MOBIS PLUS 10
PORTABLE AIR CONDITIONER
R290
USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MOBIS PLUS 10 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ariston MOBIS PLUS 10

Summary of Contents for Ariston MOBIS PLUS 10

  • Page 1 MOBIS PLUS 10 PORTABLE AIR CONDITIONER R290 USER MANUAL...

  • Page 3: Meanings Of The Symbols

    Please read this user manual first! Dear Customer, Thank you for preferring an Ariston product. We hope that you get the best results from your product which has been manufactured with high quality and state-of- the-art technology. Therefore, please read this entire user manual and all other accompanying documents carefully before using the product and keep it as a reference for future use.

  • Page 4: Table Of Contents

    Contents 1 Safety precautions 2 Warnings (for using R290 refrigerant only) 3 Preparation 4 Installation 4.1 Choosing the right location ............25 4.2 Recommend installation .

  • Page 5: Safety Precautions

    Safety precautions Warning To prevent death or injury to the user or other people and property damage, the following instructions must be followed. Incorrect operation due to ignoring of instructions may cause death, harm or damage. •Installation must be performed according to the installation instructions.
  • Page 6 Safety precautions •Do not modify the length of the power cord or use an extension cord to power the unit. •Do not share a single outlet with other electrical appliances. Improper power supply can cause fire or electrical shock. •Do not install your air conditioner in a wet room such as a bathroom or laundry room.
  • Page 7 Safety precautions •All wiring must be performed strictly in accordance with the wiring diagram located inside of the unit. •The unit’s circuit board (PCB) is designed with a fuse to provide overcurrent protection. The specifications of the fuse are printed on the circuit board, such as: T 3.15A/250V, etc.
  • Page 8 Safety precautions •Do not remove any fixed covers. Never use this appliance if it is not working properly, or if it has been dropped or damaged. •Do not run cord under carpeting. Do not cover cord with throw rugs, runners, or similar coverings. Do not route cord under furniture or appliances.
  • Page 9 Safety precautions •Do not remove any fixed covers. Never use this appliance if it is not working properly, or if it has been dropped or damaged. •Do not operate or stop the unit by inserting or pulling out the power cord plug.
  • Page 10 Safety precautions – Staff kitchen areas in shops, offices and other working environments; – farm houses; – by clients in hotels, motels and other residential type environments; – bed and breakfast type environments; 10 / Local air conditioner / Instruction Manual...

  • Page 11: Warnings (For Using R290 Refrigerant Only)

    Warnings (for using R290 refrigerant only) • Do not use means to accelerate the defrosting process or to clean, other than those recommended by the manufacturer. • The appliance shall be stored in a room without continuously operating ignition sources (for example: open flames, an operating gas appliance or an operating electric heater).
  • Page 12 Warnings (for using R290 refrigerant only) •Servicing shall only be performed as recommended by the equipment manufacturer. Maintenance and repair requiring the assistance of other skilled personnel shall be carried out under the supervision of the person competent in the use of flammable refrigerants. 1.
  • Page 13 Warnings (for using R290 refrigerant only) 2) Work procedure Work shall be undertaken under a controlled procedure so as to minimise the risk of a flammable gas or vapour being present while the work is being performed. 3) General work area All maintenance staff and others working in the local area shall be instructed on the nature of work being carried out.
  • Page 14 Warnings (for using R290 refrigerant only) in such a manner that it may lead to the risk of fire or explosion. All possible ignition sources, including cigarette smoking, should be kept sufficiently far away from the site of installation, repairing, removing and disposal, during which flammable refrigerant can possibly be released to the surrounding space.
  • Page 15 Warnings (for using R290 refrigerant only) •If an indirect refrigerating circuit is being used, the secondary circuit shall be checked for the presence of refrigerant; Marking to the equipment continues to be visible and legible. Markings and signs that are illegible shall be corrected; •Refrigeration pipe or components are installed in a position where they are unlikely to be exposed to any substance which may corrode refrigerant containing components, unless the components are...
  • Page 16 Warnings (for using R290 refrigerant only) 7. Repairs to sealed components 1) During repairs to sealed components, all electrical supplies shall be disconnected from the equipment being worked upon prior to any removal of sealed covers, etc. If it is absolutely necessary to have an electrical supply to equipment during servicing, then a permanently operating form of leak detection shall be located at the most critical point to warn of a potentially hazardous situation.
  • Page 17 Warnings (for using R290 refrigerant only) 8. Repair to intrinsically safe components Do not apply any permanent inductive or capacitance loads to the circuit without ensuring that this will not exceed the permissible voltage and current permitted for the equipment in use. Intrinsically safe components are the only types that can be worked on while live in the presence of a flammable atmosphere.
  • Page 18 Warnings (for using R290 refrigerant only) be calibrated to the refrigerant employed and the appropriate percentage of gas (25 % maximum) is confirmed. Leak detection fluids are suitable for use with most refrigerants but the use of detergents containing chlorine shall be avoided as the chlorine may react with the refrigerant and corrode the copper pipe-work.
  • Page 19 Warnings (for using R290 refrigerant only) Flushing shall be achieved by breaking the vacuum in the system with OFN and continuing to fill until the working pressure is achieved, then venting to atmosphere, and finally pulling down to a vacuum. This process shall be repeated until no refrigerant is within the system.
  • Page 20 Warnings (for using R290 refrigerant only) 14. Decommissioning Before carrying out this procedure, it is essential that the technician is completely familiar with the equipment and all its detail. It is recommended good practice that all refrigerants are recovered safely. Prior to the task being carried out, an oil and refrigerant sample shall be taken in case analysis is required prior to re-use of reclaimed refrigerant.
  • Page 21 Warnings (for using R290 refrigerant only) i. Do not exceed the maximum working pressure of the cylinder, even temporarily. j. When the cylinders have been filled correctly and the process completed, make sure that the cylinders and the equipment are removed from site promptly and all isolation valves on the equipment are closed off.
  • Page 22 Warnings (for using R290 refrigerant only) Empty recovery cylinders are evacuated and, if possible, cooled before recovery occurs. The recovery equipment shall be in good working order with a set of instructions concerning the equipment that is at hand and shall be suitable for the recovery of flammable refrigerants.

  • Page 23: Preparation

    Preparation Control panel Horizontal louver blade (swing automatically) Handle (both sides) Panel Caster Front 23 / Local air conditioner / Instruction Manual...
  • Page 24 Preparation 1. Upper air filter (behind the grille) 7. Drain outlet (only for pump heating mode) 2. Upper air intake 8. Power cord buckle 3. Drain outlet 9. Power cord outlet 4. Air outlet 10. Power plug socket 5. lower air filter 11.

  • Page 25: Installation

    Installation 4.1 Choosing the right location Your installation location should meet the following requirements: - Make sure that you install your unit on an even surface to minimize noise and vibration. - The unit must be installed near a grounded plug, and the collection tray drain (found on the back of the unit) must be accessible.

  • Page 26: Tools Needed

    Installation Note: All the illustrations in the manual are for explanation purpose only. Your machine may be slightly different. The actual shape shall prevail. The unit can be controlled by the unit control panel alone or with the remote controller. This manual does not include Remote controller operations, see the <...

  • Page 27: Window Installation Kit

    Installation Parts Description Quantity Power Cord Buckle 1 pc Bolt 1 pc Security Bracket and Screw 1 set Drain Hose 1 pc Drain Hose Adaptor (only for heat pump mode) 1 pc Foam Seal A (Adhesive) 2 pc Foam Seal B (Adhesive) 2 pc Foam Seal C (Non-adhesive) 1 pc...
  • Page 28 Installation Make sure the hook of the adaptor is aligned with the hole seat of the air outlet. Hole seat Hook adaptor Make sure the adaptor is inserted into the Lower groove lower groove of the air outlet. Step three: Preparing the adjustable window slider Depending on the size of your window, adjust the size of the window slider.
  • Page 29 Installation 1. Cut the adhesive foam seal A and B strips to the proper lengths, and attach them to the window sash and frame as shown. Window slider B (if required) Window slider B Window slider A (if required) Window slider A 2.
  • Page 30 Installation Type 2: Wall installation (optional) 1. Cut a 125mm (4.9inch) hole into the wall for the wall exhaust adaptor B. 2. Secure the wall exhaust adaptor B to the wall using the four anchors and screws provided in the kit. 3.

  • Page 31: Operation

    Operation Note: The control panel will look like following: For heat pump models For cooling only models Heat mode light High fan speed light Zone follow light Cool mode light Med fan speed light Sleep light Fan mode light Low fan speed light Degrees celsius Dry mode light Auto mode light...
  • Page 32 Operation TIMER button Used to initiate the Auto on start time and Auto off stop time program, in conjuction with the + & - buttons, The timer on/off indicator light illuminates under the timer on/off settings. MODE button Selects the appropriate operating mode. Each time you press the button, a mode is selected in a sequence that goes from Auto, Cool, Dry, Fan and Heat (cooling only models without).
  • Page 33 Operation IONIZER feature Press SPEED button for 3 seconds to initiate IONIZER feature and the IONIZER light illuminates, the LED display shows ‘ON’ for 3 seconds. The ion generator is energized and will help to purify the air inside. Press SPEED button for 3 seconds again to stop the IONIZER feature and the IONIZER light turn dark, the LED display shows ‘OFF’...

  • Page 34: Operation Instructions

    Operation Note: When one of the above malfunctions occurs, turn off the unit, and check for any obstructions. Restart the unit, if the malfunction is still present, turn off the unit and unplug the power cord. Contact the manufacturer or its service agents or a similar qualified person for service.
  • Page 35 Operation Note: Under Auto mode, both the Auto mode and the actual operation mode indicator lights illuminate for some models. Fan operation - Press the “MODE” button until the ”Fan“ indicator light comes on. - Press the “FAN SPEED” button to choose the fan speed. The temperature can not be adjusted. - Do not put the duct to window.

  • Page 36: Other Features

    Operation 5.2 Other features Zone follow Note: This feature can be activated from the remote control only. The remote control serves as a remote thermostat allowing for the precise temperature control at its location. To activate the Zone Follow feature, point the remote control towards the unit and press the Zone Follow The remote control will send this signal to the air conditioner until press the Zone Follow again.
  • Page 37 Operation Water drainage - During dehumidifying modes, remove the upper drain plug from the back of the unit, install the drain connector (5/8” universal female mender) with 3/4” hose (locally purchased). For the models without drain connector, just attach the drain hose to the hole. Place the open end of the hose directly over the drain area in your basement floor.
  • Page 38 Operation drain hose adaptor drain hose adaptor Press the power cord buckle into the rear cover. - When the water level of the bottom tray reaches a predetermined level, the unit beeps 8 times, the digital display area shows ”P1”. At this time the air conditioning/dehumidification process will immediately stop.

  • Page 39: Maintenance

    Maintenance Warning: – Always unplug the unit before cleaning or servicing. – Do not use flammable liquids or chemicals to clean the unit. – Do not wash the unit under running water. Doing so causes electrical danger. – Do not operate the machine if the power supply was damaged during cleaning.
  • Page 40 Maintenance Maintenance tips - Be sure to clean the air filter every 2 weeks for optimal performance. - The water collection tray should be drained immediately after P1 error occurs, and before storage to prevent mold. - In households with animals, you will have to periodically wipe down the grill to prevent blocked airflow due to animal hair.

  • Page 41: Faults Diagnosis

    Faults diagnosis Please check the machine according to the following form before asking for maintenance: Problem Possible cause Troubleshooting The water collection tray is full. Turn off the unit, drain P1 Error code the water from the water collection tray and restart the Unit does not turn on when unit.

  • Page 42: Design And Compliance Notes

    Design and compliance notes Design notice The design and specifications are subject to change without prior notice for product improvement. Consult with the sales agency or manufacturer for details. Any updates to the manual will be uploaded to the service website, please check for the latest version. Energy rating information The Energy Rating for this unit is based on an installation using an un-extended exhaust duct without window slider adaptor or wall exhaust adaptor A (as shown in the Installation section of this manual).

  • Page 43: Sociable Remark

    Sociable remark When using this unit in the European countries, the following information must be followed: Disposal: Do not dispose this product as unsorted municipal waste. Collection of such waste separately for special treatment is necessary. It is prohibited to dispose of this appliance in domestic household waste. For disposal, there are several possibilities: A) The municipality has established collection systems, where electronic waste can be disposed of at least free of charge to the user.

  • Page 44: Installation Instructions

    Installation instructions 10.1 F-Gas instruction This equipment contains fluorinated greenhouse gases. The fluorinated greehouse gases are contained in hermetically sealed equipment. Installs, services, maintains, repairs, checks for leaks or decommissions equipment and product recycling should be carried out by natural persons that hold relevant certificates. If the system has a leakage detection system installed, leakage checks should be performed at least every 12 months, make sure system operate properly.

  • Page 45: Specification

    Specification Model name MOBIS 10 PLUS Refrigerant R290 Total refrigerant amount (g) Climate class Heating type Cooling capacity (Btu/h) 10000 Cooling capacity (W) 2931 Heating capacity (Btu/h) Heating capacity (W) Energy efficiency cooling (W/W) Energy efficiency heating (W/W) Energy level-cooling Energy level- heating Cooling power input (W) Heating power input (W)

  • Page 47: Remote Control

    Remote Control SHORT CUT: Press the “SHORT CUT” button to select and enable ON/OFF Turn the your favorite settings (user-defined). device on and off. TEMP : It is a temperature adjustment (+) button. Each time the MODE: three modes button is pressed, the temperature available AUTO will increase by 1°C (up to 30°C at...
  • Page 48 Transmission Indicator It will illuminate when the remote control sends signals to this device. ON/OFF Function Mode It will illuminate only when The current function mode the device is started. is displayed: ● AUTO TIMER ON TIMER OFF ● COOL It will illuminate only when It will illuminate only when the related function is...

  • Page 50: Product Information Sheet

    Product Information Sheet Delegated Regulation (EU) 626/2011 ARISTON Supplier name or trademark MOBIS 10 PLUS UK Model identifier MOBIS 10 PLUS UK Indoor Model Identifier(s) Outdoor Model Identifier Inside sound power levels (Cooling mode) 62 dB ‐ Outside sound power levels (Cooling mode)
  • Page 52 DESIGN ITALIANO Ariston Thermo UK Ltd. Artisan Building • Hillbottom Road High Wycombe • HP12 4HJ UNITED KINGDOM Ariston Thermo SpA Viale A. Merloni, 45 • 60044 Fabriano (AN) - ITALY ariston.com Customer Service 0333 240 8777 Call charges depend on your agreement...
