Summary of Contents for Thetford T2208C

  • Page 1 USER MANUAL Refrigerator T2000 series...

  • Page 2: Table Of Contents

    1. Introduction General This is the user manual for your Thetford T2000 series refrigerator. Read the safety instructions and information on use and maintenance of the refrigerator carefully before continuing. This will enable you to use the refrigerator safely and efficiently.

  • Page 3: Safety

    Note. Additional information. Video. Additional instruction video available. 2. Safety Please read the safety instructions carefully before using the appliance. General Risk of serious injury through burning, explosion, clamping, electrocution,suffocation and poisoning or damage to the product. ■ Please read the safety instructions carefully before using the refrigerator. ■...
  • Page 4 Use of the product Risk of health issues or damage to the refrigerator. ■ Use the refrigerator for cooling and keeping frozen food frozen only and not for anything else. Follow the instructions in this manual. The manufacturer cannot be held liable for damage resulting from improper use or incorrect setting of the controls.

  • Page 5: Servicing And Troubleshooting

    Do not change or adjust anything on the refrigerator, unless the change is authorised by the manufacturer or its representative. ■ Thetford recommends an annual inspection service by an approved service centre. Electricity Risk of serious injury through electrocution, burns and fire or damage to the refrigerator and the surrounding.
  • Page 6 ■ Do not locate multiple portable socket-outlets or portable power supplies at the rear of the refrigerator. Storage Risk of damage to the refrigerator due to flooding and moisture. ■ If the refrigerating refrigerator is left empty for long periods, switch off, defrost, clean, dry, and leave the door open to prevent mould developing within the refrigerator.

  • Page 7: Overview

    3. Overview T2095 1. Refrigerator door 2. Control panel including in- terior light 3. Top shelf 4. Frozen food compartment door 5. Drawer divider 6. Drawer 7. Ventilation for cooling system 8. Bottle and vegetable bin 9. Drawer divider 10. Door bin 1.
  • Page 8 T2120 1. Refrigerator door 2. Control panel 3. Frozen food compartment door 4. Shelf food retainer 5. Storage shelves 6. Drawer divider 7. Bottle and vegetable bin 8. Door bins 9. Interior light 1. On/off button 2. Temperature settings - fresh food compartment 3.
  • Page 9 T2138 1. Frozen food compartment door 2. Control panel 3. Slide-out box 4. Shelf food retainer 5. Storage shelves 6. Drawer divider 7. Bottle and vegetable bin 8. Ventilation for cooling system 9. Door bins 10. Refrigerator door 11. Interior light 1.
  • Page 10 T2152 1. Refrigerator door 2. Control panel 3. Frozen food compartment door 4. Slide-out box 5. Shelf food retainer 6. Storage shelves 7. Drawer divider 8. Bottle and vegetable bin 9. Door bins 10. Interior light 1. On/off button 2. Temperature settings - fresh food compartment 3.
  • Page 11 T2156 1. Fresh food compartment door 2. Control panel 3. Storage shelves 4. Shelf food retainer 5. Vegetable bins 6. Drawer 7. Frozen food compartment door 8. Door bins 9. Interior light 1. On/off button 2. Temperature settings - fresh food compartment 3.

  • Page 12: Before Use

    T2160 / T2175 / T2208 1. Control panel 2. Shelf food retainer 3. Slide-out box 4. Storage shelves (amount may vary depending on model) 5. Vegetable bin 6. Frozen food compartment 7. Ventilation for cooling system (including filter) 8. Frozen food compartment door 9.

  • Page 13: Use

    5. Use Read the applicable instructions in chapter Safety first. Switching on To switch on the refrigerator: T2095 ■ Push the on/off button and hold it until the indicator lights up. After a few seconds the control panel will change to stand-by and locked mode. The blue on/off indicator light stays lit, indicating the refrigerator is still in function.
  • Page 14 For optimal performance, switch on the refrigerator 4 hours before placing food inside the refrigerator. ■ To switch off the refrigerator, push and hold the on/off button for a few seconds. Selecting cooling level fresh food compartment Select one of five levels to set the desired level of cooling of the fresh food compartment. To select the desired cooling level: T2095 ■...
  • Page 15 Always look at the packaging instructions of your food products for preservation level. ■ Thetford advises to set the frozen food compartment on the highest setting. A lower setting is only needed to reduce the energy consumption. ■ The T2095 has only Medium temperature setting.
  • Page 16 Medium: Temperature in the frozen food compartment is around -12°C. This setting is suited for keeping products frozen for an average period of time. This setting uses an average amount of energy. High: Temperature in the frozen food compartment is around -18°C.
  • Page 17 After a few seconds, the control panel will save the settings and go to the locked stand-by mode. When the display is locked, the icons will turn off, only on/off and night mode will stay illuminated. Selecting night mode The refrigerator will select the lowest noise setting where possible. When the refrigerator needs to run harder (due to higher ambient temperatures and/or warm products), it may result in an increase of noise.
  • Page 18 Use night mode only when temperatures in the vehicle are below 30ºC. The night mode will switch off automatically after 12 hours. When switching off the night mode manually, it will go to automatic temperature control. Switch off/on blue indication light (T2095 only) Model T2095 is equipped with an exterior light behind the vent to indicate the refrigerator is running.
  • Page 19 Ensure that the door can still be closed after reorganizing shelves and bins. To reposition an unsecured storage shelf: ■ Turn the plastic clamp of the storage shelf upwards. ■ Lift the left side a bit. Replace storage shelf ■ Move the storage shelf to the de- sired position.

  • Page 20: While Driving

    Therefore, frequently remove all dust from this area, e.g. using a vacuum cleaner. ■ Thetford recommends to clean the cooling system once every 2 years or when you suspect bad performance or too high energy consumption. ■...
  • Page 21 Replace a secured storage shelf ■ Remove the screws that are placed in the shelf near the shelf clamp. ■ Turn the plastic clamp of the storage shelf upwards. ■ Lift the left side a bit. ■ Remove the storage shelf. To replace the secured storage shelf after maintenance: ■...
  • Page 22 ■ Replace the screw. In the drawings, the clamp is shown without the shelf. Replace a secured drawer divider ■ Undo the screws that secure the drawer divider. ■ Remove the drawer divider To replace the secured drawer after maintenance: ■...
  • Page 23 ■ Clean the slide-out box and slide out box system. ■ After cleaning, place the system back in reverse order. Make sure the slide-out box system snaps into place. Remove a drawer T2095 To remove the drawer: ■ Open the door. ■...
  • Page 24 The door with drawer is one part. Preferably perform this procedure with two people. T2120 / T2138 / T2152 To remove the drawer: ■ Completely open the refrigerator door and pull the drawer until the stop. ■ Then lift the drawer at the front, as illustrated. ■...
  • Page 25 T2160 / T2175 / T2208 To remove the drawer: ■ Pull the drawer until the stop and push it a little bit back. ■ Then push the guide locks backwards, as illustrated. ■ Pull the drawer further to the front and lift the wheels over the curves. ■...
  • Page 26 Keep the doors open: T2095 ■ Open the door. ■ Pull left side of the storage lock out of the bottle and vegetable bin. ■ Rotate the storage lock towards the sidewall of the appliance. ■ Secure the storage lock in the hole in the sidewall.

  • Page 27: Disposal

    Defrosting Ice can build up in the frozen food compartment and on the back surface of the refrigerator compartment. When more than 3mm of ice has built up in any location of either compartment, the refrigerator needs to be defrosted. Failure to do this may damage the cooling system.

  • Page 28: Technical Specifications

    8. Technical specifications Refrigerator specifications Model T2095 T2120 T2138 T2152 Display LED display / Capacitive Capacitive Capacitive push-buttons touchscreen touchscreen touchscreen Total volume (L) Volume frozen 17.0 11.6 17.0 food comp. (L) Energy consump- 0.36 0.45 0.50 0.47 tion (kWh/24h)* Weight (kg) 33.0 32.0...

  • Page 29: Service & Questions

    9. Service & questions Read the applicable instructions in chapter Safety first. Service Before starting any service work, disconnect the appliance from the electrical supply. After each service the appliance must be checked for electrical safety. All servicing must be carried out by an approved competent person. Troubleshooting Problem Possible-cause...
  • Page 30 The light is not working Go to a service centre properly For more troubleshooting check the website www.thetford.com Questions If you have questions about your product, parts, accessories or authorised services visit www.thetford.com. If you contact an authorised local Service Centre in your country, provide the details of the...

  • Page 31: Warranty

    For our warranty clause, please refer to the conditions mentioned on www.thetford.com. Declaration of Conformity Thetford hereby declares that this product is in compliance with the essential requirements and other relevant provisions of the applicable Regulations, Directives and Standards. A copy of the Declaration of Conformity can be found at www.thetford.com.
  • Page 32 T +61 3 9358 0700 T +86 755 8627 1393 T +46 31 336 35 80 F not available F +86 755 8627 1673 F not available E infoaus@thetford.com.au E info@thetford.cn E infos@thetford.eu www.thetford.com.au www.thetford.cn Copyright 2017-2024 Thetford B.V. All rights reserved. 693098/1124-V01...

This manual is also suitable for:

T2000 seriesT2095T2152cT2175c
