Westerleigh Accent Table
For model number:
3619013COM/ 3619408COM/ 3619412COM/
3619807COM/ 3619811COM/ 3619872COM/
3619902COM/ 3619906COM/ 3619910COM/
3619915COM/ 3619922COM
Do Not Return This Product!
Contact our customer service team for help first.
Call: 1-800-489-3351 (toll free)
Visit: www.ameriwoodhome.com
WARNING
- Unit can tip over causing severe injury
or death.
- Do Not allow children to climb on unit.
- Put heavy items on lower shelves or
drawers.
B343619XXXCOM00HSY
Date of Purchase: ___ / ___ / ___
Lot Number:
Easy
Assembly Difficulty Meter
PEOPLE NEEDED FOR ASSEMBLY: 1
Follow Ameriwood Home
Tough
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Ameriwood HOME Westerleigh
Summary of Contents for Ameriwood HOME Westerleigh
- Page 1 Westerleigh Accent Table For model number: B343619XXXCOM00HSY 3619013COM/ 3619408COM/ 3619412COM/ 3619807COM/ 3619811COM/ 3619872COM/ 3619902COM/ 3619906COM/ 3619910COM/ 3619915COM/ 3619922COM Date of Purchase: ___ / ___ / ___ Lot Number: Do Not Return This Product! Contact our customer service team for help first.
-
Page 2: Helpful Hints
Contact Us! Call us! 1-800-489-3351 Helpful Hints PEOPLE NEEDED FOR ASSEMBLY: 1 ESTIMATED ASSEMBLY TIME: 1.0 HOUR - Open your item in the area you plan to keep it to avoid excessive heavy lifting. - Identify, sort and count the parts before attempting assembly. - Compression dowels are lightly tapped in with a hammer. -
Page 3: Before You Start
Before You Start Read through each step carefully and follow the proper order. Separate and count all your parts and hardware. Give yourself enough room for the assembly process. Have the following tools: Flat Head Screwdriver, #2 Phillips Head Screwdriver and Hammer. Caution: If using a power drill or power screwdriver for screwing, please be aware to slow down and stop when screw is tight. - Page 4 Before You Start Please Note: You may need to lightly tap the wood dowels with a hammer into the holes during your assembly process. Wood Dowel Insertion: Insert wood dowel completely into the hole. ameriwoodhome.com...
-
Page 5: Board Identification
Board Identification Not Actual Size FRONT FRAME TOP PANEL BACK FRAME LEFT SIDE PANEL DRAWER FRONT RIGHT SIDE PANEL ameriwoodhome.com... - Page 6 Board Identification Not Actual Size RIGHT DRAWER SIDE LEFT DRAWER SIDE DRAWER BACK DRAWER BOTTOM For any replacement part, see page 7, 8, 9, 10. DRAWER SUPPORT ameriwoodhome.com...
-
Page 7: Part Number Reference
Part List Part Number Reference Each part has a unique part number. Please reference the appropriate part number when contacting customer service for replacement parts. Before throwing any packaging, please verify all contents and make sure you have received all the parts listed above. - Page 8 Part List Part Number Reference Each part has a unique part number. Please reference the appropriate part number when contacting customer service for replacement parts. Before throwing any packaging, please verify all contents and make sure you have received all the parts listed above.
- Page 9 Part List Part Number Reference Each part has a unique part number. Please reference the appropriate part number when contacting customer service for replacement parts. Before throwing any packaging, please verify all contents and make sure you have received all the parts listed above.
- Page 10 Part List Part Number Reference Each part has a unique part number. Please reference the appropriate part number when contacting customer service for replacement parts. Before throwing any packaging, please verify all contents and make sure you have received all the parts listed above.
- Page 11 Part List Actual Size (x13) (x8) (x2) Wood Dowel Screw Cam Bolt Ø6X35mm Ø8x30mm Ø4x15mm (x2) (x9) (x4) Screw Screw Handle Screw 4x20mm Ø4x25mm Ø4x38mm Not Actual Size For any replacement part, see page 12. (x13) (x2) Cam Lock Handle Ø15x12mm ameriwoodhome.com...
- Page 12 Hardware Number Reference Each part has a unique part number. Please reference the appropriate part number when contacting customer service for replacement parts. Before throwing any packaging, please verify all contents and make sure you have received all the parts listed above. 3619013COM/ 3619408COM/ 3619412COM/ 3619807COM/ 3619811COM/ 3619872COM/ MODEL#...
- Page 13 STEP 1 Dowels extend out 3/8".For more details, please see (x11) (x8) page 4 proper oriention of CAM LOCK · lnsert (2) to (D), (E) & (K) as instructed. · Insert (3) to (D), (E) & (K) as instructed. ameriwoodhome.com...
- Page 14 STEP 2 (x4) · Attach (1) to (A) as illustrated. Do not over tighten. ameriwoodhome.com...
- Page 15 STEP 3 (x2) (x8) · Attach (1) to (B) & (C) as illustrated. Do not over tighten. proper oriention of CAM LOCK · Insert (2) to (B) & (C) as illustrated. Open Space Solid Panel ameriwoodhome.com...
- Page 16 STEP 4 · Attach (D) and (E) to (C) by tightening (2) as illustrated. Make sure the drawer slide wheels are at the opposite end. Proper orientation ameriwoodhome.com...
- Page 17 STEP 5 · Attach (B) to (D) & (E) by tightening (2) as illustrated. Open Space ameriwoodhome.com...
- Page 18 STEP 6 · Attach unit from Step 5 to (A) by tightening (2) as illustrated. ameriwoodhome.com...
- Page 19 STEP 7 (x2) · Fasten (5) as illustrated. ameriwoodhome.com...
- Page 20 STEP 8 (x2) · Carefully turn the unit upright. · Fasten (4) as illustrated. ameriwoodhome.com...
- Page 21 STEP 9 (x1) · Attach (1) to (F) as illustrated. Do not over tighten. ameriwoodhome.com...
- Page 22 STEP 10 (x4) · Attach (G) & (H) to (F) with (6) as illustrated. ameriwoodhome.com...
- Page 23 STEP 11 · Attach (K) to (F) by tightening (2) as illustrated. ameriwoodhome.com...
- Page 24 STEP 12 · Slide (J) into the grooves of (G) & (H) and align with the groove in (F) as illustrated. ameriwoodhome.com...
- Page 25 STEP 13 (x5) · Attach (I) to unit from Step 12 with (6) as illustrated. ameriwoodhome.com...
- Page 26 STEP 14 (x4) (x2) · Attach (8) to (F) with (7) as illustrated. ameriwoodhome.com...
- Page 27 STEP 15 · Carefully insert the drawer into the unit as illustrated. ameriwoodhome.com...
- Page 28 Maximum Loads This unit has been designed to support the maximum loads shown. Exceeding these load limits could cause sagging, instability, product collapse, and/or serious injury. 50 lbs./ 15 lbs. / 23 kg 7 kg Warning: Risk of serious injury to person - do not place a television on this furniture. This furniture is not approved for use with a television.
- Page 29 Visit your local retailer's website, rate your purchased product and leave us some feedback! We would like to extend a big "Thank You" to all of our customers for taking the time to assemble this Ameriwood Home product, and to give us your valuable feedback. ameriwoodhome.com...
- Page 30 Español Cubierta Delantera Este libro de instrucciones contiene información IMPORTANTE de seguridad. Por favor lea y manténgalo para referencia en el futuro. No Regrese este producto! Comuniquese con nuestro amistoso equipo de servicio al cliente para obtener ayuda. Llamenos al: 1-800-489-3351 (Gratis) Visitar: www.ameriwoodhome.com PRECAUCION Este mueble puede volcarse y causar graves heridas y/o muerte.
- Page 31 Español Panel superior Marco frontal Marco posterior Panel lateral izquierdo Panel lateral derecho Parte frontal del cajón Lado izquierdo del cajón Lado derecho del cajón Parte posterior del cajón Parte inferior del cajón Soporte del cajón Página 13 · Inserte (2) en (D), (E) y (K) como se indica. ·...
- Page 32 Visite el sitio web de su distribuidor local, califique el producto que compró y déjenos sus comentarios. Nos gustaría enviar un gran "Agradecimiento" a todos nuestros clientes por tomarse el tiempo de ensamblar este producto de Ameriwood Home, y por darnos sus valiosos comentarios. Gracias...
- Page 33 Français Couverture Avant CE LIVRET D'INSTRUCTION CONTIENT DES INFORMATIONS IMPORTANTES SUR LA SÉCURITÉ. VEUILLEZ LIRE ET GARDER POUR UNE RÉFÉRENCE FUTURE Ne retournez pas ce produit! Contactez notre équipe de service à la clientèle amicale d'abord pour obtenir de l'aide. Appelez-nous: 1-800-489-3351 (sans frais) - Visitez: www.ameriwoodhome.com ATTENTION Le meuble peut basculer et causer des blessures graves ou la mort.
- Page 34 Français Identification des matériaux (Page 5-10) Each part has a unique part number. Please reference the appropriate part number when contacting customer service for replacement parts. Before throwing any packaging, please verify all contents and make sure you have received all the parts listed on previous pages!.
- Page 35 Visitez le site Web de votre détaillant local, évaluez le produit que vous avez acheté et laissez-nous vos commentaires ! Nous tenons à offrir un grand "Merci" à tous nos clients pour avoir pris le temps d'assembler ce produit "Ameriwood Home", et de nous donner vos commentaires précieux. Merci ameriwoodhome.com...
