Creative Zen Air Plus
QUICK START GUIDE
使用产品前请阅读使用说明
Model No. / 型號 / 型号: EF1100
OVERVIEW
1
1. Touch Control Panel
2. Battery LED Indicator
3. USB-C Charging Port
4. Charging Case Function Button
Battery LED indicator
When charging case is closed with earbuds inside, the charging case LED indicator will display the
earbuds battery level. The LED indicator will blink green once and the following LED behavior will be
observed:
Earbuds Battery Life
0-30%
31-70%
71-99%
Full Battery at 100%
When charging case is open with earbuds outside, the charging case LED indicator will display the
charging case battery level. The following LED behavior will be observed:
Charging Case Battery Life
0-30%
31-70%
71-100%
4
3
2
LED behavior
Glowing Red
Glowing Yellow
Glowing Green
Solid Green for 20s before turning off
LED behavior
Solid Red
Solid Yellow
Solid Green
LED indicator will show for 20s before turning off
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Creative Zen Air Plus
Summary of Contents for Creative Zen Air Plus
- Page 1 Creative Zen Air Plus QUICK START GUIDE 使用产品前请阅读使用说明 Model No. / 型號 / 型号: EF1100 OVERVIEW 1. Touch Control Panel 2. Battery LED Indicator 3. USB-C Charging Port 4. Charging Case Function Button Battery LED indicator When charging case is closed with earbuds inside, the charging case LED indicator will display the earbuds battery level.
- Page 2 When user connect the USB-C cable to the charging case, the following LED behavior is observed: Charging Case Battery Life LED behavior 0-30% Glowing Red 31-70% Glowing Yellow 71-100% Glowing Green Full battery LED indicator will stay on until USB-C charging cable is removed CONTROLS During Earbuds Off...
- Page 3 Master Reset While earbuds are placed within charging case, press and hold charging case function button for 8s to initiate master reset. Charging case LED indicator will flash red 5 times and turn off upon completion. Master Reset is reserved for cases where users encounter issues while earbuds are in use or during situations such as: Bluetooth Pairing failure, failure to pair secondary earbud with the main earbud, or to reset all data.
