A A ssembly I
ssembly Instruc
Thank you for purchasing this product from Global.
Before you begin assembly, check that you have all the
parts and hardware shown on this page.
If there is any item missing, circle the item, indicating
quantity required and return to us by fax or mail:
CANADA
Global Upholstery
560 Supertest Road
Downsview, Ont.
M3J 2M6
TEL. (416)661-3660
FAX. (416)661-4300
Attn.: Customer Service
T
OOLS REQUIRED
PHILLIPS
Screwdriver size #2
It is advisable to assemble unit on a carpet to avoid scratches.
FST158
SCREW 1/4 -20 X 3/4"
P.H. QUAD ZINC
X 16
Printed in Canada
Newland
Table Desk with H-Legs
nstructions
tions
US
Global Industries Inc.
17 West Stow ROAD
P.O. 524
Marlton, NJ 08053
TEL. (856)596-3390
FAX. (856)596-5684
Attn.: Customer Service
LEVELER
PACKED WITH THE METAL LEGS
d
c
a. Top
b. Left Leg
c. Right Leg
d. Stretcher
GEN427
5/16"-18 x 1 1/2" x 15/16" base
X 4
NL3624DWL
NL4824DWL
NL5424DWL
NL6024DWL
NL6624DWL
NL7224DWL
NL6030DWL
NL6630DWL
NL7230DWL
a
Notice to installers:
Open and assemble only one
product at a time to avoid
a potential mix up of parts
and hardware.
FST028
#8 x 3/4 Pan HD.
X 4
NAIN 18 Rev.00
b
Pg 1 of 4
