Assembly Instructions
Thank you for purchasing this product from Global.
Before you begin assembly, check that you have all the
parts and hardware shown on this page.
If there is any item missing, circle the item, indicating
quantity required and return to us by fax or mail:
CANADA
Global Upholstery
560 Supertest Road
Downsview, Ont.
M3J 2M6
TEL. (416)661-3660
FAX. (416)661-4300
Attn.: Customer Service
T
OOLS REQUIRED
WRENCH
PHILLIPS
Screwdriver size #2
size #16 or 5/8"
I t is advisable to assemble unit on a carpet to avoid scratches.
FST030
#8 x9/16 Pan HD.
X 14
Printed in Canada
Newland
Multi-Storage Shell
US
Global Industries Inc.
17 West Stow ROAD
P.O. 524
Marlton, NJ 08053
TEL. (856)596-3390
FAX. (856)596-5684
Attn.: Customer Service
a
a. Storage Shell
FST 094
Wood Screw #8 x1 3/8
P.H. QUAD.DT.,BARE
X 4
NL3623MS
Notice to installers:
Open and assemble only one
product at a time to avoid
a potential mix up of parts
and hardware.
NAIN11 Rev.00 Pg 1 of 4
Advertisement
Related Manuals for Offices To Go Newland NL3623MS
Summary of Contents for Offices To Go Newland NL3623MS
- Page 1 Newland Multi-Storage Shell Assembly Instructions NL3623MS Thank you for purchasing this product from Global. Before you begin assembly, check that you have all the parts and hardware shown on this page. If there is any item missing, circle the item, indicating quantity required and return to us by fax or mail: CANADA Global Upholstery...
- Page 2 NAIN 11 Rev.00 Pg 2 of 4 Printed in Canada...
- Page 3 FST030 FST094 NAIN 11 Rev.00 Pg 3 of 4 Printed in Canada...
- Page 4 Before installing drawers, move all box drawer Ball Bearing Inserts to extreme front position. Ball Bearing Insert NAIN 11 Rev.00 Pg 4 of 4 Printed in Canada...
