THIS INSTRUCTION BOOKLET CONTAINS
IMPORTANT SAFETY INFORMATION. PLEASE
READ AND KEEP FOR FUTURE REFERENCE.
Please Recycle
Recicle Por Favor
9151026PCOM
DO NOT RETURN PRODUCT TO THE STORE
STOP
Individual stores do not stock parts.
Date of Purchase
___ / ___ / ___
If a part is missing or damaged, visit our website or call our toll-free
customer service line. We will gladly ship your replacement parts
FREE of charge.
Need Parts or Assistance?
WWW.AMERIWOOD.COM/PARTS
For prompt, reliable service please have your assembly manual ready.
Recommended # of people needed for assembly: 2
(however it is always better to have an extra hand.)
Estimated assembly time is 2 hours.
Se localizan las traducciones españolas en el centro de este
manual.
or call toll free:
1-800-489-3351
B349151026PCOM5
