- Page 1 Remote Display Annunciator Instruction Manual Document LS10310-000NF-E Rev: A 7/28/2021 ECN: 00003467...
- Page 2 Fire Alarm & Emergency Communication System Limitations While a life safety system may lower insurance rates, it is not a substitute for life and property insurance! An automatic fire alarm system—typically made up of smoke IMPORTANT! Smoke detectors must be installed in the same room detectors, heat detectors, manual pull stations, audible warning as the control panel and in rooms used by the system for the devices, and a fire alarm control panel (FACP) with remote...
-
Page 3: Installation Precautions
HARSH™, NIS™, and NOTI•FIRE•NET™ are all trademarks; and Acclimate® Plus™, eVance®, FlashScan®, FAAST Fire Alarm Aspiration Sensing Technology®, Honeywell®, INSPIRE®, Intelligent FAAST®, NOTIFIER®, ONYX®, ONYXWorks®, SWIFT®, VeriFire®, and VIEW® are all registered trademarks of Honeywell International Inc. Microsoft® and Windows® are registered trademarks of the Microsoft Corporation. Chrome™ and Google™ are trademarks of Google Inc. Firefox® is a registered trademark of The Mozilla Foundation. -
Page 4: Software Downloads
Your suggestion for how to correct/improve documentation Send email messages to: FireSystems.TechPubs@honeywell.com Please note this email address is for documentation feedback only. If you have any technical issues, please contact Technical Services. This symbol (shown left) on the product(s) and / or accompanying documents means that used electrical and electronic products should not be mixed with general household waste. -
Page 5: Table Of Contents
Table of Contents Section 1: Product Overview............................7 1.1: General..........................................7 1.2: Limits ..........................................7 1.3: Wire Runs ..........................................7 1.4: AIO Wiring Specifications....................................7 1.5: Annunciator Power Requirements & Electrical Ratings ...........................7 Section 2: Installation and Configuration ........................9 2.1: Installation Checklist ......................................9 2.2: Connectors and Switches ....................................9 2.3: Mount the 3-Gang Electrical Box and Install Annunciator ..........................10 2.4: Shielding the AIO Circuit ....................................10... - Page 6 It is imperative that the installer understand the requirements of the Authority Having Jurisdiction (AHJ) and be familiar with the standards set forth by the following regulatory agencies: • Underwriters Laboratories • National Fire Protection Association Before proceeding, the installer should be familiar with the following documents. NFPA Standards NFPA 72 National Fire Alarm Code NFPA 70 National Electrical Code...
-
Page 7: Section 1: Product Overview
Section 1: Product Overview 1.1 General The RLD annunciator provides the N16 FACP (fire alarm control panel) or NCD (Network Control Display) with remote, serially-connected remote display. A 5" touch screen display will provide an alert bar providing indication and counters for the number of events in the system, an event display area will provide a scrollable display that shows two events simultaneously, and scrollable up to 50 of the highest priority events in the system. - Page 8 Product Overview Annunciator Power Requirements & Electrical Ratings • Data Communications Port: AIO operating for the local AIO at 115.2 Kbps (must be power-limited) and for the main AIO at 57.6Kbps (must be power limited). Backlight set in range Backlight set in range Condition of 1% –...
-
Page 9: Section 2: Installation And Configuration
Section 2: Installation and Configuration 2.1 Installation Checklist Mount and ground the RLD in a standard 3 gang electrical box Connect shield for AIO circuit (Section 2.4). Connect Earth Ground to a mounting screw on the backbox or cabinet (Section 2.5). Make all electrical connections: –... -
Page 10: Mount The 3-Gang Electrical Box And Install Annunciator
Installation and Configuration Mount the 3-Gang Electrical Box and Install Annunciator 2.3 Mount the 3-Gang Electrical Box and Install Annunciator The RLD annunciators mounts on a standard 3 gang electrical box. Figure 2.1 Mounting RLD 2.4 Shielding the AIO Circuit The AIO circuit must be wired using a twisted pair cable having a characteristic impedance of 120 ohms, +/- 20%. -
Page 11: End-Of-Line Resistors
End-of-Line Resistors Installation and Configuration Reference P2 Communications AIO - (AIO to FACP) To next RLD in sequence AIO + Reference AIO - AIO + P4 Power Connection to FACP optional local earth Earth reference (cold water pipe) Ground To next RLD in sequence +24VDC Ground +24VDC... -
Page 12: Setting Addresses And Switches
Installation and Configuration Setting Addresses and Switches • Viewing/changing a module already in use - Section 3.4.4, “Configuration Menu”. 2.8 Setting Addresses and Switches 2.8.1 Addressing the RLD Set the address with the on screen menu. This address must match what is entered into VeriFire Tools programming. The system supports up to 10 router devices connected to the control panel using up to 10 unique addresses. -
Page 13: Section 3: Programming And Operations
Section 3: Programming and Operations 3.1 Capabilities The RLD will display event status and event counters on the Alert bar with the 4 configurable mapped event types plus a fifth category “other” to capture the event types not directly mapped. The RLD will display all events related to the mapped zone(s) up to 50 total events. -
Page 14: 2: General Settings For Rld
Programming and Operations Programming the N16/NCD for Remote Annunciation 3.2.2 General Settings for RLD On the VeriFire Tools General Settings for RLD, configure option as described below. Primary Label - 40 character text entry that is used as a label for the annunciator address. Language - Set to English for RLD v.1.0. -
Page 15: 3: Alert Bar Settings For Rld
Programming the N16/NCD for Remote Annunciation Programming and Operations PMB Power Supply Enabled - Select this box if the power supply node address is an NCD or N16 with an addressable power main board (PMB). PMB Address - Provide the specific address of the PMB that is providing power to the RLD for appropriate operation for power save and power indication. -
Page 16: 5: Custom Action Settings For Rld
Programming and Operations Programming the N16/NCD for Remote Annunciation 3.2.5 Custom Action Settings for RLD Program 6 custom action buttons that will be accessible to operator without panel login. NOTE: If a Custom Action Button programmed to manually control a life safety function, there must be a visual indicator programmed on an ACM-30 at the main operator to interface, to show the function's status. -
Page 17: 6: Zone Map Settings For Rld
Event Priority Programming and Operations 3.2.6 Zone Map Settings for RLD The RLD may be configured to match the NCD/N16 zone map or to operate with a subset of the NCD/N16 zone map for event filtering based on primary zone assignment. When configured for zone filtering, only the local node may be selected in the node map. 3.3 Event Priority The panel will use the highest priority event in the system that is mapped to that annunciator to appropriately control the audible pattern played by that annunciator. -
Page 18: 1: System Startup
Programming and Operations LED and Keypad Functions 3.4.1 System Startup On initial startup, RLD will display annunciator version and model number. Enter the address and termination status for the unit. Address. Press the touch point for ADDRESS 1 to ADDRESS 10. The unit will save the information and move to the next screen. Each RLD requires a unique address, and the addressing order is independent of the order in which the units are wired on the bus. -
Page 19: 3: Accessing System Settings
LED and Keypad Functions Programming and Operations 3.4.3 Accessing System Settings Turn on the keyswitch to access Custom Actions and Configuration. Home Custom Actions Configuration View programmable buttons Address Settings, LCD Backlight, Firmware Update, Statistical Info, etc. Custom Action Screen Displays label assigned in VeriFire Tools to represent map points. -
Page 20: 4: Configuration Menu
Programming and Operations LED and Keypad Functions 3.4.4 Configuration Menu Access address settings, firmware updates, statistical info, and user options. 07 02 2020 4:07 PM Configuration Address Settings Firmware Update Backlight Intensity Termination Resistor Local Event Piezo Upload Custom Image Test/Diagnostics Version Information Statistical Information... -
Page 21: 6: Event Screens
LED and Keypad Functions Programming and Operations 3.4.6 Event Screens Fire Alarm Page 2 of 3 07 02 2020 04:07 PM Key Switch : Unlocked Key Switch : Unlocked ALARMS A A A Fire Alarm ALARMS Air Reference | Custom Label Language One (RLD) from N52 Z80 | primary zone Label receive N52 L1 M1 13 04 2021 | 12:09 PM... - Page 22 Programming and Operations LED and Keypad Functions Security Alarm Page 2 of 3 07 02 2020 16:00 Key Switch : Unlocked SECURITY ALARMS A A A Security Alarm (Life) ALARMS Heat (fixed) | Custom Label Language One (RLD) from N52 Z80 | primary zone Label receive 13 04 2021 | 12:57 N52 L1 M1 CO PRE ALARM...
- Page 23 LED and Keypad Functions Programming and Operations Disable Alarm Page 2 of 3 02 07 2020 16:08 Key Switch : Unlocked Key Switch : Unlocked DISABLE A A A Disable Active ALARMS Sup L (Duct I) | Custom Label Language One (RLD) from N32 L1M1 | primary zone Label receive 04 13 2021 | 12:47 N32 Z80...
-
Page 24: 7: Local Trouble
Programming and Operations LED and Keypad Functions Other Alarm Page 2 of 3 07 02 2020 16:04 Key Switch : Unlocked Key Switch : Unlocked Other Events A A A DISABLED ALARMS Heat (fixed) | Custom Label Language One (RLD) from N52 Z80 | primary zone Label receive 13 04 2021 | 13:05 N52 L1 M1... -
Page 25: Piezo Enable
Piezo Enable Programming and Operations 3.5 Piezo Enable To enable the piezo, configure RLD for supervision using VeriFire Tools. The switch on the unit is a local disconnect. Event Piezo Frequency Fire Alarm Steady On Security 8 Hz Crit Proc 2 Hz CO Alarm 2 Hz... - Page 26 Notes RLD Manual — P/N LS10310-000NF-E:A 7/28/2021...
-
Page 27: Manufacturer Warranties And Limitation Of Liability
Manufacturer Warranties and Limitation of Liability Manufacturer Warranties. Subject to the limitations set forth herein, Manufacturer warrants that the Products manufactured by it in its Northford, Connecticut facility and sold by it to its authorized Distributors shall be free, under normal use and service, from defects in material and workmanship for a period of thirty six months (36) months from the date of manufacture (effective Jan. - Page 28 NOTIFIER 12 Clintonville Road Northford, CT 06472-1610 USA 203-484-7161 www.notifier.com...
