Summary of Contents for Toshiba BX430T-HS02-QM-S

  • Page 1 BARCODE PRINTERS Owner’s Manual BX430 T-HS 2 -QM S...
  • Page 2 © 2025 Toshiba Tec Corporation All rights reserved Under the copyright laws, this manual cannot be reproduced, duplicated, or reprinted in any form without prior written permission of Toshiba Tec Corporation.

  • Page 3: Preface

    The exclusion and limitations of liability referred to in this notice shall be effective to the fullest extent permissible at law. For the avoidance of doubt, nothing in this notice shall be taken to exclude or limit Toshiba Tec Corporation’s liability for death or personal injury caused by Toshiba Tec Corporation’s negligence or Toshiba Tec Corporation’s fraudulent misrepresentation.
  • Page 4 Product even if Toshiba Tec Corporation is advised of the possibility of such damages. Toshiba Tec Corporation shall not be liable for any loss, cost, expense, claim or damage caused by any inability to use (including, but not limited to failure, malfunction, hang-up, virus infection or other problems) which arises from use of the Product with hardware, goods or software which Toshiba Tec Corporation has not directly or indirectly supplied.

  • Page 5: Precautions For The Handling Of Wireless Communication Devices

    Standards below are certified under the operation with the provided antenna. Do not use this product with other antennas.  Europe – EU Declaration of Conformity Hereby, Toshiba Tec Corporation, declares that the BX430T series are in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU.  USA – Federal Communications Commission (FCC)

  • Page 6: Approved Countries/Regions For Use For The Devices

    à des appareils mobiles (antennes sont supérieures à 20 cm à partir du corps d'une personne). Approved Countries/Regions for Use for the Devices This equipment is approved to the radio standard by the specific countries/regions. Please ask Toshiba Tec authorized dealers or service technicians.

  • Page 7: Table Of Contents

    CONTENTS Preface..............................3 How to read this manual ............................3 Precautions for the handling of Wireless Communication Devices ............. 5 Regulatory Information .............................. 5 Approved Countries/Regions for Use for the Devices ....................6 Precaution for Use ..............................6 Chapter 1 Product Overview Accessories ............................
  • Page 8 If the media are jammed ............................78 If the ribbon is cut off in the middle.......................... 81 If the ribbon winds become disordered........................82 Chapter 5 Appendix Specifications ............................. 86 Printer..................................86 Media ..................................88 Ribbon ..................................90 Notes on using options.............................. 91 8 CONTENTS...
  • Page 9 Product Overview Accessories ........................10 Names and functions of parts ....................11 Exterior view.................................11 Printing mechanism.............................12 Operation panel ..............................14 Compatible USB memories ..........................16...

  • Page 10: Accessories

    Accessories Confirm whether all the accessories are present. If anything is missing, contact your service representative. [ 1 ] [ 2 ] Name of part Safety Information (multi-language) Quick Setup Guide (1 set) 10 Accessories...

  • Page 11: Names And Functions Of Parts

    Names and functions of parts Exterior view [15] [10] [14] [13] [11] [12] Name of part Color LCD Displays the setting screen of each function and the status of the printer. Operation panel There are two types of lamps that indicate the status of the printer and 11 buttons that operate the printer.

  • Page 12: Printing Mechanism

    Connects peripherals. For peripheral devices connected to the extended I/O port, use devices that comply with specifications and relevant laws and regulations. Note that Toshiba Tec does not manufacture any devices for connection to the extended I/O port. Serial interface port (option) Connects RS-232C compliant communication cable.
  • Page 13 1.Product Overview Name of part Cover damper Ribbon stopper Adjusts the position of the stoppers to match the width of the ribbon to be used. High-temperature warning label Be careful of high temperatures. Print head block This unit prints on media. Beneath the print head block are temperature sensor, reflective sensor, transmissive sensor, and ribbon end sensors.

  • Page 14: Operation Panel

    1.Product Overview Operation panel [ 1 ] [ 2 ] [ 3 ] [ 4 ] [ 6 ] [ 5 ] [ 7 ] [ 9 ] [ 8 ] [ 10 ] [ 11 ] Name of part Color LCD (272 x 480 dots) Displays the status of the printer and the setting screen of each function.
  • Page 15 1.Product Overview Name of part [MODE] button  Press this button to display the menu screen.  Holding this button down for more than 3 seconds in online mode will switch to user mode. [CANCEL] button  Press this button to clear the current print job. ...

  • Page 16: Compatible Usb Memories

    1.Product Overview Compatible USB memories You can save receive buffer contents and operation log information to a USB memory. For details, refer to “Key Operation Specification”. Use a USB memory that meets the following conditions:  Integrated device with flash memory (directly connects to the USB port) ...
  • Page 17 Printer Setup Preparing to use the printer ....................20 Setup locations ..............................20 When purchasing the power cable........................22 Connecting the power cable ..........................23 Connecting to a computer...........................25 Turning the printer ON/OFF....................28 Turning on the printer ............................28 Turning off the printer ............................29 Media loading procedure....................31 Loading the media ...............................32 Loading media with the optional cutter module attached ................39 Loading the fanfold paper ...........................41...

  • Page 18: Preparing To Use The Printer

    Preparing to use the printer This section explains how to set up the printer, connect a computer, and connect the power cable. Setup locations Always ensure that at least two people are involved when relocating the printer. Attempting to relocate this printer alone can lead to injury. When relocating this printer, grasp it at the indicated area shown below.
  • Page 19 2.Printer Setup Set up the printer in a location that is flat and level, with good ventilation, and enough space to do operations. Also, provide open space around the printer as shown in the illustrations below. 376 mm (14.8") 40 mm 278 mm 58 mm 460 mm...

  • Page 20: When Purchasing The Power Cable

    2.Printer Setup When purchasing the power cable In some countries/regions, the power cable is not provided with this printer. In this case, use a power cable approved for your country/region. Power cable instructions 1. For use with 100 – 125 Vac mains power supply, select a power cable rated Min. 125 V, 10 A. 2.

  • Page 21: Connecting The Power Cable

    2.Printer Setup Connecting the power cable Use the following procedure to connect the provided power cable to an electric outlet. The power plug has a ground wire, so be sure to connect it to a ground terminal also.  Use only the AC voltage specified on the rating plate. Otherwise, it may cause fire or electric shock.
  • Page 22 2.Printer Setup Confirm that the main power switch [1] of the printer is turned off. side is off. Connect the power cable [2] to the AC power inlet [1] on the rear panel. 24 Preparing to use the printer...

  • Page 23: Connecting To A Computer

    2.Printer Setup Connecting to a computer Use the following procedure to connect to a computer. Which communications cable to use depends on the means of communicating with the computer. For details, consult with your service representative.  Connecting with a LAN cable Connect the connector of the LAN cable [2] to the LAN port [1] on the back of the printer.

  • Page 24: Connecting With A Usb Cable

    2.Printer Setup  Connecting with a USB cable Turn on the computer and start up the Windows system. Turn on the main power switch on the rear of the printer and press the POWER button on the front.  P.28 “Turning on the printer” Connect the connector of the USB cable [2] to the USB interface [1] for connecting a host computer on the back of the printer.
  • Page 25 2.Printer Setup  Connecting via wireless LAN (optional)  Before doing wireless communications, be sure to carefully read the information referenced below.  P.5 “Precautions for the handling of Wireless Communication Devices”  Check that there are no obstructions between the printer and the host. Obstructions in between them could cause poor communications.

  • Page 26: Turning The Printer On/Off

    Turning the printer ON/OFF Turn the printer on or off using the main switch at the rear and the POWER button on the front. Do not connect or disconnect the power cable to on/off the printer. This could cause malfunctions. Turning on the printer Turn on the main power switch [1] on the rear of the printer.

  • Page 27: Turning Off The Printer

    2.Printer Setup “Online” is displayed on the color LCD. The ONLINE lamp (blue) flashes for about 15 seconds, and then stays lit.  If the power does not turn on or an error message is displayed, refer to the following page. ...
  • Page 28 2.Printer Setup Press the POWER button [1] on the front of the printer. The data in memory is erased and the printer is turned off. Press the [PAUSE] or [ENTER] button.  To cancel the operation and return to the previous screen, press the [FEED] or [CANCEL] button. ...

  • Page 29: Media Loading Procedure

     Use Toshiba Tec Corporation certified genuine media. For details about ordering and preparing media, contact your service representative.  Toshiba Tec Corporation shall assume no liability for any consequences of printing by loading media other than Toshiba Tec Corporation certified ones.

  • Page 30: Loading The Media

    2.Printer Setup Loading the media  Fully open the top cover to the left. Leaving it at a halfway position could cause it to close by itself, causing injury.  Immediately after printing, do not touch the print head or its surrounding area. This could cause burns.
  • Page 31 2.Printer Setup Raise the print head block [1]. Fold down the roll media holder [1]. When replacing the media, remove the old media or its core from supply shaft [2]. Media loading procedure 33...
  • Page 32 2.Printer Setup Set the media on the supply shaft [1], and pass the media behind the media guide shaft [2]. The media path varies based on the orientation of the print side, whether it faces outward or inward. Refer to the figure below for correct media installation.
  • Page 33 2.Printer Setup Place the roll media holder [1] upright. Carefully lift the roll media holder to prevent damage to the roll media. Ensure the gap between the roll media holder and the roll media is between 0.5 mm (0.02") and 2 mm (0.08"). Loosen the thumbscrew [2] on the media guides [1] and spread them slightly wider than the width of the media.
  • Page 34 2.Printer Setup For labels, cut the base [1] straight between the labels. Lift the media sensor unit [1] and feed the media to the media outlet. Adjust the gap between the media guides [1] and the media [2] to approx. 0.5 mm (0.02"), and tighten the thumbscrew [3] to secure the media guide.
  • Page 35 2.Printer Setup Lift the lock lever [1] and move the media width detection guide [2] to align with the edge of the media. When printing on care labels (wash-resistant labels) using the care label cutter, misalignment or wrinkles may occur in the print direction due to the characteristics of the care labels. In such cases, use the media width detection guide in its fully extended position.
  • Page 36 2.Printer Setup Set the ribbon shaft fixing plate [1] and turn the head lever [2] to the “LABEL2” position to secure the print head block.  Use the printer with the head lever set to the “LABEL2” position. Printing cannot be performed properly in the “LABEL1”...

  • Page 37: Loading Media With The Optional Cutter Module Attached

    2.Printer Setup Loading media with the optional cutter module attached  Fully open the top cover to the left. Leaving it at a halfway position could cause it to close by itself, causing injury.  Immediately after printing, do not touch the print head or its surrounding area. This could cause burns.
  • Page 38 2.Printer Setup Set the ribbon shaft fixing plate [1] and turn the head lever [2] to the “LABEL2” position to secure the print head block.  Use the printer with the head lever set to the “LABEL2” position. Printing cannot be performed properly in the “LABEL1”...

  • Page 39: Loading The Fanfold Paper

    2.Printer Setup Loading the fanfold paper  Fully open the top cover to the left. Leaving it at a halfway position could cause it to close by itself, causing injury.  Immediately after printing, do not touch the print head or its surrounding area. This could cause burns.
  • Page 40 2.Printer Setup Raise the print head block [1]. Lift the media sensor unit [1]. Loosen the thumbscrews [1] on the right and left sides of the external media guide to spread it slightly wider than the width of the media. 42 Media loading procedure...
  • Page 41 2.Printer Setup Place fanfold paper [1] behind the rear of the printer and insert the end of it into the media slot under the external media guide [2].  Place the fanfold paper so that the print side will face upward. ...
  • Page 42 2.Printer Setup Adjust and tighten the left and right thumbscrews [1] of the external media guide to match the width of the media. Referring to the scale [2] on the external media guide, adjust the position of the thumbscrews [1] so that the media is located in the center of the transport path.
  • Page 43 2.Printer Setup Pass the leading edge of the media [1] between the left and right media guides [2], and feed it to the media outlet through the lower side of the print head block. For labels, cut the base [1] straight between the labels. Adjust the gap between the media guides [1] and the media [2] to approx.
  • Page 44 Lift the lock lever [1] and move the media width detection guide [2] to align with the edge of the media. Push down the lock lever [1] to lock the media width detection guide. Lower the print head block [1]. To adjust the position of the media detection sensor, refer to the following reference.
  • Page 45 2.Printer Setup Set the ribbon shaft fixing plate [1] and turn the head lever [2] to the “LABEL2” position to secure the print head block.  Use the printer with the head lever set to the “LABEL2” position. Printing cannot be performed properly in the “LABEL1”...

  • Page 46: Loading The Ribbon (Thermal Transfer Method)

    This section explains the procedure for loading a ribbon in the printer. Use a Toshiba Tec Corporation certified genuine ribbon. For details about ordering a ribbon, contact your service representative.  To print with the direct thermal method, do not load a ribbon. Printing with a ribbon loaded could damage the print head and could also cause the melted ribbon to adhere to the print head, requiring the replacement of the print head (for a fee).
  • Page 47 2.Printer Setup Fully open the top cover [1] to the left. Turn the head lever [1] to the “FREE” position. Then, gently pull the ribbon shaft fixing plate [2] downwards to the right. The ribbon shaft fixing plate may fall under its own weight, causing injury. Put your hand on the ribbon shaft fixing plate and pull it down slowly.
  • Page 48 2.Printer Setup Raise the print head block [1]. Referring to the scale [1] stamped on the ribbon shafts, adjust the ribbon stoppers [2] to match the width of the ribbon being installed. While pressing the two knobs, move the ribbon stoppers [1]. ...
  • Page 49 2.Printer Setup Insert the unused side of the ribbon [1] into the rear ribbon shaft, then slide it until it reaches the ribbon stopper [2].  When inserting the ribbon, press on its core. Applying pressure to the ribbon’s side can cause it to shift diagonally, leading to wrinkles.
  • Page 50 2.Printer Setup  Align the position of the ribbon on both the unused and take-up sides. Misalignment may cause wrinkles to form on the ribbon.  Pass the ribbon through the correct path. Lower the print head block [1] and set the ribbon shaft fixing plate [2]. 52 Loading the ribbon (thermal transfer method)
  • Page 51 Turn the ribbon shaft [1] on the take-up side clockwise to fully wind up the leader tape section (silver) [2] on the ribbon.  To avoid poor print quality, remove any slack or wrinkles from the ribbon. Ensure the print head block is lowered first;...
  • Page 52 2.Printer Setup Close the top cover [1] gently. 54 Loading the ribbon (thermal transfer method)

  • Page 53: Adjusting The Position Of The Media Detection Sensor

    2.Printer Setup Adjusting the position of the media detection sensor The printer features two media detection sensors: a transmissive sensor for detecting gaps between labels, and a reflective sensor for identifying black marks on the media’s backside. If the sensor is improperly adjusted, the printer may not feed the media, displaying an “Paper Jam ****” error message.

  • Page 54: Adjusting The Position Of The Reflective Sensor

    2.Printer Setup Manually position the media sensor [1] so that the position mark of the transmissive sensor ( [2] is reliably aligned over the gap [3]. Adjusting the position of the reflective sensor Fully open the top cover to the left. Turn the head lever to the “FREE”...

  • Page 55: Adjusting The Media Near-End Sensor

    2.Printer Setup Move the media sensor [1] by hand and align the reflective sensor [2] with the center line of the black mark [3]. Adjusting the media near-end sensor For cut or peel-off issuance with inner roll media, the (ribbon near-end/paper near-end) icon will display on the color LCD to alert you as the media approaches its end.
  • Page 56 2.Printer Setup 58 Adjusting the position of the media detection sensor...
  • Page 57 Daily Maintenance Cleaning the printer ......................58 Cover..................................58 Print head................................59 Platen unit ................................61 Media detection sensors / Ribbon end sensor ....................62 Media near-end sensor ............................64 Media housing ..............................65 Cutter module (optional).............................67 When you do not use the printer for a long period of time................67...

  • Page 58: Cleaning The Printer

    Cleaning the printer Clean the printer periodically (at each media replacement) to ensure that clear prints can always be obtained. The print head and the platen unit, in particular, can easily get dirty. Clean them with the procedure below. Do not splash water directly or clean with a cloth containing a large amount of moisture. Allowing water to enter inside the printer could cause fire and electric shock.

  • Page 59: Print Head

    3.Daily Maintenance Print head Turn off the main power switch and unplug the power cable. Fully open the top cover to the left. Turn the head lever [1] to the “FREE” position. Then, gently pull the ribbon shaft fixing plate [2] downwards to the right.
  • Page 60 3.Daily Maintenance Clean the print head (hatched portion). Clean the print head heating section [1] (hatched portion), with a head cleaner pen [2], a commercially available cotton swab, or a soft cloth containing a small amount of anhydrous ethanol. Order the separately sold head cleaner pen from your service representative. ...

  • Page 61: Platen Unit

    3.Daily Maintenance Platen unit Turn off the main power switch and unplug the power cable. Fully open the top cover to the left. Turn the head lever [1] to the “FREE” position. Then, gently pull the ribbon shaft fixing plate [2] downwards to the right.

  • Page 62: Media Detection Sensors / Ribbon End Sensor

    3.Daily Maintenance Wipe dirt off the platen unit [1] a soft cloth containing a small amount of anhydrous ethanol. Conduct cleaning for each roll of media.  Do not damage the platen unit with a sharp object. This could cause print failures and malfunctions. ...
  • Page 63 3.Daily Maintenance Raise the print head block [1] and remove the media or ribbon. Clean the media detection sensor [1] and the ribbon end sensor [2] with a soft cloth containing a small amount of anhydrous ethanol or a cotton swab. Wipe paper powder and dust with a dry, soft cloth.

  • Page 64: Media Near-End Sensor

    3.Daily Maintenance Media near-end sensor Turn off the main power switch and unplug the power cable. Fully open the top cover to the left. Wipe the media near-end sensor [1] with a soft cloth containing a small amount of anhydrous ethanol or a cotton swab.

  • Page 65: Media Housing

    3.Daily Maintenance Media housing Turn off the main power switch and unplug the power cable. Fully open the top cover to the left. Turn the head lever [1] to the “FREE” position. Then, gently pull the ribbon shaft fixing plate [2] downwards to the right.
  • Page 66 3.Daily Maintenance Clean the pinch roller [1] and feed roller [2] with a soft cloth containing a small amount of anhydrous ethanol. Wipe paper powder and dust off the media housing with a dry, soft cloth. If the dirt cannot be removed, wipe the dirt off with a soft cloth moistened with a neutral detergent diluted with water.

  • Page 67: Cutter Module (Optional)

    3.Daily Maintenance Cutter module (optional) Do not touch sharp cutter blade. This could cause injury. Turn off the main power switch and unplug the power cable. Fully open the top cover to the left. Loosen screws [1] and open cutter cover [2]. Wipe paper powder and dust with a dry, soft cloth.
  • Page 68 3.Daily Maintenance 68 Cleaning the printer...

  • Page 69: Troubleshooting

    Troubleshooting Troubleshooting.......................70 Error messages..............................70 If the printer does not operate correctly ......................75 If the media are jammed .............................78 If the ribbon is cut off in the middle........................81 If the ribbon winds become disordered......................82...

  • Page 70: Error Messages

    Troubleshooting If any problems occur during use, check the following. If the printer is not restored to normal, turn off the main power switch, unplug the power cable from the electric outlet, and consult with your service representative. Error messages If an error message appears, take action according to the details of the error.
  • Page 71 4.Troubleshooting Display Cause Action No Paper The media were used up. Load new media and press the [RESTART] button to continue printing where it left off.  P.31 “Media loading procedure” No media are loaded. Load the media correctly.  P.31 “Media loading procedure” The detection level of the media Adjust the sensor by using the media used.
  • Page 72 4.Troubleshooting Display Cause Action Format Error Check the An error occurred in formatting the Turn off the power and then on again and settings. registration memory (USB memory or retry formatting. flash ROM on the CPU board). Check the details of the command to register. If the problem recurs, turn off the power and contact the service personnel.
  • Page 73 4.Troubleshooting Display Cause Action System Error ## An operation such as the following was Turn off the power and then on again. (##: 2-digit number) performed: If the problem recurs, turn off the power and contact the service personnel.  Fetch an instruction from an odd- numbered address ...

  • Page 74: Syntax Error

    4.Troubleshooting  Syntax error If a command sent from the computer has an error, 42 bytes are displayed on the LCD, starting with the command code of the command that has an error. [LF], [NUL], and any portion that exceeds 42 bytes are not displayed. Syntax error display examples [ 1 ] Syntax error...

  • Page 75: If The Printer Does Not Operate Correctly

    4.Troubleshooting If the printer does not operate correctly Symptom Cause Action The power is not supplied The power cable is disconnected from Insert the power cable into the AC power inlet even though the power is the printer. securely.  P.23 “Connecting the power cable” turned on.
  • Page 76 4.Troubleshooting Symptom Cause Action Printing is blurry. Toshiba Tec Corporation certified Replace the media with Toshiba Tec media are not used. Corporation certified ones.  P.88 “Media” Toshiba Tec Corporation certified Replace the ribbon with Toshiba Tec ribbon is not used.
  • Page 77 The label is not peeled off. Toshiba Tec Corporation certified Replace the media with Toshiba Tec (When the peel-off module media are not used. Corporation certified ones.  P.88 “Media”...

  • Page 78: If The Media Are Jammed

    4.Troubleshooting Symptom Cause Action A wireless LAN Wireless LAN communication is After turning on the power, start communication error unavailable immediately after the communication at least 10 seconds after the occurs immediately after power is turned on. ONLINE lamp turns on. the power is turned on.
  • Page 79 4.Troubleshooting Turn the head lever [1] to the “FREE” position. Then, gently pull the ribbon shaft fixing plate [2] downwards to the right. The ribbon shaft fixing plate may fall under its own weight, causing injury. Put your hand on the ribbon shaft fixing plate and pull it down slowly.
  • Page 80 4.Troubleshooting Lower the print head block [1]. Set the ribbon shaft fixing plate [1] and turn the head lever [2] to the “LABEL2” position to secure the print head block. Close the top cover gently. Turn on the power to resume printing. ...

  • Page 81: If The Ribbon Is Cut Off In The Middle

    4.Troubleshooting If the ribbon is cut off in the middle If the ribbon is cut off in the middle, repair it with the procedure below. (Temporary measure) If you have a new ribbon, replace the ribbon with that one.  P.48 “Loading the ribbon (thermal transfer method)” ...

  • Page 82: If The Ribbon Winds Become Disordered

    4.Troubleshooting Cut the cut off portions neatly. Overlay one portion on the other, aligning them horizontally, and fasten the overlay firmly with adhesive cellophane tape. Make two or three winds of the ribbon around the take-up (used ribbon) side roll. Reload the ribbon properly.
  • Page 83 4.Troubleshooting Do not pull the ribbon strongly. Pulling it more strongly than necessary could cut off the ribbon. If the ribbon cannot be wound properly, cut off the used ribbon roll. Remove the used ribbon roll from the take-up side core. Attach the supply side (unused) ribbon [2] to the take-up side core [1] firmly with adhesive cellophane tape [3].
  • Page 84 4.Troubleshooting 84 Troubleshooting...
  • Page 85 Appendix Specifications ........................86 Printer...................................86 Media ..................................88 Ribbon ..................................90 Notes on using options............................91...

  • Page 86: Specifications

    Specifications Printer Item Description Model BX430T-HS02-QM-S Power supply AC100–240 V, 50/60 Hz Power consumption During printing: 110 W (at a print rate of 20 %, slant line print format) During standby: 9 W Operating temperature range 5 to 40 °C (41 to 104 °F) 20 to 35 °C (68 to 95 °F) (when using the care label cutter module)
  • Page 87 5.Appendix Item Description Options (separately sold) Disc cutter module (BX204-QM-S) Care label cutter module (BX204-C-QM-S) Peel-off module (BX904-H-QM-S) High-precision peel-off module (BX904-HH-QM-S) Real time clock (BX704-RTC-QM-S) External media guide module (BX904-FF-QM-S) Wireless communication module (BX700-WLBT-QM-S) Serial I/F board (B-EX700-RS-QM-R) External I/O board (BX700-IO-QM-S) *1 Depending on the combination of supplies used, the print speed may be restricted.

  • Page 88: Media

    Media include labels, tags, and receipts of the heat direct coloring type. Care labels (wash-resistant labels) can also be used. Use Toshiba Tec Corporation certified genuine media. For details about ordering and preparing media, contact your service representative. Unit: mm (inch)
  • Page 89 5.Appendix  Notes for media  If the tail end of the media is fastened to the core with tape or glue, the load on the media could fluctuate at the moment the tail end is peeled off. This could cause uneven transfer, having an impact on printing. Of particular note is that in that event, the printed barcodes or 2 dimensional codes could become unreadable.

  • Page 90: Ribbon

    Winding method Outer roll  To ensure print quality and print head life use only Toshiba Tec specified ribbons.  Select a ribbon that matches the width of your media (base). A ribbon that is too narrow reduces the printable area, while one that is too wide can lead to wrinkling.

  • Page 91: Notes On Using Options

    5.Appendix Notes on using options Be sure to turn off the main power switch and unplug the power plug from the wall outlet before installing the options. Incorporating an option with the power on could cause fire, electric shock, and injury. To protect the electric circuit inside the printer, connect and disconnect cables at least 1 minute after turning off the power of the printer.
  • Page 92 5.Appendix 92 Specifications...
  • Page 93 BX430T-HS02-QM-S...
  • Page 94 BARCODE PRINTERS Owner’s Manual BX430 T-HS 2 -QM S 1-11-1, OSAKI, SHINAGAWA-KU, TOKYO, 141-8562, JAPAN BU24002400-EN R241120B6200-TTEC © 2025 Toshiba Tec Corporation All rights reserved Ver00 F 2025-03...
