Summary of Contents for WAC NOVELLE
- Page 1 NOVELLE Installation Instructions...
- Page 2 Please read and save these instructions before installation...
-
Page 3: Fan Support
FAN SUPPORT For fast service have the following information below when you call: • Model Name and Number • Part Number and Part Description • Date Of Purchase and Purchase Location 1-800-526-2588 option MON-FRI 8AM-8PM EST Email: fansupport@waclighting.com For all questions about your ceiling fan please read all included instructions, installation procedures, troubleshooting guidelines and warranty information before starting installation. -
Page 4: Safety Rules
SAFETY RULES For operation, maintenance, and troubleshooting information, visit http://waclighting.com/fan-support/ 1. To reduce the risk of electric shock, ensure electricity has been turned off at 6. To avoid personal injury or damage to the fan and other items, please be the circuit breaker before beginning. - Page 5 Substitution of parts or accessories not designated for use with this product by WAC could result in personal injury or property damage and will void the outlet box is to be sealed such that no water enters the outlet box.
- Page 6 Remove and immediately recycle or dispose of used batteries according to local Retirez les piles usagées et recyclez-les ou mettez-les au rebut immédiatement, regulations and keep away from children. Do NOT dispose of batteries in household trash conformément aux réglementations locales. Gardez-les hors de portée des enfants. Ne PAS or incinerate.
- Page 7 UL/cUL safety regulations for voice-activated control MOTOR Compatible with our WAC app Wi-Fi and Bluetooth enabled for unlimited control The WAC app synchronizes seamlessly with smart home devices you already own REMOTE CONTROL WALL CONTROL RC20-WT WC20-WT White Included Optional accessory...
-
Page 8: Table Of Contents
TABLE OF CONTENTS Package Contents Mounting Options Installing the Mounting Bracket Attaching the Fan Blades Hanging the Fan Making the Electrical Connections Installing the Optional Wall Control Finishing the Installation Installing the Adapter Plate Installing the Optional Cover Installing the Luminaire/Shade Controlling the Fan Reset Application... -
Page 9: Tools And Materials Required
TOOLS & MATERIALS REQUIRED Wire cutters Electrical tape Phillips screwdriver Step ladder Hanging Weight: 11.46 lbs NOTE: Before discarding packaging materials, be certain all parts have been removed. NOTE: Place the parts from the hardware bag into a small container to keep them from being lost. MAC ID IMPORTANT: Please make note of the MAC ID on the receiver and keep it in a safe place. -
Page 10: Package Contents
PACKAGE CONTENTS Fan Blades Canopy Ring RPL-F109-52-BD-** RPL-CAN-OCT-** Coupling Downrod Cover Assembly RPL-F109-COUCVR-** RPL-HGR-ASM-6-** Motor Housing Mounting Canopy RPL-CAN-OCT-** Bracket RPL-HGR-ASM-6-** Hardware Bag Receiver RPL-F109-PARTS Luminaire Module F-R3-109-052CS-H Junction Box F3IN-120V-R1-CS-H Safety Cable Machine Screws (2) Flat Washer (1) Spring Washers(2) Spring Washer (1) Flat Washers (2) Remote Control... -
Page 11: Mounting Options
MOUNTING OPTIONS INSTALLING THE MOUNTING BRACKET Caution: Remember to disconnect Standard Ceiling Slope Ceiling the power at the circuit breaker. CAUTION: TTo prevent electrical shock, ensure electricity has been Remove 1 set screw from mounting bracket and set aside for turned off at the circuit breaker before beginning. -
Page 12: Attaching The Fan Blades
ATTACHING THE FAN BLADES Place blade on motor assembly hole. Place the blade on the housing underneath the blade arms. Secure blade with blade attachment screws and washers - repeat for remaining blades. Use B hardware with x 3 attachment screws and washers. F - 109L... -
Page 13: Hanging The Fan
HANGING THE FAN Remove screw from hanger ball. Remove hanger ball and cross Install coupling cover, canopy screw ring, canopy and pin. downrod assembly into motor housing as shown. Loosen 2 screws, clevis pin and cotter pin. F - 1 0 9 L... - Page 14 HANGING THE FAN Slip the coupling cover, canopy screw cover (painted side Carefully lift the fan motor assembly up to the mounting face down), and canopy (opened side up) onto the downrod. bracket and seat the hanger ball in the mounting bracket Coupling cover goes all the way to the bottom.
-
Page 15: Making The Electrical Connections
MAKING THE ELECTRICAL CONNECTIONS HANGING THE FAN GREEN(Hanger Ball) RED(to Receiver) YELLOW(to Receiver) GREY(to Receiver) 1. Secure the safety cable into the structure beams using the wood Connect the labled wires from fan to the corresponding wires on the receiver. screw, washers, and spring washers provided. - Page 16 INSTALLING THE OPTIONAL WALL CONTROL NOTE: Wall control not included. A Bluetooth wall control accessory can be purchased separately. Skip this section if you did not purchase a wall control. NOTE: For multi-location wiring, skip to the next step. Connect the green wire marked “GROUND” from the wall control to the copper wire from the wall outlet box that feeds back to the circuit breaker – important for proper fan function.
-
Page 17: Installing The Optional Wall Control
INSTALLING THE OPTIONAL WALL CONTROL Install the wall control using the wiring diagram above. Individually pair each of the wall controls with the fan receiver using the pairing instruction. F - 1 0 9 L... -
Page 18: Finishing The Installation
FINISHING THE INSTALLATION Secure wire connectors with supplied wire ties. Install canopy screw ring as shown. Install canopy to mounting bracket with the screw removed in section 2. F-10 9L... -
Page 19: Installing The Adapter Plate
INSTALLING THE ADAPTER PLATE Remove 1 of 3 screws from the mounting ring and loosen the others (do not remove). Twist and lock the adapter plate into place by following the arrows above. Using the screw from the previous step, install the adapter plate. -
Page 20: Installing The Optional Cover
INSTALLING THE OPTIONAL COVER If you do not want to use the included Luminaire - twist on the cap and make sure it is on tight. F-10 9L... -
Page 21: Installing The Luminaire/Shade
INSTALLING THE LUMINAIRE/SHADE WARNING: To avoid electric shock and fire, user must adjust the Screws Return to 4CCT switch before the fan is mounted. Do not adjust the switch when the fan is powered ON. LED Module NOTE: Before installing the LED module - please note your Fan comes standard as 3000K (neutral white color). - Page 22 B: Fan On/Off, Speed Up/Down power on to the fan receiver. If you wish to pair your remote to another WAC Smart Fan or if you ever need to re-pair your remote to its original C: Season (Summer/Winter) fan, press and hold the light toggle and fan toggle for 4 seconds until Air-Gap Switch: Pull tab to power off in case of emergency.
-
Page 23: Controlling The Fan
CONTROLLING THE FAN Breeze Mode Controlling Multiple Fans with Remote or Wall Controls Your remote and wall controls are capable of controlling Breeze Mode mimics the natural ebb and flow of winds in multiple fans. A remote or wall control has the ability to control nature by varying the fan speed. - Page 24 CONTROLLING THE FAN Fan On/Off Light On/Off Fan Direction Press and hold Press and hold Press and hold button for 4 seconds. button for 4 seconds. button for 4 seconds. Fan On/Off: Press and hold button for 4 seconds. The LED on the remote will flash green and all connected fans will beep to indicate the message has been received.
-
Page 25: Reset
10 seconds. The light on the remote NOTE: Factory reset will remove remote control(s), wall control(s) and WAC will flash green and the fan will sound two long beeps. You can then use the Modern app connections. -
Page 26: Application
APPLICATION The WAC app will walk you through the main screen and show you how to create schedules, change fan speeds, dim the In addition to the included control, you can operate your fan with light, switch between Summer and Winter Modes, invite users, the WAC Smart Fans app create groups and much more. -
Page 27: Accessories
Description Finish Bluetooth 6 fan speeds, dims light to 1% Wall Control WC20- Works in conoutlet with WAC Smart Fan receiver (not included) Coupler Connects two downrods Designed to accommodate buildings with steeper Slope Ceiling Kit sloped ceilings up to 45° or 12/12 pitch... - Page 28 APPLICATION Product Model Description Downrod DR12-** 12” downrod DR18-** 18” downrod DR24-** 24” downrod All our downrods are 1” 1” O.D. and are threaded on the motor DR36-** 36” downrod end to create an extra layer of security to allow for adjustments in the field DR48-** 48”...
-
Page 29: Troubleshooting
TROUBLESHOOTING My Fan Will Not Start Check main and branch circuit fuses or circuit breakers. Check line wire connections to fan and switch wire connections in the switch housings. WARNING: Make sure the main power is turned off! My Fan is Noisy Allow for 24-hour break-in period. - Page 30 TROUBLESHOOTING My Fan is not producing Enough Air Movement If possible, please consider using a longer than included downrod. My remote or wall control is not controlling my fan Verify that the fan is receiving power by power cycling the fan. To do this: Cut power to the fan via standard On/Off wall switch, or the breaker if standard wall switch is not applicable.
- Page 31 What is Pairing? Pairing is the process of connecting your WAC remote or wall control to your fan. Your fan comes pre-paired to your included remote control. However, if you want additional controls for your fan or if you’re replacing a control, refer to the pairing and unpairing section of the instructions.
-
Page 32: Certificate Of Warranty
WAC dentro de los cinco (5) años a partir de misused. Notice of a defect in writing must be received by WAC within five (5) years la fecha de compra (o según el período de tiempo indicado en el material). - Page 33 L’obligation de WAC est expressément limitée à la réparation ou au remplacement, sans frais, dans l’usine de WAC après autorisation écrite préalable du retour. L’obligation de WAC au titre de cette garantie ne s’étendra pas au-delà du prix d’achat initial du produit par le distributeur. En conséquence, tout dommage indirect ou tout coût de main-d’œuvre résultant d’un défaut est expressément exclu.
- Page 36 F- 109L waclighting.com WAA24100401...
