- Page 1 Addressable Power Supply AMPS-24/E-S Manual Document 51907C 9/09/2009 Rev: P/N 51907C:C ECN 09-548...
-
Page 2: Fire Alarm System Limitations
Fire Alarm System Limitations While a fire alarm system may lower insurance rates, it is not a substitute for fire insurance! An automatic fire alarm system—typically made up of Heat detectors do not sense particles of combustion and smoke detectors, heat detectors, manual pull stations, audible alarm only when heat on their sensors increases at a predeter- warning devices, and a fire alarm control panel with remote mined rate or reaches a predetermined level. -
Page 3: Installation Precautions
HARSH™, NIS™, Notifier Integrated Systems™, and NOTI•FIRE•NET™ are all trademarks; and Acclimate® Plus, FlashScan®, NION®, NOTIFIER®, ONYX®, ONYXWorks®, UniNet®, VeriFire®, and VIEW® are all registered trademarks of Honeywell International Inc. Echelon® is a registered trademark and LonWorks™ is a trademark of Echelon Corporation. ARCNET® is a registered trademark of Datapoint Corporation. Microsoft® and Windows® are registered trademarks of the Microsoft Corporation. -
Page 4: Software Downloads
Brief description of content you think should be improved or corrected • Your suggestion for how to correct/improve documentation Send email messages to: FireSystems.TechPubs@honeywell.com Please note this email address is for documentation feedback only. If you have any technical issues, please contact Technical Services. AMPS-24 Manual — P/N 51907C:C 9/09/2009... -
Page 5: Table Of Contents
Table of Contents Section 1: Introduction......................6 1.1: Features................................6 1.2: Specifications..............................6 1.3: Installation Standards and Codes........................7 1.3.1: UL 9th Edition Compliance.........................7 1.4: Related Documentation ..........................8 1.5: Notes, Cautions, and Warnings........................8 1.6: Board Layout ..............................9 1.7: LED Indicators.............................10 Section 2: Installation......................12 2.1: In a CAB-4 Series Backbox.........................12 2.2: In a BB-25 Cabinet ............................13 2.3: In a BB-100 Cabinet ...........................13... -
Page 6: Section 1: Introduction
Section 1: Introduction The AMPS-24/E is an addressable power supply and battery charger with one 5VDC and two 24 VDC outputs. It operates in FlashScan or CLIP (Classic Loop Interface Protocol) mode. 1.1 Features • Addressable by any CLIP or FlashScan Fire Alarm Control Panel (FACP) •... -
Page 7: Installation Standards And Codes
Installation Standards and Codes Introduction 1.3 Installation Standards and Codes The AMPS-24/E complies with the following standards: NFPA 72 National Fire Alarm Code Underwriters Laboratories: • UL 864 Standard for Control Units and Accessories for Fire Alarm Systems Underwriters Laboratories of Canada (ULC): •... -
Page 8: Related Documentation
Introduction Related Documentation 1.4 Related Documentation To obtain a complete understanding of specific features of the AMPS-24, or to become familiar with functions in general, make use of the documentation listed in Table 1.1. Title Document Number NFS-3030 Installation Manual 51330 NFS-3030 Operation Manual 51344... -
Page 9: Board Layout
Board Layout Introduction 1.6 Board Layout The AMPS-24 board layout is illustrated in Figure 1.1. Figure 1.2 illustrates the positions of the LEDs. Slider Switch Rotary Switch See Figure 3.2 See Figure 3.2 Battery Fuse Charger Selection Switch See Figure 2.15 –... -
Page 10: Led Indicators
Introduction LED Indicators 1.7 LED Indicators UC FAILURE SLCRXA SLCTXA TRBL BAT/CHG ACCESSORIES 24VPANEL FAULT Figure 1.2 Locations of LED Indicators There are nine LEDs that indicate various conditions and troubles. The following table lists and describes each. Reference LED Name Color Description LED9... - Page 11 LED Indicators Introduction Reference LED Name Color Description LED6 FAIL Yellow Illuminates if the microcontroller fails. LED5 Green Blinks when data is received from the SLC. LED7 Green Blinks when data is transmitted to the SLC. Table 1.2 LED Indicators AMPS-24 Manual —...
-
Page 12: Section 2: Installation
Section 2: Installation WARNING: High Voltages Present! Use extreme caution when working with the AMPS-24. High voltage and AC line-connected circuits are present in this power supply. Turn off and remove all power sources. To reduce the risk of electric shock, make sure to properly ground the AMPS-24. -
Page 13: In A Bb-25 Cabinet
In a BB-25 Cabinet Installation 2.2 In a BB-25 Cabinet The AMPS-24 mounts in the left side of a BB-25 cabinet. Two 26 amp-hour batteries fit into the right side of the cabinet. A BB-100 or BB-200 cabinet is required for batteries larger than 26 amp- hour. -
Page 14: In A Bb-200 Cabinet
Installation In a BB-200 Cabinet 2.4 In a BB-200 Cabinet Fasten the AMPS-24 chassis to the backbox using the four supplied keps nuts at these positions. Figure 2.4 BB-200 Mounting The AMPS-24 mounts in a BB-200 cabinet with four 100 amp-hour batteries (two on the top shelf and two on the bottom). -
Page 15: Wiring
Wiring Installation 2.5 Wiring The terminal block and pin connections are illustrated in Figure 1.1. Power-limited wiring must remain separated from nonpower-limited wiring by at least 0.25 in. (6.4 mm), and must enter an enclosure through different knockouts. Install tie wraps and adhesive squares to secure the wiring. - Page 16 Installation Wiring The BB-100 cabinet must TB3: AC Primary Power Wiring - be located less than 20 feet Nonpower-limited and supervised from the enclosure housing the control panel and all connections must be contained in conduit. Grounding Wire TB4,TB5: Nonpower-limited and supervised TB1: SLC Circuit Wiring - Power-limited and supervised...
-
Page 17: Connecting The Power Cables
Connecting the Power Cables Installation 2.6 Connecting the Power Cables WARNING: Risk of electrical shock! Remove all power sources to equipment while connecting electrical components. Leave the external, main power breaker OFF until installation of the entire system is complete. WARNING: Risk of equipment damage! Several sources of power can be connected to the control panel and/or power supply. -
Page 18: 3: Connecting To The Slc
Installation Connecting the Power Cables 24V — Red Wire COM — Black Wire 485+ — Brown Wire 485– — Orange Wire P/N 75637 only COM — Black Wire 24V — Red Wire Figure 2.9 Connecting to the Panel Output TB2 2.6.3 Connecting to the SLC TB1 - Supervised and power-limited. -
Page 19: 5: Connecting The Power Supply To Ac Power
Connecting the Power Cables Installation Refer to the Device Compatibility Document for compatible devices and notification appliances. COM — Green Wire 24V — Brown Wire COM — Black Wire 5V — Red Wire Figure 2.11 Connecting to the Accessories Output TB6 2.6.5 Connecting the Power Supply to AC Power The AMPS-24 requires connection to a separate dedicated AC branch circuit. -
Page 20: Installing And Connecting The Batteries
Installation Installing and Connecting the Batteries Snap-on cover WARNING: High Voltage! Install the snap-on cover for TB3 after wiring. Refer to Figure 2.13 for cover installation. Press fit the snap-on cover over TB3 after AC power has been wired. Figure 2.13 Installing the TB3 Snap-on Cover 2.7 Installing and Connecting the Batteries WARNING: Risk of severe burns! -
Page 21: 1: Setting The Charger Selection Switch (Sw4)
Installing and Connecting the Batteries Installation 2.7.1 Setting the Charger Selection Switch (SW4) The AMPS-24 battery charger will charge 26 to 200 AH lead-acid batteries. The Charger Selection Switch, SW4, selects the appropriate battery charger size for the system’s battery capacity from two settings: (2.0 A) or (5.0 A). -
Page 22: 3: Connecting The Power Supply To Four Batteries
Installation Installing and Connecting the Batteries To determine battery requirements, refer to Section 4 of this manual. BATT OUT + BATT IN + BATT OUT – BATT IN – Figure 2.16 Connecting Two Batteries to the Power Supply 2.7.3 Connecting the Power Supply to Four Batteries: Set the Charger Selection Switch, SW4, to the appropriate battery charger size for the system’s battery capacity. -
Page 23: 4: Connecting Multiple Power Supplies (Separate Batteries)
Installing and Connecting the Batteries Installation 2.7.4 Connecting Multiple Power Supplies (Separate Batteries) Follow these guidelines when connecting multiple power supplies: • Disable Ground Fault detection. See Figure 1.1 on page 9. Do not disable ground fault detection on the NFS2-3030’s main power supply! •... -
Page 24: 5: Connecting Multiple Power Supplies (One Set Of Batteries)
Installation Installing and Connecting the Batteries 2.7.5 Connecting Multiple Power Supplies (One Set of Batteries) Certain system designs may require connecting multiple power supplies to one set of batteries. Follow these guidelines when connecting multiple power supplies: • For proper supervision, enable only the last charger on the wiring circuit. Disable all other chargers. -
Page 25: Section 3: Configuring The Amps-24
Section 3: Configuring the AMPS-24 3.1 DIP Switch Configuration Program the AMPS-24 by configuring the DIP switch, SW1. Table 3.1 describes how to configure the AMPS-24 DIP Switch settings. When the AMPS-24 is mounted in a BB-25 or a CAB-4 Series cabinet, the DIP switch is located on the board to the left of the battery fuse and above the metal case which covers the bottom half of the power supply. -
Page 26: Slc Addressing
Configuring the AMPS-24 SLC Addressing Switch 1.1, 1.2 1.1 OFF, 1.2 OFF = US AC Delay OFF 1.1 OFF, 1.2 ON = US 8 hour AC Delay 1.1 ON, 1.2 OFF = US 16 hour AC Delay 1.1 ON, 1.2 ON = Trouble Reporting (4 Point) Factory Set to “OFF”... -
Page 27: 2: Setting The Base Address (Slc Enabled)
SLC Addressing Configuring the AMPS-24 Four Point Four Point Trouble Trouble Reporting Trouble Reporting AMPS-24 Reporting † SELECTED SELECTED Addresses NOT SELECTED Address (SW1.1 ON, SW1.2 ON (SW1.1 ON, SW1.2 ON SW 1.7 ON) SW1.7 OFF) ✔ ✔ ‡ Monitor General ✔... -
Page 28: Configuring The Network Annunciator
Configuring the AMPS-24 Configuring the Network Annunciator Use the slider switch, SW3, to further define the SLC base address. While an address’ decade is defined by the rotary switch, the slider determines whether the base address (B) will end in a zero or a five. -
Page 29: 2: Display
Configuring the FACP Configuring the AMPS-24 3.3.2 Display When the power supply is configured for Trouble Reporting, the NCA-2 displays a system trouble for each specific trouble message for each AMPS-24. Four Point Trouble Reporting must be selected for proper AC Fail reporting. See Sections 3.1 and 3.2 for further information CAUTION: Trouble Reporting must be selected when an AMPS-24 is connected to an NCA-2. -
Page 30: Section 4: Power Supply Calculations
Section 4: Power Supply Calculations Calculations must be done to determine standby and alarm DC current loads. Ampere-hour requirements must be calculated as well to determine battery size. The AMPS-24 provides filtered 24VDC (nominal) power that may be used for operating external devices. -
Page 31: 2: Calculation For Main Supply Current
Calculating the System Current Draws Power Supply Calculations 4.1.2 Calculation for Main Supply Current Calculation Column 1 Calculation Column 2 Calculation Column 3 Quantities Primary, Non-Fire Alarm Primary, Fire Alarm Secondary, Non-Fire Alarm Current (amps) Current (amps) Current (amps) Total on: Total on: Total on: X [current... -
Page 32: 3: Calculating The Maximum Secondary Power Non-Fire Alarm Current Draw
Power Supply Calculations Calculating the System Current Draws 4.1.3 Calculating the Maximum Secondary Power Non-Fire Alarm Current Draw Use the table below to determine the maximum current requirements of the secondary power source during non-fire alarm conditions. The result obtained is the amount of current that the batteries must be able to supply to the fire alarm system. -
Page 33: Calculating The Battery Requirements
Calculating the Battery Requirements Power Supply Calculations 4.2 Calculating the Battery Requirements 4.2.1 Calculating the Battery Capacity Use this table to determine the battery capacity needed for the system: Current (amps) Time (hours) _________AH Secondary Non-Fire Required Secondary Non-Fire Alarm Alarm Current (from Standby Time (24 or 60 hours) Table 4.2) -
Page 34: 2: Calculating The Battery Size
Power Supply Calculations Calculating the Battery Requirements 4.2.2 Calculating the Battery Size Use this table to choose the battery size, in amp-hours, needed to support the fire alarm system. The AMPS-24 can charge batteries from 26 to 200 AH. Select batteries that meet or exceed the Total Amp-Hours calculated in Table 4.4 and that are within the acceptable battery charger range. -
Page 35: Appendix A: Compatibility With Other Systems
A.1.1 Power Supply Calculations Table A.1 on the following page provides Honeywell-specific current draw calculations for devices powered by the AMPS-24. This table replaces Table 4.1 on page 31 when AMPS-24 is used to power XLS3000 systems. - Page 36 Compatibility with Other Systems XLS3000 Calculation Column 1 Calculation Column 2 Calculation Column 3 Quantities Primary, Non-Fire Alarm Primary, Fire Alarm Secondary, Non-Fire Alarm Current (amps) Current (amps) Current (amps) Total on: Total on: Total on: X [current X [current X [current draw]= draw]=...
-
Page 37: Index
Index Numerics 24VDC 30 Electrical connections 17 unsupervised output 17 485 18 and address consumption 26 FlashScan 6 AC loss detection, delay 6 Ground fault detection 9 DIP Switch settings 26 grounding the AMPS-24 12 Address block 26 address block 26 address decade 27 Addressing 26 Installation... - Page 38 R–X Index Power specifications 17 – Power supply calculations 30 see also XLS3000 Programming, AMPS-24 see also Configuring the AMPS-24 Rotary Switch 27 setting address decade 27 Selectable charger current see also Charge Selection Switch self-threading screws 12 SLC 18 Address Selection 28 determining address block size 26 Wiring 17...
-
Page 39: Manufacturer Warranties And Limitation Of Liability
Manufacturer Warranties and Limitation of Liability Manufacturer Warranties. Subject to the limitations set forth herein, Manufacturer warrants that the Products manufactured by it in its Northford, Connecticut facility and sold by it to its authorized Distributors shall be free, under normal use and service, from defects in material and workmanship for a period of thirty six months (36) months from the date of manufacture (effective Jan. - Page 40 World Headquarters NOTIFIER is a Honeywell company. 12 Clintonville Road Northford, CT 06472-1653 USA 203-484-7161 fax 203-484-7118 www.notifier.com...
