A A ssembly I
ssembly Instruc
nstructions
Thank you for purchasing this product from Global.
Before you begin assembly, check that you have all the
parts and hardware shown on this page.
If there is any item missing, circle the item, indicating
quantity required and return to us by fax or mail:
CANADA
Global Upholstery
560 Supertest Road
Downsview, Ont.
M3J 2M6
TEL. (416)661-3660
FAX. (416)661-1384
Attn.: Customer Service
T
OOLS REQUIRED
Screwdriver size #2
I t is ad vis able to as s em ble un it on a c ar pe t to avoid s cratches.
Printed in Canada
Newland
Newland
Hutch Doors
tions
U. S.
Global Industries Inc.
17 West Stow ROAD
P.O. Box 562
Marlton, NJ 08053
TEL. (856)596-3390
FAX. (856)596-5684
Attn.: Customer Service
PHILLIPS
GEN003
Bumper pad
8
X
NL33DRL
NL36DRL
Notice to installers:
Open and assemble only one
product at a time to avoid
a potential mix up of parts
and hardware.
NAIN 21 Rev.00
Pg 1 of 2
