INSTRUCTION
MANUAL
2-Door Elevated
Storage Cabinet
SKY9541 + SKY9542 + SKY9543
Ver. 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SKY9541 and is the answer not in the manual?

Questions and answers

Related Manuals for BCP SKY9541

Summary of Contents for BCP SKY9541

  • Page 1 INSTRUCTION MANUAL 2-Door Elevated Storage Cabinet SKY9541 + SKY9542 + SKY9543 Ver. 1...
  • Page 2 As shoppers, we’re always trying to find the perfect balance between quality & value. At BCP, we believe we’ve achieved that. Our diverse catalog of everyday essentials is tailored especially to our customers & guaranteed to hit that sweet spot of high quality & low price.

  • Page 3: Tools Required

    63 LBS 28 LBS 22 LBS 13 LBS 2 PERSON UP TO 60 MIN. TOTAL CABINET TOP BOTTOM BOARD SHELF ASSEMBLY ASSEMBLY CAPACITY CAPACITY CAPACITY CAPACITY NOTICE Please retain these instructions for future reference. • Please do not exceed the weight limitations of this item. •...
  • Page 4 HARDWARE M6 x 60mm MOUNTING BARREL BOLT M3.5 x 12mm BARREL BOLT HARDWARE COVER SCREW & NUT SET 4 PCS 2 SETS 4 PCS 24 PCS M4 x 35mm BACK SCREW DOOR SCREW & GUIDE HANDLE 3 PCS 8 PCS 2 PCS PARTS CABINET TOP...
  • Page 5 PARTS BASE FRAME LEG I LEG II CONNECTOR 2 PCS 2 PCS 2 PCS TOP FRAME BACK DIVIDER BACK BOARD CONNECTOR 1 PC 1 PC 2 PCS BASE SIDE FRAME SHELF 2 PCS 1 PC...
  • Page 6 PRODUCT ASSEMBLY Locate the part A cabinet top and insert four part 1 cam bolts, set aside. Locate the part C and part D cabinet sides and insert three part 1 cam bolts into each, six cam bolts total. Insert two part 2 cam locks into the part K back divider, then attach the divider to the part C cabinet right side.
  • Page 7 PRODUCT ASSEMBLY Insert two part 2 cam locks into the part K back divider, then attach the divider to the part D cabinet left side. Turn the cam locks to secure. Insert one part 2 cam lock and one part 3 dowel into the part J top frame connector, then attach the frame connector to the part D cabinet left side.
  • Page 8 PRODUCT ASSEMBLY Insert four part 2 cam locks into the part D and part C cabinet sides, two cam locks per side. Insert two part 3 dowels each into the part D cabinet left side, part C cabinet right side, and the part J top frame connector, six dowels total.
  • Page 9 PRODUCT ASSEMBLY Locate the part H and part I legs and insert two part 1 cam bolts each, eight cam bolts total. Locate the part B cabinet bottom and insert ten part 1 cam bolts. Insert four part 2 cam locks into one part M base side frame, then attach one part I and one part H leg.
  • Page 10 PRODUCT ASSEMBLY Flip the assembly upside down, then slide one part L back board into the designated slots between the part D and part C cabinet sides. Insert two part 3 dowels each into the part D and part C cabinet sides, four dowels total. Attach the part B cabinet bottom to the part D and C cabinet sides with four part 4 screws.
  • Page 11 PRODUCT ASSEMBLY Insert eight part 3 dowels into the part B cabinet bottom. Insert three part 2 cam locks each into the part G base frame connectors, six cam locks total.
  • Page 12 PRODUCT ASSEMBLY Insert two part 2 cam locks each into the part M base side frames, four cam locks total. Attach the base frame assembly to the part B cabinet bottom, then turn the cam locks to secure. Place four part 8 foot sliders onto the bottom of the part H & I legs.
  • Page 13 PRODUCT ASSEMBLY Locate the part E left door then attach one part 15 door handle with two part 6 screws. Attach two part 7 hinges to the part E left door with four part 12 screws, two screws per hinge. Repeat to assemble the part F right door.
  • Page 14 PRODUCT ASSEMBLY Insert four part 5 shelf supports into the part D & part C cabinet sides at your desired height. Note: Be sure the shelf supports sit parallel to properly install the shelf. Slide the part N shelf onto the part 5 shelf supports.
  • Page 15 PRODUCT ASSEMBLY Secure the part L back boards with eight part 14 back screws and guides. Attach the part 10 mounting straps to the part A cabinet top with the included mounting screw.

  • Page 16: Wall Mounting

    WALL MOUNTING Select an appropriate location, then mark two spaces on the wall using the part 10 mounting straps as guides. Use a drill on the marked spaces. Insert two included wall anchors into the new holes in the wall. Overlap the holes with the mounting straps, then attach the cabinet to the wall by drilling two part 4 wood screws through the part 10 mounting straps and into the wall anchors.

  • Page 17: Door Alignment

    DOOR ALIGNMENT If your door is too low or too high... door Loosen the height screws, then move the door up or down to make it level. If you need to adjust the depth of the doors... door Adjust the in-and-out screws until the door is aligned with the side of cabinet. If the space between your doors is o ...
  • Page 18 Check out more great products: bestchoiceproducts.com...
  • Page 19 Earn points while you shop. Join today! Give your friends 15% o their first order! For each successful referral you’ll receive 100 points. bestchoiceproducts.com...

  • Page 20: Help Center

    HELP CENTER Question about your product? We're here to help. Visit us at: help.bestchoiceproducts.com CHAT Chat Support Product Inquiry Orders FAQ Product Assembly Returns & Refunds PRODUCT WARRANTY INFORMATION All items can be returned for any reason within 60 days of the receipt and will receive a full refund as long as the item is returned in its original product packaging and all accessories from its original shipment are included.
