- Page 1 English USER'S MANUAL Please read this manual carefully before use! 24-004-1798-00 Rev2.0...
-
Page 2: Table Of Contents
Contents Features 1 General Instructions 2 1. Overview 3 1.1 Front View 3 1.2 Rear View 5 1.3 Wiring Diagram 6 2. Menu System 7 2.1 Default Menu 7 2.1.1 Adjust channel intensity temporarily 7 2.1.2 Adjust whole intensity temporarily 7 2.2 Setting Menus 8 2.2.1 Patching 8 2.2.2 DMX fail 11... -
Page 3: Features
Features Thank you for your purchase. This product features include: Microcomputer control. Separate DMX addressing for each channel ,Start and Independ address setting modes selectable. Each channel can be programmed with the DMX address, and Max/Min intensity level of the lamps. 12 chase programs can be recalled as required, chase velocity is adjustable. -
Page 4: General Instructions
General Instructions Please read through this operating instructions before installing or using your new product. After you have finished reading the instructions, put them away in a safe place for future reference. WARNING! This product must be earthed. To prevent fire or shock hazard, do not expose this product under high temperature or moisture area. -
Page 5: Overview
1. Overview 1.1 Front View... - Page 6 1. Overview 1.1 Front View 1. 2x8 LCD Display Shows the current activities or adjustments of menus. 2. Channel LEDx6 These LEDs show the activities of corresponding channels. 3. DMX LED This LED blinks when DMX signal is present. 4. Channel Buttonx6 These buttons are used to change the intensity of corresponding channel.
-
Page 7: Rear View
1. Overview 1.2 Rear View 1. Power Input DMX IN AC 230V~50/60Hz,120A max. 1. Ground 2. Data- 2. Terminal Output 3. Data+ Single phase: 20A/CH., Total 120A ANALOG Three phase: 20A/CH., Total 40A/Phase INPUT DC 0-10V 3. DMX OUTPUT This connector sends DMX signal through to the next DMX device. -
Page 8: Wiring Diagram
1. Overview 1.3 Wiring Diagram SINGLE PHASE CONNECTION L1 L2 L3 LOADING OUTPUT: POWER INPUT: 20A PER CHANNEL, TOTAL 120A AC 230V~ 50/60Hz THREE-PHASE CONNECTION L1 L2 L3 LOADING L1 L2 L3 OUTPUT : POWER INPUT : 20A PER CHANNEL, TOTAL 40A PER PHASE AC 230V~ 50/60Hz SINGLE POWER INPUT: ..AC 230V~ 50-60Hz,120A MAX... -
Page 9: Menu System
Default Menu is displayed. Default Menu consists of a row of dynamic images and a row of characters , the first row represents the intensity value, and the second row indicates the channel. Botex Rev1.0 1 1 2 3 4 5 6 2.1.1 Adjust channel intensity temporarily... -
Page 10: Setting Menus
2. Menu System 2.2 Setting Menus In Default Menu, tap MENU button to enter Setting Menus system. Patching There are 5 menus: Patching, DMX Fail, MaxLevel, MinLevel and Curve, you can use UP/DOWN button to scroll through the menus. Tap ESC button to exit Setting MENU UP DOWN ESC Menus. - Page 11 2. Menu System 2.2.1 Patching 3. Tap UP/DOWN button to scroll to Start/Independent menu, and tap MENU to enter Start/Independent mode. Patching Start Start Addr:001 MENU UP DOWN ESC MENU UP DOWN ESC Start 4. In Start mode, you can use UP/DOWN Addr:001 button to select the starting address of 6 channels from [001-512].
- Page 12 2. Menu System 2.2.1 Patching Independ Chan[1] 7. In Single Mode, tap MENU to select between channel and address. In Single mode, the DMX address of each MENU UP DOWN ESC channel can be selectable separately. Chan[1] 8. When channel is activated, tap UP/DOWN Addr:001 button to select from [1-6];...
-
Page 13: Dmx Fail
2. Menu System 2.2.2 DMX Fail Dmx fail 1. Tap UP/DOWN button to scroll to DMX Fail menu. MENU UP DOWN ESC Dmx fail 2. Tap MENU button to enter sub-menu system. LastHold You can use UP/DOWN button to select LastHold/Analog/Progr:01-12. -
Page 14: Maxlevel
2. Menu System 2.2.3 MaxLevel MaxLevel 1. Tap UP/DOWN button to scroll to Maxlevel menu. MENU UP DOWN ESC MaxLevel 2. Tap MENU button to enter sub-menu system. MENU UP DOWN ESC 3. Tap UP/DOWN button to select between All/Single mode, and tap MENU to enter All/Single mode. -
Page 15: Minlevel
2. Menu System 2.2.3 MaxLevel Chan[1] 6. When channel is activated, tap UP/DOWN 070% button to select from [1-6]; when MaxLevel value is activated, tap UP/DOWN button to select from [070%-100%]. MENU UP DOWN ESC MaxLevel 7. Tap ESC button to save in memory and back to step 1. - Page 16 2. Menu System 2.2.4 MinLevel 000% 4. In All mode, tap UP/DOWM to select MinLevel value of all channels between 000%-030%. MENU UP DOWN ESC Chan[1] 000% 5. In Single mode, tap MENU to select between channel and MinLevel value. MENU UP DOWN ESC Chan[1]...
-
Page 17: Curve
2. Menu System 2.2.5 Curve Curve 1. Tap UP/DOWN button to scroll to Curve menu. MENU UP DOWN ESC Curve 2. Tap MENU button to enter sub-menu system. MENU UP DOWN ESC 3. Tap UP/DOWM button to scroll to All/Single menu, and tap MENU button to enter All/Single mode. - Page 18 2. Menu System 2.2.5 Curve Chan[1] 6. When channel is activated, tap UP/DOWN Linear button to select from [1-6]; when chase mode is activated, tap UP/DOWN button to select from Linear/S-Curve/Non Dim/Square. MENU UP DOWN ESC Curve 7. Tap ESC button to save in memory and back to step 1.
-
Page 19: Technical Specifications
3. Technical Specifications Power Input ......... AC 230V~50-60Hz, 120A max. Channel Output(Single phase)......20A/CH., Total 120A Channel Output(Three phases)....20A/CH.,Total 40A per phase DMX Output ..........3 pin female XLR socket DMX Input ............3 pin male XLR socket Analogue Input ..........0-10V, 8-pin din socket Dimensions ..............482x390x90mm Weight(appro.) ................9.0kg... - Page 20 24-004-1798-00 E-mail: info@botex.com Web Site: www.botex.com Rev 2.0...
