Summary of Contents for Thetford T1000E Series

  • Page 1 USER MANUAL REFRIGERATOR T1000E series...

  • Page 2: Table Of Contents

    1. Introduction General This is the user manual for your Thetford T1000E series refrigerator. Read the safety instructions and information on use and maintenance of the refrigerator carefully before continuing. This will enable you to use the refrigerator safely and efficiently.

  • Page 3: Safety

    Note. Additional information. Video. Additional instruction video available. 2. Safety Please read the safety instructions carefully before using the appliance. General Risk of serious injury through burning, explosion, clamping, electrocution,suffocation and poisoning or damage to the product. ■ Please read the safety instructions carefully before using the refrigerator. ■...

  • Page 4: Use Of The Product

    Use of the product Risk of health issues or damage to the refrigerator. ■ Use the refrigerator for cooling and keeping frozen food frozen only and not for anything else. Follow the instructions in this manual. The manufacturer cannot be held liable for damage resulting from improper use or incorrect setting of the controls.

  • Page 5: Servicing And Troubleshooting

    Do not change or adjust anything on the refrigerator, unless the change is authorised by the manufacturer or its representative. ■ Thetford recommends an annual inspection service by an approved service centre. Electricity Risk of serious injury through electrocution, burns and fire or damage to the refrigerator and the surrounding.

  • Page 6: Before Use

    ■ Do not locate multiple portable socket-outlets or portable power supplies at the rear of the refrigerator. Storage Risk of damage to the refrigerator due to flooding and moisture. ■ If the refrigerating refrigerator is left empty for long periods, switch off, defrost, clean, dry, and leave the door open to prevent mould developing within the refrigerator.

  • Page 7: Overview

    4. Overview T1090E and T1090EX 1. Refrigerator door 2. Control panel T1090E 3. Control panel T1090EX (Separate) 4. Frozen food compartment door 5. Storage shelves 6. Vegetable bins 7. Door bins 8. Bottle retainer 9. Interior light...
  • Page 8 T1152E 1. Refrigerator door 2. Control panel 3. Frozen food compartment door 4. Storage shelves 5. Drawer divider 6. Drawer 7. Door bins 8. Interior light...
  • Page 9 T1156E 1. Fresh food compartment door 2. Control panel 3. Storage shelves 4. Vegetable bins 5. Drawer 6. Frozen food compartment door 7. Door bins 8. Interior light...

  • Page 10: Use

    Control panel T1090E, T1152E and T1156E 1. Temperature setting button 2. Night mode button 3. On/off button Control panel T1090EX 1. On/off button 2. Temperature setting button 3. Night mode button 5. Use Read the applicable instructions in chapter Safety first. Switching on To switch on the refrigerator: ■...
  • Page 11 T1090E, T1152E, T1156E T1090EX After a few seconds the control panel will change to stand-by and locked mode. The blue on/off indicator light stays lit, indicating the refrigerator is still in function. For optimal performance, switch on the refrigerator 4 hours before placing food.
  • Page 12 Selecting night mode The refrigerator will select the lowest noise setting where possible. When the refrigerator needs to run harder (due to higher ambient temperatures and/or warm products), it may result in an increase of noise. You can switch on the night mode, to reduce the noise to a minimum.
  • Page 13 To reposition an unsecured storage shelf: ■ Turn the plastic clamp of the storage shelf upwards. ■ Lift the left side a bit. Replace storage shelf ■ Move the storage shelf to the de- sired position. ■ Place right side (side without clamp) of the storage shelf in the refrigerator wall.

  • Page 14: While Driving

    6. Maintenance and cleaning Read the applicable instructions in chapter Safety first. Thetford recommends an annual inspection service by an approved service centre. Clean the refrigerator on a regular basis. ■ Always remove any spills or contamination immediately with a mild household cleaner and soft cloth.
  • Page 15 ■ Turn the plastic clamp of the storage shelf upwards. ■ Lift the left side a bit. ■ Remove the storage shelf. To replace the secured storage shelf after maintenance: ■ Place right side (side without clamp) of the storage shelf in the refrigerator wall.
  • Page 16 Remove a drawer To remove the drawer: ■ Completely open the refrigerator door and pull the drawer until the stop. ■ Then lift the drawer at the front, as illustrated. ■ Remove and clean the drawer. ■ After cleaning, place the drawer back in reverse order. Empty the drip tray (T1090E / T1090EX only) During use, water will collect on the back wall of the refrigerator.
  • Page 17 Storage If you do not use the refrigerator for a longer period: ■ Empty the refrigerator. ■ Defrost the frozen food compartment. ■ Clean the complete refrigerator thoroughly. ■ Keep the refrigerator door and the frozen food compartment door open. Keep the doors open ■...

  • Page 18: Disposal

    7. Disposal When your refrigerator has reached its end of life, dispose the product according to the local rules. Do not dispose the refrigerator with normal household waste. Risk of fire and explosion with flammable refrigerant R600a. Environmental Protection Discarded electric appliances are recyc- lable and should not be discarded in the domestic waste.

  • Page 19: Service & Questions

    9. Service & questions Read the applicable instructions in chapter Safety first. Service Before starting any service work, disconnect the appliance from the electrical supply. After each service the appliance must be checked for electrical safety. All servicing must be carried out by an approved competent person. Troubleshooting Problem Possible-cause...
  • Page 20 The light is not working Go to a service centre properly For more troubleshooting check the website www.thetford.com Questions If you have questions about your product, parts, accessories or authorised services visit www.thetford.com. If you contact an authorised local Service Centre in your country, provide the details of the...

  • Page 21: Warranty

    For our warranty clause, please refer to the conditions mentioned on www.thetford.com. Declaration of Conformity Thetford hereby declares that this product is in compliance with the essential requirements and other relevant provisions of the applicable Regulations, Directives and Standards. A copy of the Declaration of Conformity can be found at www.thetford.com.
  • Page 22 T +61 3 9358 0700 T +86 755 8627 1393 T +46 31 336 35 80 F not available F +86 755 8627 1673 F not available E infoaus@thetford.com.au E info@thetford.cn E infos@thetford.eu www.thetford.com.au www.thetford.cn Copyright 2024 Thetford B.V. All rights reserved. 693095/1124-V02...

This manual is also suitable for:

T1090eT1090exT1152eT1156e
