Summary of Contents for Makita HR2670

  • Page 1 INSTRUCTION MANUAL Combination Hammer HR2670 HR2670FT DOUBLE INSULATION Read before use.
  • Page 2: Specifications

    Be sure that you understand their meaning before use. The typical A-weighted noise level determined accord- ing to EN62841-2-6: Read instruction manual. Model HR2670 Sound pressure level (L ) : 94 dB (A) Sound power level (L ) : 102 dB (A)
  • Page 3: Declarations Of Conformity

    The following table shows the vibration total value (tri-axial The term "power tool" in the warnings refers to your vector sum) determined according to applicable standard. mains-operated (corded) power tool or battery-operated Model HR2670 (cordless) power tool. Work area safety Work mode...
  • Page 4 as a dust mask, non-skid safety shoes, hard hat or Disconnect the plug from the power source hearing protection used for appropriate conditions and/or remove the battery pack, if detachable, from the power tool before making any adjust- will reduce personal injuries. ments, changing accessories, or storing power Prevent unintentional starting.
  • Page 5: Functional Description

    freely without contacting the workpiece, resulting FUNCTIONAL in personal injury. Apply pressure only in direct line with the bit DESCRIPTION and do not apply excessive pressure. Bits can bend, causing breakage or loss of control, result- ing in personal injury. CAUTION: Always be sure that the tool is Additional safety warnings switched off and unplugged before adjusting or checking function on the tool.
  • Page 6 NOTE: Use a dry cloth to wipe the dirt off the lens of the lamp. Be careful not to scratch the lens of the lamp, or it may lower the illumination. Reversing switch action CAUTION: Always check the direction of rotation before operation. CAUTION: Use the reversing switch only after the tool comes to a complete stop. Changing the direction of rotation before the tool stops may dam- age the tool.
  • Page 7 Rotation with hammering Torque limiter For drilling in concrete, masonry, etc., rotate the action NOTICE: As soon as the torque limiter actuates, mode changing knob to the symbol. Use a tungsten- switch off the tool immediately. This will help pre- carbide tipped bit (optional accessory).
  • Page 8 The attachment ring can be enlarged by pressing Insert the drill bit into the tool. Turn the drill bit and push the thumb screw down so that the ring is easily and it in until it engages. securely engaged over the barrel neck of the gear After installing the drill bit, always make sure that the housing.
  • Page 9: Depth Gauge

    Depth gauge Dust cup set The depth gauge is convenient for drilling holes of Optional accessory uniform depth. Loosen the thumb screw and adjust Installing the dust cup set the depth gauge to the desired depth. After adjusting, tighten the thumb screw firmly. Before installing the dust cup set, remove the drill bit from the tool if installed. Fully insert the dust cup set. Engage the protrusions and grooves by turning the attachment unit as shown in the arrow until it sounds click.
  • Page 10 To place the cap back to the original position, follow the NOTE: If you connect a vacuum cleaner to the dust steps below. cup set, remove the dust cap before connecting it. Turn the symbol to the unlock position to remove the bellows.
  • Page 11: Operation

    Chipping/Scaling/Demolition OPERATION CAUTION: When using short-sized bits, there CAUTION: Always use the side grip (auxiliary may be cases where the bit continues to strike handle) and firmly hold the tool by both side grip even when it is away from the workpiece. In such and switch handle during operations.
  • Page 12 For Model HR2670FT Set the action mode changing knob to the symbol. Use the quick change drill chuck as standard equip- For Model HR2670 ment. When installing it, refer to "changing the quick change chuck for SDS-plus". Optional accessory Hold the ring and turn the sleeve counterclockwise to Use the drill chuck assembly.
  • Page 13: Maintenance

    To maintain product SAFETY and RELIABILITY, NOTE: When using the bellows for chiselling, adjust repairs, any other maintenance or adjustment should the length by expanding and contracting the bellows be performed by Makita Authorized or Factory Service according to the length of the bit. Centers, always using Makita replacement parts. OPTIONAL ACCESSORIES...
  • Page 14 • Depth gauge • Blow-out bulb • Dust cup • Dust cup set • Plastic carrying case NOTE: Some items in the list may be included in the tool package as standard accessories. They may differ from country to country. 14 ENGLISH...
  • Page 16 Makita Europe N.V. Jan-Baptist Vinkstraat 2, 3070 Kortenberg, Belgium Makita Corporation 3-11-8, Sumiyoshi-cho, Anjo, Aichi 446-8502 Japan 885A80-227 20240718...
