Sonar-Spot™ Wheel Balancer
Installation and Operation Manual
Manual P/N 5900407 — Manual Revision A — September 2024
Model:
• LS45DS
⚠
Designed and engineered in Southern California, USA. Made in China
DANGER
Read the entire contents of this manual before using this product. Failure to follow the
instructions and safety precautions in this manual can result in serious injury or death. Make sure all
other operators also read this manual. Keep the manual near the product for future reference.
By proceeding with setup and operation, you agree that you fully understand the contents
of this manual and assume full responsibility for product use.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Sonar-Spot LS45DS and is the answer not in the manual?

Questions and answers

Related Manuals for Ranger Sonar-Spot LS45DS

Summary of Contents for Ranger Sonar-Spot LS45DS

  • Page 1 30440 Agoura Road Agoura Hills, CA 91301 USA Toll Free: (800) 253-2363 Tel: (805) 933-9970 rangerproducts.com Sonar-Spot™ Wheel Balancer Installation and Operation Manual Manual P/N 5900407 — Manual Revision A — September 2024 Model: • LS45DS ⚠ Designed and engineered in Southern California, USA. Made in China DANGER Read the entire contents of this manual before using this product.
  • Page 2 Warranty. The BendPak Ranger warranty is more than a commitment to you: it is also a commitment to the value of your new product. For full warranty details, contact your nearest BendPak Ranger dealer or visit bendpak.com/support/warranty.

  • Page 3: Table Of Contents

    Maintenance Log Installation Introduction This manual describes the Installation and Operating instructions for the Ranger LS45DS Wheel Balancer. The LS45DS is a computer-controlled Wheel Balancer providing fast, accurate Wheel balancing for a wide variety of Wheels. The LS45DS includes our exclusive Laser-Spot™ technology for precise weight placement and Sonar- Spot for accurate Wheel Width measurements.

  • Page 4: Shipping Information

    Shipping Information Your equipment was carefully checked before shipping. Nevertheless, you should thoroughly inspect the shipment before you sign to acknowledge that you received it. When you sign the bill of lading, it tells the carrier that the items on the invoice were received in good Do not sign the bill of lading until after you have inspected the shipment.

  • Page 5: Liability Information

    Instead, take the unit out of service, then contact an authorized repair facility, your distributor, or Ranger Products at (805) 933-9970. • BendPak Ranger recommends making a thorough inspection of the product once a month. Replace any damaged or severely worn parts, decals, or warning labels. Symbols Following are the symbols that may be used in this manual: ⚠...

  • Page 6: Components

    Components Wheel Balancer components include: • Display Panel. Shows balance and test mode data when using the Balancer. • Cover. Protects the operator from the Wheel while it is in motion. • Inner Arm / Distance Ruler. Used to determine the Distance between the Balancer and the inner edge of the Wheel being balanced.
  • Page 7 Balancer accessories include: • Quick-Release Hub Nut. Holds the Wheel on the Balancer once the Wheel is mounted. • Hex Key Wrenches. Used during installation. Hex key wrenches are sometimes called Allen® wrenches. • Anchor Bolts. Anchor the Balancer to the floor at the desired location. Anchoring the Balancer is optional, but strongly recommended.

  • Page 8: Frequently Asked Questions

    • Dynamic Balancing. Balancing a steel Wheel where each of the two planes are analyzed separately. If there is an imbalance, the two planes are brought back into balance separately. Dynamic Balancing is newer technology than Static Balancing and generally provides a better balance.

  • Page 9: Specifications

    Specifications Model LS45DS Motor 220 VAC, 3A, 50/60 Hz, 1 Ph, 0.55kW Working Temperature 27°F to 82°F (-5°C to 50°C) Balancing Modes 1 dynamic / 1 static / 3 aluminum alloy / 1 hidden Maximum Tire Diameter 31.5" (800 mm) Maximum Wheel Weight 145 lbs.

  • Page 10: Installation Checklist

    Installation Checklist Following are the steps required to install the LS45DS Wheel Balancer. Perform them in the order shown. ☐ 1. Review the installation Safety Rules. ☐ 2. Plan for Electrical Work. ☐ 3. Make sure you have the necessary Tools. ☐...

  • Page 11: Installation

    Certain parts of installing the Balancer are difficult for just one person. BendPak CAUTION Ranger strongly recommends having two or more persons working together to install the Balancer. If you have to use an extension cord, make sure its current rating is equal to or greater than that of the equipment being used.

  • Page 12: Find A Location

    Find a Location Keep in mind the following when deciding on a location: • Power source. The Balancer needs to be near an appropriate 220 VAC power source. • Floor. The Balancer is best used on a flat, concrete floor. If the floor is unstable or not flat, the Balancer will not function correctly and will create faulty balance results.
  • Page 13 Balancer! ⚠ CAUTION Ranger recommends having at least two people move the Balancer; it is heavy. If it is dropped or falls, it could cause injury and/or the Balancer could be damaged. Install the Cover Mounting Bracket Assembly 1.
  • Page 14 Install the Cover on the Bracket 1. Retrieve the following: a. 2x Cover (half) b. Cover Bracket c. 10 mm Socket Cap Hex Screw d. 10mm Flat Washer e. 2x M2 x 12 mm Pan Head Screw 2. Remove the two M4 x 12 screws securing the Cover Lock to the Bracket. 3.
  • Page 15 4. Secure the Cover to the Bracket using the Cover Lock and two M4 x 12 Screws. 5. Secure the Sonar Wiring to the Wiring Clips on the Bracket and Cover. 6. Secure the Bracket and Cover onto the Shaft Exiting the Mounting Bracket assembly on the rear of the Balancer Cabinet Using the M10 x 20 SHCS.

  • Page 16: Installing The Display Panel

    Installing the Display Panel The Display Panel shows information about what is happening during the balancing of a Wheel. To install the Display Panel: 7. Locate the Display Panel and the Display Panel Support. – The Display Panel Base Plate (located on the bottom of the Display Panel Support, connects to the back of the Balancer using four hex bolts, four split lock washers, and four standard washers;...
  • Page 17 Connections on the Back of the Balancer Make the electrical connections on the back panel. • Display Cable and Connector. Connects to the back of the Balancer via the Display Panel Base Plate Five-Pin Connector refer to the figure below. •...

  • Page 18: Installing The Shaft

    Installing the Shaft The Shaft supports the Wheels you are balancing. Consider having two assistants to install the Shaft: one to hold the Shaft Assembly in place while the second person screws in the Mounting Bolt. Also, consider having shop towels nearby as the Shaft is shipped with a heavy protective grease coating.

  • Page 19: Anchoring The Balancer

    M10 diameter Anchor Bolt, for example, use an M10 diameter drill bit. 3. Clean each hole. Ranger recommends using a vacuum to clean the hole. Do not ream the hole. Do not make the hole any wider than the drill bit made it.

  • Page 20: Connect To A Power Source

    Even using a hammer or mallet, the Anchor Bolt should only go into the hole part of the way; this is normal. If the Anchor Bolt goes all the way in with little or no resistance, the hole is too wide. Once past the hole in the Base Plate, the Anchor Bolt eventually stops going down into the hole as the Expansion Sleeve contacts the sides of the hole;...

  • Page 21: Test The Balancer

    • The Balancer includes a case (chassis) ground terminal. In case of installations in a high EMF environment with strong induced currents that could interfere with the balance measurements connect this terminal to ground. • Damage caused by improper electrical installation voids the warranty. •...

  • Page 22: Operation

    • Do not remove the Storage Trays unless instructed to do so by Ranger Support. There are no user serviceable parts underneath. When using the product, you must wear appropriate work clothing: leather gloves, non-skid steel- •...

  • Page 23: Viewing Information On The Display Panel

    Viewing Information on the Display Panel Data about the Wheel you are balancing, and the test modes is provided on the Display Panel. There are no controls or buttons on the Display Panel, only information. Note: The Display Panel is separated into sections: •...
  • Page 24 • Indicators around the Wheel. When Weight correction needs to be added to a Wheel, raise the Cover, and turn the Wheel slowly by hand while watching the indicators on the appropriate side of the Wheel. When all of the indicators are lit, the Wheel will lock automatically, and the laser will indicate the exact spot to place the Weight.

  • Page 25: About Planes

    About Planes If you were to split a Wheel down the center (as shown below), it would be divided into two “Planes,” an Inner plane and an Outer plane. Balancing a Wheel on both planes at the same time is the most effective method. Of the five Balancing Modes (DYN, STA, ALU1, ALU2, and ALUS) supported by the LS45DS, four of them balance on both planes at the same time.
  • Page 26 Because balancing a Wheel on both planes is critical to using the LS45DS, the Display Panel shows a two-plane view of the Wheel being balanced. The Inner “Plane” is on the left (based on the main placement method for Wheels on the Balancer, where the visible Rim on the outside) and the Outer “Plane”...

  • Page 27: About Measurements

    About Measurements There are three Wheel measurements that are important to understand for correct balancing. The LS45DS determines these measurements automatically when you use the Inner Arm and the Sonar. The three measurements are: • Distance. The distance from the side of the Balancer to the Inner Edge of the Wheel. Measured by the Inner Arm.
  • Page 28 The LS45DS Control Panel The Control Panel is used to input data and control aspects of the Balancer during both the Measurements and Weights phases. • Distance, Width, Diameter + / — buttons. Used to change the Distance, Width, and Diameter settings during the Measurements phase of the balancing session (before the Wheel is spun).
  • Page 29 Mounting a Wheel When you want to balance a Wheel, the first step is to mount it on the Shaft. Important: All Wheels should be mounted so that the inside goes on the Shaft first. There are three methods to mount a Wheel onto the Shaft using the Collets supplied with the Balancer: •...
  • Page 30 • Dual-Collet Mounting. Generally used only for some aftermarket or OEM performance Wheels that have a center hole that is deep enough to allow the use of two Collets on the Shaft. The Spring goes on first, then an appropriately sized Collet, the Wheel, a second appropriately sized Collet, and finally the Quick Nut.
  • Page 31 2. The Lug-Centric Plate is delivered with three sets of Lug Pins (5 each) to address wheels that use Tapered and Radius (Ball) Tapered Lug Bolts. a. 92mm Lug Pin for Tapered Lug Bolts (use with wide wheels) b. 114mm Lug Pin for Tapered Lug Bolts (use with narrow wheels) c.

  • Page 32: Balancing Modes

    Balancing Modes Balancing Modes (5 Modes) are based on the locations where the weight is installed to balance the Wheel: • Dynamic (DYN). The most common Balancing Mode; used with steel rims, and when weights placed on the visible side of the wheel is not a concern to the customer. If the Wheel is out of balance, weights go on the Inner Edge and the Outer Edge.

  • Page 33: Opt (Optimize) Function

    OPT (Optimize) Function Not a Balancing Mode. The Optimize Function is an optional procedure to lessen the imbalance in a Wheel that is more than 3 ounces (90 grams) out of balance. For more information, refer to Using the Optimize Function.

  • Page 34: Dynamic Balancing

    Dynamic Balancing Dynamic Balancing evaluates and balances a Wheel with weights clipped to both the Inner and Outer Edges. The Clip-On Weight may be installed on the Inner Edge, the Outer Edge, or both. To Balance a Wheel using Dynamic Mode: 1.
  • Page 35 7. Lower the Cover to automatically determine the width and to evaluate the wheel for balance. This data may also be entered manually. If you wish to turn off the automatic spin feature, press and hold STOP, then press C. You will then be required to press START to spin the Wheel. To turn the Automatic Spin feature back on, repeat the same process.
  • Page 36 14. Press Stop to release the Wheel from the automatic lock. 15. Turn the Wheel slowly again to find the best location for weight on the Outer Edge (again, assuming it needs weight; if the Outer Window shows 00, do not add weight to the Outer Edge). 16.
  • Page 37 Upper and Lower Laser Instructions ⚠ WARNING Do not look directly into the laser. Doing so may damage your eyes. Upper Laser Instructions. The Laser will clearly define the inside and outside Weight position in Dynamic Balancing Mode. 1. The Laser function is enabled when the Dynamic Balancing Mode is selected.

  • Page 38: Static Balancing

    Static Balancing Static Balancing is typically for older Wheels, vintage custom wheels, and similar. Typically, where the customer does not want weights either visible and/or applied to a chrome or polished surface. Also used when rims measure under 4 inches wide and with most motorcycle Wheels. Note: The Optimize Function is not available for Static Mode.

  • Page 39: Aluminum Alloy Balancing

    Aluminum Alloy Balancing The following procedure describes the three Aluminum Alloy (ALU) Modes available. Important: ALU Modes are for balancing Wheels made of aluminum alloy. The weights can be placed in various locations on these Wheels. Determine where the weights are to be applied, and then select the appropriate ALU Mode.
  • Page 40 g. The Balancer displays the correction weights for the inner and outer planes shown on the display panel. h. Spin the wheel by hand slowly until all the indicators are illuminated on either the Outer or Inner Planes. The balancer will automatically lock the wheel position and a laser generated line will indicate the weight location on the Wheel.
  • Page 41 h. Place the correction Weight on the Wheel at the 6 o’clock position for the Center Plane and 12 o’clock position for the Inner Edge as indicated by the laser. Press STOP to unlock the Wheel. Spin the wheel slowly by hand again until the opposite plane indicators are all lit, and the balancer locks the tire.
  • Page 42 ALUS without the Lower Laser ALUS Mode without the Laser uses the Inner Measurement Arm to apply the correction weights on the Inner and Center Plane. a. Verify the Lower Laser is in the Off condition. b. Pull out the Inner Arm, place it on the Inner Plane, and hold it there. See figure below. c.

  • Page 43: Hidden Weight Balancing

    n. Place the correction weight on the Inner Arm Gauge Head and pull the inner Arm out until the Center Window displays – – . o. Lift up the Lift Arm Gauge Head and apply the Weight. p. Return the Inner Arm Gauge to its rest position.
  • Page 44 Do not return the Inner Arm to its rest location between the two locations. See figure to the right. 9. Listen for the beep. 10. After the beep, return the Inner Arm to the rest position. 11. Make sure that the ALUS mode indicator is lit on the Display Panel (the Balancer should enter this mode automatically when the Inner Arm is returned to its rest position).
  • Page 45 19. The Inner and Outer Display Windows should now display -2-. 20. Rotate the wheel to bring the next closest Wheel Spoke to the left of the ideal weight location to the 6 o’clock position. Press ALU. See the figure below. This indicates to the Balancer where the second hidden weight is to be placed.

  • Page 46: Using The Optimize Function

    24. Rotate the Wheel toward position -2- (to the left of the ideal position) and when all the Outer Plane indicators light and the Wheel locks, apply the correction weight shown in the Outer Display window position -2- on the Center Plane behind and as close to the Wheel Spoke as possible. 25.
  • Page 47 6. Lower the Wheel Cover or press the Start button. 7. When the Wheel stops, turn the Wheel until the Inner Placement Indicators are all lit and the Wheel locks in position. 8. Put a Mark at Top Dead Center on the Wheel Rim. 9.
  • Page 48 • Diameter. Read the value from the tire sidewall or measure with the Calipers, then enter that — buttons on the Control Panel. value using the Diameter — • Width. Measure with the Calipers, then enter that value using the Width buttons on the Control Panel.

  • Page 49: Maintenance

    Maintenance Make sure your Wheel Balancer is maintained on a regular basis. ⚠ WARNING: Disconnect the Power Cord from power before performing any maintenance and take whatever steps are necessary to make sure the unit cannot be re-energized until Maintenance is over. Because the unit uses electricity, you could be electrocuted or even killed if the unit is powered back on during Maintenance.

  • Page 50: Troubleshooting

    Troubleshooting Perform the following checks if you are experiencing balancing problems: • Confirm the location and position of the alignment marks on the Shaft Assembly and Shaft Housing (see Installing the Shaft for more information). • Make sure the Balancer is anchored in place (see Anchoring the Balancer for more information).
  • Page 51 Balancer. Outer Arm Mount Bar. Data must be entered manually. If you continue to have problems with your Wheel Balancer, visit www.bendpak.com/support call BendPak Ranger at (805) 933-9970. 5900407 LS45DS Laser-Spot™ Wheel Balancer — Rev. A — September 2024...

  • Page 52: System Self-Test

    Restoring System Default Parameter Values Use the following procedure to reset the factory parameter defaults on the Balancer. A label on the inside of the balancer includes the Balancer default parameters. 1. Press and hold the C and T keys simultaneously. The display will indicate CAL CAL CAL and the indicator lights will flash.

  • Page 53: Calibrating The Inner Arm

    System Self Calibration The Dual-Plane Self-Calibration Procedure ensures the Balancer is producing accurate readings by aligning the software with the existing spindle positions and hardware on the Balancer. Replacement of the computer board or the pressure sensor requires running this procedure. Before performing the Self-Calibration Procedure, verify the Balancer is anchored to the floor and that the shaft and centering cones or collets are clean and undamaged.

  • Page 54: Changing The Setting Of The Lower Laser

    5. To disable the Lower Laser Function, repeat the steps above but change the Lower Laser status in step 4 to Off. If the Lower Laser still does not appear, contact Ranger Support by visiting www.bendpak.com/support or call BendPak Ranger at (805) 933-9970 for assistance.

  • Page 55: Wiring Diagram

    LS45DS Wheel Balancer Disposal - End of Service Life Once LS45DS has reached the end of its service life it must be disposed of properly. Disconnect the Balancer from power and disassemble. Classify the components by material and dispose of in accordance with national and local regulations.

  • Page 56: Labels

    Labels 5900407 LS45DS Laser-Spot™ Wheel Balancer — Rev. A — September 2024...
  • Page 57 5900407 LS45DS Laser-Spot™ Wheel Balancer — Rev. A — September 2024...

  • Page 58: Parts

    Parts Cabinet Assy. Part Number Description 5328420 Weight Tray 5328422 Keyboard Cover Keyboard Plate Cross Recessed Flat Head Screw Nut, M3 5530304 Hex Socket Head Screws M8 x 20 Washer Φ8 Spring 5530104 Washer Φ8 Flat 5402104 Storage Cover 5525251 Rocker Switch 5400959 Hexagon socket head screws M6 x 30...
  • Page 59 Upper and Lower Laser Assy. Part Number Description Cross Recessed Pan Head Screw M4 x 12 Thread Shaft Plastic Cover 5328483 One Font Laser Light Source Laser Chassis Cross Recessed Pan Head Screw M4 x 12 5327505 Inner Hexagon End Set Screw M5 x 5 5328009 Lower Laser Light Assembly SHCS M4 x 20...
  • Page 60 Main Shaft Assy. Part Number Description Deformation of Beams SHCS M4 x 12 5328261 Tooth 64 Bearing Cover 5400957 SHCS M6 x 20 Round Nut Snap Ring 30 mm Bearing 6006 Bearing 6005 5327179 Snap Ring 25 mm Axle Sleeve Assembly Adapter Assy.
  • Page 61 Sensor Assy. Part Number Description 5400457 Hex Nut M10 Piezo Sensor Pad Sensor (Horizontal) 5327141 Sensor (Vertical) Sensor Wire 5327140 Piezo Horizontal Shaft 5327139 Piezo Vertical Shaft Washer 5900407 LS45DS Laser-Spot™ Wheel Balancer — Rev. A — September 2024...
  • Page 62 Touch Photovoltaic Panel Part Number Description 5327870 SHCS M4 x 8 Spring Pad Plain Washer 5328011 Photovoltaic Panels Hex Nut M3 Spring Pad Washer 5327686 Encoder Bracket Cross Recessed Pan Head Screw M3 x 10mm 5900407 LS45DS Laser-Spot™ Wheel Balancer —...
  • Page 63 Motor Assy. Part Number Description 5328448 Electromagnetic Brake Motor 5400913 Plain Washer 5327793 Spring Pad 5327730 SHCS M6 x 16 5327144 Small Belt Pulley 5327091 Motor Belt 5327145 Motor Pulley Key 5 x 5 x 30 Hexagon Head Bolt Full Thread Big Washer Motor Cabinet 5328414...
  • Page 64 Inner Distance Arm Assy. Part Number Description 5327591 Distance Arm Sticker 5328023 Distance Arm Spring Distance Arm Rod Distance Arm Rod Washer Snap Ring 20 5328022 Distance Arm Gear FHPS 5328021 Wheel Distance Potentiometer 5328020 Distance Arm Slide Block 5328019 Wheel Diameter Potentiometer Hexagon Socket Set Screw with Flat Point M4 x 4 5327889...
  • Page 65 Power Panel Assy. Part Number Description Nut M4 Washer 4 mm Split Lock Washer 6 mm Split Lock Cross Recessed Pan Head Screw M4 x 16 HHB M6 x 16 Nut M8 5327148 Resistor Electrical Mounting Plate Cross Recessed Pan Head Screw M3 x 25 Thermal Slug Nut M3 5328413...
  • Page 66 Computer Board Assy. Part Number Description Cross Recessed Pan Head Screw M3 x 25 Washer 3 mm Split Lock Nut M3 5328402 Computer Board 5900407 LS45DS Laser-Spot™ Wheel Balancer — Rev. A — September 2024...
  • Page 67 Display Support Assy. Part Number Description Display Mounting Plate Cross Recessed Pan Head Screw M4 x 16 SHCS M10 x 20 Non-Metal Insert Self-Locking Nut Display Support SHCS M4 x 12 Back Shroud SHCS M4 x 20 SHCS M10 x 20 5328423 Non-Metal Insert Hexagonal Lock Nut Non-Metal Insert Hexagonal Lock Nut...
  • Page 68 Display Support Assy. Part Number Description SHCS M4 x 8 5328403 Display Baseplate 5328404 Display Board 5328516 Display Board Cover Cross Slotted Half-Round Head Self-Tapping Screw 5328405 Display Board Mask 5328406 Display Cover 5328412 Display Board Top Harness Display Support Assembly 5900407 LS45DS Laser-Spot™...
  • Page 69 Wheel Cover Mounting Assy. Part Number Description 5328012 Wheel Cover Mounting Assembly Bracket 5327932 Wheel Cover Switch Short Wheel Cover Switch Wires Hexagon Socket Set Screw with Flat Point M8 x 12 Wheel Cover Cam 5327168 Wheel Cover Spring 5327180 Adjustable Eye Bolt Wheel Cover Cam Stop Nut M8...
  • Page 70 Tire Cover Assy. Part Number Description Cover Cross Recessed Pan Head Screw M5X12 Shield bracket Hexagon Socket Cap Screws M10X20 Flat washer Ø10 Sonar Hexagon Socket Cap Screws M6X16 Sonar Plate Sonar Hood Cross recess pan head screw M4X12 Cover Lock Sonar Circuit Board 5900407 LS45DS Laser-Spot™...
  • Page 71 Wiring Assy. Part Number Description Connecting Wire Keyboard Wire Switch Wire Cover Wire Sonar Connection Wire Display Board Wire 5900407 LS45DS Laser-Spot™ Wheel Balancer — Rev. A — September 2024...
  • Page 72 LS45DS Accessories Parts List Part Number Description 5327063 Spacer Ring 5327074 Quick Nut Cup Cover 5327061 Quick Nut Cup 5327172 Quick Nut Cover 5328537 Quick Nut; 36mm 5327720 Allen Wrench; 12mm 5328055 Allen Wrench; 6mm 5328056 Allen Wrench; 4mm 5328057 Allen Wrench;...
  • Page 73 Lug-Centric Pressure Plate Part Number Description 5328635 Lug-Centric Pressure Plate Assembly Lock Nut 92 (Lug Pin) Lock Nut 114 (Lug Pin) Moving Piece Turntable Lock Nut 101 (Lug Pin) Market Component (40mm Spindle) Cap Nut Caliper, Plastic Wrench, Open End 17mm Wrench, Allen 5mm 5900407 LS45DS Laser-Spot™...

  • Page 74: Maintenance Log

    Maintenance Log ___________________________________________________________________________________________ ___________________________________________________________________________________________ ___________________________________________________________________________________________ ___________________________________________________________________________________________ ___________________________________________________________________________________________ ___________________________________________________________________________________________ ___________________________________________________________________________________________ ___________________________________________________________________________________________ ___________________________________________________________________________________________ ___________________________________________________________________________________________ ___________________________________________________________________________________________ ___________________________________________________________________________________________ ___________________________________________________________________________________________ ___________________________________________________________________________________________ ___________________________________________________________________________________________ ___________________________________________________________________________________________ ___________________________________________________________________________________________ ___________________________________________________________________________________________ ___________________________________________________________________________________________ ___________________________________________________________________________________________ ___________________________________________________________________________________________ ___________________________________________________________________________________________ ___________________________________________________________________________________________ ___________________________________________________________________________________________ ___________________________________________________________________________________________ ___________________________________________________________________________________________ ___________________________________________________________________________________________ ___________________________________________________________________________________________ ___________________________________________________________________________________________ 5900407 LS45DS Laser-Spot™ Wheel Balancer — Rev. A — September 2024...
  • Page 75 Maintenance Log 5900407 LS45DS Laser-Spot™ Wheel Balancer — Rev. A — September 2024...
  • Page 76 30440 Agoura Road Agoura Hills, CA 91301 USA bendpak.com © 2024 BendPak Inc. All rights reserved.
