LineEye SI-60F Instruction Manual

Interface converter
Hide thumbs Also See for SI-60F:
Table of Contents

Advertisement

Quick Links

Download this manual
LAN
LAN
LAN
The CD-ROM attached to a product contains the newest English and Japanese
instruction manuals in a PDF format. Please also refer to them.
Interface Converter
Instruction Manual
RS-232C
RS-232C
RS-422/485
16 th
SI-60F
SI-60
SI-65

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SI-60F and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for LineEye SI-60F

Summary of Contents for LineEye SI-60F

  • Page 1 Interface Converter Instruction Manual RS-232C SI-60F RS-232C SI-60 RS-422/485 SI-65 The CD-ROM attached to a product contains the newest English and Japanese instruction manuals in a PDF format. Please also refer to them. 16 th...
  • Page 2 This manual has been designed and edited with great care to give you all information. If you have any questions, feel free to direct your inquiries to LINEEYE. LINEEYE makes no warranty or guarantee, either expressed or implied with respect to its quality, performance, merchantability, or fitness for a particular purpose. LINEEYE shall not be liable for direct, in-direct, special, incidental, or consequential damages resulting from any defect in the product.
  • Page 3 Safety Information Be sure to read the following LINEEYE has developed and manufactured this product for purpose of using with electrical devices such as a computer, a personal device, a measurement device, semiconductor manufacturing equipment, a vending machine, a sequencer, display equipment and so on.
  • Page 4 Do not use the damaged cables. Doing so may cause fire by overheating. Use the included AC adapter or ones specified by LINEEYE. Failure to do so may cause overheating, fire, an electric shock, or injury. Never touch the converters and cables while thunderbolts are occurring.

  • Page 5: Table Of Contents

    XPort ........6 8-2. SI60/65/60F Basic Setting ..30 Chapter2 SI-60F Usage ..... 7 8-3. Install COM Port Redirector ..30 2-1. SI-60F Overview and Features ..7 8-4. COM Port Redirector Ver4.x.x.x 2-2. SI-60F Panel Explanation ..7 Setup ........31 2-3. SI-60F Cable Connection...8 Chapter 9 Documents ......

  • Page 6: Chapter 1 Before Using The Product

    Chapter 1 Before Using The Product 1-1. Overview SI-60F/SI-60/SI-65 are communication converters to convert asynchronous communications for devices with the serial interface, which is often used in the FA field, into TCP/IP communications on Ethernet LAN. These converters have built-in Lantronix XPort at the LAN interface part, and enable a high- reliability communications.

  • Page 7: Unpacking And Product Composition

    Instruction Manual AC Adapter Warranty Utility CD-ROM Please let your LINEEYE distributor or LINEEYE know if you find any damage to the product caused by transportation, or if there are accessories lacking. 1-4. CD-ROM Included The converter includes the following CD-ROM...

  • Page 8: Chapter2 Si-60F Usage

    Chapter2 SI-60F Usage 2-1. SI-60F Overview and Features SI-60F is a converter to convert asynchronous communications for devices equipped with the RS-232C interface to TCP/IP or UDP/IP communications on Ethernet LAN. It connects RS-232C interface device to a PC without a serial port via LAN, with a small DTE(fixed) Dsub9 pin (male).

  • Page 9: 60F Cable Connection

    Connect by the proper RS-232C cable which fits the shape of the RS-232C connector on the target devices. Then, make sure of the input/output specification of signal pins. e.g.1: Connecting the serial port (Dsub9 pin - male) of SI-60F to the device (Dsub25 pin, female) of DCE specification.

  • Page 10: Chapter3 Si-60 Usage

    Chapter3 SI-60 Usage 3-1. SI-60 Overview and Features SI-60 is a communication converter to convert asynchronous communications for devices equipped with the RS-232C interface to TCP/IP or UDP/IP communications on Ethernet LAN. Since the slide switch on the converter is designed for DTE/DCE switchable, any devices can be connected to the RS-232C side.

  • Page 11: Panel Explanation

    3-2. SI-60 Panel Explanation Changes the RS-232C connector specification of the converter to 1 DTE/DCE Switch DTE or DCE. 2 Power Supply LED Lights when powering the converter. Indicates a data transmission/ reception status for the RS-232C.Lights 3 Data Status LED when the pin signal corresponding to Dsub connector is above +3V.

  • Page 12: Cable Connection

    3-3. SI-60 Cable Connection Connect by the proper UTP category cable which matches the Ethernet connector. For 10Base-T ------------------- Category 3, 4, 5 For 100Base-TX --------------- Category 5 Note: Although the standardized length of a LAN cable is max. 100 meters, use the cable as short as possible if there is much noise.

  • Page 13: Chapter4 Si-65 Usage

    Chapter4 SI-65 Usage 4-1. SI-65 Overview and Features SI-65 is a communication converter to convert asynchronous communications for devices equipped with the RS-422/485 interface to TCP/IP communications on Ethernet LAN. Since the converter supports both two-wire and four-wire full duplex, using the device allows you to support various systems.

  • Page 14: Panel Explanation

    4-2. SI-65 Panel Explanation 1 Power Supply LED Lights when turning on the power. Indicates a data transmission/ reception status for RS-422/485.Blinks the 2 Data Status LED SD LED if there is data from LAN to RS-422/485. Blinks the RD LED if there is data from RS-422/485 to LAN.

  • Page 15: Hardware Setup

    4-3. SI-65 Hardware Setup The two 4-position dip switches on the converter allows you to conduct the following setups: the line monitoring function, the driver control method, terminator enable/disable, and echo back enable/disable. SW-A No.1-3 (Baud Rate Setup) Following communication speed (baud rate) you wish to use, this setup is to set the internal timer used for the non-communication monitoring circuit and driver control circuit.
  • Page 16 SW-B Meaning No.1 Select a line mode RS-422 (full duplex) RS-485(half duplex) No.2 Echo reception of transmission With echo back Without echo back data No.3 Terminal control between SD+ Without terminal With terminal and SD- control control(100 ohm) No.4 Terminal control between SD/ Without terminal With terminal RD+ and SD/RD-.

  • Page 17: Cable Connection

    4-4. SI-65 Cable Connection Connect by the proper UTP category cable which matches the Ethernet connector. For 10Base-T ------------------- Category 3, 4, 5 For 100Base-TX --------------- Category 5 Note: Although the standardized length of a LAN cable is a maximum 100 meter, use the cable as short as possible.

  • Page 18: Power Source

    <Transfer Distance> The faster communication speed is, the shorter the transfer distance for RS-422/485 is. See the right table Distance (m) Speed (bps) and set communication speed following the actual to 920k distance. to 230.4k Also, the maximum of the actual communication to 115.2k speed changes depending on conditions: environments 1200...

  • Page 19: Chapter 5 Basic Configuring Tasks

    LAN Cable SI-60F/SI-60/SI-65 LAN Cable(Cross Cable) SI-60F/SI-60/SI-65 *SI-60F/SI-60/SI-65 does not have AutoMDI/MDI-X Function. 5-2.Basic Set-Up Tasks Depending on network environments used or the usage, you can use the following procedures remotely or locally: Configure the unit over the network by using Web Manager To configure the unit over the network, enter the IpAddress of SI60/65/60F to Web browser and use web manager.

  • Page 20: Ip Address Assignment

    5-3. IP Address Assignment Before using the converter, you need to assign IP address to the built-in XPort. There are some IP address assignment methods. Assign by the proper method, concerning the usage and environments, and consulting with your network manager. * When the configuration of the IP Address of XPort (built-in) is 0.0.0.0 (factory setting), these functions will be Enable.

  • Page 21: Check Ip Address

    3. The main window of Device Installer appears.It finds SI-60F/SI-60/SI-65 connected to the network automatically and lists in a table on the main window. (If there are devices other than SI-60F/SI-60/SI-65 using XPort on the network, they are also listed in a table..)

  • Page 22: Assign Ip Address

    * We recommend you to disable DHCP and BOOTP or always keep Auto-IP effective because when failing in the address assignment, Device Installer cannot detect SI-60F/SI-60/SI-65 even if DHCP, BOOTP or both are effective. 4. XPort restart by pressing "Assign" button on the "Assignment" page.

  • Page 23: Chapter 6 Configuration Using Web Manager

    Configuration Using Web Manager Chapter 6 6-1. Web Manager Usage The configuration can be changed from a Web manager(Lantronix’s browser-based configuration tool). For more details refer to XPort user’s manual(XPort_UG.pdf ) in tne CD-ROM. Accessing from the deviceinstaller Start DeviceInstaller from the start menu to display DeviceInstaller window.Select the device being set.
  • Page 24 Web Manager Usage Server setting such as CPU Performance Serial Commnunication Conditions setting LAN Connection setting. After setting the various settings such as [Port Settings] ,[Connection] etc.., click “OK” button. Then“Done!” will be displayed and the setup contents hold by Web Manager temporarily.

  • Page 25: Communication Conditions Of Serial Port

    6-2. Communication conditions of serial port 1.When using SI-60F/SI-65 with baud rate 460800/921600bps of the serial port, select "Server" and set High to "CPU Performance Mode". Then, set baud rate of "Serial Settings". 2.Select [Channel1 ] -> [Serial Settings]. Set “Protocol” to be “RS-232C”in serial side. Set Baud Rate, Data Bits, Parity, Stop Bits and Flow Control to be same as the target device.

  • Page 26: Other Setting

    6-4. Other Setting For more details , refer to the online help or XPort user’s manual (XPort_UG.pdf)] in the CD-ROM. Pack Control The packing algorithms define how and when packets are sent to the network. Select [ Channel 1 ] -->[ Serial Settings ] and check [ Pack Control ]--> [ Enable Packing ] to control the received data as you define.

  • Page 27: Chapter 7 Setup Example

    Chapter 7 Setup Example 7-1. Server mode usage To use Device A (connected with the serial port of SI-60/65/60F) through network connection by TCP connection request from a device on the network such as PC to SI-60/65/60F, please refer following setting. Device Serial IP Address:...

  • Page 28: Client Mode Usage

    7-2. Client Mode Usage To use the serial port of the Device A through network connection by TCP connection request from SI-60/65/60F to a server on the network when SI-60/65/60F has received a serial data of Device A, please refer following setting. Device A Server Serial...

  • Page 29: Using Two Units Of Si-60/65/60F

    7-3. Using two units of SI-60/65/60F To extend serial communication between Device A and Device B through network by using two units of SI-60/65/60F, please refer following setting. Device A Device B Serial Serial SI60/65/60F 1 SI60/65/60F 2 Condition: Condition: IPAddress : IPAddress : Speed 9600bps,...
  • Page 30 LANConnection Mode SI60/65/60F 1(Server Mode: Enable,ClientMode:Enable) Remote Remote Host Host Port No. IPAddress SI60/65/60F 2(Server Mode: Enable,ClientMode:Enable) Remote Remote Host Host Port No. IPAddress Because "Active Connect" of both SI-60/65/60F 1 and SI-60/65/60F 2 are configured as "With Any Character", when a serial port of SI-60/65/60F 1 or 2 receives data, the device which received the data will connect with the other device by TCP and send the data through the network.

  • Page 31: Chapter 8 Com Port Redirector

    Chapter 8 COM Port Redirector 8-1.About Virtual COM Port The COM Port Redirector is the utility software to get the serial communication application not supporting the network connection to be able to use on the network. The redirector creates the virtual COM ports in Windows. Communications for these virtual COM ports are transferred to the serial port on the converter through the network.

  • Page 32: Com Port Redirector Ver4.X.x.x Setup

    8-4. COM Port Redirector Ver4.x.x.x Setup Connect SI60/65/60F to the network. Login to the PC as administrator. 1. From start menu, go to "Lantronix" -> "CPR 4.x" -> "CPR Manager. "CPR Manager" window will be displayed. 2.Click [Com Port]-[Add and Remove] of toolbar to open the dialog to register/delete the virtual COM port.

  • Page 33: Chapter 9 Documents

    Chapter 9 Documents 9-1. Built in XPort XPort is built in SI60/65/60F and it is the lan communication module of Lantronix. Web Manager Web-Manager is Lantronix’s browser-based configuration tool to configure the XPort. For more details , refer to [Chapter 6 Configuration Using Web Manager ] DHCP Client Function and AutoIP Function Before using the converter, you need to assign IP address to the built-in XPort.

  • Page 34: Factory Setting

    Port No.10001, IP Address0.0.0.0 (DHCP Client Function and AutoIP Function : Enable) Telnet password: (Password : Disable) Configurable Pins: Setting Values Item SI-60F SI-60 SI-65 HW Flow Control out HW Flow Control out HW Flow Control out General Purpose I/O...

  • Page 35: How To Apply The Factory Setting

    9-3. How to apply the factory setting To apply the factory setting into SI60/65/60F, download the configuration file from the utility CD([ /LINEEYE/SetupRecord ]).Apply the downloaded file when selecting the setup record file. Version SI-60 SI-65 SI-60F Ver6.9.0.2 SI_60V6902_xxxxxx. SI_65_V6902_xxxxxx.
  • Page 36 Operation of DeviceInstaller 1. Install DeviceInstaller to your PC and download the configuration file from the utility CD to the appropriate folder (For example, "c:/setup/"). [ 5-4. DeviceInstaller Usage] 2. Set your device in the same network segment as your PC.(If your devices are not in the same network segment, you may not able to set.) 3.

  • Page 37: General-Purpose I/O Pins

    9-4. General-purpose I/O pins XPort CP1 pin of SI-60F/60 is for the input pin between DR and ER lines of RS-232C. And, XPort CP1 pin of SI-65 is for the output pin of RS-422/485 driver control. To read the input status, send TCP/IP or UDP/IP command to the port number 30704.

  • Page 38: Installation Method

    Rubber feet are put on the bottom of the device. Please set it on a flat and stable place. Fix the converter There are the four M3 screw holes on the back of the converter. When you fix the converter in place, screw the screws into those holes. SI-60F Connecter AC Adaputer plug SI-60/SI-65...

  • Page 39: Chapter 10 Warranty And After-Sales Service

    Chapter 10 Warranty and After-Sales Service 10-1. Troubleshooting The "PWR" LED does not light. < When using the AC adapter > Check that you plug the AC adapter Is the AC adapter connected correctly? into the AC adapter plug or wall outlet correctly.
  • Page 40 Is the connection mode set to Server Check the condition of SI60/65/60F. Mode? Cannot communicate on the serial port side (SI-60F,SI-60) Are Data Status LEDs blinking? It is working correctly if the SD and RD LEDs are blinking on the timing of data transmission.

  • Page 41: Warranty And Repair

    10-2. Warranty and Repair Warranty Within a period of 12 months from the date of shipment, LINEEYE warrants that your purchased products (excepting consumable parts such as the batteries and software) are free of charge from any defects in material and workmanship, only when the products are operated in accordance with procedures described in the documents supplied by LINEEYE.
  • Page 42 ●Head Office: 4F.,Marufuku Bldg.,39-1, Karahasi, Nishihiragaki-cho, Minami-ku, Kyoto, 601-8468, Japan TEL: 075-693-0161 FAX: 075-693-0163 ●Technical Center: 8-49 Kouen-cho, Nagahama, Shiga, 526-0065 TEL: 0749-63-7762 FAX: 0749-63-4489 URL: http://www.lineeye.com Printed In Japan M-G3606560FE/SI...
