Assembly Instructions
Thank you for purchasing this product from Global.
Before you begin assembly, check that you have all the
parts and hardware shown on this page.
If there is any item missing, circle the item, indicating
quantity required and return to us by fax or mail:
CANADA
Global Upholstery
560 Supertest Road
Downsview, Ont.
M3J 2M6
TEL. (416)661-3660
FAX. (416)661-4300
Attn.: Customer Service
T
OOLS REQUIRED
PHILLIPS
Screwdriver size #2
I t i s a d v i s a b l e to a s s e m b l e u n i t o n a c a r p e t to avo i d s c ratc h e s.
FST028
#8 3/4 Pan HD.
x 24
Printed in Canada
Newland
Bridge Top
US
Global Industries Inc.
17 West Stow ROAD
P.O. 524
Marlton, NJ 08053
TEL. (856)596-3390
FAX. (856)596-5684
Attn.: Customer Service
a
a. Top
CST318
TRANSACTION TOP
FLAT PLATE
X 4
NL3624B
NL4224B
NL4824B
Notice to installers:
Open and assemble only one
product at a time to avoid
a potential mix up of parts
and hardware.
GEN160
Rectangular Grommet
x 1
NAIN 06 Rev.00
Pg 1 of 3
