  • Page 1 INSTRUCTION MANUAL Farmhouse Kitchen Set SKY6344 + SKY6345 Ver. 1...
  • Page 2 As shoppers, we’re always trying to find the perfect balance between quality & value. At BCP, we believe we’ve achieved that. Our diverse catalog of everyday essentials is tailored especially to our customers & guaranteed to hit that sweet spot of high quality & low price.
  • Page 3 This item is intended to be mounted to a wall following assembly. Do not attempt to use this item otherwise as it may result in personal injury and property damage. bestchoiceproducts.com...

  • Page 4: Tools Required

    NOTICE Please retain these instructions for future reference. • This product requires adult assembly and supervision when in use. • This product is intended for indoor use only. • Do not stand on or use any part of this item as a step ladder. •...
  • Page 5 HARDWARE UTENSIL BRACKET HINGE PEG WALL ANCHOR HANGERS ANCHOR STANDOFF 3 PCS 1 PC 2 PCS 1 PCS 1 PC PARTS BASE CENTER WALL LEFT WALL 1 PC 1 PC 1 PC CENTER SHELF RIGHT LEG SUPPORT SINK SIDE SUPPORT 1 PC 1 PC 2 PCS...
  • Page 6 PARTS RIGHT BACK LEG RIGHT FRONT LEG OVEN BACK 1 PC 1 PC 1 PC COUNTERTOP LEFT COUNTER RIGHT COUNTER WINDOW WINDOW 1 PC 1 PC 1 PC BACKSPLASH BACKSPLASH TOP + ROOF FRONT ROOF FRAME 1 PC 1 PC 1 PC ROOF PANEL LEFT LEG...

  • Page 7: Pre-Assembly

    PARTS SINK BOTTOM OVEN HANDLE FAUCET SUPPORT 1 PC 1 PC 1 PC FAUCET KNOB BURNER SAUCE PAN 2 PCS 2 PCS 1 PC DUTCH OVEN UTENSILS 1 PC 1 SET PRE-ASSEMBLY Insert two part F dowels into the part 1 base.
  • Page 8 PRE-ASSEMBLY Insert four part F dowels into the part 2 Insert two part F dowels into the part 3 center wall. left wall. Screw the part J door latch (female) to the part 2 center wall with two part D screws. Insert four part F dowels into the part 5 Insert four part F dowels into the part 6 right leg support.

  • Page 9: Product Assembly

    PRE-ASSEMBLY Insert two part F dowels into the part 7 Insert two part F dowels into the part 8 sink back support. counter panel, then attach the part L bracket with two part D screws. PRODUCT ASSEMBLY Attach one part 21 center leg to the part 1 base with one part A screw. Attach two part 20 left legs to the part 1 base with two part B screws.
  • Page 10 PRODUCT ASSEMBLY Attach the part 3 left wall to the part 1 base and part 20 legs with two part B screws, and two part G screws. Attach the part 2 center wall to the part 1 base with two part B screws. Attach the part 4 center shelf to the center wall with two part B screws, set this assembly aside.
  • Page 11 PRODUCT ASSEMBLY Attach two part 6 sink side supports to the part 7 sink back support and attach this assembly to the part 2 center wall with one part B screw.
  • Page 12 PRODUCT ASSEMBLY Insert the part 22 sink bottom between the two part 6 sink side supports.
  • Page 13 PRODUCT ASSEMBLY Insert the lower hinge peg (see previous step) into the part 1 base. Attach the part 8 counter panel to the two side supports, then secure to the part 2 & 3 walls with two part B screws. Attach two part 10 &...
  • Page 14 PRODUCT ASSEMBLY Secure the part 10 back leg to the part 7 back sink support with one part B screw, then attach the right legs to the part 8 counter panel, part 4 center shelf, and part 1 base with five part A screws.
  • Page 15 PRODUCT ASSEMBLY Flip the countertop and attach two part 26 burners with eight part C screws, four per burner. Attach the part 24 and 25 faucet and faucet knobs with three part G screws. Attach the part 14 & 15 left and right counter windows with four part B screws. Set aside.
  • Page 16 PRODUCT ASSEMBLY Attach three part K utensil hangers to the part 16 backsplash with three part E screws. Insert the backsplash between the part 14 & 15 side windows. Attach the part 17 backsplash top with two part B screws.
  • Page 17 PRODUCT ASSEMBLY Attach the part 18 roof front with two part B screws. Attach two part 19 roof panels to the part 17 & 18 roof frames with eight part B screws, four screws per panel.
  • Page 18 PRODUCT ASSEMBLY Attach the part 13 countertop to the part 3 left wall and part 5 right leg support with five part C screws...

  • Page 19: Wall Mounting

    WALL MOUNTING Select an appropriate location, then place the product against the wall. Open the part 9 oven door and mark the wall through the hole in the part 12 oven back. Move the product aside. Drill a hole in the indicated spot on the wall, then insert the part N wall anchor. Insert one part A screw through the hole in the pat 12 oven back and place the part O standoff...

  • Page 20: Help Center

    HELP CENTER Question about your product? We're here to help. Visit us at: help.bestchoiceproducts.com CHAT Chat Support Product Inquiry Orders FAQ Product Assembly Returns & Refunds PRODUCT WARRANTY INFORMATION All items can be returned for any reason within 60 days of the receipt and will receive a full refund as long as the item is returned in its original product packaging and all accessories from its original shipment are included.
