- Page 1 INSTRUCTION MANUAL 7-Piece Modern Industrial Dining Table Set SKY9407 + SKY9408 + SKY9409 Ver. 1...
- Page 2 As shoppers, we’re always trying to find the perfect balance between quality & value. At BCP, we believe we’ve achieved that. Our diverse catalog of everyday essentials is tailored especially to our customers & guaranteed to hit that sweet spot of high quality & low price.
-
Page 3: Tools Required
NOTICE Please retain these instructions for future reference. • Please do not exceed the weight limitations of this item. • Do not stand on or use any part of this item as a step ladder. • Firmly secure all bolts, screws and knobs before use. •... - Page 4 PARTS TABLE TOP END I TABLE TOP CENTER TABLE TOP END II 1 PC 1 PC 1 PC TABLE END FRAME I TABLE LEG TABLE LEG SUPPORT 1 PC 4 PCS 2 PCS TABLE SIDE FRAME TABLE FRAME JOINT SEAT CUSHION 4 PCS 2 PCS 6 PCS...
- Page 5 PARTS BACKREST CHAIR SUPPORT TABLE END FRAME II FRAME 6 PCS 6 PCS 1 PC PRODUCT ASSEMBLY – CHAIR Attach one part J leg frame I to one part L chair front frame with two part 1 bolts. Attach one part N chair support frame to the part J leg frame I with two part 3 bolts. Attach the one part K leg frame II to the part L chair front frame with two part 1 bolts.
- Page 6 PRODUCT ASSEMBLY – CHAIR Attach the part J & K leg frames to the part M backrest with four part 1 bolts. Locate one part I seat cushion and place it face down on a flat, level surface then attach the part J &...
- Page 7 PRODUCT ASSEMBLY – TABLE Connect two part G table side frames with one part H table frame joint, two part 8 bolts, and two part 7 bolt sleeves. Secure with two part 3 bolts. Repeat to assemble a second side frame. Attach two part E table legs to the part D table end frame I with four part 1 bolts.
- Page 8 PRODUCT ASSEMBLY – TABLE Attach two part E table legs to the part O table end frame II with four part 1 bolts. Connect the part E table legs with one part F table leg support and four part 1 bolts. Insert two part 9 table slider into the part F table leg support.
- Page 9 PRODUCT ASSEMBLY – TABLE Connect the part B table top center to the part A and part C table top ends with four part 11 Connect the part B table top center to the part A and part C table top ends with four part 11 joiner plates and eight part 10 screws, two screws per plate on the inner table surface.
- Page 10 PRODUCT ASSEMBLY – TABLE Place the two part G table side frame assemblies between the part E table legs before Place the two part G table side frame assemblies between the part E table legs before proceeding to assure proper placement. proceeding to assure proper placement.
- Page 11 PRODUCT ASSEMBLY – TABLE Attach the table frame assembly to the table top assembly with thirty-six part 4 bolts as shown. Attach the table frame assembly to the table top assembly with thirty-six part 4 bolts as shown. Secure the table frame assembly with two part 6 bolts and two part 7 bolt sleeves. Flip the assembled table, and arrange the chairs as desired.
-
Page 12: Help Center
HELP CENTER Question about your product? We're here to help. Visit us at: help.bestchoiceproducts.com CHAT Chat Support Product Inquiry Orders FAQ Product Assembly Returns & Refunds PRODUCT WARRANTY INFORMATION All items can be returned for any reason within 60 days of the receipt and will receive a full refund as long as the item is returned in its original product packaging and all accessories from its original shipment are included.
