Boser HS-1760 Manual

Intel core 2 duo/mobile celeron processor mini itx board
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
All manuals and user guides at all-guides.com
HS-1760
Intel® Core™ 2 Duo/Mobile Celeron® processor
Mini ITX Board
•1066/800MHz FSB•DDR3•CompactFlash•
•PCIe x1•PCIe x16•Mini PCI•PCI•
•GPIO•DVI-I/CRT/LVDS•Dual GB LAN•
•HD Audio• 4 SATA•RS-232/422/485•4 COM•
•6 USB2.0•WDT•H/W Monitor•

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HS-1760 and is the answer not in the manual?

Questions and answers

Related Manuals for Boser HS-1760

Summary of Contents for Boser HS-1760

  • Page 1 All manuals and user guides at all-guides.com HS-1760 Intel® Core™ 2 Duo/Mobile Celeron® processor Mini ITX Board •1066/800MHz FSB•DDR3•CompactFlash• •PCIe x1•PCIe x16•Mini PCI•PCI• •GPIO•DVI-I/CRT/LVDS•Dual GB LAN• •HD Audio• 4 SATA•RS-232/422/485•4 COM• •6 USB2.0•WDT•H/W Monitor•...
  • Page 2 Unauthorized reproduction, transmission, translation, and storage of any form and means (i.e., electronic, mechanical, photocopying, recording) of this document, in whole or partly, is prohibited, unless granted permission by BOSER Technology Co., Ltd. reserves the right to change or improve the contents of BOSER Technology Co., Ltd.

  • Page 3: Table Of Contents

    All manuals and user guides at all-guides.com Table of Contents Chapter 1 General Description ........1 1.1 Major Features ............... 2 1.2 Specifications ................ 2 1.3 Board Dimensions ..............4 Chapter 2 Unpacking ..........5 2.1 Opening the Delivery Package ..........5 2.2 Inspection ................
  • Page 4 All manuals and user guides at all-guides.com Chapter 4 AMI BIOS Setup ........25 4.1 Starting Setup ..............25 4.2 Using Setup ................. 26 4.3 Main Menu ................27 4.4 Advanced Settings .............. 28 4.5 Advanced PCI/PnP Settings ..........32 4.6 Boot Settings ...............
  • Page 5 All manuals and user guides at all-guides.com Declaration of Conformity -- CE Mark BOSER Technology hereby acknowledges that compliance testing in accordance with applicable standards of the EU’s EMC Directive, 89/336/EEC, was successfully completed on a sample of the equipment...
  • Page 6 Fasten the ALLIGATOR clip of the strap to the end of the shielded wire lead from a grounded object. Please wear and connect the strap before handle the HS-1760 to ensure harmlessly discharge any static electricity through the strap.

  • Page 7: Chapter 1 General Description

    The HS-1760 is an Intel® GM45/ICH9-M chipset-based board designed, the board supports Intel® Mobile Dual-Core processor. The HS-1760 is an ideal all-in-one mini ITX board. Additional features include an enhanced I/O with CF, DVI-I/CRT/LVDS, dual GB LAN, HD audio, 4 SATA, 4 COM, and 6 USB2.0 interfaces.

  • Page 8: Major Features

    (WDT) onboard , the HS-1760 is designed with software that does not need the arithmetical functions of a real-time clock chip. If any program causes unexpected halts to the system, the onboard WDT will automatically reset the CPU or generate an interrupt to resolve such condition.
  • Page 9 All manuals and user guides at all-guides.com Watchdog Timer: Software programmable time-out intervals from 1~255 sec. or 1~255 min. H/W Status Monitor: Monitoring temperatures, voltages, and cooling fan status Expansion Interface: 1 x PCIe x1 slot 1 x PCIe x16 slot 1 x Type III mini PCI slot 1 x Standard PCI slot Power Function:...

  • Page 10: Board Dimensions

    All manuals and user guides at all-guides.com Ethernet Chipset: Dual RealTek RTL8111C 10/100/1000 Mbps LAN Ethernet Interface: 2 x RJ-45 Board Dimensions...

  • Page 11: Chapter 2 Unpacking

    Chapter 2 Unpacking Opening the Delivery Package The HS-1760 is packed in an anti-static bag. The board has components that are easily damaged by static electricity. Do not remove the anti-static wrapping until proper precautions have been taken. Safety Instructions in front of this manual describe anti-static precautions and procedures.
  • Page 12 All manuals and user guides at all-guides.com Cables Package Description QTY. SATA cable 50cm (w/Lock) Print DB25-26P(2.0) cable SATA power cable 15cm It is recommended that you keep all the parts of the delivery package intact and store them in a safe/dry place for any unforeseen event requiring the return shipment of the product.

  • Page 13: Chapter 3 Hardware Installation

    Chapter 3 Hardware Installation This chapter provides the information on how to install the hardware using the HS-1760. This chapter also contains information related to jumper settings of switch, and watchdog timer selection etc. Before Installation After confirming your package contents, you are now ready to install your hardware.

  • Page 14: Board Layout

    All manuals and user guides at all-guides.com Board Layout TOP Side...

  • Page 15: Jumper List

    All manuals and user guides at all-guides.com Solder Side Jumper List Jumper Default Setting Setting Page Panel Voltage Select: +3.3V Short 2-3 Clear CMOS: Normal Operation Short 1-2 Short 2-3 JP11 FSB Frequency Select: CPU Driven Short 1-2 JP12 Short 1-2 JP13 Short 2-3 JP14...

  • Page 16: Connector List

    All manuals and user guides at all-guides.com Connector List Connector Definition Page ATX1 24-pin ATX Power Connector PS/2 6-pin Mini DIN KB & MS Connector CN3/CN5 LVDS Panel Connector System Front Panel Connector 15-pin CRT/DVI-I Connector COM 1/COM 2 Connector (DB9) CN8/CN11/CN13/CN15 SATA 0~SATA 3 Connector CN9/CN12...

  • Page 17: Configuring The Cpu

    All manuals and user guides at all-guides.com Configuring the CPU The HS-1760 use Socket P for Intel® Core™ 2 Duo (Penryn 45nm) and Mobile Celeron® processor. JP9/JP11/JP12: FSB Frequency Select Settings Options JP11 JP12 CPU Driven (default) Short 2-3 Short 1-2...
  • Page 18 If you want to use 48-bit dual channel LVDS panel, please use CN3 and CN5 combined. The HS-1760 has an onboard jumper that selects the working voltage of the flat panel connected to the system. Jumper JP3 offers two voltage settings for the user.

  • Page 19: Serial Ata Connector

    All manuals and user guides at all-guides.com CN6B: DVI-I Connector PIN Description PIN Description - DATA2 DATA2 -DATA4 DATA4 DDCCLK DDCDATA VSYNC -DATA1 DATA1 -DATA3 DATA3 VCC5 HPDET -DATA0 DATA0 -DATA5 DATA5 -CLK GREEN BLUE HSYNC Serial ATA Connector You can connect the Serial ATA device that provides you high speeds transfer rates (300MB/sec.).

  • Page 20: Serial Port Connectors

    SATA 3 (default) Short 2-3 Short 1-2 Serial Port Connectors The HS-1760 offers 16C550 compatible UARTs with Send/ Receive 16-byte FIFO serial ports. CN7: COM 1/COM 2 Connector (DB9) PIN Description PIN Description CN18/CN19: COM 3/COM 4 Connector (5x2 Header) PIN Description PIN Description Don’t Use...

  • Page 21: Ethernet Connector

    4-wires point-to-point full duplex RS-422/485 Typical RS-485 2-wires Mutildrop Network 3.10 Ethernet Connector The HS-1760 provides two RJ-45 connectors for 10/100/1000 Based LAN. Please refer to the following for its pin information. When installs OS, this driver namely can automatically install. User does not need to renewal.

  • Page 22: Usb Port

    All manuals and user guides at all-guides.com 3.11 USB Port The HS-1760 provides one 8-pin connectors, at location CN16, for two USB2.0 ports, and CN9/CN12 are external USB2.0 ports, there are total six USB2.0 ports in HS-1760. CN9/CN12: External USB2.0 Port...

  • Page 23: Parallel Port

    All manuals and user guides at all-guides.com 3.13 Parallel Port CN24 is a standard 26-pin flat cable connector designed to accommodate parallel port connection onboard the HS-1760. CN24: Parallel Port Description Description Strobe Auto From Feed DATA 0 ERROR# DATA 1...

  • Page 24: Power And Fan Connectors

    All manuals and user guides at all-guides.com 3.14 Power and Fan Connectors ATX1: 24-pin ATX Power Connector PIN Description PIN Description PS_ON Power OK 5VSB +12V +12V FN1/FN2: Fan Power Connector Description +12V Fan In CN26: External ATX Power Connector Description ATX Power Button...

  • Page 25: Keyboard/Mouse Connectors

    All manuals and user guides at all-guides.com 3.15 Keyboard/Mouse Connectors The CN2 is a PS/2 6-pin Mini DIN connector for HS-1760. CN2: PS/2 6-pin Mini DIN Keyboard & Mouse Connector Description Description Keyboard Data Keyboard Clock Mouse Data Mouse Clock 3.16 System Front Panel Control...

  • Page 26: Watchdog Timer

    A reset system signal will restart when such error happens. The HS-1760 custom WDT circuit is implemented using the internal IO of the Winbond Super I/O W83627UHG which is at 2Eh of LPC. The following sample programs show how to enable, disable and...
  • Page 27 All manuals and user guides at all-guides.com counting++; if(counting > 255) counting = 255; printf("WDT timeout in %d minutes.\n", counting); else outportb(83627UHG_Port, 0xf5); Register_Setup = inportb(83627UHG_Port+1); Register_Setup &= 0xf7; outportb(83627UHG_Port+1, Register_Setup); / / set as second mode Counting = count_setup; printf("WDT timeout in %d seconds.\n", counting);...

  • Page 28: Audio Connectors

    CN14(Green) is Line Out, CN14(PINK) is MIC In. 3.19 CompactFlash Connector The HS-1760 also offers a Type I/II CompactFlash connector is IDE interface located at the solder side of the board. The designated CN25 connector, once soldered with an adapter, can hold CompactFlash...
  • Page 29 All manuals and user guides at all-guides.com CN25: CompactFlash Connector Description Description DATA3 DATA4 DATA5 DATA6 DATA7 SDCS1# SDA2 SDA1 SDA0 DATA0 DATA1 DATA2 470Ω pull GND DATA11 DATA12 DATA13 DATA14 DATA15 SDCS3# EWE0 RESET IORDY DACK IDE LED PDIAG DATA8 DATA9 DATA10...

  • Page 30: 8-Bit Gpio Function

    All manuals and user guides at all-guides.com 3.20 8-bit GPIO Function The HS-1760 offers one 8-bit input/output port. CN22: 8-bit GPIO PIN Description PIN Description EX. Sample Code Using GPIO 5 #include <conio.h> #include <stdio.h> #include <io.h> void main(void) unsigned char byte_cr29;...

  • Page 31: Chapter 4 Ami Bios Setup

    All manuals and user guides at all-guides.com Chapter 4 AMI BIOS Setup The HS-1760 uses AMI BIOS for the system configuration. The AMI BIOS setup program is designed to provide the maximum flexibility in configuring the system by offering various options that could be selected for end-user requirements.

  • Page 32: Using Setup

    All manuals and user guides at all-guides.com Using Setup In general, you use the arrow keys to highlight items, press <Enter> to select, and press <Esc> to quit. The following table provides more detail about how to navigate in the Setup program using the keyboard. Move to previous item ↑...

  • Page 33: Main Menu

    All manuals and user guides at all-guides.com Main Menu Once you enter the AMI BIOS CMOS Setup Utility, the Main Menu will appear on the screen. The Main Menu allows you to select from several setup functions and two exit choices. Use the arrow keys to select among the items and press <Enter>...

  • Page 34: Advanced Settings

    All manuals and user guides at all-guides.com Advanced Settings This section allows you to configure your system for the basic operation. You have the opportunity to select the system’s default speed, boot-up sequence, keyboard operation, shadowing and security. BIOS SETUP UTILITY Main Advanced PCIPnP...
  • Page 35 All manuals and user guides at all-guides.com BIOS SETUP UTILITY Main Advanced PCIPnP Boot Security Chipset Exit IDE Configuration Configure SATA#1 as [IDE] SATA PORT0 : [Not Detected] SATA PORT1 : [Not Detected] SATA PORT2 : [Not Detected] Select Screen SATA PORT3 : [Not Detected] Select Item...
  • Page 36 All manuals and user guides at all-guides.com BIOS SETUP UTILITY Main Advanced PCIPnP Boot Security Chipset Exit ACPI Settings Suspend mode [Auto] Select Screen Select Item Change Field Select Field General Help Save and Exit Exit v02.61 (C)Copyright 1985-2006, American Megatrends, Inc. BIOS SETUP UTILITY Main Advanced...
  • Page 37 All manuals and user guides at all-guides.com BIOS SETUP UTILITY Main Advanced PCIPnP Boot Security Chipset Exit AHCI Settings AHCI BIOS Support [Enabled] Select Screen AHCI Port0 [Not Detected] Select Item AHCI Port1 [Not Detected] Change Field AHCI Port2 [Not Detected] Select Field AHCI Port3 [Not Detected]...

  • Page 38: Advanced Pci/Pnp Settings

    All manuals and user guides at all-guides.com Advanced PCI/PnP Settings This section describes configuring the PCI bus system. PCI, or Personal Computer Interconnect, is a system that allows I/O devices to operate at speeds nearing the speed the CPU itself uses when communicating with its own special components.

  • Page 39: Boot Settings

    All manuals and user guides at all-guides.com Boot Settings BIOS SETUP UTILITY Main Advanced PCIPnP Boot Security Chipset Exit Boot Settings Boot Settings Configuration Select Screen Select Item Change Field Select Field General Help Save and Exit Exit v02.61 (C)Copyright 1985-2006, American Megatrends, Inc. BIOS SETUP UTILITY Main Advanced...

  • Page 40: Security Settings

    All manuals and user guides at all-guides.com Security Settings BIOS SETUP UTILITY Main Advanced PCIPnP Boot Security Chipset Exit Security Settings Supervisor Password : Not Installed User Password : Not Installed Select Screen Change Supervisor Password Select Item Change User Password Change Field Boot Sector Virus Protection [Disabled]...

  • Page 41: Advanced Chipset Settings

    All manuals and user guides at all-guides.com Advanced Chipset Settings BIOS SETUP UTILITY Main Advanced PCIPnP Boot Security Chipset Exit Advanced Chipset Settings WARNING: Setting wrong values in below sections may cause system to malfunction. North Bridge Configuration Select Screen South Bridge Configuration Select Item Change Field...

  • Page 42: Exit Options

    All manuals and user guides at all-guides.com BIOS SETUP UTILITY Main Advanced PCIPnP Boot Security Chipset Exit Sorth Bridge Chipset Configuration PCIE Ports Configuration PCIE Port 0 [Auto] PCIE Port 1 [Auto] Select Screen PCIE Port 2 [Auto] Select Item PCIE Port 3 [Auto] - Change Field...

  • Page 43: Chapter 5 Software Utilities

    All manuals and user guides at all-guides.com Chapter 5 Software Utilities This chapter contains the detailed information about installation procedures of chipset, VGA, LAN, audio and other drivers. The utility CD disk that comes with the package contains an auto-run program that invokes the installation programs for the chipset, VGA, LAN and audio drivers.
  • Page 44 All manuals and user guides at all-guides.com Immediately after clicking the CHIPSET button in Step 1, the program launches the Setup that will assist you in the installation process. Click on the Next > button to proceed. The License Agreement dialog box then appears on the screen. Choose Yes to proceed.
  • Page 45 All manuals and user guides at all-guides.com When the Readme File Information dialog box pops up, just clock on the Next> button to proceed. Click on the Finish to completed the installation.

  • Page 46: Vga Driver Installation

    All manuals and user guides at all-guides.com VGA Driver Installation Insert the CD that comes with the board into the CD-ROM drive. Click VGA to install Intel® GM45 video driver. The Welcome to the Setup program dialog box appears on the screen.
  • Page 47 All manuals and user guides at all-guides.com The Intel® License Agreement dialog box appears on the screen. Choose Yes to proceed. When the Readme File Information dialog box pops up, just click on the Next> button to proceed.
  • Page 48 All manuals and user guides at all-guides.com The Installshield Wizard dialog box appears on the screen. Click on Next> to proceed. When Setup Progress finished, just click on Next button to proceed.

  • Page 49: Lan Driver Installation

    All manuals and user guides at all-guides.com Please select “Yes, I want to restart my computer now” button then click “Finish” to reboot your system to take the effect once the installation is completed. LAN Driver Installation Insert the CD that comes with the board into the CD-ROM drive. Click LAN to install RTL8111 LAN driver.
  • Page 50 All manuals and user guides at all-guides.com When the dialog box below appears, make sure you close all other Windows applications the click on the Next> button to proceed. The Setup Status dialog box then appears on the screen.

  • Page 51: Audio Driver Installation

    All manuals and user guides at all-guides.com When setup is finished, please reboot your computer to take the effect. Audio Driver Installation Insert the CD that comes with the board into the CD-ROM drive. Click Audio to install audio driver.
  • Page 52 All manuals and user guides at all-guides.com When the dialog box below appears, Click on Yes to proceed. Please select “Yes, I want to restart my computer now” button then click “Finish” to reboot your system to take the effect once the installation is completed.

  • Page 53: Appendix A Riser Card Application

    All manuals and user guides at all-guides.com Appendix A Riser Card Application BOSER released PCI Riser Card A-1103 (option) to expend PCI interface card for HS-1760. A-1103 has two PCI slots and individual AD for user to select. JP1/JP2: PCI1/PCI2 AD Select Settings...
  • Page 54 All manuals and user guides at all-guides.com This page is the blank page.
