Ameriwood HOME Westerleigh 3640013COMS Manual

4 drawer dresser white
Hide thumbs

Advertisement

Quick Links

Download this manual
BBBBBBBBBBB
WWWWWWWWWWW B WWWWWW WWWWWWW WWWWW
Date of Purchase: ____/____/_____
Lot Number:
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Do Not Return This Product!
Contact our customer service team for help first
Call: 1-800-489-3351 (toll free)
Visit: www.ameriwoodhome.com
WARNING
–Unit can tip over causing severe injury or death.
–Anchor unit to stud in wall (if instructed to)
–Do not allow children climb on unit
–Put heavy items on lower shelves or drawers
BBBBBBBBBBBBBBBBPP
Easy
Assembly Difficulty Meter
Follow Ameriwood Home
122023PK
Tough

Advertisement

loading
Need help?

Need help?

Do you have a question about the Westerleigh 3640013COMS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ameriwood HOME Westerleigh 3640013COMS

Summary of Contents for Ameriwood HOME Westerleigh 3640013COMS

  • Page 1 Easy Tough Assembly Difficulty Meter WARNING Follow Ameriwood Home –Unit can tip over causing severe injury or death. –Anchor unit to stud in wall (if instructed to) –Do not allow children climb on unit –Put heavy items on lower shelves or drawers...
  • Page 2 BonWWcW UW! BonWWcW UW! Wo NBT WWWuWn WWWW pWoducW! Contact our friendly customer service team first for help BWWW uW! VWWWW WmWWWWoodWomW.com 1-800-489-3351 HWWpfuW HWnWW PEOPLE NEEDED FOR ASSEMBLY: 2 - Open your item in the area you plan to keep it for less heavy lifting. - Identify, sort, and count the parts before attempting assembly.
  • Page 3 BWfoWW You BWWWW Read through each step carefully and follow the proper order Separate and count all your parts and hardware Give yourself enough room for the assembly process Have the following tools: Phillips Head Screwdriver and Hammer Caution: If using a power drill or power screwdriver for screwing, please be aware to slow down and stop when screw is tight.
  • Page 4 Please Note: You may need to lightly tap the wood dowels with a hammer into the holes during your assembly process. Wood Dowel Insertion: Insert wood dowel Not Actual Size completely into the hole. Wood Dowel Wood Dowel will Actual Size extend out approximately 3/8”.
  • Page 5 BoWWd IdWnt f cWt on Not actual size T3640013S010PK T3640013S020PK T3640013S030PK TOP PANEL LEFT SIDE PANEL RIGHT SIDE PANEL T3640013S040PK T3640013S050PK T3640013S060PK BOTTOM PANEL MOLDING RIGHT DRAWER SIDE T3640013S070PK T3640013S080PK T3640013S090PK LEFT DRAWER SIDE (LOCK) DRAWER FRONT DRAWER BACK ameriwoodhome.com...
  • Page 6 BoWWd IdWnt f cWt on Not actual size T3640013S100PK T3640013S110PK T3640013S120PK DRAWER BOTTOM DRAWER SUPPORT T3640013S130PK T3640013S140PK BACK PANEL COUNTER WEIGHT PANEL ameriwoodhome.com...

  • Page 7: Actual Size

    Hardware Bag Reference Number: 23640013COMS0PK PWWW LWWW Actual Size FoW Wny WWpWWcWmWnW WWWdWWWW, oWdWW uWWnW pWWW # 2BBBBBBBBBBBPP TPK0001 TPK0002 TPK0004 TPK0008 CAM BOLT CAM LOCK DOWEL SCREW 15 x 9 M8 x 30 CBS M4 x 38 TPK3005 TPK0015 PH SCREW NAIL M4 x 20...
  • Page 8 Hardware Bag Reference Number: 23640013COMS0PK PWWW LWWW Not Actual Size TPK0011 TPK0012 TPK0013 TPK0014 JCBC SCREW SPRING WASHER FLAT WASHER HEX KEY M6 x 60 x1 SET TPK3007 TPK2004 RECTANGLE ANTI TIPPING KIT HANDLE (GOLD) ameriwoodhome.com...
  • Page 9 Step 1 TPK0014 TPK0011 TPK0012 TPK0013 Attach Legs (K) to Bottom Panel (D). Insert JCBC Screws (7), Spring Washers (8), and Flat Washers (9) to Bottom Panel (D) using Hex Key (10). Tight ameriwoodhome.com...
  • Page 10 Step 2 TPK0001 Properly insert Cam Bolts (1) to Top Panel (A), Bottom Panel (D), Drawer Fronts (H) x 4, and Drawer Backs (I) x 4 and fully tighten. ameriwoodhome.com...
  • Page 11 Step 3 TPK0001 TPK0002 TPK0004 TPK2004 Proper orientation of CAM LOCK Insert Cam Bolts (1), Cam Locks (2), and Dowels (3) to Left Side Panel (B) and Right Side Panel (C). Loosely attach Anti-Tipping Kit (12) and (12c) to Right Side Panel (C). Note: This will be tightened in Step 17.
  • Page 12 Step 4 TPK0002 Proper orientation of CAM LOCK Insert Cam Locks (2) into Counterweight Panel (N) and Drawer Supports (L) x 4. ameriwoodhome.com...
  • Page 13 Step 5 TPK0008 Connect Molding Panel (E) to Top Panel (A) and Bottom Panel (D) using Screws (4) as illustrated. Do NOT over-tighten. ameriwoodhome.com...
  • Page 14 Step 6 Attach Counterweight Panel (N) to Left Side Panel (B), tighten by turning cam locks clockwise. Pro Tip: Second person recommended for ease of assembly on this step. ameriwoodhome.com...
  • Page 15 Step 7 Attach Right Side Panel (C) to Counterweight Panel (N), tighten by turning cam locks clockwise. Pro Tip: Second person recommended for ease of assembly on this step. ameriwoodhome.com...
  • Page 16 Step 8 Attach Bottom Panel (D) to Left and Right Side Panels (B) & (C). Tighten by turning cam locks clockwise. Pro Tip: Second person recommended for ease of assembly on this step. ameriwoodhome.com...
  • Page 17 Step 9 With a assistance of second person, carefully turn up the unit. Attached Top Panel (A) to Left and Right Side Panels (B) & (C). Tighten by turning cam locks clockwise. Pro Tip: Second person recommended for ease of assembly on this step. ameriwoodhome.com...
  • Page 18 Step 10 TPK0015 IBPBRTANT! THE BACK PANEL IS A STRUCTURAL PART OF THIS UNIT AND MUST BE INSTALLED PROPERLY. With the assistance of a second person, carefully lay the unit face down. Attached Back Panel (M) using nails (6) as shown and nailing straight into the raw edges. Ensure that the unit is square.
  • Page 19 Step 11 TPK0008 Connect Left Drawer Sides (G) to Drawer Front (H) using Screws (4) as illustrated x4. Do NOT over-tighten. ameriwoodhome.com...
  • Page 20 Step 12 TPK0008 Connect Right Drawer Sides (F) to Drawer Front (H) using Screws (4) as illustrated x4. Do NOT over-tighten. ameriwoodhome.com...
  • Page 21 Step 13 Attach Drawer Support (L) to Drawer Front (H) x4, and tighten by turning cam lock clockwise. ameriwoodhome.com...
  • Page 22 Step 14 Insert Drawer Bottom (J) into the grooves of Drawer Sides (F) & (G) and align with the groove in Drawer Front (H). Pro Tip: Second person recommended for ease of assembly on this step. ameriwoodhome.com...
  • Page 23 Step 15 TPK0008 Line up the groove in Drawer Back (I) with Drawer Bottom (J) and attach to Left and Right Drawer Sides (F) & (G) using Screws (4). Do NOT over-tighten. Attach Drawer Back (I) to Drawer Support (L) and tighten by turning cam lock clockwise.
  • Page 24 Step 16 TPK3005 TPK3007 Connect Handle (11) to Drawer Front (H) using Screws (5) as illustrated x4. ameriwoodhome.com...
  • Page 25 Step 17 For Masonry, Concrete, or other wall materials: Consult your local hardware store for appropriate anchors to securely attach the safety bracket. IMPORTANT: THIS UNIT MUST BE SECURE TO THE WALL TO HELP PREVENT TIPOVER. FOLLOW THESE INSTRUCTIONS TO INSTALL THE ANTI-TIPPING SAFETY BRACKET PROVIDED WITH THIS PRODUCT.
  • Page 26 Step 18 Carefully insert each drawer into the unit as illustrated. ameriwoodhome.com...

  • Page 27: Maximum Loads

    Maximum Loads This unit has been designed to support the maximum loads shown. Exceeding these load limits could cause sagging, instability, product collapse, and/or serious injury. 50 lbs. 22.7 kg 25 lbs. 11.3 kg Each drawers Enjoy your furniture. WWWnWnW: RWWk of WWWWouW WnjuWy Wo pWWWon - do noW pWWcW W WWWWvWWWon on WWWW fuWnWWuWW. TWWW fuWnWWuWW WW noW WppWovWd foW uWW WWWW W WWWWvWWWon.
  • Page 28 We would like to extend a big “Thank You” to all to assemble this our customers for taking the of our customers for taking the time to assemble Seeds product, and to give us your valuable this Ameriwood Home product, and to give us your feedback. valuable feedback ameriwoodhome.com...
  • Page 29 Español BubWWWWW WWWWnWWWW Este libro de instrucciones contiene información IMPORTANTE de seguridad. Por favor lea y manténgalo para referencia en el futuro. No Regrese este producto! Comuniquese con nuestro amistoso equipo de servicio al cliente para obtener ayuda. Llamenos al: 1-800-489-3351 (Gratis) Visitar: www.ameriwoodhome.com PRECAUCION Este mueble puede volcarse y causar graves heridas y/o muerte.
  • Page 30 Español Página 11 Paso 3 - Inserte el Bolt(1) x4, el Lock(2) x8, el Dowel(3) x12 en el panel lateral(B) y (C) y el panel de moldeo(E) x2. Inserte el kit de anti-tipping(12) y (12c) en el panel lateral derecho(C), no apriete completamente hasta el paso 17. Página 12 Paso 4 - Inserte Cam Lock(2) x12 en el panel de contrapeso(N) y el soporte de la caja(L) x4.
  • Page 31 Español AWVERTENBIA Lesiones por aplastamiento graves o fatales puede ocurrir desde la punta del mueble. Para evitar volcar: * Instale la restricción de vuelco provista * coloque los artículos más pesados en los cajones más bajos * A menos que esté específicamente diseñado para acomodar, no instale televisores u otros objetos pesados en la parte superior de este producto * Nunca permita que los niños trepen o cuelguen de los cajones, puertas o estanterías * Nunca abra más de un cajón a la vez...
  • Page 32 Français cWpoW WvWnW Ce livret d’instructions contient d’importantes informations de sécurité. S’il vous plaît lire et conserver pour référence ultérieure. Ne pas retourner ce produit! Contactez notre équipe de service à la clientèle amical pour aider. Appel: 1-800-489-3351 (gratuit) Visite: www.ameriwoodhome.com BIBE EN GARWE Ce mobilier peut basculer et causer des blessures graves et / ou la mort.
  • Page 33 Français PWWW BB Étape 3 - Insérez le Bolt(1) x4, le Lock(2) x8, le Dowel(3) x12 dans le panneau latéral(B) et (C) et le panel de moulage(E) x2. Insérez le kit anti-tipping(12) et (12c) dans le panneau latéral droit(C), ne pas serrer complètement jusqu’à l’étape 17. PWWW B2 Étape 4 - Insérez Cam Lock(2) x12 dans le panneau de contrepoids(N) et le support de la boîte(L) x4.
  • Page 34 Français Avertssement Des lésions graves ou fatales par écrasement peuvent survenir à partr de la pointe du meuble. Pour éviter de se retourner : * Installez la restriction de retournement fournie * Placez les objets les plus lourds dans les boîtes inférieures * Sauf si elle est spécifiquement conçue pour accueillir, n’installez pas de téléviseurs ou d’autres objets lourdes dans la partie supérieure de ce produit * Ne laissez jamais les enfants grimper ou pendre sur les tiroirs, portes ou étagères...
