DELONGHI PAC1000
Owner's Manual
Shop genuine replacement parts for DELONGHI
PAC1000
Find Your DELONGHI Air Conditioner Parts - Select From 155 Models
-------- Manual continues below --------

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PAC1000 and is the answer not in the manual?

Questions and answers

Related Manuals for DeLonghi PAC1000

Summary of Contents for DeLonghi PAC1000

  • Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. DELONGHI PAC1000 Owner's Manual Shop genuine replacement parts for DELONGHI PAC1000 Find Your DELONGHI Air Conditioner Parts - Select From 155 Models -------- Manual continues below --------...
  • Page 2 14-05-2001 8:18 Pagina 3 IMPORTANT INFORMATION When using electrical appliances, basic safety precautions should always be followed, including the following: Read all instructions. To protect against fire, electrical shock and personal injury, do not immerse cord, plug or appliance in water or other liquid. Close supervision is necessary when any appliance is used by or near children.

  • Page 3: Specifications

    14-05-2001 8:18 Pagina 4 SPECIFICATIONS Power supply voltage see rating label* Frequency Cooling capacity: see rating label* Current consumption see rating label* Air flow capacity 188.35 cfm Room thermostat adjustable Dimensions : width in.(mm) 18.03 (458) height in.(mm) 33.46 (850) depth in.(mm) 15.74 (400)
  • Page 4 14-05-2001 8:18 Pagina 5 ILLUSTRATED MAIN FEATURES LIST Control panel cover Control panel Air vent control knob Removable filter Exaust hose Hose coupling Suction hose Red reset button Carrying handle Cable storage compartment Condensation discharge tube Castors...

  • Page 5: Accessory List

    14-05-2001 8:18 Pagina 6 ACCESSORY LIST ILLUSTRATION DESCRIPTION N° SUPPLIED Cap + flange Castor stop Window nozzle Adj window bracket Exhaust hose USING THE UNIT AS AN AIR- Minimum distance from the walls: 30cm CONDITIONER Installation This new air-conditioner is highly versatile. It is portable, and can therefore be moved from room to room as required.
  • Page 6 14-05-2001 8:18 Pagina 7 Vent holes for air discharge to the exterior can be made in any wall or window frame as shown in fig. A1, A2 and A3. A1 in a window pane A2 in a door/window frame A3 in a wall Whichever method is preferred, the window should be opened as little as possible in order to ensure maximum efficiency.

  • Page 7: Electrical Connections

    14-05-2001 8:18 Pagina 8 ELECTRICAL CONNECTIONS • Ensure that the air intake and discharge vents are not obstructed. Before plugging the unit into the mains, check • Make sure that there are no sources of heat the following: in the room. •...

  • Page 8: Control Panel

    14-05-2001 8:18 Pagina 9 CONTROL PANEL TIMER ON signal lamp “Alarm” warning light “Ventilation” signal lamp ON/OFF signal lamp “Air-conditioning” signal lamp Dehumidifier pilot lamp Min. speed signal lamp Water trap full pilot lamp Max. speed signal lamp Dehumidifier ON/OFF button Fan speed selection key Timer notches...

  • Page 9: Air Conditioning

    14-05-2001 8:18 Pagina 10 HOW TO START UP THE AIR CONDITIONER Plug the appliance into the wall socket. The ON/OFF signal lamp (2) comes on and stays on for as long as the appliance is connected to the socket. Select either Programmed or Non-programmed mode (see previous page).
  • Page 10 14-05-2001 8:18 Pagina 11 MAINTENANCE PRECAUTIONS During cleaning and normal maintenance operations Under no circumstances should appliance be remember to disconnect plug. washed with running water. Damage could be caused to the electrical circuit. CLEANING OF EXTERNAL HOUSING Never use petrol, gas, alcohol or solvents for cleaning.

  • Page 11: Air Filter Cleaning

    14-05-2001 8:18 Pagina 12 AIR FILTER CLEANING Maintenance of air filter Removal and replacement of air filter A clogged air filter reduces the quantity of cir- Gently pull filter upwards (as shown in figure). culating air and the efficiency of the appliance. Push to replace.

  • Page 12: Troubleshooting

    14-05-2001 8:18 Pagina 13 TROUBLESHOOTING Most malfunctions are caused by a very minor and easily solved problem. Before contacting your nearest authorized Service Center for assistance, consult the troubleshooting chart below. SYMPTOMS CAUSE SOLUTION The Pinguino does not power failure wait function: the appliance is not plugged in...

  • Page 13: Limited Warranty

    14-05-2001 8:18 Pagina 14 FOR UNITED STATES ONLY: LIMITED WARRANTY We warrant each DE’LONGHI AIR-CONDITIONER to be free from defects in material and workmanship. Our obligation under this warranty is to provide one year parts and labor free from purchase date, with an additional four (4) years on any part of the sealed system consisting of the compressor, evaporator, condenser and factory connected refrigerant tubing.
