LineEye SI-35USB Instruction Manual

3000v high-voltage resistant isolation type, interface converter, usb - serial conversion model
Hide thumbs Also See for SI-35USB:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Instruction Manual
[3000V High-voltage Resistant Isolation Type]
Interface Converter
USB ⇔ Serial Conversion Model
Instruction Manual
SI-35USB / SI-35USB-2
The latest instruction manual is in the attached CD as PDF format.
(2nd edition)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SI-35USB and is the answer not in the manual?

Questions and answers

Related Manuals for LineEye SI-35USB

Summary of Contents for LineEye SI-35USB

  • Page 1 [3000V High-voltage Resistant Isolation Type] Interface Converter USB ⇔ Serial Conversion Model Instruction Manual SI-35USB / SI-35USB-2 The latest instruction manual is in the attached CD as PDF format. (2nd edition)
  • Page 2 This manual has been designed and edited with great care to give you all necessary  information. If you have any questions, feel free to direct your inquiries to LINEEYE. LINEEYE makes no warranty or guarantee, either expressed or implied with respect to ...
  • Page 3 Safety Information Be sure to read the following. LINEEYE has developed and manufactured this product for purpose of using with electrical devices such as a computer, a personal device, a measurement device, semiconductor manufacturing equipment, a vending machine, a sequencer, display equipment and so on.
  • Page 4 ■ Do not disassemble or modify the converter . This may cause overheating, a fire, an electric shock, injury or unit malfunction. ■ Stop using the converter immediately when smoke, smells, or unusual sound emanates from itself. Continuous use may cause a burn, fire, or electric shock. ■...

  • Page 5: Table Of Contents

    ■■■ 　Contents　 ■■■ Chapter 1 Before Using the Product ............1 1-1. Overview ......................1 1-2. Specification .....................1 1-3. Unpacking and Product Composition ...............2 1-4. CD-ROM Included ...................2 1-5. Mounting Arrangement ...................2 Chapter 2 Driver Installation and Usage ..........4 2-1. Driver Installation for Windows 10/8.1/8/7 (32bit/64bit) ........4 2-2.

  • Page 6: Chapter 1 Before Using The Product

    FA equipment and medical equipment that require high safety and reliability. It is able to access the USB port as a COM port using the application software by virtual COM port driver. 1-2. Specification Specifications SI-35USB-2 SI-35USB USB ⇔ RS-422/485 Conversion USB Interface USB1.1/2.0, full speed transmission B onnector...

  • Page 7: Unpacking And Product Composition

    Utility CD-ROM Instruction Manual Warranty Please let your LINEEYE distributor or LINEEYE know if you find any damage to the product caused by transportation, or if there are accessories lacking. 1-4. CD-ROM Included This CD-ROM includes the document file such as the instruction manual, and driver for Windows to connect it to the PC, and software for communication loop-back test.
  • Page 8 With a wall bracket (SI-WM1, optional), you can fix the converter to a wall by screwing from the upper side of the bracket or hooking it to screws or nails hammered into the wall. Wall bracket (SI-WM1) Two φ3.2 holes are for attaching this bracket on the backside of the converter, other holes on each side of the bracket are for attaching on the wall.

  • Page 9: Chapter 2 Driver Installation And Usage

    Chapter 2 Driver Installation and Usage When connecting this converter to a USB port of the PC for the first time, an installation of the driver is necessary for the USB port. If your PC has several USB ports, it is recommend using the specific USB port. Because driver installation is necessary for each USB port to which you connect this converter for the first time.
  • Page 10 3. Click “OK” to start install of the driver package. 4. Then the installation wizard runs. Click “Next” button.
  • Page 11 Two drivers are installed automatically. 5. Click “Finish ” button to finish the installation of the driver package. 6. Connect the USB connector to the USB port. The driver Installation has completed.

  • Page 12: The Way To Confirm The Installed Driver

    2-3. The Way to Confirm the Installed Driver From “Start” menu -> “Control Panel ” -> (“Hardware and Sound” in case of Windows7), run “Device Manager”. Confirm that the name of the converter is shown in the items of Ports (COM & LPT) and Universal Serial Bus Controllers.

  • Page 13: Usage Of Virtual Com Port Driver

    2-4. Usage of Virtual COM Port Driver After the installation of the drivers, the serial port of the converter can be accessed from application software in the same way as Windows standard COM port. [ Precautions for usage ] *Virtual COM port number is the number shown in the Ports (COM & LPT) items of the device manager when this converter is connected with PC.

  • Page 14: Chapter 3 Usage

    Chapter 3 Usage 3-1. Overview and Features SI-35USB/SI-35USB-2 is a USB converter that converts USB port of PC into RS-422/ RS-485, which enables to transmit for a long distance and multi-drop bus connection. This device is suitable for use in situations in which security and reliability are needed...

  • Page 15: Panel Explanation

    USB / RS-422,RS-485 インターフェースコンバータ 外形図 型番：SI-35USB 株式会社ラインア 3-2. Panel Explanation ■ SI-35USB ① ② ⑤ ⑥ 株式会社ライ 単位  ： ④ ③ ■ SI-35USB-2 ① ② 22.5 ⑤ ⑥ ③ ④ Power Lights when USB bus power is supplied Supply LED Indicates a data transmission/ reception status for RS-422/485.Blinks Data Status the TXD LED if there is data from USB to RS-422/485.Blinks the RXD...
  • Page 16 5 Pole Terminal Block Pin Assignment for RS-422/485 Full Duplex Mode *1 Half Duplex Mode *1 Terminal Name Direction Description Direction Description Transmission/ Transmission Data + Reception Data + Transmission/ Transmission Data – Reception Data – Signal Grand *4 Signal Grand *4 Reception Data + Cannot use *3 R–...

  • Page 17: Hardware Setup

    3-3. Hardware Setup The two dip switches on the converter allows you to conduct the following setups: the line monitoring function, the driver control method, terminator enable/disable, and echo back enable/disable. ■ SW-A No. 1-3 (Baud Rate Setup) When using the line monitoring function or RS-485 driver control by RTS/DTS signal (when SW-A No.4 is ON), set this converter referring to the table below depending on the speed.
  • Page 18 * When SW-A No.4 is off, both on and off are acceptable for No.5. Example: The driver control for the data of 31H, 9600bps, SW-A No.1-4 off/off/ off(1.35mS)/on is as the following figure. * RTS and DTR for driver control should be selected by SW-A No.5. Mark Data Idle(Mark)

  • Page 19: Cable Connection

    Please do not connect to the different USB port. Please do not connect to a USB hub, which only uses bus power, and do not have any other power supply. It may cause the insufficient of power and LINEEYE cannot have operation guarantee.
  • Page 20 SI-35USB-2 SI-35USB-2 SI-35USB-2 SI-35USB-2 *Maximum of 128 devices can be connected if constituted only by SI-35USB/SI- 35USB-2. (tested by LINEEYE) [ Applicable RS-422/485 cable] Cable of which conductor size should be AWG24-14, single wire 0.2- 2.5mm2, twisted cable 0.12- 1.5mm2, L=6mm can be removed. If using the ferrule terminal, ferrule diameter should be 1.5mm or less.

  • Page 21: Chapter 4 Warranty And After-Sales Service

    4-2. Loop-back Test by Communication Software The following example is a case by Tera Term (freeware). (Note: Tera Term is not supported by LINEEYE. Procedure may be different depending on the version of the software.) 1. Make a loop-back setting referring to following tables depending on the model of the 　...
  • Page 22 2. Run Tera Term and select the serial port of the converter. And set the communication speed if you need. 3. Confirm the box “Local echo” is not checked. -17-...
  • Page 23 4. Confirm that characters entered from the keyboard are displayed. -18-...

  • Page 24: Warranty And Repair

    4-3 Warranty and Repair ■ Warranty Within a period of 12 months from the date of shipment, LINEEYE warrants that your purchased products (excepting consumable parts such as the batteries and software) are free of charge from any defects in material and workmanship, only when the products are operated in accordance with procedures described in the documents supplied by LINEEYE.
  • Page 25 T h e c a r d p a c k e d w i t h t h e p r o d u c t i s t h e u s e r registration card for Japanese customers. For overseas customers, there is a registration page on our web site.(www.lineeye.com) 4F., Marufuku Bldg.,39-1, Karahasi, Nishihiragaki-cho, Minami-ku, Kyoto, 601-8468, Japan TEL: 81-75-693-0161 　　 FAX: 81-75-693-0163 URL: http://www.lineeye.com...
