP command to the port number 30704. CP2(DR and ER of RS-232C Control line) check command of SI-60F/SI-60 Command : 13h 00h 00h 00h 00h 00h 00h 00h 00h (9 byte)

  • Page 36: Installation Method

    9-5. Installation Method Rubber feet are put on the bottom of the device. Please set it on a flat and stable place. Set in the stable place Rubber feet are put on the bottom of the device. Please set it on a flat and stable place. Using screws There are four M3 screw holes on the back of converter.
  • Page 37 Usage of Wall bracket (SI-WM1) (For SI-60/SI-60F) With a wall bracket (SI-WM1, optional), you can fix the converter to a wall by screwing from the upper side of the bracket or hooking it to screws or nails hammered into the wall.

  • Page 38: Ordering Information

    DIN vertical plate SI-DIN30 For installation to 35mm DIN rail vertically (for SI- 60X). DIN vertical plate SI-DIN30S For installation to 35mm DIN rail vertically (It does not support SI-60X.) For more details about optional goods, please contact LINEEYE distirutors or LINEEYE.

  • Page 39: Chapter 10 Warranty And After-Sales Service

    Chapter 10 Warranty and After-Sales Service 10-1. Troubleshooting The "PWR" LED does not light. < When using the AC adapter > Check that you plug the AC adapter Is the AC adapter connected correctly? into the AC adapter plug or wall outlet correctly.Check the voltage of AC adapter.
  • Page 40 Is the connection mode set to Server Check the condition of converter. Mode? Cannot communicate on the serial port side (SI-60F,SI-60,SI-60X) Are Data Status LEDs blinking? It is working correctly if the SD and RD LEDs are blinking on the timing of data transmission.

  • Page 41: Warranty And Repair

    10-2. Warranty and Repair Warranty Within a period of 12 months from the date of shipment, LINEEYE warrants that your purchased products (excepting consumable parts such as the batteries and software) are free of charge from any defects in material and workmanship, only when the products are operated in accordance with procedures described in the documents supplied by LINEEYE.
  • Page 42 There is a registration page on our web site. ( https://www.lineeye.com ) Please register your product for further support. We will provide you the firmware update information and sales information etc. LINEEYE CO., LTD. 4F., Marufuku Bldg., 39-1, Karahasi, Nishihiragaki-cho, Minami-ku, Kyoto, 601-8468, Japan TEL: 075-693-0161 FAX: 075-693-0163 URL: https://www.lineeye.com...
