- Page 1 MP465 Panel Mount Controller for Cut-to-Length Machines Technical Reference & Installation Guide...
- Page 2 Copyright 2012 − AMS Controls, Inc. All rights reserved. The information contained in this document is proprietary to AMS Controls, Inc., and is not to be reproduced in any form without the specific written authorization of AMS Controls, Inc.
-
Page 3: Table Of Contents
MP465 Technical Reference & Installation Guide Table of Contents TABLE OF CONTENTS ......................I CHAPTER 1: INTRODUCTION..................... 3 ..........................3 VERVIEW Features ...........................3 CHAPTER 2: INSTALLATION SPECIFICS ................ 4 ......................4 ECHANICAL ETAILS Dimensional Drawing ......................4 Cutout Drawing ........................5 ........................ 5... -
Page 5: Chapter 1: Introduction
MP450S Operator Manual Chapter 1: Introduction Overview The AMS Controls MP465 is an industrial controller used to control cut-to-length machinery. Figure 1 shows the front panel of the MP465. Figure 1: AMS Controls MP465 Controller Features The MP465 controller’s features include: •... -
Page 6: Chapter 2: Installation Specifics
MP465 Technical Reference & Installation Guide Chapter 2: Installation Specifics Mechanical Details Dimensional Drawing Figure 2: MP465 Dimensional Drawing... -
Page 7: Cutout Drawing
MP465 Technical Reference & Installation Guide Cutout Drawing Figure 3: MP465 Cutout Drawing Electrical Details Specifications Power 24VDC (+/- 20%) Supply voltage Supply current 400mA + Outputs Max. inrush current... -
Page 8: Inputs
MP465 Technical Reference & Installation Guide Inputs Sourcing Type Voltage 12VDC or 24VDC 1.8 KΩ Input resistance “ON” voltage 13.4 VDC Optical Isolation 2500V Outputs Sourcing Type Voltage 12VDC or 24 VDC Continuous Current Optical Isolation 2500V Encoder Supply voltage... -
Page 9: Pin Assignments And Descriptions
MP465 Technical Reference & Installation Guide Pin Assignments and Descriptions J301 Function Assignment/Notes I/O Ground 6A maximum Output 1 Fast Output 2 Shear Down Output 3 Reverse Output 4 Shear Up Output 5 Slow I/O Ground 6A maximum I/O V (+24V) -
Page 10: J401
MP465 Technical Reference & Installation Guide J401 Function Notes RS485 2B+ Unused RS485 2A- RS485 1A+ For firmware updates RS485 1B- Encoder A+ Encoder A- Encoder B+ Encoder B- Encoder +5V Encoder Ground Power +VDC Power Ground Power switch 20A maximum... -
Page 11: Mp465 Interface Drawing
MP465 Technical Reference & Installation Guide MP465 Interface Drawing... -
Page 12: Software Configuration
• Use the Up and Down soft keys (white keys just below the display, see Figure 5) to navigate from item to item. Figure 4: AMS Controls MP465 Controller front panel (Up and Down Soft Keys highlighted) • Press a number key to change a selected setting temporarily, causing the field to blink. -
Page 13: Setup Parameters
MP465 Technical Reference & Installation Guide Setup Parameters Note: These parameters retain their value while the machine is powered off. Display Units The display unit setting enables the operator to choose between viewing the part length in either feet and inches or metric millimeters. - Page 14 MP465 Technical Reference & Installation Guide displayed. Then, at the prompt “Enter Code to Clear Total,” enter 1984 and press [Enter] . The total will reset to zero.
-
Page 15: Chapter 3: Operational Reference
MP465 Technical Reference & Installation Guide Chapter 3: Operational Reference Note: For details on operating a machine with the MP465 Controller, see the MP465 Operator Manual. Positioning Control Speed Logic Table Output Function Slow Fast Reverse Jog Forward Jog Reverse... -
Page 16: Speed Diagram For Two-Speed Positioning
The material then decelerates to a stop and is hopefully within the desired tolerance. The MP465 constantly monitors the deceleration rate of the machine and makes slight adjustments to the time at which the motion output is turned off. This constant monitoring and adjustment is an important feature for machines that have stopping dynamics that change over time.
